Imaging and analysis guidance was provided by the Research Resources Center &#8211; Research Histology and Tissue Imaging Core at the University of Illinois at Chicago established with the support from the office of the Vice Chancellor for Research. The work was supported by NIH/NCI RO1CA191317 to CLP, by NIH/NIAMS (SBDRC grant 1P30AR075049-01) to Dr. A. Paller, and by support of the Robert H. Lurie Comprehensive Cancer Center to the Immunotherapy Assessment Core at Northwestern University.

Mouse spleen and HLF16 mouse tumor tissues23 were obtained from our laboratory. Human tonsil tissue was purchased from a commercial vendor. Details are provided in the Table of Materials.
1. Tissue Embedding
<ol>
	<li>Embed fresh tissue in OCT (optimal cutting temperature) solution and snap freeze using either dry ice or liquid nitrogen.</li>
	<li>Store tissues at -80 &#176;C.</li>
</ol>
2. Cryosectioning
<ol>
	<li>Cut 8 &#956;m sections in a cryostat with temperatures set at -25 &#176;C.
	NOTE: The preferred section thickness can be adjusted to generate crisper images.</li>
	<li>Place sections on charged glass slides.</li>
	<li>Air-dry the sections for 1 h at room temperature (RT) prior to fixing in histology grade ice-cold acetone for 10 min.
	NOTE: Acetone causes coagulation of water-soluble proteins and extracts lipids but does not impact carbohydrate-containing components. In contrast, formalin preserves most lipids and has little impact on carbohydrates24. The choice of fixative is important depending on the choice of marker being detected.</li>
	<li>Store the slides at -20 &#176;C.</li>
</ol>
3. Selection of Antibodies and Fluorophores
NOTE: Before tissue staining, antibody clones that will robustly and specifically stain their antigens of interest within sequential sections from acetone fixed tissue must be validated. Some antibodies may require a different fixative, and their compatibility with other antibodies in the panel will also have to be empirically determined. The goal is also to identify fluorophores with minimal overlap that can be detected with the epifluorescence filters for DAPI, FITC, Cy3, Texas Red, and Cy5.
<ol>
	<li>Confirm staining by conventional IHC or immunofluorescence (IF) detection in tissue sections with known expression target antigen.</li>
	<li>Using the excitation and emission filter sets available on the semiautomated imaging system and after testing various combinations of fluorophore-conjugated primary antibodies, prepare fluorophores to be used that have minimal spectral overlap (e.g., see Table 1).</li>
</ol>
4. Staining
NOTE: The tissue rehydration and slide washes were performed in a Coplin jar. The blocking and antibody incubation steps were performed in a humidified slide box.
<ol>
	<li>Allow the slides to warm to RT for 5&#8211;10 min.</li>
	<li>Rehydrate in phosphate buffered saline (PBS) for 5 min.</li>
	<li>Perform a blocking step prior to staining tissues with antibodies. For mouse sections, use specialized blocking solution (see Table of Materials) for 10 min at RT. For human sections, use 10% normal pooled human serum (NHS) diluted in PBS for 15 min at RT.
	NOTE: Different blocking buffers may be tested as needed to preserve the specific properties of the sections depending on the follow-up procedures to be used.</li>
	<li>Wash the slides for 5 min in PBS after blocking.</li>
	<li>For multiplex staining, prepare a cocktail of antibodies with compatible fluorophores at predetermined optimal dilutions.</li>
	<li>Add the cocktail of fluorophore-conjugated antibodies to the slides. For single-marker staining, add only the primary-conjugated antibody to the slide.</li>
	<li>Include a control unstained slide that undergoes the same staining procedure without the addition of any primary-conjugated antibody.</li>
	<li>Incubate the slides for 1 h at RT in the dark and then wash the slides 2x with PBS for 5 min each. From here on, the resulting slide is referred to as multiplex-stained.</li>
	<li>To counterstain, add DAPI to the multiplex-stained slide, incubate for 7 min in the dark at RT, and wash the slides 2x with PBS for 5 min each. Do not counterstain single-stained and unstained slides.</li>
	<li>To coverslip, add a drop of the mounting medium, and gently place the glass coverslip over the tissue.</li>
</ol>
5. Preparing a Spectral Library
<ol>
	<li>Image acquisition
	<ol>
		<li>Set the lamp power to 100%. Usually the power is set to 10% because fluorescence detection on FFPE tissues includes a signal amplification step.</li>
		<li>Begin by opening the microscope operating software (see Table of Materials).</li>
		<li>Select Edit Protocol and then New Protocol.</li>
		<li>Provide a &#34;Protocol Name&#34;, and select Fluorescence&#160;under Imaging Mode, and provide a &#34;Study Name&#34;.</li>
		<li>Place the single-stained slides on the stage and examine each marker in its corresponding fluorescence channel to ensure staining. Choose a region on the tissue expressing the strongest signal for the marker.</li>
		<li>Adjust the exposure times using the Autofocus and Autoexpose options.</li>
		<li>Acquire snapshots for the single-stained and unstained slides and save the protocol.
		NOTE:&#160;The following steps are performed in machine learning software (see&#160;Table of Materials), using the single stained and unstained slides to verify specific staining as well as to determine antibody cross talk.</li>
		<li>Under the Build Libraries tab in the software, load each single-stained slide image, choose the appropriate Fluor, and click Extract. The software will automatically extract the fluorescence signal chosen in the Fluor.</li>
		<li>To save the extracted color, click on Save to Store. A &#34;New Group&#34; may be created or the extracted color can be stored to an existing group.</li>
	</ol>
	</li>
	<li>Verifying the spectral library
	<ol>
		<li>Check the emission spectral curve window, located to the right of the extracted image, for each filter set.
		NOTE: The extracted signal is correct if the spectral curve is observed only in the filter sets where the fluorophore is detected. If a spectral curve is observed in the wrong filter set, it can mean that either the primary signal expected in the filter set is not strong enough, or the software is detecting another signal that is too high, possibly due to spectral overlap. In this case, first try using the Draw Processing Regions tool to draw regions around areas expressing the fluorescent marker and autofluorescence in the image. This trains the software to detect the true signal and remove any interfering signals. If this does not work, repeat the staining process for the single-stained slide to test different antibody titrations.</li>
	</ol>
	</li>
</ol>
6. Multispectral Imaging
NOTE: Once the spectral library is created and verified, perform the following steps for the multiplex-stained slide.
<ol>
	<li>Whole slide scan
	<ol>
		<li>Adjust focus and exposure times on the multiplex-stained slide as mentioned under in section 5.1.</li>
		<li>Under Scan Slides, create a New Task and choose the protocol saved above.</li>
		<li>Perform a whole slide scan on the multiplex-stained slide.</li>
		<li>Using the whole slide scan software, open the whole slide scan image. This image has not been spectrally unmixed.</li>
		<li>Select regions of interest (ROI) across the whole slide scan image using the Stamp or ROI tool. These ROIs will be scanned using the exposure times set in 6.1.1 to be used for spectral unmixing and analysis.</li>
		<li>Click Process Slide to acquire ROIs at 20x magnification</li>
	</ol>
	</li>
	<li>Spectral unmixing
	<ol>
		<li>Once the ROIs have been acquired, in the machine learning software, under the Manual Analysis tab, load the multiplex stained images by clicking Open under File.</li>
		<li>In the Spectral Library Source dropdown menu click Select Fluors.</li>
		<li>A new window will open. Here, choose the spectral library or group created above.</li>
		<li>Load the unstained slide image. Click the AF ink marker icon located above the selected spectral library and draw a line or region on the unstained slide to identify autofluorescence in the tissue.</li>
		<li>Under the Edit Markers and Colors tab, assign names for each marker. Pseudo colors can be assigned at this step.
		NOTE: The color for the Autofluorescence image defaults to DarkSlateGray. Change this to Black.</li>
		<li>Click Prepare All.</li>
	</ol>
	</li>
	<li>Verifying spectrally unmixed images
	NOTE: When the spectral unmixing step is completed, a composite image consisting of all the colors is created.
	<ol>
		<li>Click the Edit the View eye icon. Here, each color in the &#34;Component Display&#34; can be turned off or on to view the staining of each individual marker.</li>
		<li>Visually inspect the staining and the morphology of the cells to ensure that there is no overlapping of marker, unless it is biologically relevant. A pathologist can help verify the staining as well.
		NOTE: The staining on the multiplexed slide should be validated by leaving out one fluorophore at a time and reviewing the staining pattern. In addition, the validation will also help to identify strong fluorophores that appear in adjacent spectra due to antibody cross talk or bleed-through.</li>
		<li>For Pathology Views, which simulate brightfield images for each fluorescent marker, click the Select a Component Image button. Here, choose a marker to view a simulated brightfield image.</li>
	</ol>
	</li>
</ol>
7. Analyzing Multispectral Images via Cell Segmentation and Phenotyping
NOTE: After verifying the spectrally unmixed image, cell segmentation can be performed using the machine learning software, which will provide step-by-step instructions. Tissue segmentation was not performed here. If the panel includes one or more tissue specific marker and especially if the tissue is messy, tissue segmentation should be performed.
<ol>
	<li>Select &#34;Cytoplasm&#34; and &#34;Membrane&#34; under the &#39;Segment&#39; option.
	NOTE: &#34;Nuclei&#34; is chosen by default.</li>
	<li>Select a marker from the panel. Configure the marker to detect either nuclei, cytoplasm, or membrane. For example, DAPI can be selected to detect nuclei and CD3 for membrane.</li>
	<li>Click on the ellipsis button (&#39;...&#39;) to select an option under &#34;use this signal to find&#34;. For example, &#39;nuclei&#39; for DAPI. Multiple markers from the panel can be selected for segmentation.
	NOTE: For cytoplasmic or membrane markers, select the &#34;Use this signal to assist in nuclear segmentation&#34; option.</li>
	<li>The software automatically detects and creates a mask each for the nucleus, cytoplasm, and membrane in the image.</li>
	<li>Ensure all the cells are &#39;masked&#39; for segmentation. To adjust, switch to the Pathology View for the specific marker chosen in 7.3. and use the configuration options in the software.</li>
	<li>Click &#34;Segment All&#34; to segment cells.</li>
	<li>After cell segmentation, proceed with phenotyping cells. In this step, choose the markers needed for phenotyping and manually select at least five cells that are brightly stained with the chosen marker. This trains the software to then automatically detect all cells stained with the chosen marker in the image.</li>
	<li>A phenotype map is created. Analyze to ensure that the cell stained with the marker is correctly phenotyped.
	NOTE: Cell phenotyping can be an iterative process. If the software is unable to phenotype the cells correctly, it means that the training is inadequate or incorrect. In this case, the user has to manually select more cells and retrain the software and repeat this step until the user is satisfied with the training.</li>
	<li>Create a group named &#34;Others&#34; and include cells that are not stained for any of the markers.
	NOTE: This step is important to train the software to exclude all the unstained cells from phenotyping.</li>
</ol>
8. Exporting Images and Analysis Tables
<ol>
	<li>Click the Export button to view the Export Settings panel.</li>
	<li>In the &#34;Export Directory&#34;, click Browse to select a location to export the images.</li>
	<li>In the &#34;Image Export Options&#34;, choose the Image Output Format.</li>
	<li>In the &#34;Images to Export&#34; list, select the images to be exported. &#34;Composite image&#34; is the final pseudocolored unmixed image. &#34;Pathology Views&#34; are the individual simulated brightfield images and the &#34;Component Images (multi-image TIFF)&#34; is a multi-image TIFF file of component data that can be used by third party analysis software.</li>
	<li>Click &#34;Export for All&#34; button to export the images.
	NOTE: Tables from analysis can also be selected and exported at this step.</li>
</ol>

The authors have no conflicts of interest to disclose.

Frozen tissues have extensively been used for mIF imaging to traditionally detect three to four markers31 on a tissue using the direct and indirect method32. In the direct method, antibodies are conjugated to fluorescing dyes or quantum dots33 to label the tissue, whereas in the indirect method, an unconjugated primary antibody is used to label the tissue followed by a fluorophore-conjugated secondary antibody that specifically recognizes the primary antibody. Some of the recent simultaneous multiplex staining approaches discussed earlier can also be used to stain frozen tissues and detect more than four markers. But the cost for the reagents and the time taken for staining become intensive depending on the number of markers being detected. Another multiplex technique for frozen tissues is the multi-epitope-ligand-cartography (MELC)34. The technique involves staining the sample with fluorophore-conjugated antibodies, imaging, and photobleaching of the fluorophore. A major caveat of this technique is that only one field or region of the tissue can be multiplexed. In order to multiplex other fields or regions the technique needs to be performed manually, which is time-consuming, or requires automation, which is costly. One group35 was able to detect six colors on frozen tissues using a combination of direct, indirect, and TSA staining. However, the tissue staining took 2 days. In comparison, our methodology uses a simultaneous multiplex staining method involving the application of a cocktail of five directly conjugated antibodies plus DAPI to stain frozen tissues within 90 min. Furthermore, using a semiautomated multispectral fluorescence imaging system, we were able to spectrally separate and detect six markers in frozen spleen, tonsil, and tumor tissues using this simplified multiplex staining technique. The Cy3, Texas Red, and the Cy5 filter sets available on the microscope provide opportunities for detecting additional fluorophores, thereby potentially increasing the number of markers that can be detected simultaneously in frozen tissues.
Multiplex staining using the TSA approach on FFPE tissues requires an antigen retrieval step followed by sequential labeling, washing, and stripping steps. Performing the procedure ranges from 1&#8211;2 days depending on the incubation times used for the antibodies6. Recently, using a microfluidic tissue processor, a four-plex staining using the TSA approach was performed on FFPE tissues under 90 min. Other multiplex techniques for FFPE tissues can be performed under 4&#8211;5 h using an automated stainer. However, the appropriate antigen retrieval steps need to be optimized to ensure epitope availability for the antibodies36, which in turn relies on the careful consideration of the antibody clones as well as the order of markers being detected. For example, some antibody clones of CD3 cannot be used, because subsequently CD4 and CD8 antibodies are not detected37. Similarly, there is variability of antigen detection among the available antibody clones17,18. Therefore, multiplex staining of FFPE tissues requires optimization of antibody clones, their concentrations, and the order in which they are stained, all of which is time-consuming. In contrast, the lack of extensive tissue processing of frozen tissues allows for the use of various antibody clones with high specificity. Moreover, antibody clones available for frozen tissues can also be used in flow cytometry and ELISA, allowing simultaneous validation across various assays. Tissue architecture is also a concern in frozen tissues38. The multiplex staining shown here on frozen tissues is significantly faster than the TSA approach. The fluorophore combinations require a careful selection of markers to ensure that antibodies do not sterically hinder each other, especially when different antigens expressed in the same cellular location are detected. We chose markers that stain different cells on fluorophores that are spectrally separate, enabling better detection. The antibody concentrations also require optimization, but because the staining protocol is quick, the overall time taken for optimization is not time-consuming. A caveat to our method may be the inability to detect low expressing markers in tissues. Some of the multiplex staining approaches on FFPE tissues involve a signal amplification step that is useful to detect low expressing markers. However, the use of secondary and tertiary antibodies can be employed to boost the signal. In such cases, cross reactivity to antibodies in the panel should be avoided to prevent incorrect interpretation of the results.
In addition to mouse spleen and human tonsil tissues, which are rich in immune cells, we have used tumor tissue as an example for the proposed multispectral fluorescence imaging of frozen tissues. Multispectral fluorescence imaging in tumors has provided valuable information, such as characterizing the tumor microenvironment (TME)39, predicting the success of adoptive T cell transfers in malignant melanoma40, and characterizing proteins in tumor signal transduction pathways41. Using markers specific to immune cells commonly found in tumors, we were able to detect infiltrating CD8 T cells and TAMs in the HLF16 tumor tissue used in this study. We used the machine learning software to successfully segment and phenotype cells. Multiplex staining for FFPE tissues employs a signal amplification step to enhance signal-to-noise (SNR) ratio that helps image processing and quantification42,43. The machine learning software has been used for analyses on FFPE tissues stained with signal amplification2. The methodology present here does not use signal amplification, but we were able to successfully segment and phenotype cells using the software. For further analysis (e.g., phenotype coexpression and spatial relationships) and accurate interpretation of the quantitation, the software training requires validation using a training set, test set, and validation set. In an iterative process, one set of images (i.e., the training set) is used to train the machine learning software to identify the phenotypes until the model&#8217;s predictions for a separate set of images (i.e., the test set) are accurate. After training is complete, a final set-aside batch of images (i.e., the validation set) is analyzed to see if there has been over-fitting.
In conclusion, the methodology presented here is a rapid way of performing multispectral fluorescence imaging using frozen tissues. The method is useful to detect markers to which either antibodies are not available or cannot be detected in FFPE tissues. In conjunction with the machine learning software, the time taken to perform quantitative analyses can significantly facilitate rapid preclinical and clinical diagnoses and may be applied in the field of high-resolution spatial transcriptomics that utilizes frozen tissues44.

Recent advances in microscopic imaging techniques have significantly improved our knowledge and understanding of biological processes and disease states. In situ detection of proteins in tissues via chromogenic immunohistochemistry (IHC) is routinely performed in pathology. However, detection of multiple markers using chromogenic IHC staining is challenging1 and newer methods to use multiplex immunofluorescence (mIF) staining approaches, wherein multiple biological markers are labeled on a single tissue sample, are being developed. The detection of multiple biological markers is useful, because information related to tissue architecture, spatial distribution of cells, and antigen co-expression are all captured in a single tissue sample2. The use of multispectral fluorescence imaging technology has made detection of multiple biological markers possible. In this technology, using specific optics the fluorescence spectra of each individual fluorophore can be separated or &#34;unmixed&#34;, enabling the detection of multiple markers without any spectral crosstalk3. Multispectral fluorescence imaging is becoming a critical approach in cell biology, preclinical drug development, clinical pathology, and tumor immune-profiling4,5,6. Importantly, the spacial distribution of immune cells (specifically CD8 T cells) can serve as a prognostic factor for patients with existing tumors7.
Various approaches to multiplex fluorescence staining have been developed and can be performed either simultaneously or sequentially. In the simultaneous staining method, all the antibodies are added together as a cocktail in a single step to label the tissue. UltraPlex technology uses a cocktail of hapten-conjugated primary antibodies followed by a cocktail of fluorophore-conjugated anti-hapten secondary antibodies. InSituPlex technology8 uses a cocktail of unique DNA-conjugated primary antibodies that are simultaneously added to the tissue followed by an amplification step and finally fluorophore-conjugated probes that are complementary to each unique DNA sequence on the primary antibody. Both of these technologies enable the detection of four markers plus 4&#8217;,6-diamino-2-phenylindole (DAPI) for nuclear staining. Two other approaches for simultaneous multiplex staining are based on secondary ion mass spectrometry9. The Hyperion Imaging System uses imaging mass cytometry10 to detect up to 37 markers. This technology uses a cocktail of metal-conjugated antibodies to stain the tissues, and specific areas of the tissues are ablated by a laser and transferred to a mass cytometer where the metal ions are detected. Another similar technology is the IONPath, which uses multiplexed ion beam imaging technology11. This technology uses a modified mass spectrometry instrument and an oxygen ion source instead of laser to ablate the metal-conjugated antibodies. While all these simultaneous multiplex staining approaches enable the detection of multiple markers, the costs involved for conjugating DNA, haptens, or metals to antibodies, the loss of tissue due to ablation, and the extensive image processing for unmixing cannot be underestimated. Moreover, kits and staining protocols are currently available only for FFPE tissues and developing custom panels entails additional time and expenditure.
The sequential multiplex staining method, in contrast, includes labeling the tissue with an antibody to one marker, stripping to remove the antibody, followed by sequential repeats of this process to label multiple markers12. The tyramide signal amplification (TSA) is the most frequently used sequential multiplexing method. Two other multiplexing technologies use a combination of simultaneous and sequential staining methods. The CODEX platform13 employs a cocktail of antibodies conjugated to unique DNA oligonucleotide sequences that are eventually labeled with a fluorophore using an indexed polymerization step followed by imaging, stripping, and repeating the process to detect up to 50 markers. The MultiOmyx multiplex staining approach14 is an iteration of staining with a cocktail of three to four fluorophore-conjugated antibodies, imaging, quenching the fluorophores, and repeating this cycle to detect up to 60 markers on a single section. Similar to the simultaneous multiplex staining method, while a broad range of markers can be detected, the time involved in staining, image acquisition, processing, and analysis is extensive. The stripping/quenching step involves heating and/or bleaching the tissue sample and thus, the sequential multiplex staining approach is commonly performed on FFPE tissues that maintain tissue integrity upon heating or bleaching.
Formalin fixation and subsequent paraffin embedding is readily performed in a clinical setting, tissue blocks are easy to store, and several multiplex staining protocols are available. However, the processing, embedding, and deparaffinization of FFPE tissues, as well as antigen retrieval15, a process by which antibodies can better access epitopes, is time-consuming. Furthermore, the processing involved in FFPE tissues contributes to autofluorescence16 and masks target epitopes, resulting in the variability and lack of antibody clone available to detect antigens in FFPE tissues17,18,19. An example is the human leukocyte antigen (HLA) class I alleles20. In contrast, snap freezing of tissues does not involve extensive processing steps prior to or after fixing, circumventing the need for antigen retrieval21,22, and making it beneficial for detecting a wider range of targets. Therefore, using frozen tissues for multispectral fluorescence imaging can be valuable to detect targets for preclinical and clinical studies.
Given the above mentioned limitations when using FFPE tissues, we asked whether multispectral fluorescence imaging can be performed on frozen tissues. To address this question, we tested a simultaneous multiplex staining method using a panel of fluorophore-conjugated antibodies to detect multiple antigens and analyzed the staining using a semiautomated multispectral imaging system. We were able to simultaneously stain up to six markers in a single tissue section within 90 min.

<table><tbody><tr><td>Acetone (histological grade)</td><td>Fisher Scientific</td><td>A16F-1GAL</td><td>Fixing tissues</td></tr><tr><td>Alexa Fluor 488 anti-mouse CD3</td><td>BioLegend</td><td>100212</td><td>Clone - 17A2; primary conjugated antibody</td></tr><tr><td>Alexa Fluor 488, eBioscience anti-human CD20</td><td>ThermoFisher Scientific</td><td>53-0202-82</td><td>Clone - L26; primary conjugated antibody</td></tr><tr><td>Alexa Fluor 555 Mouse anti-Ki-67</td><td>BD Biosciences</td><td>558617</td><td>Primary conjugated antibody</td></tr><tr><td>Alexa Fluor 594 anti-human CD3</td><td>BioLegend</td><td>300446</td><td>Clone - UCHT1; primary conjugated antibody</td></tr><tr><td>Alexa Fluor 594 anti-mouse CD8a</td><td>BioLegend</td><td>100758</td><td>Clone - 53-6.7; primary conjugated antibody</td></tr><tr><td>Alexa Fluor 647 anti-human CD8a</td><td>BioLegend</td><td>372906</td><td>Clone - C8/144B; primary conjugated antibody</td></tr><tr><td>Alexa Fluor 647 anti-mouse CD206 (MMR)</td><td>BioLegend</td><td>141711</td><td>Clone - C068C2; primary conjugated antibody</td></tr><tr><td>Alexa Fluor 647 anti-mouse CD4 Antibody</td><td>BioLegend</td><td>100426</td><td>Clone - GK1.5; primary conjugated antibody</td></tr><tr><td>C57BL/6 Mouse</td><td>Charles River Laboratories</td><td>27</td><td>Mouse frozen tissues used for multispectral training</td></tr><tr><td>Coplin Jar</td><td>Sigma Aldrich</td><td>S6016-6EA</td><td>Rehydrating and washing slides</td></tr><tr><td>DAPI Solution</td><td>BD Biosciences</td><td>564907</td><td>Nucleic Acid stain</td></tr><tr><td>Diamond White Glass Charged Slides</td><td>DOT Scientific</td><td>DW7590W</td><td>Adhering tissue sections</td></tr><tr><td>Dulbecco&#039;s Phosphate Buffered Saline 1x (without Ca and Mg)</td><td>Fisher Scientific</td><td>MT21031CV</td><td>Washing and diluent</td></tr><tr><td>Gold Seal Cover Slips</td><td>ThermoFisher Scientific</td><td>3306</td><td>Protecting stained tissues</td></tr><tr><td>Human Normal Tonsil OCT frozen tissue block</td><td>AMSBio</td><td>AMS6023</td><td>Human frozen tissue used for multispectral staining</td></tr><tr><td>Human Serum 1x</td><td>Gemini Bio-Products</td><td>100-512</td><td>Blocking and diluent for human tissues</td></tr><tr><td>inForm</td><td>Akoya Biosciences</td><td>Version 2.4.1</td><td>Machine learning software</td></tr><tr><td>PerCP/Cyanine5.5 anti-human CD4</td><td>BioLegend</td><td>300529</td><td>Clone - RPA-T4; primary conjugated antibody</td></tr><tr><td>PerCP-Cy 5.5 Rat Anti-CD11b</td><td>BD Biosciences</td><td>550993</td><td>Clone - M1/70; primary conjugated antibody</td></tr><tr><td>Phenochart</td><td>Akoya Biosciences</td><td>Version 1.0.8</td><td>Whole slide scan software</td></tr><tr><td>ProLong Diamond Antifade Mountant</td><td>ThermoFisher Scientific</td><td>P36965</td><td>Mounting medium</td></tr><tr><td>Research Cryostat</td><td>Leica Biosystems</td><td>CM3050 S</td><td>Sectioning tissues</td></tr><tr><td>Superblock 1x</td><td>ThermoFisher Scientific</td><td>37515</td><td>Blocking mouse tissues</td></tr><tr><td>Tissue-Tek O.C.T Solution</td><td>Sakura Finetek</td><td>4583</td><td>Embedding tissues</td></tr><tr><td>Vectra 3.0 Automated Quantitative Pathology Imaging System, 6 Slide</td><td>Akoya Biosciences</td><td>CLS142568</td><td>Semi-automated multispectral imaging system</td></tr><tr><td>Vectra Software</td><td>Akoya Biosciences</td><td>Version 3.0.5</td><td>Software to operate microscope</td></tr></tbody></table>

a rapid method for multispectral fluorescence imaging of frozen tissue sections

Multispectral fluorescence imaging on formalin-fixed paraffin-embedded (FFPE) tissues enables the detection of multiple markers in a single tissue sample that can provide information about antigen coexpression and spatial distribution of the markers. However, a lack of suitable antibodies for formalin-fixed tissues may restrict the nature of markers that can be detected. In addition, the staining method is time-consuming. Here we describe a rapid method to perform multispectral fluorescence imaging on frozen tissues. The method includes the fluorophore combinations used, detailed steps for the staining of mouse and human frozen tissues, and the scanning, acquisition, and analysis procedures. For staining analysis, a commercially available semiautomated multispectral fluorescence imaging system is used. Through this method, up to six different markers were stained and detected in a single frozen tissue section. The machine learning analysis software can phenotype cells that can be used for quantitative analysis. The method described here for frozen tissues is useful for the detection of markers that cannot be detected in FFPE tissues or for which antibodies are not available for FFPE tissues.

Detection of single-stained markers on frozen spleen sections
As the semiautomated imaging system uses a liquid crystal tunable filter (LCTF) system that allows for a wider range of wavelength detection25, and because no signal amplification steps were performed here, we first optimized the detection of our primary-conjugated antibodies for each marker on the microscope. An example is shown in Figure 1, where each single-stained marker is pseudo-colored red. The Alexa Fluor conjugated antibodies used here have been validated by the companies for immunofluorescence and flow cytometry. However, the Per-CP-Cy5.5 fluorophore is only validated for flow cytometry. We were able to detect this color in our single-stained slides, supporting the suitability of flow cytometry validated antibodies for use in multispectral imaging and providing the benefit of using such antibodies to validate observations using two different techniques (i.e., flow cytometry and multispectral imaging). We then proceeded to perform multispectral imaging on frozen tissues.
Multicolor fluorescence detection on frozen mouse spleen
To test the multiplex staining method and spectral imaging, we used mouse frozen spleen tissue, which has an abundance of immune cells. Figure 2 shows a spectrally unmixed image of different markers in a section of frozen mouse spleen. The antibodies, clones, and concentrations used for staining are described in Table 2. The captured image shows a portion of the T cell zone identified by the presence of CD3, CD4, and CD8 markers, surrounded by myeloid cells expressing CD11b mostly observed in the marginal zone. Regions of proliferating cells expressing Ki67 are observed primarily in germinal centers. The &#34;Pathology Views&#34; option for each marker showed its individual staining pattern within the tissue. Distinct staining patterns for CD11b, Ki67 and the CD3, CD4, and CD8 markers together were observed, suggesting that the multiplex staining method and spectral imaging worked on the frozen tissue.
Multi-color fluorescence detection on frozen human tonsil
After testing a staining panel suited for mouse tissue, we next assessed a separate panel for frozen human tonsil tissue. Figure 3 shows a spectrally unmixed image of the different markers used. The antibodies, clones, and concentrations used for staining are described in Table 2. The captured image shows a follicular germinal center26 expressing B-cells identified by the CD20 marker. Proliferating cells in the follicular germinal center were identified by Ki67. Some of these proliferating cells costained with CD20 and may be centroblasts27, na&#239;ve B-cells that undergo active somatic hypermutation. The follicular germinal centers were surrounded by the interfollicular T cell region identified by the expression of CD3, CD4, and CD8. Again, distinct staining patterns were observed here, confirming that the methodology worked on a frozen tissue.
Application of multispectral fluorescence imaging on frozen mouse tumor tissue
Multispectral imaging is a useful tool for monitoring immune cell infiltration in tumors as a prognosis for immunotherapies. To this end, we set out to stain a frozen mouse tumor tissue sample and detect immune cell infiltrates. The HLF16 cell line is used as a human papillomavirus (HPV)+ tumor model of cervical cancer in HLA-A*0201 transgenic mice28. The transgenic cell line was developed by transfecting heart lung fibroblasts from HLA-A*0201 with HPV16 E6 and E7 oncogenes and H-Ras V1228. T cells and tumor associated macrophages are the most common immune infiltrates present in tumors29. Figure 4 shows a spectrally unmixed image on a frozen HLF16 tumor section along with the pathology views; the individual staining patterns are shown in Supplementary Figure 1. The antibodies, clones, and concentrations used for staining are described in Table 2. The captured image shows regions of tumor-infiltrating T cells identified by the CD3 and CD8 markers along with the presence of other myeloid cell lineages identified by the CD11b marker. The captured region also shows tumor associated macrophages (TAMs), possibly of the M2 phenotype, detected by the CD206 marker30, which is closely associated to several proliferating cells detected as Ki67+.
The machine learning software2 comes with features like tissue and cell analyses. These analyses are commonly performed on FFPE tissues stained with signal amplification. As our methodology does not use signal amplification, we wanted to test if the software could be used to analyze staining on frozen tissues. Using the adaptive feature of the software, we were able to segment cells based on a nuclear and membrane marker and to phenotype cells based on the markers used for staining. Figure 5 shows the cell segmentation and phenotype maps and the number of stained cells for each marker analyzed by the software, demonstrating that the software can be used for quantification of multispectral staining on frozen tissues.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/60806/60806fig01.jpg" />
Figure 1: Detecting primary-conjugated antibodies using a liquid crystal tunable filter microscope.&#160;Primary-conjugated antibodies to the indicated markers were stained on a frozen mouse spleen and detected using the Vectra 3.0 multispectral imaging system under 20x objectives. CD3 on Alexa Fluor 488, CD8 on Alexa Fluor 594, CD11b on Per-CP Cy5.5, CD206 on Alexa Fluor 647, and Ki67 on Alexa Fluor 555 were used. Each marker is pseudo-colored red. No counterstain was used on these slides. Scale bar = 20 &#956;m. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/60806/60806fig01large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/60806/60806fig02.jpg" />
Figure 2: Multispectral imaging on a frozen mouse spleen.&#160;(A) Whole slide scan of the multiplexed stained slide taken under 4x objectives. A 2 x 2 stamp across different regions of the tissue were chosen for multispectral imaging. Scale bar = 100 &#956;m. (B) Composite image taken under a 20x objective after spectral unmixing. The pseudo-colored markers are indicated and a magnified image within the red box is shown next to the image. Scale bar = 20 &#956;m. (C) Pathology views for each individual marker. A magnified image for each marker within the red box is shown next to the image. Scale bar = 20 &#956;m. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/60806/60806fig02large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/60806/60806fig03.jpg" />
Figure 3: Multispectral imaging on a frozen human tonsil.&#160;(A) Whole slide scan of the multiplexed stained slide taken under a 4x objective. A 1 x 1 stamp (669 &#956;m x 500 &#956;m) across different regions of the tissue was chosen for multispectral imaging. Scale bar = 100 &#956;m. (B) Composite image after spectral unmixing taken under a 20x objective. The pseudo-colored markers are indicated and a magnified image within the red box is shown next to the image. Scale bar = 20 &#956;m. (C) Pathology views for each individual marker. A magnified image for each marker within the red box is shown next to the image. Scale bar = 20 &#956;m. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/60806/60806fig03large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 4" class="xfigimg" src="/files/ftp_upload/60806/60806fig04.jpg" />
Figure 4: Multispectral imaging on a frozen mouse tumor.&#160;Multispectral imaging was performed on a 1 x 1 region of a frozen mouse HLF16 tumor taken under a 20x objective. The composite image (above). The pseudo-colored markers are indicated and the pathology views (below) for each individual marker is depicted. A magnified image for each marker within the red box is shown next to the original image. Scale bar = 20 &#956;m <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/60806/60806fig04large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 5" class="xfigimg" src="/files/ftp_upload/60806/60806fig05.jpg" />
Figure 5: Analysis of a frozen mouse tumor section.&#160;(A) Cell segmentation map. Adaptive cell segmentation using inForm was performed. The software was trained to identify nuclei (green) and membrane (red). (B) Phenotype maps for each stained marker. The software was trained to identify phenotypes based on the staining. Colored dot represents the indicated marker. &#34;Other&#34; (black) refers to cells that were not stained for the indicated marker. (C) Bar plot (mean &#177; STDEV) depicting the number of stained cells for each marker in two multispectral images. The number indicates cells phenotyped in each image but does not indicate if the markers are coexpressed. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/60806/60806fig05large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Fluorophore</td>
			<td>Excitation maximum (nm)</td>
			<td>Emission maximum (nm)</td>
			<td>Expected Detection in Filter Set (name)</td>
		</tr>
		<tr>
			<td>Alexa Fluor 488</td>
			<td>488</td>
			<td>519</td>
			<td>FITC</td>
		</tr>
		<tr>
			<td>Alexa Fluor 555</td>
			<td>555</td>
			<td>580</td>
			<td>Cy3 and Texas Red</td>
		</tr>
		<tr>
			<td>Alexa Fluor 594</td>
			<td>590</td>
			<td>617</td>
			<td>Texas Red</td>
		</tr>
		<tr>
			<td>Alexa Fluor 647</td>
			<td>650</td>
			<td>668</td>
			<td>Texas Red and Cy5</td>
		</tr>
		<tr>
			<td>DAPI</td>
			<td>350</td>
			<td>470</td>
			<td>DAPI</td>
		</tr>
		<tr>
			<td>PerCP-Cy 5.5</td>
			<td>482</td>
			<td>690</td>
			<td>Cy3, Texas Red and Cy5</td>
		</tr>
	</tbody>
</table>
Table 1: List of fluorophores with their maximum excitation and emission wavelengths and expected detection in appropriate filter sets.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td colspan="4">Frozen Mouse Spleen</td>
		</tr>
		<tr>
			<td colspan="2">Antibody/Dye</td>
			<td>Clone</td>
			<td>Concentration (&#956;g/mL)</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 594 anti-mouse CD8a</td>
			<td>53-6.7</td>
			<td>10</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 488 anti-mouse CD3</td>
			<td>17A2</td>
			<td>20</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 647 anti-mouse CD4</td>
			<td>GK1.5</td>
			<td>10</td>
		</tr>
		<tr>
			<td colspan="2">PerCP-Cy 5.5 Rat Anti-CD11b</td>
			<td>M1/70</td>
			<td>2</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 555 Mouse anti-Ki-67</td>
			<td>B56</td>
			<td>10</td>
		</tr>
		<tr>
			<td colspan="2">DAPI</td>
			<td></td>
			<td>0.1</td>
		</tr>
		<tr>
			<td colspan="4"></td>
		</tr>
		<tr>
			<td colspan="4">Frozen Mouse Tumor</td>
		</tr>
		<tr>
			<td colspan="2">Antibody/Dye</td>
			<td>Clone</td>
			<td>Concentration (&#956;g/mL)</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 594 anti-mouse CD8a</td>
			<td>53-6.7</td>
			<td>20</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 488 anti-mouse CD3</td>
			<td>17A2</td>
			<td>20</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 647 anti-mouse CD206 (MMR)</td>
			<td>C068C2</td>
			<td>5</td>
		</tr>
		<tr>
			<td colspan="2">PerCP-Cy5.5 Rat Anti-CD11b</td>
			<td>M1/70</td>
			<td>1</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 555 Mouse anti-Ki-67</td>
			<td>B56</td>
			<td>0.25</td>
		</tr>
		<tr>
			<td colspan="2">DAPI</td>
			<td></td>
			<td>0.1</td>
		</tr>
		<tr>
			<td colspan="4"></td>
		</tr>
		<tr>
			<td colspan="4">Frozen Human Tonsil</td>
		</tr>
		<tr>
			<td colspan="2">Antibody/Dye</td>
			<td>Clone</td>
			<td>Concentration (&#956;g/mL)</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 594 anti-human CD3</td>
			<td>UCHT1</td>
			<td>10</td>
		</tr>
		<tr>
			<td colspan="2">PerCP/Cyanine5.5 anti-human CD4</td>
			<td>RPA-T4</td>
			<td>4</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 647 anti-human CD8a</td>
			<td>C8/144B</td>
			<td>10</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 488, eBioscience anti-human CD20</td>
			<td>L26</td>
			<td>10</td>
		</tr>
		<tr>
			<td colspan="2">Alexa Fluor 555 Mouse anti-Ki-67</td>
			<td>B56</td>
			<td>1</td>
		</tr>
		<tr>
			<td colspan="2">DAPI</td>
			<td></td>
			<td>0.1</td>
		</tr>
	</tbody>
</table>
Table 2: List of antibodies, clones, and concentrations used.
Supplementary Figure 1: Individual staining patterns of the frozen HLF16 tumor after spectral unmixing. Scale bar = 20 &#956;m <a href="https://cloudflare-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/60806/60806supfig01.jpg" target="_blank">Please click here to download this figure.</a>

Watch this Scientific Journal Video about A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections at JoVE.com

A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections

We describe a rapid staining method to perform multispectral imaging on frozen tissues.

Multispectral fluorescence imaging on formalin-fixed paraffin-embedded (FFPE) tissues enables the detection of multiple markers in a single tissue sample ...

a-rapid-method-for-multispectral-fluorescence-imaging-frozen-tissue

Nanyang Technological University

Research

JoVE Journal

Immunology and Infection

7.7K Views.  Northwestern University. We describe a rapid staining method to perform multispectral imaging on frozen tissues.

Video: A Rapid Method for Multispectral Fluorescence Imaging of Frozen Tissue Sections

A Rapid Approach to High-Resolution Fluorescence Imaging in Semi-Thick Brain Slices

A fundamental goal to both basic and clinical neuroscience is to better understand the identities, molecular makeup, and patterns of connectivity that are characteristic to neurons in both normal and diseased brain. Towards this, a great deal of effort has been placed on building high-resolution neuroanatomical maps1-3. With the expansion of molecular genetics and advances in light microscopy has come the ability to query not only neuronal morphologies, but also the molecular and cellular makeup of individual neurons and their associated networks4. Major advances in the ability to mark and manipulate neurons through transgenic and gene targeting technologies in the rodent now allow investigators to 'program' neuronal subsets at will5-6. Arguably, one of the most influential contributions to contemporary neuroscience has been the discovery and cloning of genes encoding fluorescent proteins (FPs) in marine invertebrates7-8, alongside their subsequent engineering to yield an ever-expanding toolbox of vital reporters9. Exploiting cell type-specific promoter activity to drive targeted FP expression in discrete neuronal populations now affords neuroanatomical investigation with genetic precision.
Engineering FP expression in neurons has vastly improved our understanding of brain structure and function. However, imaging individual neurons and their associated networks in deep brain tissues, or in three dimensions, has remained a challenge. Due to high lipid content, nervous tissue is rather opaque and exhibits auto fluorescence. These inherent biophysical properties make it difficult to visualize and image fluorescently labelled neurons at high resolution using standard epifluorescent or confocal microscopy beyond depths of tens of microns. To circumvent this challenge investigators often employ serial thin-section imaging and reconstruction methods10, or 2-photon laser scanning microscopy11. Current drawbacks to these approaches are the associated labor-intensive tissue preparation, or cost-prohibitive instrumentation respectively.
Here, we present a relatively rapid and simple method to visualize fluorescently labelled cells in fixed semi-thick mouse brain slices by optical clearing and imaging. In the attached protocol we describe the methods of: 1) fixing brain tissue in situ via intracardial perfusion, 2) dissection and removal of whole brain, 3) stationary brain embedding in agarose, 4) precision semi-thick slice preparation using new vibratome instrumentation, 5) clearing brain tissue through a glycerol gradient, and 6) mounting on glass slides for light microscopy and z-stack reconstruction (Figure 1).
For preparing brain slices we implemented a relatively new piece of instrumentation called the 'Compresstome' VF-200 (http://www.precisionary.com/products_vf200.html). This instrument is a semi-automated microtome equipped with a motorized advance and blade vibration system with features similar in function to other vibratomes. Unlike other vibratomes, the tissue to be sliced is mounted in an agarose plug within a stainless steel cylinder. The tissue is extruded at desired thicknesses from the cylinder, and cut by the forward advancing vibrating blade. The agarose plug/cylinder system allows for reproducible tissue mounting, alignment, and precision cutting. In our hands, the 'Compresstome' yields high quality tissue slices for electrophysiology, immunohistochemistry, and direct fixed-tissue mounting and imaging. Combined with optical clearing, here we demonstrate the preparation of semi-thick fixed brain slices for high-resolution fluorescent imaging.

Here we describe a rapid and simple method to image fluorescently labeled cells in semi-thick brain slices. By fixing, slicing, and optically clearing brain tissue we describe how standard epifluorescent or confocal imaging can be used to visualize individual cells and neuronal networks within intact nervous tissue.

A fundamental goal to both basic and clinical neuroscience is to better understand the identities, molecular makeup, and patterns of connectivity that are ...

Neuroscience

Long-term Intravital Immunofluorescence Imaging of Tissue Matrix Components with Epifluorescence and Two-photon Microscopy

Besides being a physical scaffold to maintain tissue morphology, the extracellular matrix (ECM) is actively involved in regulating cell and tissue function during development and organ homeostasis. It does so by acting via biochemical, biomechanical, and biophysical signaling pathways, such as through the release of bioactive ECM protein fragments, regulating tissue tension, and providing pathways for cell migration. The extracellular matrix of the tumor microenvironment undergoes substantial remodeling, characterized by the degradation, deposition and organization of fibrillar and non-fibrillar matrix proteins. Stromal stiffening of the tumor microenvironment can promote tumor growth and invasion, and cause remodeling of blood and lymphatic vessels. Live imaging of matrix proteins, however, to this point is limited to fibrillar collagens that can be detected by second harmonic generation using multi-photon microscopy, leaving the majority of matrix components largely invisible. Here we describe procedures for tumor inoculation in the thin dorsal ear skin, immunolabeling of extracellular matrix proteins and intravital imaging of the exposed tissue in live mice using epifluorescence and two-photon microscopy. Our intravital imaging method allows for the direct detection of both fibrillar and non-fibrillar matrix proteins in the context of a growing dermal tumor. We show examples of vessel remodeling caused by local matrix contraction. We also found that fibrillar matrix of the tumor detected with the second harmonic generation is spatially distinct from newly deposited matrix components such as tenascin C. We also showed long-term (12 hours) imaging of T-cell interaction with tumor cells and tumor cells migration along the collagen IV of basement membrane. Taken together, this method uniquely allows for the simultaneous detection of tumor cells, their physical microenvironment and the endogenous tissue immune response over time, which may provide important insights into the mechanisms underlying tumor progression and ultimate success or resistance to therapy.

The extracellular matrix undergoes substantial remodeling during wound healing, inflammation and tumorigenesis. We present a novel intravital immunofluorescence microscopy approach to visualize the dynamics of fibrillar as well as mesh-like matrix components with high spatial and temporal resolution using epifluorescence or two-photon microscopy.

Besides being a physical scaffold to maintain tissue morphology, the extracellular matrix (ECM) is actively involved in regulating cell and tissue ...

Bioengineering

Quantitative Multispectral Analysis Following Fluorescent Tissue Transplant for Visualization of Cell Origins, Types, and Interactions

With the desire to understand the contributions of multiple cellular elements to the development of a complex tissue; such as the numerous cell types that participate in regenerating tissue, tumor formation, or vasculogenesis, we devised a multi-colored cellular transplant model of tumor development in which cell populations originate from different fluorescently colored reporter gene mice and are transplanted, engrafted or injected in and around a developing tumor. These colored cells are then recruited and incorporated into the tumor stroma. In order to quantitatively assess bone marrow derived tumor stromal cells, we transplanted GFP expressing transgenic whole bone marrow into lethally irradiated RFP expressing mice as approved by IACUC. 0ovarian tumors that were orthotopically injected into the transplanted mice were excised 6-8 weeks post engraftment and analyzed for bone marrow marker of origin (GFP) as well as antibody markers to detect tumor associated stroma using multispectral imaging techniques. We then adapted a methodology we call MIMicc- Multispectral Interrogation of Multiplexed cellular compositions, using multispectral unmixing of fluoroprobes to quantitatively assess which labeled cell came from which starting populations (based on original reporter gene labels), and as our ability to unmix 4, 5, 6 or more spectra per slide increases, we&#39;ve added additional immunohistochemistry associated with cell lineages or differentiation to increase precision. Utilizing software to detect co-localized multiplexed-fluorescent signals, tumor stromal populations can be traced, enumerated and characterized based on marker staining.1

Complex tissue masses, from organs to tumors, are composed of various cellular elements. We elucidated the contribution of cellular phenotypes within a tissue utilizing multi-labeled fluorescent transgenic mice in combination with multiparameter immunofluorescent staining followed by spectral unmixing to decipher cell origin as well as cell characteristics based on protein expression.

With the desire to understand the contributions of multiple cellular elements to the development of a complex tissue; such as the numerous cell types that ...

Medicine

Three and Four-Dimensional Visualization and Analysis Approaches to Study Vertebrate Axial Elongation and Segmentation

Somitogenesis is a hallmark of vertebrate embryonic development. For years, researchers have been studying this process in a variety of organisms using a wide range of techniques encompassing ex vivo and in vitro approaches. However, most studies still rely on the analysis of two-dimensional (2D) imaging data, which limits proper evaluation of a developmental process like axial extension and somitogenesis involving highly dynamic interactions in a complex 3D space. Here we describe techniques that allow mouse live imaging acquisition, dataset processing, visualization and analysis in 3D and 4D to study the cells (e.g., neuromesodermal progenitors) involved in these developmental processes. We also provide a step-by-step protocol for optical projection tomography and whole-mount immunofluorescence microscopy in mouse embryos (from sample preparation to image acquisition) and show a pipeline that we developed to process and visualize 3D image data. We extend the use of some of these techniques and highlight specific features of different available software (e.g., Fiji/ImageJ, Drishti, Amira and Imaris) that can be used to improve our current understanding of axial extension and somite formation (e.g., 3D reconstructions). Altogether, the techniques here described emphasize the importance of 3D data visualization and analysis in developmental biology, and might help other researchers to better address 3D and 4D image data in the context of vertebrate axial extension and segmentation. Finally, the work also employs novel tools to facilitate teaching vertebrate embryonic development.

Here, we describe computational tools and methods that allow visualization and analysis of three and four-dimensional image data of mouse embryos in the context of axial elongation and segmentation, obtained by in toto optical projection tomography, and by live imaging and whole-mount immunofluorescence staining using multiphoton microscopy.

Somitogenesis is a hallmark of vertebrate embryonic development. For years, researchers have been studying this process in a variety of organisms using a ...

Developmental Biology

Automated Slide Scanning and Segmentation in Fluorescently-labeled Tissues Using a Widefield High-content Analysis System

Automated slide scanning and segmentation of fluorescently-labeled tissues is the most efficient way to analyze whole slides or large tissue sections. Unfortunately, many researchers spend large amounts of time and resources developing and optimizing workflows that are only relevant to their own experiments. In this article, we describe a protocol that can be used by those with access to a widefield high-content analysis system (WHCAS) to image any slide-mounted tissue, with options for customization within pre-built modules found in the associated software. Not originally intended for slide scanning, the steps detailed in this article make it possible to acquire slide scanning images in the WHCAS which can be imported into the associated software. In this example, the automated segmentation of brain tumor slides is demonstrated, but the automated segmentation of any fluorescently-labeled nuclear or cytoplasmic marker is possible. Furthermore, there are a variety of other quantitative software modules including assays for protein localization/translocation, cellular proliferation/viability/apoptosis, and angiogenesis that can be run. This technique will save researchers time and effort and create an automated protocol for slide analysis.

Here we describe a protocol for the automated segmentation of fluorescently labeled tissues on slides using a widefield high-content analysis system (WHCAS). This protocol has wide-ranging applications in any field which involves the quantitation of fluorescent markers in biological tissues including the biological sciences, medical engineering, and health sciences.

Automated slide scanning and segmentation of fluorescently-labeled tissues is the most efficient way to analyze whole slides or large tissue sections. ...

Simultaneous Multicolor Imaging of Biological Structures with Fluorescence Photoactivation Localization Microscopy

Localization-based super resolution microscopy can be applied to obtain a spatial map (image) of the distribution of individual fluorescently labeled single molecules within a sample with a spatial resolution of tens of nanometers. Using either photoactivatable (PAFP) or&#160;photoswitchable (PSFP) fluorescent proteins fused to proteins of interest, or organic dyes conjugated to antibodies or other molecules of interest, fluorescence photoactivation localization microscopy (FPALM) can simultaneously image multiple species of molecules within single cells. By using the following approach, populations of large numbers (thousands to hundreds of thousands) of individual molecules are imaged in single cells and localized with a precision of ~10-30 nm. Data obtained can be applied to understanding the nanoscale spatial distributions of multiple protein types within a cell. One primary advantage of this technique is the dramatic increase in spatial resolution: while diffraction limits resolution to ~200-250 nm in conventional light microscopy, FPALM can image length scales more than an order of magnitude smaller. As many biological hypotheses concern the spatial relationships among different biomolecules, the improved resolution of FPALM can provide insight into questions of cellular organization which have previously been inaccessible to conventional fluorescence microscopy. In addition to detailing the methods for sample preparation and data acquisition, we here describe the optical setup for FPALM. One additional consideration for researchers wishing to do super-resolution microscopy is cost: in-house setups are significantly cheaper than most commercially available imaging machines. Limitations of this technique include the need for optimizing the labeling of molecules of interest within cell samples, and the need for post-processing software to visualize results. We here describe the use of PAFP and PSFP expression to image two protein species in fixed cells. Extension of the technique to living cells is also described.

We demonstrate the use of fluorescence photo activation localization microscopy (FPALM) to simultaneously image multiple types of fluorescently labeled molecules&#160;within cells. The techniques described yield the localization of thousands to hundreds of thousands of individual fluorescent labeled proteins, with a precision of tens of nanometers&#160;within single cells.

Localization-based super resolution microscopy can be applied to obtain a spatial map (image) of the distribution of individual fluorescently labeled ...

Biology

Indirect Immunofluorescence on Frozen Sections of Mouse Mammary Gland

Indirect immunofluorescence is used to detect and locate proteins of interest in a tissue. The protocol presented here describes a complete and simple method for the immune detection of proteins, the mouse lactating mammary gland being taken as an example. A protocol for the preparation of the tissue samples, especially concerning the dissection of mouse mammary gland, tissue fixation and frozen tissue sectioning, are detailed. A standard protocol to perform indirect immunofluorescence, including an optional antigen retrieval step, is also presented. The observation of the labeled tissue sections as well as image acquisition and post-treatments are also stated. This procedure gives a full overview, from the collection of animal tissue to the cellular localization of a protein. Although this general method can be applied to other tissue samples, it should be adapted to each tissue/primary antibody couple studied.

The indirect immunofluorescence protocol described in this article allows the detection and the localization of proteins in the mouse mammary gland. A complete method is given to prepare mammary gland samples, to perform immunohistochemistry, to image the tissue sections by fluorescence microscopy, and to reconstruct images.

Indirect immunofluorescence is used to detect and locate proteins of interest in a tissue. The protocol presented here describes a complete and simple ...

A Fluorescence Assay for Evaluating the Permeability of a Cardiac Microvascular Endothelial Barrier in a Rat Model of Ischemia/reperfusion

Revascularization therapies for culprit arteries, regardless of percutaneous coronary intervention and coronary artery bypass grafting, are considered the best strategy for improving the clinical prognosis of patients with acute coronary syndrome (ACS). Nonetheless, myocardial reperfusion following effective revascularization can trigger significant cardiomyocyte death and coronary endothelial collapse, known as myocardial ischemia/reperfusion injury (MIRI). Usually, endothelial cells and their intercellular tight junctions cooperatively maintain the microvascular endothelial barrier and its relatively low permeability but fail in reperfusion areas.
Microvascular endothelial hyperpermeability induced by ischemia/reperfusion (IR) contributes to myocardial edema, increased infiltration of pro-inflammatory cells, and aggravated intramyocardial hemorrhage, which may worsen the prognosis of ACS. The tracer used in this study-70,000 Da FITC-dextran, a branched glucose molecule labeled by fluorescein isothiocyanate (FITC)-appears too large to infiltrate the cardiac microvascular endothelium in normal conditions. However, it is capable of infiltrating a broken barrier after MIRI. Thus, the higher the endothelial permeability is, the more FITC-dextran accumulates in the extravascular intercellular space. Thus, the intensity of fluorescence from FITC can indicate the permeability of the microvascular endothelial barrier. This protocol takes advantage of FITC-dextran to evaluate the cardiac microvascular endothelial barrier functionally, which is detected by an automated quantitative pathology imaging system.

Here, we describe a method to functionally assess the endothelial barrier of cardiac microvessels after ischemia/reperfusion injury via the measurement of the mean fluorescence intensity of extravasated 70,000 Da FITC-dextran in comparison with Evans Blue.

Revascularization therapies for culprit arteries, regardless of percutaneous coronary intervention and coronary artery bypass grafting, are considered the ...

High-Throughput, Multi-Image Cryohistology of Mineralized Tissues

There is an increasing need for efficient phenotyping and histopathology of a variety of tissues. This phenotyping need is evident with the ambitious projects to disrupt every gene in the mouse genome. The research community needs rapid and inexpensive means to phenotype tissues via histology. Histological analyses of skeletal tissues are often time consuming and semi-quantitative at best, regularly requiring subjective interpretation of slides from trained individuals. Here, we present a cryohistological paradigm for efficient and inexpensive phenotyping of mineralized tissues. First, we present a novel method of tape-stabilized cryosectioning that preserves the morphology of mineralized tissues. These sections are then adhered rigidly to glass slides and imaged repeatedly over several rounds of staining. The resultant images are then aligned either manually or via computer software to yield composite stacks of several layered images. The protocol allows for co-localization of numerous molecular signals to specific cells within a given section. In addition, these fluorescent signals can be quantified objectively via computer software. This protocol overcomes many of the shortcomings associated with histology of mineralized tissues and can serve as a platform for high-throughput, high-content phenotyping of musculoskeletal tissues moving forward.

In this manuscript, we present a high-throughput, semi-automated cryohistology platform to produce aligned composite images of multiple response measures from several rounds of fluorescent imaging on frozen sections of mineralized tissues.

There is an increasing need for efficient phenotyping and histopathology of a variety of tissues. This phenotyping need is evident with the ambitious ...

Innovative Lung Imaging Using Agarose-Embedded Vibratome Sections

Automated Vibratome Sectioning of Agarose-Embedded Lung Tissue for Multiplex Fluorescence Imaging

Due to its inherent structural fragility, the lung is regarded as one of the more difficult tissues to process for microscopic readouts. To add structural support for sectioning, pieces of lung tissue are commonly embedded in paraffin or OCT compound and cut with a microtome or cryostat, respectively. A more recent technique, known as precision-cut lung slices, adds structural support to fresh lung tissue through agarose infiltration and provides a platform to maintain primary lung tissue in culture. However, due to epitope masking and tissue distortion, none of these techniques adequately lend themselves to the development of reproducible advanced light imaging readouts that would be compatible across multiple antibodies and species.
To this end, we have developed a tissue-processing pipeline, which utilizes agarose embedding of fixed lung tissue, coupled to automated vibratome sectioning. This facilitated the generation of lung sections from 200 &#181;m to 70 &#181;m thick, in mouse, pig, and human lungs, which require no antigen retrieval, and represent the least "processed" version of the native isolated tissue. Using these slices, we reveal a multiplex imaging readout capable of generating high-resolution images whose spatial protein expression can be used to quantify and better understand the mechanisms underlying lung injury and regeneration.

Author Spotlight: Studying Spatial Protein Expression Using Agarose Embedded Lung Tissue Sections

We have developed a tissue-processing technique utilizing a vibratome and agarose-embedded lung tissue to generate lung sections, thereby permitting the acquisition of high-resolution images of lung architecture. We employed immunofluorescence staining to observe spatial protein expression using specific lung structural markers.

Due to its inherent structural fragility, the lung is regarded as one of the more difficult tissues to process for microscopic readouts. To add structural ...
