We thank Dr. David O&#8217;Brochta and all members of the Insect Genetic Technologies Coordination Research Network for the help and training that they provide to us and others on the implementation of genetic technologies. We especially thank Channa Aluvihare for optimizing the micromanipulation protocol to allow Culex embryos to be injected and hatch. We also thank Devante Simmons and Joseph Urso, undergraduate students working in the Meuti lab, for their assistance caring for and screening transgenic mosquitoes, and Zora Elmkami from the ITF for assistance rearing and prepping mosquitoes for injection. This work was supported by an Interdisciplinary Seeds grant from the Infectious Diseases Institute at OSU provided to MEM.

<ol>
	<li>Hamer, G. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Culex+pipiens+(Diptera:+Culicidae):+a+bridge+vector+of+West+Nile+virus+to+humans.">Culex pipiens (Diptera: Culicidae): a bridge vector of West Nile virus to humans.</a> Journal of Medical Entomology. 45 (1), 125-128 (2008).</li><li>Bailey, C. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Isolation+of+St.+Louis+encephalitis+virus+from+overwintering+Culex+pipiens+mosquitoes.">Isolation of St. Louis encephalitis virus from overwintering Culex pipiens mosquitoes.</a> Science. 199 (4335), 1346-1349 (1978).</li><li>Sabry, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+realistic+index+of+experimental+transmission+efficiency+for+Bancroftian+filariasis.">A new realistic index of experimental transmission efficiency for Bancroftian filariasis.</a> The Journal of Tropical Medicine and Hygiene. 94 (4), 283-290 (1991).</li><li>Cancrini, G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Aedes+albopictus+and+Culex+pipiens+implicated+as+natural+vectors+of+Dirofilaria+repens+in+central+Italy.">Aedes albopictus and Culex pipiens implicated as natural vectors of Dirofilaria repens in central Italy.</a> Journal of Medical Entomology. 44 (6), 1064-1066 (2007).</li><li>Wilton, D. P., Smith, G. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ovarian+diapause+in+three+geographic+strains+of+Culex+pipiens+(Diptera:+Culicidae).">Ovarian diapause in three geographic strains of Culex pipiens (Diptera: Culicidae).</a> Journal of Medical Entomology. 22 (5), 524-528 (1985).</li><li>Mattingly, P. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Culex+pipiens+complex.">The Culex pipiens complex.</a> Transactions of the Royal Entomological Society of London. 102 (7), 331-342 (1951).</li><li>Eldridge, B. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+effect+of+temperature+and+photoperiod+on+blood-feeding+and+ovarian+development+in+mosquitoes+of+the+Culex+pipiens+complex.">The effect of temperature and photoperiod on blood-feeding and ovarian development in mosquitoes of the Culex pipiens complex.</a> The American Journal of Tropical Medicine and Hygiene. 17 (1), 133-140 (1968).</li><li>Spielman, A., Wong, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Environmental+control+of+ovarian+diapause+in+Culex+pipiens.">Environmental control of ovarian diapause in Culex pipiens.</a> Annals of the Entomological Society of America. 66 (4), 905-907 (1973).</li><li>Fritz, M. L., Walker, E. D., Miller, J. R., Severson, D. W., Dworkin, I. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Divergent+host+preferences+of+above-and+below-ground+Culex+pipiens+mosquitoes+and+their+hybrid+offspring.">Divergent host preferences of above-and below-ground Culex pipiens mosquitoes and their hybrid offspring.</a> Medical and Veterinary Entomology. 29 (2), 115-123 (2015).</li><li>Meola, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+influence+of+temperature+and+humidity+on+embryonic+longevity+in+Aedes+aegypti.">The influence of temperature and humidity on embryonic longevity in Aedes aegypti.</a> Annals of the Entomological Society of America. 57 (4), 468-472 (1964).</li><li>Dong, S., Lin, J., Held, N. L., Clem, R. J., Passarelli, A. L., Franz, A. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Heritable+CRISPR/Cas9-mediated+genome+editing+in+the+yellow+fever+mosquito,+Aedes+aegypti.">Heritable CRISPR/Cas9-mediated genome editing in the yellow fever mosquito, Aedes aegypti.</a> PloS one. 10 (3), (2015).</li><li>Kyrou, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+CRISPR-Cas9+gene+drive+targeting+doublesex+causes+complete+population+suppression+in+caged+Anopheles+gambiae+mosquitoes.">A CRISPR-Cas9 gene drive targeting doublesex causes complete population suppression in caged Anopheles gambiae mosquitoes.</a> Nature Biotechnology. 36 (11), 1062-1066 (2018).</li><li>Liu, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Construction+of+an+efficient+genomic+editing+system+with+CRISPR/Cas9+in+the+vector+mosquito+Aedes+albopictus.">Construction of an efficient genomic editing system with CRISPR/Cas9 in the vector mosquito Aedes albopictus.</a> Insect Science. 26 (6), 1045-1054 (2019).</li><li>Itokawa, K., Komagata, O., Kasai, S., Ogawa, K., Tomita, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Testing+the+causality+between+CYP9M10+and+pyrethroid+resistance+using+the+TALEN+and+CRISPR/Cas9+technologies.">Testing the causality between CYP9M10 and pyrethroid resistance using the TALEN and CRISPR/Cas9 technologies.</a> Scientific Reports. 6, 24652 (2016).</li><li>Li, M., Li, T., Liu, N., Raban, R. R., Wang, X., Akbari, O. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Methods+for+the+generation+of+heritable+germline+mutations+in+the+disease+vector+Culex+quinquefasciatus+using+clustered+regularly+interspaced+short+palindrome+repeats-associated+protein+9.">Methods for the generation of heritable germline mutations in the disease vector Culex quinquefasciatus using clustered regularly interspaced short palindrome repeats-associated protein 9.</a> Insect Molecular Biology. 29, 214-220 (2019).</li><li>Anderson, M. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CRISPR/Cas9+gene+editing+in+the+West+Nile+Virus+vector,+Culex+quinquefasciatus+Say.">CRISPR/Cas9 gene editing in the West Nile Virus vector, Culex quinquefasciatus Say.</a> PloS one. 14 (11), (2019).</li><li>Van der Oost, J., Jore, M. M., Westra, E. R., Lundgren, M., Brouns, S. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=CRISPR-based+adaptive+and+heritable+immunity+in+prokaryotes.">CRISPR-based adaptive and heritable immunity in prokaryotes.</a> Trends in Biochemical Sciences. 34 (8), 401-407 (2009).</li><li>Heyer, W. D., Ehmsen, K. T., Liu, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Regulation+of+homologous+recombination+in+eukaryotes.">Regulation of homologous recombination in eukaryotes.</a> Annual Review of Genetics. 44, 113-139 (2010).</li><li>Monnerat, A. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Anopheles+albitarsis+embryogenesis:+morphological+identification+of+major+events.">Anopheles albitarsis embryogenesis: morphological identification of major events.</a> Memorias do Instituto Oswaldo Cruz. 97 (4), 589-596 (2002).</li><li>Davis, C. W. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+comparative+study+of+larval+embryogenesis+in+the+mosquito+Culex+fatigans+Wiedemann+(Diptera:+Culicidae)+and+the+sheep-fly+Lucilia+sericata+Meigen+(Diptera:+Calliphoridae).">A comparative study of larval embryogenesis in the mosquito Culex fatigans Wiedemann (Diptera: Culicidae) and the sheep-fly Lucilia sericata Meigen (Diptera: Calliphoridae).</a> Australian Journal of Zoology. 15 (3), 547-579 (1967).</li><li>Port, F., Chen, H. M., Lee, T., Bullock, S. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optimized+CRISPR/Cas+tools+for+efficient+germline+and+somatic+genome+engineering+in+Drosophila.">Optimized CRISPR/Cas tools for efficient germline and somatic genome engineering in Drosophila.</a> Proceedings of the National Academy of Sciences. 111 (29), 2967-2976 (2014).</li><li>Kistler, K. E., Vosshall, L. B., Matthews, B. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genome+engineering+with+CRISPR-Cas9+in+the+mosquito+Aedes+aegypti.">Genome engineering with CRISPR-Cas9 in the mosquito Aedes aegypti.</a> Cell Reports. 11 (1), 51-60 (2015).</li><li>Gokcezade, J., Sienski, G., Duchek, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Efficient+CRISPR/Cas9+plasmids+for+rapid+and+versatile+genome+editing+in+Drosophila.">Efficient CRISPR/Cas9 plasmids for rapid and versatile genome editing in Drosophila.</a> G3: Genes, Genomes, Genetics. 4 (11), 2279-2282 (2014).</li><li>Hwang, W. Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Efficient+in+vivo+genome+editing+using+RNA-guided+nucleases.">Efficient in vivo genome editing using RNA-guided nucleases.</a> Nature Biotechnology. 31 (3), 227-229 (2013).</li><li>Basu, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Silencing+of+end-joining+repair+for+efficient+site-specific+gene+insertion+after+TALEN/CRISPR+mutagenesis+in+Aedes+aegypti.">Silencing of end-joining repair for efficient site-specific gene insertion after TALEN/CRISPR mutagenesis in Aedes aegypti.</a> Proceedings of the National Academy of Sciences. 112 (13), 4038-4043 (2015).</li><li>Hammond, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+CRISPR-Cas9+gene+drive+system+targeting+female+reproduction+in+the+malaria+mosquito+vector+Anopheles+gambiae.">A CRISPR-Cas9 gene drive system targeting female reproduction in the malaria mosquito vector Anopheles gambiae.</a> Nature Biotechnology. 34 (1), 78-83 (2016).</li><li>Lin, S., Staahl, B. T., Alla, R. K., Doudna, J. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enhanced+homology-directed+human+genome+engineering+by+controlled+timing+of+CRISPR/Cas9+delivery.">Enhanced homology-directed human genome engineering by controlled timing of CRISPR/Cas9 delivery.</a> eLife. 3, 04766 (2014).</li></ol>

RH works for the Insect Transformation Facility, which provides services in insect genetic modification.

This protocol presents methods to introduce specific mutations into the genome of Culex mosquitoes and can be used to edit the genome of other mosquitoes as well. The protocol is significant in that it provides specific details of not only how to prepare the injection materials, but also a detailed video overview of how to induce mosquitoes to lay eggs, as well as how to prepare and inject those eggs. We also summarize of how to take advantage of the biology of female Cx. pipiens to lay eggs in individual rafts and thereby screen a smaller proportion of offspring from each female for desired mutations. The methods presented here have been optimized for Cx. pipiens but can be adapted, with small adjustments, to edit the genomes of other mosquitoes or insects. Additionally, the micromanipulation and microinjection protocols described here are amenable to injecting several different materials into insect embryos, including transposons, dsRNA or other endonucleases such as TALENs or Zinc-Finger nucleases. Moreover, the beveling protocol generates microinjection needles with variable opening sizes therefore creating needles that can be used for injecting a wide variety of injection materials. The open size of the needle can be inferred by slowly decreasing the pressure of air after the needle has been beveled, and noting the pressure at which bubbles of air stop flowing from the tip of the newly opened needle. The less air pressure that is needed to produce bubbles indicates that the needle has a larger the opening size, and conversely, higher air pressures indicate that the needle has a smaller opening size. Needles with a larger opening sizes are better for injecting larger particles and more viscous materials, but will likely cause greater damage to the embryo and therefore reduce survival.
Microinjection experiments are in many ways a race against the clock. First, one must inject individual embryos within the first 2 hours of oviposition, before the chorion hardens and blastoderm formation occurs. Therefore, it is imperative to note when the mosquitoes were first placed in the oviposition chamber, how long it takes to manipulate the eggs for injection (we recommend no more than 20-30 minutes), and how long it takes to inject all embryos. Time is also limited when screening adult mosquitoes for mutations as Cx. pipiens are quite sensitive to their surroundings and mosquitoes generally only survive for 3-5 days in individual glass vials. Therefore, it is imperative to screen mosquito pupal exuvia as quickly as possible. Alternatively, one could also extract genomic DNA from a single mosquito leg14. In order to do so, however, the mosquitoes should first be anesthetized on ice. As we were weary of how the cold treatment and loss of limbs might impact mosquito survival and their ability to mate and lay viable eggs, we decided to instead screen the discarded pupal exuvia for mutations. The level of gDNA within the exuvia is likely lower than inside a mosquito leg, and this does add extra effort and time to separate mosquitoes at the pupal stage, but also ensures that all of the adults are unmated when they are released into their appropriate cages, which is absolutely vital. We feel that the results are worth it, but encourage others to consider if removing a leg might be a better course of action for their experimental needs.
The best way to expedite screening for mutations is to inject a plasmid containing a genetic marker, such as a fluorescent protein, flanked by homologous sequences on either side of the cut site. Rates of knock-in mutations using&#160;homology directed-repair (HDR) are generally lower than non-homologous end-joining (NHEJ), knock-out mutations (HDR=0.71%; NHEJ=24.87%;22). Therefore, the insertion of the marker will likely occur with a much lower frequency, but the time-savings offered by being able to quickly screen mosquito larvae under a fluorescent microscope may be worth the risk, depending on the project. Additionally, rates of HDR and knock-in mutations are enhanced when one also injects a plasmid containing the genetic sequence of the Cas9 protein, driven by the a well-characterized embryonic promotor, and the gRNA driven by the U6 promotor24,26. This is likely because early in embryonic development, when nuclei are rapidly dividing (S phase of the cell cycle), the error-prone but expedient NHEJ mechanism seems to be the preferred method of repairing double-stranded breaks (reviewed18). However, as embryogenesis progresses the cellular machinery is primed to use the more accurate HDR mechanism to repair double-stranded breaks (late S phase and G2 phase). Injecting a plasmid that contains the Cas9 sequence early in embryonic development allows the Cas9 protein to reach most target cells while the embryo is still in its syncytial state and before cellular membranes have formed, but the slight delay required to transcribe and translate the Cas9 protein seems to increase the likelihood that the endonucleasewill be active at a time when the developing embryo is more likely to use HDR to accurately repair double-stranded breaks in genomic DNA. For example, Lin et al.27 discovered that rates of HDR were enhanced to ~33% when the Cas9 protein complexed with gRNA were injected in human cell lines arrested in the M phase of the cell cycle. An additional benefit of delivering Cas9 and gRNAs on plasmids is that they are less viscous and therefore less likely to clog the needle during injections (R. Harrell, personal observation). However, until embyronic promoters are characterized and validated in Culex mosquitoes, we recommend injecting Cas9 protein or mRNA as described here.
Additionally, given the amount of time that one must dedicate to rearing and screening mosquitoes, we recommend having at least one full-time technician, student or researcher devoted to this task. We also recommend strategically considering how many null mutants one needs for a given experiment and the importance of genetic diversity within the null line. While we were able to identify mosquitoes in the F1 and F2 generations that had the mutation, only a handful of the F2 mosquitoes survived to adulthood the heterozygous mutant mosquitoes failed to produce viable offspring. We think that this is much less to do with the mutation, and more likely is a result of the lengthy period of time that both male and female mosquitoes were confined to glass tubes while we were screening them. This prolonged period of isolation most likely interfered with their ability to successfully mate and, in the case of females, obtain a blood meal and lay viable eggs. Outcrossing for a single generation and/or having optimized screening techniques in place should prevent this issue from occurring in the future. Therefore, by following this protocol we are confident that researchers will be able to successfully generate null lines of Culex mosquitoes and, with minor adjustments, additional insects.

Culex mosquitoes are distributed throughout the temperate and tropical regions of the world and transmit several deadly viruses including West Nile virus1, St. Louis encephalitis2 as well as filarial nematodes that cause canine heartworm3 and elephantiasis4. Members of the Culex pipiens complex, which includes Cx. quinquefasciatus, Cx. pipiens pipiens and Cx. pipiens molestus, show striking variations in many aspects of their biology. For example, while Cx. quinquefasciatus and Cx. pipiens molestus are incapable of entering an overwintering dormancy5,6, Cx. pipiens pipiens display robust seasonal responses and enter diapause in response to short days7,8. Additionally, Cx. pipiens molestus tend to be more anthropophilic while Cx. pipiens and Cx. quinquefasciatus are more zoophilic6. However, in the United States and throughout many other places in the world, these species interbreed, which has strong implications for disease transmission as hybrids of the Cx. pipiens pipiens and Cx. pipiens molestus are opportunistic feeders and will bite both birds and humans9, thereby serving as bridge vectors for West Nile virus. Studying these and other fascinating aspects of the biology of Culex mosquitoes has been hampered, in part, because Culex mosquitoes are slightly more difficult to rear in the lab than Aedes mosquitoes, which produce quiescent and desiccation-resistant eggs10 and because functional molecular tools are not as well developed for Culex species.
CRISPR/Cas9 genome editing is a powerful technology that has been used to evaluate the biology of several important mosquito species11,12,13, including the Southern house mosquito, Culex quinquefasciatus14,15,16. This technology, developed by Jennifer Doudna and Emmanuelle Charpentier, exploits a natural bacterial defense against viruses by bacterially-derived, CRISPR-associated endonucleases (Cas proteins; see review by Van der Oost et al.17). When injected into animal embryos, the Cas9 proteins in combination with an appropriate guide RNA can produce double-stranded breaks within the genome. This is most frequently done by using the Cas9 protein that is complexed with guide RNAs, which directs endonuclease activity to a specific region of the genome. After the Cas9 protein has created a site-specific double-stranded break, the cellular machinery attempts to repair the break using one of two mechanisms. The first entails ligating the two ends together through non-homologous end joining (NHEJ), which is error-prone and often produces out-frame insertions and deletions in the genome that can result in non-functional proteins, thereby generating a knock-out mutation. Alternatively, the cellular machinery might use homology-directed repair (HDR) by finding similar sequences to correctly repair the break. The similar sequence may be provided by the second chromosome within the organism (see review18). However, if the repaired sequence exactly matches the original sequence, the Cas9 protein will be able to again cut the DNA. Alternatively, researchers can also include a donor plasmid that contains homologous sequences on either side of the cut site of the target sequence with an alternative repair sequence&#8212;often a fluorescent marker protein, modified version of the original gene, or other modification&#8212;that can be copied and inserted into the genome, or &#8220;knocked-in.&#8221;
Timing is critical when injecting embryos, and this is especially the case when using CRISPR/Cas9 genome editing to create mutations in insects. This is because the Cas9 protein and gRNAs have the greatest capacity to generate mutations only when the embryo is in its syncytial state, before cellular membranes have formed and when multiple nuclei are accessible within the embryo. For mosquitoes, nuclei reach the periphery ~2-4 hours after oviposition, depending on temperature19, and therefore successful microinjection must occur before this time. Additionally, the Cas9 protein will cut any nuclear DNA that it can access, such that the individual resulting from the injection will contain a mosaic of cells, some having the desired mutation, and others not. In order for these mutations to be successfully inherited, the Cas9 protein must cut DNA that resides in the germline that will give rise to the future eggs and sperm. To ensure that mutations are generated in the germline it is best to inject all materials close to the location of the pole cells within the embryo, which are the progenitors of the insect germline. The pole cells are located near the posterior end of Culex embryos20. In addition to injecting embryos, it is imperative to develop a careful plan for crossing and screening offspring in order to detect the desired mutation.
This protocol describes how to generate gRNAs and complex them with Cas9 protein to prepare injection mixes, as well as how to induce female mosquitoes of Culex pipiens to lay eggs and how to prepare and inject those eggs for CRISPR/Cas9-mediated genome editing. Additionally, we describe how to rear, cross and screen injected embryos and their progeny to confirm that the desired mutation has been obtained. Using this protocol, we generated null mutations for a gene of interest, cycle, in the Buckeye strain of Culex pipiens. This strain was originally established in 2013 from field-collected mosquitoes in Columbus, Ohio and is maintained by the Meuti lab. This protocol can be used for additional studies that require CRISPR/Cas9 genome editing in Culex mosquitoes, as well as other mosquito species, and, more generally, is relevant to employing CRISPR/Cas9 genome editing to any insect species.

<table><tbody><tr><td>Artificial Membrane Feeder</td><td>Hemotek</td><td>SP5W1-3</td><td>Company location: Blackburn, UK</td></tr><tr><td>ATP</td><td>Invitrogen</td><td>18330019</td><td>Company location: Carlsbad, CA, USA</td></tr><tr><td>Borosilicate glass mirocapillary tubes, 1 mm outer diameter</td><td>World Precision Instruments</td><td>1B100-6</td><td>Company Location: Sarasota, FL, USA</td></tr><tr><td>BV10 Needle Beveler</td><td>Sutter Instruments</td><td>BV-10-B</td><td>Company Location: Nobato, CA, USA</td></tr><tr><td>Whatman Circular filter paper (12.5 cm)</td><td>Sigma Aldrich</td><td>WHA1001125</td><td>Company Location: St. Louis, MO, USA</td></tr><tr><td>Conical tube (50 mL)</td><td>Thermo Fisher Scientific</td><td>339652</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Fisherbrand course filter paper with fast flow rate</td><td>Thermo Fisher Scientific</td><td>09-800</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Cover glass (24 x 40 mm)</td><td>Thermo Fisher Scientific</td><td>50-311-20</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Dental dam</td><td>Henry Schein Inc</td><td>1010171</td><td>Company Location: Melville, NY USA</td></tr><tr><td>Scotch double-sided tape</td><td>Thermo Fisher Scientific</td><td>NC0879005</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>FemtoJet 4i microinjector</td><td>Eppendorf</td><td>5252000021</td><td>Company Location: Hamburg, Germany</td></tr><tr><td>Glass vial (2 dram)</td><td>Thermo Fisher Scientific</td><td>033401C</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Halocarbon oil</td><td>Sigma Aldrich</td><td>H8898-50ML</td><td>Company Location: St. Louis, MO, USA</td></tr><tr><td>P-2000 Laser Needle Puller</td><td>Sutter Instruments</td><td>P-2000/G</td><td>Company Location: Nobato, CA, USA</td></tr><tr><td>Parafilm</td><td>Thermo Fisher Scientific</td><td>50-998-944</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>PC-100 Weighted Needle Puller</td><td>Narishige</td><td>PC-100</td><td>This is compatabile with the earlier PC-10 model, which has been discontinued. Company Location: Amityville, NY, USA</td></tr><tr><td>Phire Direct PCR Kit</td><td>Thermo Fisher Scientific</td><td>F140WH</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Kodak Photo-Flo (1%)</td><td>Thermo Fisher Scientific</td><td>50-268-05</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Quartz glass mirocapillary tubes, 1 mm outer diameter</td><td>Capillary Tube Supplies Limited</td><td>QGCT 1.0</td><td>Company Location: Cornwall, UK</td></tr><tr><td>Guide-it&amp;trade; sgRNA Screening Kit</td><td>Takara, Bio USA</td><td>632639</td><td>This kit allows you to determine if gRNAs cut DNA sequences in vitro. Company Location: Mountain View, CA, USA</td></tr><tr><td>Sigmacote</td><td>Sigma Aldrich</td><td>SL2-100ML</td><td>Company Location: St. Louis, MO, USA</td></tr><tr><td>Small petri dishes (35X10 mm)</td><td>Thermo Fisher Scientific</td><td>50-190-0273</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Sodium citrate chicken blood</td><td>Lampire biologicals</td><td>7201406</td><td>Company Location: Everett, PA, USA</td></tr><tr><td>Fisherbrand Square petri dish (10 cm x 10 cm)</td><td>Thermo Fisher Scientific</td><td>FB0875711A</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Tegaderm</td><td>Henry Schein Inc.</td><td>7771180</td><td>Company Location: Melville, NY USA</td></tr><tr><td>Tropical fish food</td><td>Tetramin</td><td>N/A</td><td></td></tr><tr><td>Whatman filter paper</td><td>Thermo Fisher Scientific</td><td>09-927-826</td><td>Company Location: Waltham, MA, USA</td></tr><tr><td>Whatman filter paper, 4.25 cm</td><td>Sigma Aldrich</td><td>1001-042</td><td>Company Location: St. Louis, MO, USA</td></tr></tbody></table>

preparing and injecting embryos of culex mosquitoes to generate null mutations using crispr/cas9

Culex mosquitoes are the major vectors of several diseases that negatively impact human and animal health including West Nile virus and diseases caused by filarial nematodes such as canine heartworm and elephantasis. Recently, CRISPR/Cas9 genome editing has been used to induce site-directed mutations by injecting a Cas9 protein that has been complexed with a guide RNA (gRNA) into freshly laid embryos of several insect species, including mosquitoes that belong to the genera Anopheles and Aedes. Manipulating and injecting Culex mosquitoes is slightly more difficult as these mosquitoes lay their eggs upright in rafts rather than individually like other species of mosquitoes. Here we describe how to design gRNAs, complex them with Cas9 protein, induce female mosquitoes of Culex pipiens to lay eggs, and how to prepare and inject newly laid embryos for microinjection with Cas9/gRNA. We also describe how to rear and screen injected mosquitoes for the desired mutation. The representative results demonstrate that this technique can be used to induce site-directed mutations in the genome of Culex mosquitoes and, with slight modifications, can be used to generate null-mutants in other mosquito species as well.&#160;

Using the described protocol, we were able to successfully inject embryos of Cx. pipiens, and observed a high rate of survival among the injected embryos (~55%, Figure 1). Earlier trials had a lower percentage of survival, likely because the anterior of the egg follicle was attached to the medical dressing strip, preventing mosquito larvae from escaping from the chorion and successfully swimming into the water. Ensuring that the anterior end extends beyond the strip of medical dressing greatly increased larval survival, and results in high quality offspring that are capable of developing to adulthood and reproducing (Figure 2B).
Subsequent experiments and screening indicate that the null mutation for the circadian clock gene cycle (cyc; KM355981) made it into the germline of the injected embryos (Figure 3). Given that our primers amplified a large region of the cyc gene near the cut-sites, it was difficult to observe two separate bands in heterozygous, F1 mosquitoes. This demonstrates the utility of designing primers that will amplify fragments that are ~100-200 bp around the cut site, and also the importance of sequencing all suspected mutant mosquitoes. Sequencing revealed that approximately 10% of the screened mosquitoes showed a small insertion or deletion near the Cas9 cut site of the first guide RNA that we had designed (Figure 3), suggesting that this was a highly effective gRNA and that we successfully targeted the pole cells during microinjections. The F1 individuals successfully mated and produced viable offspring (F2 generation), some of which also contained the mutation.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/61651/61651fig1.jpg" />
Figure 1: Example of a beveled borosilicate needle. This needle was fabricated from a siliconized borosilicate microcapillary tube, pulled using a PC-10 vertical needle puller, and then beveled on a BV-10 Beveller. The needle is viewed under ~63x magnification. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/61651/61651fig1large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/61651/61651fig2.jpg" />
Figure 2: Survival of the F0&#173; generation across their development. (A) Image of 1st instar larvae that hatched from 3 slides containing injected embryos. (B) Graphical representation of the number of individuals at each life stage. Of the 801 embryos that were injected, 441 1st instar larvae hatched, and of these 149 individuals reached pupation, resulting in a total of 121 adults (73 males and 43 females). <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/61651/61651fig2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/61651/61651fig3.jpg" />
Figure 3: Representative results showing the transmission of the desired mutation. The top two sequences represent the sequence of the cycle gene in Culex quinquefascaitus (Cx.quinq; XP_001865023.1) and in wild type females of Cx. pipiens (WT.F; KM355981). The sequences below represent sequences in three male F&#173;1 offspring (I.DM1; II.JM4; II.K10M). The green box represents the PAM sequence recognized by the Cas9 protein (CGG) while the green arrow represents where the Cas9 protein cleaved genomic DNA. These results show that short deletions of 2 or 4 nucleotides were inherited in the F1 males. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/61651/61651fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
