This work was supported by an NIH grant R01DK119183 (to G.A. and M.D.C.), a pilot project award through P30DK079307 (to M.G.D.), an American Urology Association Career Development award and a Winters Foundation grant (to N.M.), and by the Cell Physiology and Model Organisms Kidney Imaging Cores of the Pittsburgh Center for Kidney Research (P30DK079307).

<ol>
	<li>Dalghi, M. G., Montalbetti, N., Carattino, M. D., Apodaca, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+urothelium:+life+in+a+liquid+environment.">The urothelium: life in a liquid environment.</a> Physiological Reviews. 100 (4), 1621 (2020).</li><li>de Groat, W. C., Griffiths, D., Yoshimura, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neural+control+of+the+lower+urinary+tract.">Neural control of the lower urinary tract.</a> Comprehensive Physiology. 5 (1), 327 (2015).</li><li>Dalghi, M. G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Functional+roles+for+PIEZO1+and+PIEZO2+in+urothelial+mechanotransduction+and+lower+urinary+tract+interoception.">Functional roles for PIEZO1 and PIEZO2 in urothelial mechanotransduction and lower urinary tract interoception.</a> JCI Insight. 6 (19), (2021).</li><li>Montalbetti, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bladder+infection+with+uropathogenic+Escherichia+coli+increases+the+excitability+of+afferent+neurons.">Bladder infection with uropathogenic Escherichia coli increases the excitability of afferent neurons.</a> American Journal of Physiology. Renal Physiology. 322 (1), 1 (2022).</li><li>Montalbetti, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Increased+urothelial+paracellular+transport+promotes+cystitis.">Increased urothelial paracellular transport promotes cystitis.</a> American Journal of Physiology. Renal Physiology. 309 (12), 1070 (2015).</li><li>Montalbetti, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Urothelial+tight+junction+barrier+dysfunction+sensitizes+bladder+afferents.">Urothelial tight junction barrier dysfunction sensitizes bladder afferents.</a> eNeuro. 4 (3), (2017).</li><li>Montalbetti, N., Stocker, S. D., Apodaca, G., Bastacky, S. I., Carattino, M. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Urinary+K++promotes+irritative+voiding+symptoms+and+pain+in+the+face+of+urothelial+barrier+dysfunction.">Urinary K+ promotes irritative voiding symptoms and pain in the face of urothelial barrier dysfunction.</a> Scientific Reports. 9 (1), 5509 (2019).</li><li>Kim, A. K., Hamadani, C., Zeidel, M. L., Hill, W. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Urological+complications+of+obesity+and+diabetes+in+males+and+females+of+three+mouse+models:+temporal+manifestations.">Urological complications of obesity and diabetes in males and females of three mouse models: temporal manifestations.</a> American Journal of Physiology. Renal Physiology. 318 (1), 160 (2020).</li><li>Bartolone, S. N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Micturition+defects+and+altered+bladder+function+in+the+klotho+mutant+mouse+model+of+aging.">Micturition defects and altered bladder function in the klotho mutant mouse model of aging.</a> American Journal of Clinical and Experimental Urology. 8 (3), (2020).</li><li>de Rijk, M. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Aging-associated+changes+in+oxidative+stress+negatively+impacts+the+urinary+bladder+urothelium.">Aging-associated changes in oxidative stress negatively impacts the urinary bladder urothelium.</a> International Neurourology Journal. 26 (2), 111 (2022).</li><li>Coyne, K. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+prevalence+of+lower+urinary+tract+symptoms+(LUTS)+and+overactive+bladder+(OAB)+by+racial/ethnic+group+and+age:+results+from+OAB-POLL.">The prevalence of lower urinary tract symptoms (LUTS) and overactive bladder (OAB) by racial/ethnic group and age: results from OAB-POLL.</a> Neurourology and Urodynamics. 32 (3), 230 (2013).</li><li>Wittig, L., Carlson, K. V., Andrews, J. M., Crump, R. T., Baverstock, R. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diabetic+bladder+dysfunction:+a+review.">Diabetic bladder dysfunction: a review.</a> Urology. 123, (2019).</li><li>Irwin, D. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Population-based+survey+of+urinary+incontinence,+overactive+bladder,+and+other+lower+urinary+tract+symptoms+in+five+countries:+results+of+the+EPIC+study.">Population-based survey of urinary incontinence, overactive bladder, and other lower urinary tract symptoms in five countries: results of the EPIC study.</a> European Urology. 50 (6), 1314 (2006).</li><li>Bogart, L. M., Berry, S. H., Clemens, J. Q. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Symptoms+of+interstitial+cystitis,+painful+bladder+syndrome+and+similar+diseases+in+women:+a+systematic+review.">Symptoms of interstitial cystitis, painful bladder syndrome and similar diseases in women: a systematic review.</a> The Journal of Urology. 177 (2), 450 (2007).</li><li>Foxman, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Urinary+tract+infection+syndromes:+occurrence,+recurrence,+bacteriology,+risk+factors,+and+disease+burden.">Urinary tract infection syndromes: occurrence, recurrence, bacteriology, risk factors, and disease burden.</a> Infectious Disease Clinics of North America. 28 (1), 1 (2014).</li><li>Fall, M., Logadottir, Y., Peeker, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Interstitial+cystitis+is+bladder+pain+syndrome+with+Hunner's+lesion.">Interstitial cystitis is bladder pain syndrome with Hunner's lesion.</a> International Journal of Urology. 21, 79 (2014).</li><li>Birder, L. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Urinary+bladder,+cystitis+and+nerve/urothelial+interactions.">Urinary bladder, cystitis and nerve/urothelial interactions.</a> Autonomic Neuroscience: Basic &amp; Clinical. 182, 89 (2014).</li><li>Rosen, J. M., Klumpp, D. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanisms+of+pain+from+urinary+tract+infection.">Mechanisms of pain from urinary tract infection.</a> International Journal of Urology. 21 Suppl. 1, 26 (2014).</li><li>Birder, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Neural+control+of+the+lower+urinary+tract:+peripheral+and+spinal+mechanisms.">Neural control of the lower urinary tract: peripheral and spinal mechanisms.</a> Neurourology and Urodynamics. 29 (1), 128 (2010).</li><li>Desjardins, C., Maruniak, J. A., Bronson, F. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Social+rank+in+house+mice:+differentiation+revealed+by+ultraviolet+visualization+of+urinary+marking+patterns.">Social rank in house mice: differentiation revealed by ultraviolet visualization of urinary marking patterns.</a> Science. 182 (4115), 939 (1973).</li><li>Sugino, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Voided+stain+on+paper+method+for+analysis+of+mouse+urination.">Voided stain on paper method for analysis of mouse urination.</a> Neurourology and Urodynamics. 27 (6), 548 (2008).</li><li>Hill, W. G., Zeidel, M. L., Bjorling, D. E., Vezina, C. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Void+spot+assay:+recommendations+on+the+use+of+a+simple+micturition+assay+for+mice.">Void spot assay: recommendations on the use of a simple micturition assay for mice.</a> American Journal of Physiology. Renal Physiology. 315 (5), (2018).</li><li>Rajandram, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Intact+urothelial+barrier+function+in+a+mouse+model+of+ketamine-induced+voiding+dysfunction.">Intact urothelial barrier function in a mouse model of ketamine-induced voiding dysfunction.</a> American Journal of Physiology. Renal Physiology. 310 (9), (2016).</li><li>Ruetten, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+uropathogenic+E.+coli+UTI89+model+of+prostatic+inflammation+and+collagen+accumulation+for+use+in+studying+aberrant+collagen+production+in+the+prostate.">A uropathogenic E. coli UTI89 model of prostatic inflammation and collagen accumulation for use in studying aberrant collagen production in the prostate.</a> American Journal of Physiology. Renal Physiology. 320 (1), 31 (2021).</li><li>Wegner, K. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Void+spot+assay+procedural+optimization+and+software+for+rapid+and+objective+quantification+of+rodent+voiding+function,+including+overlapping+urine+spots.">Void spot assay procedural optimization and software for rapid and objective quantification of rodent voiding function, including overlapping urine spots.</a> American Journal of Physiology. Renal Physiology. 315 (4), (2018).</li><li>Wood, R., Eichel, L., Messing, E. M., Schwarz, E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Automated+noninvasive+measurement+of+cyclophosphamide-induced+changes+in+murine+voiding+frequency+and+volume.">Automated noninvasive measurement of cyclophosphamide-induced changes in murine voiding frequency and volume.</a> The Journal of Urology. 165 (2), 653 (2001).</li><li>Dmochowski, R. R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bladder+outlet+obstruction:+etiology+and+evaluation.+Reviews+in+Urology.">Bladder outlet obstruction: etiology and evaluation. Reviews in Urology.</a> 7 (Suppl 6), S3&#8211;S13. , (2005).</li><li>Aizawa, N., Homma, Y., Igawa, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Influence+of+high+fat+diet+feeding+for+20+weeks+on+lower+urinary+tract+function+in+mice.">Influence of high fat diet feeding for 20 weeks on lower urinary tract function in mice.</a> Lower Urinary Tract Symptoms. 5 (2), 101 (2013).</li><li>Wang, Z., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Void+sorcerer:+an+open+source,+open+access+framework+for+mouse+uroflowmetry.">Void sorcerer: an open source, open access framework for mouse uroflowmetry.</a> American Journal of Clinical and Experimental Urology. 7 (3), 170 (2019).</li><li>Verstegen, A. M., Tish, M. M., Szczepanik, L. P., Zeidel, M. L., Geerling, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Micturition+video+thermography+in+awake,+behaving+mice.">Micturition video thermography in awake, behaving mice.</a> Journal of Neuroscience Methods. 331, 108449 (2020).</li><li>Keller, J. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Voluntary+urination+control+by+brainstem+neurons+that+relax+the+urethral+sphincter.">Voluntary urination control by brainstem neurons that relax the urethral sphincter.</a> Nature Neuroscience. 21 (9), (2018).</li><li>Hou, X. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Central+control+circuit+for+context-dependent+micturition.">Central control circuit for context-dependent micturition.</a> Cell. 167 (1), 73 (2016).</li><li>Negoro, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Involvement+of+urinary+bladder+Connexin43+and+the+circadian+clock+in+coordination+of+diurnal+micturition+rhythm.">Involvement of urinary bladder Connexin43 and the circadian clock in coordination of diurnal micturition rhythm.</a> Nature Communication. 3, (2012).</li><li>Montalbetti, N., Carattino, M. D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Acid-sensing+ion+channels+modulate+bladder+nociception.">Acid-sensing ion channels modulate bladder nociception.</a> American Journal of Physiology. Renal Physiology. 321 (5), (2021).</li><li>Chen, H., Zhang, L., Hill, W. G., Yu, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Evaluating+the+voiding+spot+assay+in+mice:+a+simple+method+with+complex+environmental+interactions.">Evaluating the voiding spot assay in mice: a simple method with complex environmental interactions.</a> American Journal of Physiology. Renal Physiology. 313 (6), (2017).</li><li>Dalghi, M. G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Expression+and+distribution+of+PIEZO1+in+the+mouse+urinary+tract.">Expression and distribution of PIEZO1 in the mouse urinary tract.</a> American Journal of Physiology. Renal Physiology. 317 (2), 303 (2019).</li><li>Birder, L., Andersson, K. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Animal+modelling+of+interstitial+cystitis/bladder+pain+syndrome.">Animal modelling of interstitial cystitis/bladder pain syndrome.</a> International Neurourology Journal. 22, (2018).</li><li>Okinami, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Altered+detrusor+gap+junction+communications+induce+storage+symptoms+in+bladder+inflammation:+a+mouse+cyclophosphamide-induced+model+of+cystitis.">Altered detrusor gap junction communications induce storage symptoms in bladder inflammation: a mouse cyclophosphamide-induced model of cystitis.</a> PLoS One. 9 (8), (2014).</li><li>Tungtur, S. K., Nishimune, N., Radel, J., Nishimune, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mouse+Behavior+Tracker:+An+economical+method+for+tracking+behavior+in+home+cages.">Mouse Behavior Tracker: An economical method for tracking behavior in home cages.</a> Biotechniques. 63 (5), (2017).</li><li>Negoro, H., Kanematsu, A., Yoshimura, K., Ogawa, O. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chronobiology+of+micturition:+putative+role+of+the+circadian+clock.">Chronobiology of micturition: putative role of the circadian clock.</a> The Journal of Urology. 190 (3), (2013).</li></ol>

The authors have nothing to disclose.

The incorporation of video-monitoring is a cost-effective modification that presents several advantages over the classical VSA. In the classical VSA, which is typically used as an end-point assay, it is difficult to distinguish overlapping void spots. This is not a trivial concern, as mice tend to urinate multiple times in the same area when the assay is prolonged for several hours, typically in the corners of their cage. Thus, the first advantage of RT-VSA is that the investigator can readily identify individual spots that have been deposited partially or totally on top of each other. This is well illustrated in the experiment shown in Figure 12. In this case, video recording confirms that the mouse voided three times in the same corner, depositing overlapping void spots. If the filter paper was analyzed only at the end of the experiment, in the manner typical of a VSA, only one spot could be distinguished. So, while the classical, endpoint VSA can be useful in identifying large differences in voiding behavior, it may fail to discriminate between more subtle phenotypes. With the current advances in genetics and the generation of transgenic animals, the development of methods that can accurately assess voiding behavior is essential.
Second, RT-VSA provides the investigator with temporal information about the voiding events. Thus, one can determine true micturition frequencies, as well as establish relationships between voiding events. For example, in a situation where a cluster of SVSs is observed next to a single large PVS, in the classical VSA, one cannot readily discriminate if the mouse voided several times during the experiment (with three small and one large void) or if the animal deposited one large urine volume, and the three smaller spots are a result of post-micturition dribbling or carryover from fur. RT-VSA can be used to address these questions.
Third, RT-VSA allows one to analyze the behavior of a mouse before, during, and after the voiding event. The investigator can also monitor the mouse&#8217;s overall activity profile by analyzing RT-VSA recordings with freely available software such as Mouse Behavior Tracker39. In addition, one can discriminate whether an animal stops to urinate (typical behavior of females), whether the animal is in motion during voiding (which in males can result in the trailing of void spots), or whether it voids during its sleep/rest phase. We have observed the latter behavior, although it is normally rare. Thus, if properly validated and interpreted, observing voiding behavior can provide the investigator with valuable insights into voiding dysfunction, including, for example, nocturia or incontinence. RT-VSA (and VSA) allows investigators to determine the fraction of void events that occur in the central area of a cage, as opposed to the corners. Normally, center voiding is rare, and increased numbers of such events is a sign of bladder dysfunction8,22. The one exception is dominant alpha-males, which urinate frequently and across the entirety of their enclosures20. In order to perform an analysis of central voiding using RT-VSA, one should consider moving the food dish to a side wall and remove the dome (or fix it to a particular region of the cage), so spatial patterns of urination could be more readily established.
Fourth, the RT-VSA allows one to more effectively manage the stresses associated with cage exchange compared to classical VSA. Mice are skittish by nature and handling them or transferring them to a new environment causes stress, which is known to impact voiding behavior35. By its nature, it is difficult to incorporate a period of acclimatization into the standard VSA. In contrast, in RT-VSA, a period of acclimatization can be easily incorporated in each experiment, and any voiding events during this period disregarded during the analysis. An additional stress-relieving aspect of RT-VSA implemented in this protocol is the duplication of conditions under which mice are normally housed (i.e., access to food and water ad libitum, a dome, and a toy). This is, to the best of our knowledge, one of the richest environments described for this type of experiment. In a typical endpoint VSA, mice are deprived from water (and sometimes also from food)8,22, which we provide ad libitum.
Fifth, in addition to the positive effect that this enriched environment may have on the stress levels of mice, it allows the investigator to perform RT-VSA for extended periods of time, typically in 6 h time windows; however, more recently we have been performing experiments that run for 24 h (data not shown). This is ideal when assessing the effects of circadian rhythmicity or when studying mice that may exhibit an underactive bladder phenotype, and thus urinate infrequently.
For 24 h video monitoring, we recommend using thin filter paper and analyzing the experiments using the bottom cameras. This combination of type of paper and camera is the best option that allows for sensitivity of detection in the dark and light phases. As mentioned earlier, bottom cameras cannot readily detect void spots on the thick filter paper and top cameras do not reliably detect void spots during the light phase. If performing these extended analyses, we suggest placing the animals in the recording cages at 05:00 p.m., analyzing from 06:00 p.m. on day 1 and completing the experiment at 06:00 p.m. on the following day.
While RT-VSA has many positives aspects, there are some caveats worth noting. While we make every attempt to limit stress when performing these analyses, we cannot completely replicate the mouse&#8217;s habitat, as the animals are normally group-housed. They also drink water from a bottle instead of getting water from non-wetting water gel. However, our observation that mice have fewer voids during their inactive light phase versus their active dark phase indicates to us that the mice retain their normal patterns of circadian voiding behavior40. Reflecting their easily stressed nature, we found that mice exhibit disrupted voiding behavior on the days of cage cleaning. Thus, one must limit analysis to periods of time when the animals will be less impacted by routine animal husbandry. An important factor to consider is whether the UV light has any impact on voiding function. Because our findings show a distinct circadian difference in VSA parameters between light and dark phases, which are consistent with other techniques that descrive a similar phenomenon but not using UV light40, we conclude that UV light illumination does not impact voiding function. Notice that the filter paper prevents light from passing from the lower chamber to the upper chamber.
An additional caveat is that the longer one keeps the mice in the chamber, the more likely they are to chew or damage the filter paper (irrespective of the thickness of the paper). While none of the animals disrupted the paper during the light phase, almost 30% of mice damaged the paper during the dark active phase. In the analysis of the 24 h experiments, we observed that a similar proportion (one third) of the experiments could not be analyzed due to paper damage, meaning that not only the amount of time, but also the phase of the day affects the shredding behavior of the animal. Unfortunately, in our experience, we have&#160;noticed that an animal that disrupts the cage&#8217;s paper will continue to do so even upon re-testing. As noted above, mice sometimes urinate on the bare acrylic floor, and thus loss of the paper makes the analysis incomplete and of limited value.
Further, the analysis of male voiding behavior can be more difficult as they tend to void more frequently, they can dribble after voiding, and there is a population of males (20%) with a more aggressive alpha-male phenotype characterized by large numbers of small voids that are distributed across the cage, as discussed in an earlier publication3. As this alpha-male behavior can constitute a confounding factor for establishing voiding phenotypes, we exclude animals with &#8805;50 (light phase experiments) or &#8805;100 (dark phase experiments) voids from analysis.
There are situations in which the discrimination of voids based on their volume (i.e, PVS vs SVS) is not necessarily warranted. For instance, in our experience, mice with bacterial or chemical cystitis tend to void smaller volumes than controls4,34. However, there are great differences in the voided volume between individual mice; in some, most voids have a volume &#8804;20 &#956;L, while in others the majority is &#62;20 &#956;L. Consequently, the discrimination of the voided volume does not provide any advantage for the characterization of these phenotypes.
In sum, RT-VSA is an easy to implement tool for analyzing mouse voiding behavior in freely mobile mice. Unlike tools such as cystometry, it does not require surgical implantation of a catheter or non-physiological rates of bladder filling. It allows for the determination of voiding behavior in both sexes of mice, over extended periods of time, and during the light and dark phases of the day cycle. It is also relatively affordable, especially when compared to more specialized and expensive devices such as metabolic cages. While there are caveats associated with this tool, they are generally easy to manage. Finally, this technique could be easily adapted to other animal species, including other rodents.

Urine storage and micturition are coordinated by a central circuitry (central nervous system) that receives information about the bladder filling status through the pelvic and hypogastric nerves. The urothelium, the epithelium that lines the urinary tract from the renal pelvis to the proximal urethra, forms a tight barrier to the metabolic waste products and pathogens present in urine. It is an integral component of a sensory web, which senses and communicates the filling state of the bladder to underlying tissues and afferent nerves1,2. Disruption of the urothelial barrier, or alterations in urothelial mechanotransduction pathways, can lead to voiding dysfunction along with lower urinary tract symptoms such as frequency, urgency, nocturia, and incontinence3,4,5,6,7. Likewise, aging, diabetes, lower urinary tract infections, interstitial cystitis, and other disease processes that affect the urinary bladder, or the associated circuitry that controls its function, are known to cause bladder dysfunction8,9,10,11,12,13,14,15,16,17,18,19. A better understanding of normal and abnormal voiding behavior depends on the development of methods that can reliably discriminate among different urination patterns.&#160;
Traditionally, the voluntary voiding behavior of mice has been studied using the void spot assay (VSA), developed by Desjardins and colleagues20, and broadly adopted due to its simplicity, low cost, and noninvasive approach8,21,22,23,24. This assay is typically performed as an endpoint assay, in which a mouse spends a defined amount of time in a cage lined by a filter paper, which is subsequently analyzed by counting the number and assessing the size of urine spots when the filter paper is placed under ultraviolet (UV) light (the urine spots fluoresce under these conditions)20. Despite these many advantages, the traditional VSA presents some major limitations. Because mice often urinate in the same areas, investigators have to restrict the duration of the assay to a relatively short period of time (&#8804;4 h)25. Even when the VSA is performed over shorter time periods, it is almost impossible to resolve small void spots (SVSs) that fall over large void spots or, to discriminate SVSs from the carryover of urine adhered to tails or paws. It is also very difficult to distinguish if SVSs are a consequence of frequent but individual voiding events (a phenotype that is often observed in response to cystitis4,26), or due to post-micturition dribbling (a phenotype associated with bladder outlet obstruction27). Furthermore, the desire to complete the assay during working hours, coupled with difficulties accessing housing facilities when the lights are turned off, often limits these assays to the light period of the 24 h circadian cycle. Thus, these time constraints prevent the evaluation of mouse voiding behavior during their active night phase, lessening the ability to analyze specific genes or treatments that are governed by circadian rhythms.&#160;
To overcome some of these limitations, researchers have developed alternative methods to assess voiding behavior in real time26,28,29,30,31,32. Some of these approaches involve the use of expensive equipment such as metabolic cages26,28,29, or the use of thermal cameras30; however, these too have limitations. For example, in metabolic cages, urine tends to adhere to the wires of the mesh floor and to the walls of the funnel, reducing the amount of urine that is collected and measured. Thus, it can be difficult to accurately collect data about small voids. Moreover, metabolic cages do not provide information about the spatial distribution of the voiding events (i.e., urination in the corners vs. the center of the chamber). Given that long-wavelength infrared radiation used by the thermographic cameras does not penetrate solids, voiding activity assessed by video thermography must be performed in an open system, which can be challenging with active mice, as they can jump several inches in the air. Another system is the automated voided stain on paper (aVSOP) approach33, which consists of rolled filter paper that winds up at a constant speed below the wire mesh floor of a mouse cage. This approach prevents paper damage and the overlap of urine spots that occur in the classical VSA, and its implementation allows the investigator to perform experiments over several days. However, it does not provide the investigator with precise timing of the voiding events, and there is no ability to examine behavior and how it correlates with spotting. To obtain this information, researchers have incorporated video-monitoring to voiding assays, an approach that allows the simultaneous assessment of mouse activity and urination events31,32. One approach consists of placing a blue light emitting diode (LED) and a video-camera with a green fluorescence protein filter set under the experimental cage to visualize the voiding events, and an infrared LED and a video-camera above the cage to capture mouse position32. This setup has been used to monitor voiding behavior while performing fiber photometry; however, the brightly lit environment of this system required the investigators to treat their mice with a diuretic agent to stimulate voiding. In another experimental design, wide-angle cameras were placed above and below the experimental cage to visualize mouse motor activity and urination events, respectively. In this case, urine spots deposited on a filter paper lining the cage&#8217;s floor were revealed by illuminating the filter paper with UV lights placed under the cage31. This setup was used in short assays, 4 min in duration, during the light phase of the day to study the brainstem neurons involved in voluntary voiding behavior31. The suitability of this system for its use during the dark phase or for periods of time &#62;4 min was not reported.&#160;
In this article, a method is described that enhances the traditional VSA by allowing for long-term video monitoring of mouse voiding behavior. This cost-effective approach provides temporal, spatial, and volumetric information about voiding events for extended periods of time during the light and dark phases of the day, along with details related to mouse behavior3,4,34. Detailed information for the construction of the voiding chambers, the implementation of a real-time VSA (RT-VSA), and the analysis of the data is provided. The RT-VSA is valuable for researchers seeking to understand the physiological mechanisms that control the function of the urinary system, to develop pharmacological approaches to control micturition, and to define the molecular basis of disease processes that affect the lower urinary tract.&#160;

<table><tbody><tr><td>1.00&amp;rdquo; X 1.00&amp;rdquo; T-Slotted Profile - Four Open T-Slots &amp;ndash;&amp;nbsp; cut to 10 inches</td><td>80/20</td><td>1010</td><td>Amount: 20</td></tr><tr><td>1.00&amp;rdquo; X 1.00&amp;rdquo; T-Slotted Profile - Four Open T-Slots &amp;ndash;&amp;nbsp; cut to 12 inches</td><td>80/20</td><td>1010</td><td>Amount: 6</td></tr><tr><td>1.00&amp;rdquo; X 1.00&amp;rdquo; T-Slotted Profile - Four Open T-Slots &amp;ndash;&amp;nbsp; cut to 40 inches</td><td>80/20</td><td>1010</td><td>Amount: 4</td></tr><tr><td>1.00&amp;rdquo; X 1.00&amp;rdquo; T-Slotted Profile - Four Open T-Slots &amp;ndash; cut to 14.75 inches</td><td>80/20</td><td>1010</td><td>Amount: 12</td></tr><tr><td>1.00&amp;rdquo; X 1.00&amp;rdquo; T-Slotted Profile - Four Open T-Slots &amp;ndash; cut to 32 inches</td><td>80/20</td><td>1010</td><td>Amount: 5</td></tr><tr><td>1/4-20 Double Slide-in Economy T-Nut</td><td>80/20</td><td>3280</td><td>Amount: 16</td></tr><tr><td>1/4-20 Triple Slide-in Economy T-Nut</td><td>80/20</td><td>3287</td><td>Amount: 18</td></tr><tr><td>10 &amp;amp; 25 Series 2 Hole - 18mm Slotted Inside Corner Bracket with Dual Support</td><td>80/20</td><td>14061</td><td>Amount: 6</td></tr><tr><td>10 Series 3 Hole - Straight Flat Plate</td><td>80/20</td><td>4118</td><td>Amount: 8</td></tr><tr><td>10 Series 5 Hole - &quot;L&quot; Flat Plate</td><td>80/20</td><td>4081</td><td>Amount: 8</td></tr><tr><td>10 Series 5 Hole - &quot;T&quot; Flat Plate</td><td>80/20</td><td>4080</td><td>Amount: 8</td></tr><tr><td>10 Series 5 Hole - Tee Flat Plate</td><td>80/20</td><td>4140</td><td>Amount: 2</td></tr><tr><td>10 Series Standard Lift-Off Hinge - Right Hand Assembly</td><td>80/20</td><td>2064</td><td>Amount: 2</td></tr><tr><td>10 to 15 Series 2 Hole - Lite Transition Inside Corner Bracket</td><td>80/20</td><td>4509</td><td>Amount: 6</td></tr><tr><td>24&amp;rdquo;-long UV tube lights</td><td>ADJ Products LLC</td><td>T8-F20BLB24</td><td>Amount: 2&lt;br/&gt; 20W bulb &amp;ndash; 24&amp;rdquo; Wavelength: 365nm</td></tr><tr><td>Acrylic Mirror Sheet</td><td>Profesional Plastics</td><td></td><td>Amount: 1&lt;br/&gt; 82.5 cm x 26.5 cm</td></tr><tr><td>Acrylic Mirror Sheet</td><td>Profesional Plastics</td><td></td><td>Amount: 2&lt;br/&gt; 26.5 cm X 30.5 cm</td></tr><tr><td>Acrylic Mirror Sheet</td><td>Profesional Plastics</td><td></td><td>Amount: 2&lt;br/&gt; 82.5 cm x 30.5 cm</td></tr><tr><td>AR polycarbonate (UV resistance)</td><td>80/20</td><td>65-2641</td><td>Amount: 2&lt;br/&gt; 4.5mm Thick, Clear, 38.5 cm x 26.5 cm</td></tr><tr><td>AR polycarbonate (UV resistance)</td><td>80/20</td><td>65-2641</td><td>Amount: 4&lt;br/&gt; 4.5mm Thick, Clear, 38.5 cm x 21.5 cm</td></tr><tr><td>AR polycarbonate (UV resistance)</td><td>80/20</td><td>65-2641</td><td>Amount: 4&lt;br/&gt; 4.5mm Thick, Clear, 26.5 cm x 21.5 cm</td></tr><tr><td>AR polycarbonate (UV resistance)</td><td>80/20</td><td>65-2641</td><td>Amount: 4&lt;br/&gt; 4.5mm Thick, Clear 37.5 cm x 23.9 cm</td></tr><tr><td>AR polycarbonate (UV resistance)</td><td>80/20</td><td>65-2641</td><td>Amount: 4&lt;br/&gt; 4.5mm Thick, Clear , 24.4 cm x 23.9 cm</td></tr><tr><td>Chromatography paper (thin paper)</td><td>&amp;nbsp;Thermo Fisher Scientific</td><td>57144</td><td></td></tr><tr><td>Cosmos blotting paper (thick paper)</td><td>Blick Art Materials</td><td>10422-1005</td><td></td></tr><tr><td>Excel</td><td>Microsoft Corporation</td><td></td><td></td></tr><tr><td>GraphPad Prism</td><td>GraphPad Software</td><td>Version 9.4.0</td><td>graphing and statistics software</td></tr><tr><td>ImageJ FIJI</td><td>NIH</td><td></td><td></td></tr><tr><td>Parafilm</td><td>Merck</td><td></td><td>transparent film</td></tr><tr><td>Quick Time Player 10.5 software&amp;nbsp;</td><td>Apple</td><td></td><td>multimedia player</td></tr><tr><td>Security spy</td><td>Ben software</td><td></td><td>video surveillance software system</td></tr><tr><td>Standard End Fastener, 1/4-20</td><td>80/20</td><td>3381</td><td>Amount: 80</td></tr><tr><td>UV transmitting acrylic</td><td>Spartech</td><td>Polycast Solacryl SUVT</td><td>Amount: 2&lt;br/&gt; 38.5 cm x 26.5 cm&amp;nbsp;</td></tr><tr><td>Water gel: HydroGel</td><td>ClearH2O&amp;nbsp;</td><td>&amp;nbsp;70-01-5022</td><td>(https://www.clearh2o.com/product/hydrogel/)</td></tr><tr><td>Webcam</td><td>Logitech</td><td>C930e</td><td>Amount: 4</td></tr></tbody></table>

real-time void spot assay

Normal voiding behavior is the result of the coordinated function of the bladder, the urethra, and the urethral sphincters under the proper control of the nervous system. To study voluntary voiding behavior in mouse models, researchers have developed the void spot assay (VSA), a method that measures the number and area of urine spots deposited on a filter paper lining the floor of an animal&#8217;s cage. Although technically simple and inexpensive, this assay has limitations when used as an end-point assay, including a lack of temporal resolution of voiding events and difficulties quantifying overlapping urine spots. To overcome these limitations, we developed a video-monitored VSA, which we call real-time VSA (RT-VSA), and which allows us to determine voiding frequency, assess voided volume and voiding patterns, and make measurements over 6 h time windows during both the dark and light phases of the day. The method described in this report can be applied to a wide variety of mouse-based studies that explore the physiological and neurobehavioral aspects of voluntary micturition in health and disease states.

Watch this Scientific Journal Video about Real-Time Void Spot Assay at JoVE.com

Real-Time Void Spot Assay

This article describes a new method to study mouse voiding behavior by incorporating video monitoring in the conventional void spot assay. This approach provides temporal, spatial, and volumetric information on the voiding events and details of mouse behavior during the light and dark phases of the day.
