This work was supported by the National Institutes of Health grant 5R21AI081041-02 and Georgetown University.

1. Larval Rearing of Two A. albopictus Groups to Adulthood
<ol>
	<li>Set two photoperiod cabinets with programmable lighting at 21 &#176;C for optimal diapause expression16 and approximately 80% relative humidity.
	<ol>
		<li>Program one cabinet for a 16L:8D light:dark cycle (a non-diapause inducing LD photoperiod). Set the second cabinet for an 8L:16D light:dark cycle (diapause inducing)13.</li>
		<li>Program &#8216;lights on&#8217; at the same time in both cabinets to synchronize circadian time between photoperiods.&#160;</li>
	</ol>
	</li>
	<li>Calculate the quantity of eggs needed to perform the experiment. Aim for 300-500 eggs per cage. At least three replicate diapause cages and three replicate non-diapause cages are needed for RNA generation. This totals to ca. 1,800-3,000 eggs per experiment.
	<ol>
		<li>Hatch the eggs by submerging egg papers into ca. 500 ml of deionized H2O.</li>
		<li>Add ca. 1 ml food slurry consisting of ground dog food and brine shrimp as previously described24. Cover container with mesh, and keep the mesh in place with a rubber band.</li>
		<li>Place in the LD photoperiod cabinet for ca. 24 hr.</li>
	</ol>
	</li>
	<li>Transfer hatched larvae to 10 x 10 x 2 cm Petri dishes filled with ca. 90 ml deionized H2O.
	<ol>
		<li>Maintain ca. 30 larvae per dish. Transfer larvae to clean dishes every 48&#8211;72 hr, for example every Monday, Wednesday, and Friday (M-W-F)24.</li>
		<li>Feed ca. 1 ml food slurry consisting of ground dog food and brine shrimp in deionized water every M-W-F as previously described24.&#160;</li>
	</ol>
	</li>
	<li>Set up three to four adult cages for each photoperiod treatment, where each cage comprises a biological replicate.
	<ol>
		<li>From opposite sides of 9.5 L buckets, cut out one 10-by-14 cm hole, and another hole with 15 cm diameter. Cover the first with mesh. Cut approximately one foot length of an orthopedic stocking, and glue one end around the inside of the other hole.</li>
		<li>Cut the foot end of the stocking off and knot shut &#8212; open only when access to the interior of the cage is needed. For the cage lid, cut out all of the interior, leaving only the rim, and replace the interior plastic with mesh24.</li>
		<li>Note the photoperiod, replicate number, cage start date, and other information relevant to the experiment with permanent marker on the side of the cage.&#160;</li>
	</ol>
	</li>
	<li>Line the bottom of the adult cages with wet filter paper. Dampen the filter paper with enough deionized H2O to increase local humidity in the cage, but avoid standing water, which can stimulate oviposition on the filter paper24. Check the filter paper daily for drying, re-wet when necessary.</li>
	<li>To produce sufficient eggs for an RNA library, include at least 100 females/9.5 L cage, with no more than 500 mosquitoes per cage.</li>
	<li>Collect pupae M-W-F and place in a small cup of clean H2O at a density of no more than 50 pupae per 25 ml H2O. Transfer the pupae cup to an adult cage. Place cages in the respective photoperiod cabinet &#8212; A. albopictus pupae are photosensitive15.</li>
	<li>Ensure daily that H2O in cups is clean and clear, and remove dead pupae, because build-up of dead pupae can cause mass mortality. Remove H2O cups after all pupae emerge.</li>
	<li>Place organic raisins on the top mesh of the cage to provide sugar for emerged adults. Monitor raisins, and change them every 3-5 days to prevent mold accumulation.</li>
</ol>
2. Maintenance of Adults to Allow Mating and Egg Production
<ol>
	<li>Maintain cages at high humidity (approx. 80%) by lining the cage bottom with a moist filter paper, and provide access to non-moldy raisins, as described above (Sections 1.5 and 1.9).</li>
</ol>
3. Blood-feeding
<ol>
	<li>Prepare to blood-feed females between two to six days after eclosion to ensure that females have been exposed to at least eight unambiguous short days before oviposition commences for nearly 100% diapause eggs14.</li>
	<li>Prepare the Hemotek Membrane Feeding system. Plug the feeding units into the power supply. Adjust the temperature of each unit to 37 &#176;C using the adjustment screw. Use an electronic thermometer and probe to measure the temperature of the feeding unit during calibration.</li>
	<li>Prepare the meal reservoir. Stretch a square of collagen feeding membrane over the aperture of the meal reservoir and secure it with an O-ring. Carefully pull the corners to remove wrinkles; trim the excess membrane with scissors.
	NOTE: Collagen membrane may not work well for all mosquito species, and it may be necessary to try several types to find the optimal membrane if working with a species other than A. albopictus. Parafilm works well with Culex pipiens.
	<ol>
		<li>If blood is stored frozen, thaw at room temperature for at least 1 hr before using.</li>
		<li>Hold the reservoir so the membrane is facing down, unsupported, and the filling ports are facing up. Use a transfer pipette or syringe to fill the reservoir with approximately 3 ml of whole blood from chickens that has sodium citrate as an anti-coagulant. Seal filling ports with plastic plugs.</li>
	</ol>
	</li>
	<li>Attach the prepared reservoir to the feeder by screwing it onto the stud on the heat transfer plate on the bottom of the feeder. Invert the feeder and place it on top of the cage, membrane side down, so that mosquitoes can feed through the mesh of the cage. Keep the feeder on the cage for approximately 45 min to maximize feeding.</li>
</ol>
4. Stimulate Oviposition
<ol>
	<li>Four to five days post blood meal, equip each cage with a dark colored 50 ml cup lined with unbleached seed germination paper (egg paper) or textured non-bleached paper towel and fill halfway with deionized water9. If more than 250 mosquitoes are in a cage, use two cups.
	NOTE: For small cages or single-female vials, &#8220;hay infusion&#8221; in oviposition containers may increase oviposition due to the odor of the microbial flora25.</li>
</ol>
5. Collect and Store Eggs
<ol>
	<li>Commence egg collection within 4-5 days of blood feeding because egg production typically peaks approximately five days after blood feeding, and then subsides over the next week.</li>
	<li>Vary egg collection frequency on necessities of the experiment. For general purposes, collect egg papers on an M-W-F schedule. Remove egg papers from each cage and replace with fresh paper. Place recently removed papers in Petri dishes and store in SD photoperiod cabinet to avoid confounding effects of egg storage.</li>
	<li>Allow egg papers to remain wet for 2 days post-oviposition to allow serosal cuticle formation, which increases egg desiccation resistance26.</li>
	<li>Approximately 48 hr post collection, dry eggs in open air. Dry the paper such that it is limp and slightly damp to the touch, but not so wet that the paper is dark from H2O or stimulates hatching of eggs.
	NOTE: A 6.5&#8221; x 4&#8221; paper may take approximately 3.5 hr to dry. Be cautious not to over-dry egg papers, as this will result in egg desiccation27.</li>
	<li>Reserve additional eggs from both LD and SD photoperiods to assess diapause incidence and interpret the photoperiodic effect (see Measuring Diapause, Section 6).</li>
	<li>For long-term storage, keep egg papers at 21 &#176;C and approximately 80% humidity in Petri dishes. Keep Petri dishes in a Tupperware storage container with a flask of water to maintain local humidity as embryonic development takes four to five days at 21 &#176;C.</li>
</ol>
6. Measure Diapause Incidence
<ol>
	<li>Use additional reserved embryos (see Stimulate Oviposition, Section 4) that are 7&#8211;20 days old to quantify the diapause response.</li>
	<li>Record the number of eggs present on each egg paper.</li>
	<li>Stimulate eggs to hatch by completely submerging individual egg papers in a 90 ml Petri dish with approximately 80 ml deionized H2O. Add approximately 0.25 ml food slurry.</li>
	<li>After 24 hr tally the number of hatched first instar larvae. Place the Petri dish on a black surface to visualize larvae and place a light source on one side of dish. Larvae will move away from the light source, allowing for a clear tally of individual larvae. Remove individual larvae with a pipette while counting to prevent recounting individual larvae.</li>
	<li>Place egg papers in a new Petri dish and re-dry. Re-hatch eggs after ~1 week and again tally eggs hatched using the above method.</li>
	<li>Place egg papers with the remaining un-hatched eggs in new 90 ml Petri dishes with approximately 80 ml bleaching solution28. Ensure that the egg papers are completely submerged in the bleaching solution and leave under a fume hood overnight to avoid the odor of bleach.
	NOTE: Bleaching solution can be stored for ~1 week at 4 &#176;C, but should otherwise be made fresh.</li>
	<li>Inspect eggs using a light microscope as the bleaching will clear the chorion and allow visualization of embryonated, un-hatched eggs. If the egg is embryonated, the egg will have an off-white color with eyes appearing as two small black dots opposite each other on the dorsal side. Tally the number of un-hatched, embryonated eggs13.</li>
	<li>Determine diapause incidence with the following formula: % diapause = no. embryonated un-hatched eggs / (no. hatched eggs + no. embryonated un-hatched eggs) x 100 13.</li>
</ol>
7. RNA Extraction from Eggs/pharate Larvae

NOTE: Use Trizol in a laminar flow hood.

<ol>
	<li>Brush mosquito eggs containing developing embryos or pharate larvae at distinct development time points from egg papers to glass grinders using a camel-hair brush. Grind the eggs in Trizol (1 ml&#160;per 50&#8211;100 mg of&#160;tissue) until completely pulverized. Use at least 400 eggs per library to yield sufficient RNA.
	<ol>
		<li>Alternatively, snap freeze eggs in liquid nitrogen and stored at -80 &#176;C in microcentrifuge tubes for up to a month before grinding in Trizol.</li>
	</ol>
	</li>
	<li>Perform RNA extraction in Trizol followed by isopropanol precipitation according to manufacturer&#8217;s instructions.</li>
	<li>Treat the bench with RNase decontamination solution or other agents to remove any residual nucleases to avoid RNA degradation.
	<ol>
		<li>Treat the extracted RNA with DNase. According to manufacturer&#8217;s instructions, incubate the RNA samples with DNase for 30 min at 37 &#176;C. Use 1 &#181;l DNase for up to 10 &#181;g of RNA in a 50 &#181;l reaction. Increase the amount of DNase if there are more than 10 &#181;g of RNA in one reaction.</li>
		<li>Inactivate DNase by adding 5 &#181;l suspended DNase inactivation reagent. Incubate 5 min at room temperature, mixing three times during incubation period (gentle vortexing).</li>
		<li>Centrifuge at 10,000 x g for 1.5 min. Transfer the supernatant containing the treated RNA samples to fresh tubes for subsequent steps.</li>
	</ol>
	</li>
	<li>Assess the quality of the total RNA samples by fluorometry. Send the samples to a specialty facility with proper instrument for this task. The facility will perform on-chip gel electrophoresis to determine the sizes of RNA species in the sample, visualized by fluorescent dye instilled in the chip. The results will be returned as an electropherogram.
	<ol>
		<li>Determine the integrity of total RNA samples by the presence or absence of degradation products, as evidenced by the presence of peaks between the 18S and 5S ribosomal RNA peaks on the resulting electropherogram (Figure 1B).</li>
	</ol>
	</li>
</ol>
8. RNA Sequencing
<ol>
	<li>Send total RNA samples with sufficiently high quality (Figure 1A) and quantity (usually &#62;3 &#956;g per library) to a commercial sequencing center for construction of enriched paired-end mRNA libraries and mRNA sequencing, following standard protocols.</li>
	<li>If more than one lane is being used for sequencing a single experiment, split individual libraries into two lanes for sequencing to account for technical variation among lanes during sequencing.</li>
</ol>
9. lllumina Read Cleaning
NOTE: Figure 2 summarizes the bioinformatics portion of this protocol. For a full list of all programs and resources used in the bioinformatics section of this protocol, refer to Table 1. In addition, Supplemental File 1 contains command line examples for each of the following bioinformatics protocol steps.
<ol>
	<li>Use ssaha229 (Table 1) to identify matches of 95% identity or higher to the NCBI UniVec Core database (Table 1), A. albopictus rRNA sequence (GenBank #L22060.1), and sequencing adapters (detailed command-line examples provided in Supplemental File 1). Remove read pairs with matches using Perl or a similar scripting tool, for example by adapting the provided Perl script (Supplemental File 2).</li>
	<li>Clean remaining reads with the SolexaQA package30 (Table 1; Supplemental File 1): trim regions with a phred score equivalent of less than 20 using the default settings of DynamicTrim.pl.
	<ol>
		<li>Remove reads shorter than 25 bp with LengthSort.pl on both forward and reverse reads simultaneously. Evaluate the quality of the cleaned fastq files with FastQC (Table 1) &#8212; in particular, verify that the per-base sequence quality and the per-sequence quality scores are above 20.</li>
	</ol>
	</li>
</ol>
10. Digital Normalization
<ol>
	<li>Perform one round of digital normalization on the cleaned reads using the khmer tool31 (Table 1; Supplemental File 1), specifically normalize-by-median.py (using k-mer size 20, a coverage cut-off of 20, and x = 1e10).</li>
	<li>Alternatively, if a machine with high RAM is available (hundreds of GBs), use Trinity&#39;s normalize_by_kmer_coverage.pl script (Table 1).</li>
</ol>
11. De Novo Transcriptome Assembly
<ol>
	<li>Obtain access to a computer or computer cluster with up to 256 Gb of RAM and 24 cpus, depending on the size of the assembly.</li>
	<li>Use Trinity32 (Table 1; Supplemental File 1) to assemble the digitally normalized read set into contigs. To reduce memory usage, use --min_kmer_cov 2.</li>
</ol>
12. Assembly Evaluation
<ol>
	<li>Run assemblathon_stats.pl from the Assemblathon2 project33 on the Trinity contig output. This script performs basic calculations relevant to evaluating assembly quality, such as number of scaffolds, N50, assembly composition, and more (Table 1; Supplemental File 1).</li>
</ol>
13. Annotation of the Assembled Transcriptome
<ol>
	<li>Perform Blastx (Table 1) of the assembly against a reference protein set; for mosquitoes, Drosophila melanogaster, Anopheles gambiae, Culex pipiens, and Aedes aegypti are suitable references. Specifically, format the reference protein fasta file for blast, followed by blastx (Supplemental File 1).</li>
</ol>
14. Map Reads to the Assembly Using RSEM34 (Table 1)
<ol>
	<li>Create a &#39;transcript-to-gene-map&#39; file, in which the first column contains the reference gene IDs, and the second column the contig IDs. In a spreadsheet editor, swap the first and second columns from the Blastx output, and write these columns to a .txt file. Use the LineBreak program to convert line breaks in the resulting .txt file to Unix format.</li>
	<li>Create a reference dataset from the transcriptome fasta file using the rsem-prepare-reference script, provided in the RSEM package (Supplemental File 1).</li>
	<li>Calculate the expression values separately for each library using the rsem-calculate-expression command, provided in the RSEM package (Supplemental File 1). As reads, use the paired fastq files resulting from the read-cleaning step (step 9.2).
	<ol>
		<li>If RNA from a biological replicate was split into two lanes for sequencing, include both fastq files in the expression calculation to generate a single file.</li>
	</ol>
	</li>
	<li>Convert the expression results from each library to a matrix easily processed by other programs using the provided script rsem-generate-data-matrix, provided in the RSEM package (Supplemental File 1).</li>
</ol>
15. Differential Expression Analysis
<ol>
	<li>Install R and EdgeR (Table 1).</li>
	<li>Use read.delim to load the RSEM results from step 14.3 (Supplemental File 1). If necessary, round the counts to the nearest integer.
	NOTE: The EdgeR guide recommends limiting the dataset to genes with high enough expression to detect significance.</li>
	<li>To format the data for EdgeR, generate a DGEList object from the loaded data file (Supplemental File 1). Then, normalize the data using TMM normalization (Supplemental File 1). Estimate the common and tagwise dispersions of the data (Supplemental File 1).</li>
	<li>Identify differentially expressed genes with a Benjamini-Hochberg corrected p-value &#60;0.05 (Supplemental File 1). Plot the distribution of log-fold-change vs. abundance (Supplemental File 1).</li>
</ol>

<ol>
	<li>Bilyk, K. T., Cheng, C. H. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Model+of+gene+expression+in+extreme+cold+-+reference+transcriptome+for+the+high-Antarctic+cryopelagic+notothenioid+fish+Pagothenia+borchgrevinki.">Model of gene expression in extreme cold - reference transcriptome for the high-Antarctic cryopelagic notothenioid fish Pagothenia borchgrevinki.</a> BMC Genomics. 14, 634 (2013).</li><li>Chapman, M. A., Hiscock, S. J., Filatov, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genomic+divergence+during+speciation+driven+by+adaptation+to+altitude.">Genomic divergence during speciation driven by adaptation to altitude.</a> Mol. Biol. Evol. 30, 2553-2567 (2013).</li><li>Schwarz, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Sympatric+ecological+speciation+meets+pyrosequencing:+sampling+the+transcriptome+of+the+apple+maggot+Rhagoletis+pomonella.">Sympatric ecological speciation meets pyrosequencing: sampling the transcriptome of the apple maggot Rhagoletis pomonella.</a> BMC Genomics. 10, 633 (2009).</li><li>Barshis, D. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genomic+basis+for+coral+resilience+to+climate+change.">Genomic basis for coral resilience to climate change.</a> P. Natl Acad. Sci. USA. 110, 1387-1392 (2013).</li><li>Urbanski, J. M., Aruda, A., Armbruster, P. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+transcriptional+element+of+the+diapause+program+in+the+Asian+tiger+mosquito,+Aedes+albopictus,+identified+by+suppressive+subtractive+hybridization.">A transcriptional element of the diapause program in the Asian tiger mosquito, Aedes albopictus, identified by suppressive subtractive hybridization.</a> J. Insect Physiol. 56, 1147-1154 (2010).</li><li>Huang, Y. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+duck+genome+and+transcriptome+provide+insight+into+an+avian+influenza+virus+reservoir+species.">The duck genome and transcriptome provide insight into an avian influenza virus reservoir species.</a> Nat. Genet. 45, 776-783 (2013).</li><li>Sessions, O. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Host+cell+transcriptome+profile+during+wild-type+and+attenuated+dengue+virus+infection.">Host cell transcriptome profile during wild-type and attenuated dengue virus infection.</a> PLoS Negl. Trop. Dis. 7 (3), 2107 (2013).</li><li>Poelchau, M. F., Reynolds, J. A., Elsik, C. G., Denlinger, D. L., Armbruster, P. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Deep+sequencing+reveals+complex+mechanisms+of+diapause+preparation+in+the+invasive+mosquito,+Aedes+albopictus.">Deep sequencing reveals complex mechanisms of diapause preparation in the invasive mosquito, Aedes albopictus.</a> P. R. Soc B. 280, (2013).</li><li>Poelchau, M. F., Reynolds, J. A., Elsik, C. G., Denlinger, D. L., Armbruster, P. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transcriptome+sequencing+as+a+platform+to+elucidate+molecular+components+of+the+diapause+response+in+Aedes+albopictus.">Transcriptome sequencing as a platform to elucidate molecular components of the diapause response in Aedes albopictus.</a> Physiol. Entomol. 38, 173-181 (2013).</li><li>Poelchau, M. F., Reynolds, J. A., Denlinger, D. L., Elsik, C. G., Armbruster, P. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+de+novo+transcriptome+of+the+Asian+tiger+mosquito,+Aedes+albopictus,+to+identify+candidate+transcripts+for+diapause+preparation.">A de novo transcriptome of the Asian tiger mosquito, Aedes albopictus, to identify candidate transcripts for diapause preparation.</a> BMC Genomics. 12, 619 (2011).</li><li>Benedict, M. Q., Levine, R. S., Hawley, W. A., Lounibos, L. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Spread+of+the+tiger:+Global+risk+of+invasion+by+the+mosquito+Aedes+albopictus.">Spread of the tiger: Global risk of invasion by the mosquito Aedes albopictus.</a> Vector-Borne Zoonot. 7, 76-85 (2007).</li><li>Lounibos, L. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Invasions+by+insect+vectors+of+human+disease.">Invasions by insect vectors of human disease.</a> Annu. Rev. Entomol. 47, 233-266 (2002).</li><li>Urbanski, J. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+adaptive+evolution+of+photoperiodic+response+during+invasion+and+range+expansion+across+a+climatic+gradient.">Rapid adaptive evolution of photoperiodic response during invasion and range expansion across a climatic gradient.</a> Am. Nat. 179, 490-500 (2012).</li><li>Lounibos, L. P., Escher, R. L., Lourenco-de-Oliveria, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Asymmetric+evolution+of+photoperiodic+diapause+in+temperate+and+tropical+invasive+populations+of+Aedes+albopictus+(Diptera+Culicidae).">Asymmetric evolution of photoperiodic diapause in temperate and tropical invasive populations of Aedes albopictus (Diptera Culicidae).</a> Ann. Entomol. Soc. Am. 96, 512-518 (2003).</li><li>Mori, A., Oda, T., Wada, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Studies on the egg diapause and overwintering of Aedes albopictus in Nagasaki. Trop. Med. 23, 79-90 (1981).</li><li>Pumpuni, C. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Factors influencing photoperiodic control of egg diapause in Aedes albopictus [dissertation]. , (1989).</li><li>Wang, R. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Observations+on+the+influence+of+photoperiod+on+egg+diapause+in+Aedes+albopictus+Skuse.">Observations on the influence of photoperiod on egg diapause in Aedes albopictus Skuse.</a> Acta Entomol. Sinica. 15, 75-77 (1966).</li><li>Sota, T., Mogi, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Survival-time+and+resistance+to+desiccation+of+diapause+and+non-diapause+eggs+of+temperate+Aedes+(Stegomyia)+mosquitoes.">Survival-time and resistance to desiccation of diapause and non-diapause eggs of temperate Aedes (Stegomyia) mosquitoes.</a> Entomol. Exp. Appl. 63, 155-161 (1992).</li><li>Reynolds, J. A., Poelchau, M. F., Rahman, Z., Armbruster, P. A., Denlinger, D. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transcript+profiling+reveals+mechanisms+for+lipid+conservation+during+diapause+in+the+mosquito,+Aedes+albopictus.">Transcript profiling reveals mechanisms for lipid conservation during diapause in the mosquito, Aedes albopictus.</a> J. Insect Physiol. 58, 966-973 (2012).</li><li>Andrewartha, H. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Diapause+in+relation+to+the+ecology+of+insects.">Diapause in relation to the ecology of insects.</a> Biol. Rev. 27, 50-107 (1952).</li><li>Danks, H. V. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Insect+Dormancy:+An+Ecological+Perspective.">Insect Dormancy: An Ecological Perspective.</a> Biological Survey of Canada (Terrestrial Arthropods). , (1987).</li><li>Denlinger, D. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Regulation+of+diapause.">Regulation of diapause.</a> Ann. Rev. Entomol. 47, 93-122 (2002).</li><li>Rev Entomol, A. n. n. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> 59, 93-122 (2014).</li><li>Armbruster, P. A., Conn, J. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Geographic+variation+of+larval+growth+in+North+American+Aedes+albopictus+(Diptera).">Geographic variation of larval growth in North American Aedes albopictus (Diptera).</a> Culicidae). Ann. Entomol. Soc. Am. 99, 1234-1243 (2006).</li><li>Reiter, P., Amador, M. A., Colon, N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Enhancement+of+the+CDC+ovitrap+with+hay+infusions+for+daily+monitoring+of+Aedes+aegypti+populations.">Enhancement of the CDC ovitrap with hay infusions for daily monitoring of Aedes aegypti populations.</a> J. Am. Mosquito Contr. Association. 7 (1), 52 (1991).</li><li>Rezende, G. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Embryonic+desiccation+resistance+in+Aedes+aegypti:+presumptive+role+of+the+chitinized+serosal+cuticle.">Embryonic desiccation resistance in Aedes aegypti: presumptive role of the chitinized serosal cuticle.</a> BMC Dev. Biol. 8, 182 (2008).</li><li>Munstermann, L., Crampton, J., Beard, C., C, L. o. u. i. s. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Care+and+maintenance+of+Aedes+mosquito+colonies.">Care and maintenance of Aedes mosquito colonies.</a> The Molecular Biology of Insect Disease Vectors. , 13-20 (1997).</li><li>Trpis, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+bleaching+and+decalcifying+method+for+general+use+in+zoology.">A new bleaching and decalcifying method for general use in zoology.</a> Can. J. Zoolog. 48, 892-893 (1970).</li><li>Ning, Z. M., Cox, A. J., Mullikin, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=SSAHA:+A+fast+search+method+for+large+DNA+databases.">SSAHA: A fast search method for large DNA databases.</a> Genome Res. 11 (10), 1725-1729 (2001).</li><li>Cox, M. P., Peterson, D. A., Biggs, P. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=SolexaQA:+At-a-glance+quality+assessment+of+Illumina+second-generation+sequencing+data.">SolexaQA: At-a-glance quality assessment of Illumina second-generation sequencing data.</a> BMC Bioinformatics. 11, 485 (2010).</li><li>Grabherr, M. G., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Full-length+transcriptome+assembly+from+RNA-Seq+data+without+a+reference+genome.">Full-length transcriptome assembly from RNA-Seq data without a reference genome.</a> Nat. Biotechnol. 29 (7), 644-652 (2011).</li><li>Bradnam, K. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Assemblathon+2:+evaluating+de+novo+methods+of+genome+assembly+in+three+vertebrate+species.">Assemblathon 2: evaluating de novo methods of genome assembly in three vertebrate species.</a> GigaScience. 2, 10 (2013).</li><li>Li, B., Dewey, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=RSEM:+accurate+transcript+quantification+from+RNA-Seq+data+with+or+without+a+reference+genome.">RSEM: accurate transcript quantification from RNA-Seq data with or without a reference genome.</a> BMC Bioinformatics. 12, 323 (2011).</li><li>White, B. N., De Lucca, F. L., Turner, R. B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+and+analysis+of+RNA.">Preparation and analysis of RNA.</a> Analytical Biochemistry of Insects. , (1977).</li><li>Hawley, W. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+biology+of+Aedes+albopictus.">The biology of Aedes albopictus.</a> J. Am. Mosq. Contr. Assoc. 4, 1-39 (1988).</li><li>Dowling, Z., Ladeau, S. L., Armbruster, P., Biehler, D., Leisnham, P. T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Socioeconomic+status+affect+mosquito+(Diptera:Culicidae)+larval+habitat+type+availability+and+infestation+level.">Socioeconomic status affect mosquito (Diptera:Culicidae) larval habitat type availability and infestation level.</a> J. Med Entomol. 50, 764-772 (2013).</li><li>Benedict, M. Q. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chapter+2,4,10.+Bloodfeeding:+Membrane+apparatuses+and+animals.">Chapter 2,4,10. Bloodfeeding: Membrane apparatuses and animals.</a> Methods in Anopheles Research. , (2010).</li><li>Das, S., Garver, S., Ramirez, J. R., Xi, Z., Dimopolous, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Protocol+for+dengue+infections+in+mosquitoes+(A.+aegypti)+and+infection+phenotype+determination.">Protocol for dengue infections in mosquitoes (A. aegypti) and infection phenotype determination.</a> J. Vis. Exp. 5 (220), (2007).</li><li>Goff, S. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+iPlant+collaborative:+cyberinfrastructure+for+plant+biology.">The iPlant collaborative: cyberinfrastructure for plant biology.</a> Plant Sci. 2 (34), (2011).</li><li>Robinson, M. D., McCarthy, D. J., Smyth, G. K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=edgeR:+a+Bioconductor+package+for+differential+expression+analysis+of+digital+gene+expression+data.">edgeR: a Bioconductor package for differential expression analysis of digital gene expression data.</a> Bioinformatics. 26, 139-140 (2010).</li><li>Edgar, R. C., Haas, B. J., Clemente, J. C., Quince, C., Knight, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=UCHIME+improves+sensitivity+and+speed+of+chimera+detection.">UCHIME improves sensitivity and speed of chimera detection.</a> Bioinformatics. 27 (16), 2194-2220 (2011).</li><li>Goecks, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Galaxy:+a+comprehensive+approach+for+supporting+accessible,+reproducible,+and+transparent+computational+research+in+the+life+sciences.">Galaxy: a comprehensive approach for supporting accessible, reproducible, and transparent computational research in the life sciences.</a> Genome Biol. 11 (8), 86 (2010).</li></ol>

The authors have nothing to disclose.

This protocol presents methods to discover differentially expressed genes due to photoperiodically induced diapause in A. albopictus. The protocol is significant in that it uniquely combines mosquito rearing and bioinformatics techniques to make all experimental aspects of a molecular physiology program accessible to novice users &#8212; in particular for those focusing on the photoperiodic diapause response. Existing methods, to our knowledge, do not provide as much detail in the rearing protocol &#8212; which is often necessary to identify rearing mistakes &#8212; nor do they provide insight on experimental design during the rearing stage that will enable successful bioinformatic analysis downstream. The methods presented here have been optimized for A. albopictus, especially the rearing methods, which generally take six weeks from one laboratory generation to the next. However, in future applications this method could be adapted with modest adjustments to other mosquito species that exhibit photoperiodic diapause23. Furthermore, the general experimental design and bioinformatics workflow are applicable to the study of other polyphenisms.
Several points not detailed in the protocol should be considered when rearing A. albopictus larvae. First, A. albopictus can be found in a wide variety of natural and artificial container habitats as described in previous papers36, 37. Used tire lots are a common source of larvae for establishing laboratory colonies. Populations collected above 32N latitude in North America can be expected to exhibit a strong diapause response13. The A. albopictus strain used in this protocol was collected from Manassas, VA, and was reared in a laboratory setting for more than eight generations prior to experimental manipulation. Second, lighting in the photoperiod cabinets should be chosen with care. Bulbs in cabinets with built-in lighting functions can cause temperature spikes within the cabinet when the lighting turns on or off. Anecdotal observation suggests these temperature spikes can disrupt the diapause response. To prevent this, built-in lighting functions should be disabled and cabinets should be equipped with a 4-watt cool-fluorescent bulb. Third, larvae are sensitive to H2O quality and food abundance. Therefore, over-feeding may lead to bacterial accumulation and larval mortality. Fourth, there are alternative methods to blood-feed adult female mosquitoes. Glass membranes are an alternative artificial membrane system38, 39, although the HemoTek system performs better in the authors&#8217; experience. Live animals (usually chicken or rodent) can also be used38 &#8212; in this case, it is essential to first obtain appropriate certification from your Institutional Animal Care and Use Committee (IACUC). Fifth, although there is no clear published evidence that eggs are photosensitive15, anecdotal observations suggest that eggs from an SD photoperiod treatment exhibit slightly reduced diapause incidence when exposed to an LD photoperiod within 10 days of oviposition. Thus, store both SD and LD eggs under SD conditions to produce a maximal diapause response in the SD eggs and avoid any confounding effect of photoperiod (SD vs. LD) during egg storage.
High RNA quality is essential for generating high quality RNA-Seq data. Abundant care should be taken during the RNA extraction to avoid any nuclease contamination. Low quality RNA samples, such as that shown in Figure 1B, are not appropriate for sequencing. Assessing the RNA quality before sending the samples for sequencing is imperative. Characteristic bands of RNA molecules might be visible for different types of insect tissue used for RNA extraction, such as the four bands smaller than 18S shown in the high quality RNA electropherogram in Figure 1A. Consistent patterns of RNA bands other than the two bands at 18S across samples under distinct biological treatments can strongly indicate that these bands do not result from degradation, but represent biological composition of the RNA molecules in the specific tissue types chosen in the experimental design.
The bioinformatics workflow outlined here allows a user with some command-line and scripting skills to obtain a list of differentially expressed genes from Illumina sequencing data generated from replicated RNA libraries from two contrasting experimental conditions. While this example concerns genes differentially expressed due to photoperiod, this workflow can be applied to any experimental design with two or more treatments, in any organism. There are many other ways to arrive at a list of differentially expressed genes; however, this protocol is likely to be the most straightforward approach for the novice user. More experienced bioinformaticians may want to take extra measures to improve the contiguity and redundancy of their assembly. Biologists with little to no bioinformatics experience may also complete at least part of this pipeline within the iPlant40 Discovery Environment, which is a free graphical-user-interface driven analysis environment. It is likely that iPlant&#8217;s functionality will grow larger in the future in order to accommodate full RNA-Seq pipelines from de novo transcriptome assemblies. Finally, note that the excellent User&#39;s Guide thoroughly discusses the many ways to use EdgeR41 (Table 1) for differential expression analysis.
In some cases, mis-assemblies can generate chimeric contigs. There are several methods that can help to identify these mis-assemblies, for example, Uchime42. However, from past experience, the number of detected chimeras is exceedingly low (&#60; 0.1%); therefore, employing a chimera detection program may not be worth the extra effort.
Processing high-throughput, next-generation sequencing data requires the ability to 1) store large amounts of data (for a single project, &#62;500 Gb); 2) manipulate large data files that cannot be opened in traditional word processors or spreadsheet programs; 3) perform analyses that require large amounts of RAM, e.g., for de novo assembly; and 4) analyze large datasets, either through programs driven by a command-line interface (which requires the ability to install these programs, which is often non-trivial), or through analysis suites with graphical user interfaces (e.g. Galaxy43 or iPlant40). Researchers with some proficiency in Unix command line and a scripting language will gain the most benefit from access to a local computing cluster - either University-owned, via a collaborator, or purchased for their own laboratory. For example, the above workflow was accomplished using a laboratory-owned Macintosh (12 cores, 64 GB RAM, 1 Tb hard drive), and a University-owned computer cluster for the Trinity assembly. If similar resources are not available, researchers can still turn to iPlant to perform large-scale analyses at no cost, and with relatively lower investment in training due to the graphical interface environment. However, those performing and interpreting the analyses still need to understand the assumptions of each program used.

Rapid advances in next-generation sequencing (NGS) technologies are providing exciting opportunities to probe the molecular underpinnings of a wide range of genetically complex ecological adaptations in a broad diversity of non-model organisms1&#8211;3. This approach is extremely powerful because it establishes a basis for population and functional genomics studies of organisms with an especially interesting and/or well-described ecology or evolutionary history, as well as organisms of practical concern, such as agricultural pests and disease vectors. Thus, NGS technologies are leading to rapid advances in the fields of ecology and have the potential to address problems such as understanding the mechanistic bases of biological responses to rapid contemporary climate change4, the spread of invasive species5, and host-pathogen interactions6,7.
The extraordinary potential of NGS technologies for addressing basic and applied questions in ecology and evolutionary biology is in part due to the fact that these approaches can be applied to any organism at a moderate cost that is feasible for most research laboratories. Furthermore, these approaches provide genome-wide information without the requirement of a priori genetic resources such as a microarray chip or complete genome sequence. Nevertheless, to maximize the productivity of NGS experiments requires careful consideration of experimental design including issues such as the developmental timing and tissue-specificity of RNA sampling. Furthermore, the technical skills required to analyze the massive amounts of data produced by these experiments, often up to several hundred million DNA sequence reads, has been a particular challenge and has limited the widespread implementation of NGS approaches.
Recent RNA-Seq studies on the transcriptional bases of diapause in the invasive and medically important mosquito Aedes albopictus provide a useful example of some of the experimental protocols that can be employed to successfully apply NGS technology to studying the molecular basis of a complex ecological adaptation in a non-model organism8&#8211;10. A. albopictus is a highly invasive species that is native to Asia but has recently invaded North America, South America, Europe, and Africa11,12. Like many temperate insects, temperate populations of A. albopictus survive through winter by entering a type of dormancy referred to as photoperiodic diapause. In A. albopictus, exposure of pupal and adult females to short (autumnal) day lengths leads to the production of diapause eggs in which embryological development is completed, but the pharate larva inside the chorion of the egg enters a developmental arrest that renders the egg refractory to hatching stimulus15&#8211;17. Diapause eggs are more desiccation resistant5,18 and contain more total lipids19 than non-diapause eggs. Photoperiodic diapause in A. albopictus is thus a maternally controlled, adaptive phenotypic plasticity that is essential for surviving the harsh conditions of winter in temperate environments. Despite the well-understood ecological significance of photoperiodic diapause in a wide range of insects20,21, the molecular basis of this crucial adaptation is not well characterized in any insect22. In organisms such as A. albopictus that undergo an embryonic diapause at the pharate larval stage, it remains a particularly compelling challenge to understand how the photoperiodic signal received by the mother is passed to the offspring and persists through the course of embryonic development to cause arrest at the pharate larval stage.
This protocol describes mosquito rearing, experimental design and bioinformatics analyses for NGS experiments (transcriptome sequencing) performed to elucidate transcriptional components of photoperiodic diapause in A. albopictus. This protocol can be used for additional studies of diapause in A. albopictus, can be adapted to investigate diapause in other closely related species such as other aedine mosquitoes that undergo egg diapause23, and is also more generally relevant to employing NGS approaches to study the transcriptional bases of any complex adaptation in any insect.

<table><tbody><tr><td>Incubator - Model 818</td><td>Thermo-Scientific</td><td>3751</td><td>120 V</td></tr><tr><td>Controlled environment room</td><td>Thermax Scientific</td><td>N/A</td><td>Walk-in controlled environment room built to custom specifications by Thermax Scientific Products. A larger alternative to an incubator. http://thermmax.com/</td></tr><tr><td>Cool Fluorescent bulb</td><td>Philips</td><td>392183</td><td>4 W</td></tr><tr><td>Petri Dish 100 mm x 20 mm</td><td>Fisher</td><td>08-772-E</td><td></td></tr><tr><td>Filter Paper 20.5 cm</td><td>Fisher</td><td>09-803-6J</td><td></td></tr><tr><td>9.5 L Bucket</td><td>Plastican</td><td>Bway Products</td><td>http://www.bwayproducts.com/sites/portal/plastic-products/plastic-open-head-pails/117</td></tr><tr><td>Utility Fabric-Mosquito Netting White</td><td>Joann</td><td>10173292</td><td>http://www.joann.com/utility-fabric-mosquito-netting-white/10173292.html</td></tr><tr><td>Orthopedic stockings</td><td>Albahealth</td><td>23650-040</td><td>product no. 081420</td></tr><tr><td>Organic Raisins</td><td>Newman&#039;s Own</td><td>UPC: 884284040255</td><td></td></tr><tr><td>Oviposition cups (brown)</td><td>Fisher Scientific</td><td>03-007-52</td><td>The product is actually an amber 125 ml bottle that we saw the top off of.</td></tr><tr><td>Recycled Paper Towels</td><td>Seventh Generation</td><td>30BPT120</td><td></td></tr><tr><td>Modular Mates Square Tupperware Set</td><td>Tupperware</td><td></td><td>http://order.tupperware.com/pls/htprod_www/coe$www.add_items</td></tr><tr><td>Glass Grinder</td><td>Corning Incorporated</td><td>7727-2</td><td>These Tenbroeck tissue grinders break the eggs and release RNA into the TRI Reagent.</td></tr><tr><td>TRI Reagent</td><td>Sigma Aldrich</td><td>T9424</td><td>Apply 1 ml TRI Reagent per 50-100 mg of tissue. Caution &amp;#8212; this reagent is toxic.</td></tr><tr><td>TURBO DNA-free</td><td>Ambion/Life Technologies</td><td>AM1907</td><td>This kit generates greater yield than traditional DNase treatment followed by phenol/chloroform cleanup, and it is simpler to use.</td></tr><tr><td>RNaseZap</td><td>Ambion/Life Technologies</td><td>AM9782</td><td>Apply liberally on the bench surfaces and any equipment that might be in contact with the RNA samples. The solution is slightly alkaline/corrosive, can cause irritation and is harmful when swallowed.</td></tr><tr><td>2100 Bioanalyzer</td><td>Agilent Technologies</td><td>G2939AA</td><td>Place up to 12 RNA samples on one chip.</td></tr><tr><td>Hemotek Membrane Feeder</td><td>Hemotek&amp;nbsp;</td><td>5W1</td><td>This system&amp;nbsp; provides 5 feeding stations that can be used simultaneously. Includes PS5 Power Unit and Power cord; 5 FUI Feeders + Meal Reservoirs and O-rings; Plastic Plugs, Hemotek collagen feeding membrane; Temperature setting tool; and Plug extracting tool. The company&#039;s mailing address is: Hemotek Ltd; Unit 5 Union Court; Alan Ramsbottom Way; Great Harwood; Lancashire, UK; BB6 7FD; tel: +44 1254 889 307.</td></tr><tr><td>Digital Thermometer and Probe</td><td>Hemotek&amp;nbsp;</td><td>MT3KFU</td><td>MicroT3 thermometer and KFU probe. This is used to set the temperature of each FUI feeding unit.</td></tr><tr><td>Chicken Whole Blood, non-sterile with Sodium Citrate</td><td>Pel-Freez Biologicals</td><td>33130-1</td><td>The 500 ml of blood were frozen and stored in 20 ml aliquots at -80 &amp;#176;C for up to 1 year. Thaw blood at room temperature for at least 1 hr before using.</td></tr></tbody></table>

an experimental and bioinformatics protocol for rna-seq analyses of photoperiodic diapause in the asian tiger mosquito, aedes albopictus

Photoperiodic diapause is an important adaptation that allows individuals to escape harsh seasonal environments via a series of physiological changes, most notably developmental arrest and reduced metabolism. Global gene expression profiling via RNA-Seq can provide important insights into the transcriptional mechanisms of photoperiodic diapause. The Asian tiger mosquito, Aedes albopictus, is an outstanding organism for studying the transcriptional bases of diapause due to its ease of rearing, easily induced diapause, and the genomic resources available. This manuscript presents a general experimental workflow for identifying diapause-induced transcriptional differences in A. albopictus. Rearing techniques, conditions necessary to induce diapause and non-diapause development, methods to estimate percent diapause in a population, and RNA extraction and integrity assessment for mosquitoes are documented. A workflow to process RNA-Seq data from Illumina sequencers culminates in a list of differentially expressed genes. The representative results demonstrate that this protocol can be used to effectively identify genes differentially regulated at the transcriptional level in A. albopictus due to photoperiodic differences. With modest adjustments, this workflow can be readily adapted to study the transcriptional bases of diapause or other important life history traits in other mosquitoes.

Fluorometry of two representative RNA samples showed two bands at approximately 2,000 nt (Figure 1A, B). The insect 28S ribosomal RNA is comprised of two polynucleotide chains held together by hydrogen bonds, which are easily disrupted by brief heating or agents that disrupt hydrogen bonds35. The resulting two components are approximately the same size as the 18S ribosomal RNA. The second RNA sample showed high levels of degradation (Figure 1B).
Photoperiodic treatment of a representative group of A. albopictus mosquitoes resulted in high diapause incidence in short-day-reared mosquitoes, and low diapause incidence in long-day-reared mosquitoes, although there was some variation among replicates (Table 2). For example, replicate SD2 shows lower (80%) diapause incidence than the remaining replicates (87.18% &#8211; 97.67%). This replicate also had the smallest sample size, so it is recommended to set aside a sufficient number of eggs (&#62;150) for the diapause measurement in order to obtain an accurate result.
Post-sequencing read cleaning on one representative library from adult A. albopictus females removed a substantial number of reads (from 83,853,322 to 52,736,065 total reads for one representative library). Digital normalization further reduced the number of total reads to 41,435,934. A Trinity assembly of these reads generated 76,377 contigs, with an N50 of 1,879, mean contig length of 1,023.1, and a maximum contig length of 20,892 (Figure 3). Differential expression analyses from a similar workflow of embryos reared under diapause-inducing conditions at 11 and 21 days post-oviposition revealed 3,128 differentially expressed genes between these two time periods (Figure 4).
<img alt="Figure 1" src="/files/ftp_upload/51961/51961fig1highres.jpg" width="600px" />
Figure 1: Fluorometry profiles of example high-quality (A) and low-quality (B) RNA extractions from A. albopictus. The x-axis represents the sizes of the nucleotide fragments, and the y-axis represents the fluorescent readings. Note the difference in the y-axis scale between panels (A) and (B). Arrows mark the positions of the different ribosomal RNAs. The apparent bands close to the green marker band indicate degradation.
<img alt="Figure 2" src="/files/ftp_upload/51961/51961fig2highres.jpg" />
Figure 2: Summary of the bioinformatics workflow from read preparation to differential expression. Each box represents a step in the bioinformatics section of this protocol, accompanied by the corresponding number of each protocol step.
<img alt="Figure 3" src="/files/ftp_upload/51961/51961fig3highres.jpg" />
Figure 3: Histogram of contig lengths from a Trinity de novo transcriptome assembly. The average contig length is 1,023.1. Note that the distribution of contig lengths is heavily skewed towards shorter contigs; this is typical of de novo transcriptome assembly.
<img alt="Figure 4" src="/files/ftp_upload/51961/51961fig4highres.jpg" />
Figure 4: Log2-fold-change vs. abundance of TMM-normalized gene expression of diapause pharate larvae at 11 days vs. 21 days post-oviposition. Each point designates a unigene; differentially expressed unigenes are in red. Unigenes with higher expression at 11 days post-oviposition have positive fold-change values, whereas unigenes with higher expression 21 days post-oviposition have negative fold-change values.
<table border="0" cellpadding="0" cellspacing="0">
	<tbody>
		<tr>
			<td>Program/Resource</td>
			<td>Website URL (accessed 1/13/2014)</td>
		</tr>
		<tr>
			<td>perl</td>
			<td>http://www.perl.org/get.html</td>
		</tr>
		<tr>
			<td>python</td>
			<td>http://www.python.org/download/</td>
		</tr>
		<tr>
			<td>ssaha2</td>
			<td>http://www.sanger.ac.uk/resources/software/ssaha2/</td>
		</tr>
		<tr>
			<td>NCBI UniVec Core</td>
			<td>ftp://ftp.ncbi.nih.gov/pub/UniVec/UniVec_Core</td>
		</tr>
		<tr>
			<td>SolexaQA</td>
			<td>http://solexaqa.sourceforge.net/</td>
		</tr>
		<tr>
			<td>FastQC</td>
			<td>http://www.bioinformatics.babraham.ac.uk/projects/fastqc/</td>
		</tr>
		<tr>
			<td>khmer</td>
			<td>https://github.com/ged-lab/khmer</td>
		</tr>
		<tr>
			<td>Trinity</td>
			<td>http://trinityrnaseq.sourceforge.net/</td>
		</tr>
		<tr>
			<td>Trinity normalization script</td>
			<td>http://trinityrnaseq.sourceforge.net/trinity_insilico_normalization.html</td>
		</tr>
		<tr>
			<td>Assemblathon 2 evaluation scripts</td>
			<td>https://github.com/ucdavis-bioinformatics/assemblathon2-analysis</td>
		</tr>
		<tr>
			<td>BLAST+(which includes makeblastdb and blastx)</td>
			<td>ftp://ftp.ncbi.nlm.nih.gov/blast/executables/blast+/LATEST/</td>
		</tr>
		<tr>
			<td>linebreak</td>
			<td>https://code.google.com/p/linebreak/</td>
		</tr>
		<tr>
			<td>RSEM</td>
			<td>http://deweylab.biostat.wisc.edu/rsem/</td>
		</tr>
		<tr>
			<td>EdgeR User&#39;s Guide</td>
			<td>http://www.bioconductor.org/packages/2.13/bioc/vignettes/edgeR/inst/doc/edgeRUsersGuide.pdf</td>
		</tr>
		<tr>
			<td>R&#160;</td>
			<td>http://www.r-project.org/</td>
		</tr>
		<tr>
			<td>EdgeR</td>
			<td>http://www.bioconductor.org/packages/2.13/bioc/html/edgeR.html</td>
		</tr>
	</tbody>
</table>
Table 1: Programs and resources used for the bioinformatics procedures in this protocol. URLs are listed to easily access each of the resources needed in this protocol.
<table border="0" cellpadding="0" cellspacing="0">
	<tbody>
		<tr>
			<td>Treatment</td>
			<td>Replicate</td>
			<td>No. of eggs from 1st hatch</td>
			<td>No. of eggs from 2nd hatch</td>
			<td>No. embryonated, unhatched eggs</td>
			<td>% Diapause</td>
		</tr>
		<tr>
			<td>SD</td>
			<td>1</td>
			<td>10</td>
			<td>0</td>
			<td>68</td>
			<td>87.18</td>
		</tr>
		<tr>
			<td>SD</td>
			<td>2</td>
			<td>3</td>
			<td>0</td>
			<td>12</td>
			<td>80.00</td>
		</tr>
		<tr>
			<td>SD</td>
			<td>3</td>
			<td>1</td>
			<td>0</td>
			<td>42</td>
			<td>97.67</td>
		</tr>
		<tr>
			<td>SD</td>
			<td>4</td>
			<td>5</td>
			<td>0</td>
			<td>46</td>
			<td>90.20</td>
		</tr>
		<tr>
			<td>SD</td>
			<td>5</td>
			<td>6</td>
			<td>0</td>
			<td>79</td>
			<td>92.94</td>
		</tr>
		<tr>
			<td>LD</td>
			<td>1</td>
			<td>79</td>
			<td>4</td>
			<td>9</td>
			<td>9.78</td>
		</tr>
		<tr>
			<td>LD</td>
			<td>2</td>
			<td>28</td>
			<td>0</td>
			<td>4</td>
			<td>12.50</td>
		</tr>
		<tr>
			<td>LD</td>
			<td>3</td>
			<td>92</td>
			<td>1</td>
			<td>6</td>
			<td>6.06</td>
		</tr>
		<tr>
			<td>LD</td>
			<td>4</td>
			<td>30</td>
			<td>0</td>
			<td>5</td>
			<td>14.29</td>
		</tr>
		<tr>
			<td>LD</td>
			<td>5</td>
			<td>43</td>
			<td>0</td>
			<td>3</td>
			<td>6.52</td>
		</tr>
	</tbody>
</table>
Table 2: Diapause incidence calculations. Results from five replicates per photoperiod of diapause incidence calculations. Numbers of hatched larvae from two separate hatchings are included, as are the number of un-hatched, embryonated eggs, all of which are necessary to calculate diapause incidence.

Watch this Scientific Journal Video about An Experimental and Bioinformatics Protocol for RNA-seq Analyses of Photoperiodic Diapause in the Asian Tiger Mosquito, Aedes albopictus at JoVE.com

An Experimental and Bioinformatics Protocol for RNA-seq Analyses of Photoperiodic Diapause in the Asian Tiger Mosquito, Aedes albopictus

RNA-Seq analyses are becoming increasingly important for identifying the molecular underpinnings of adaptive traits in non-model organisms. Here, a protocol to identify differentially expressed genes between diapause and non-diapause Aedes albopictus mosquitoes is described, from mosquito rearing, to RNA sequencing and bioinformatics analyses of RNA-Seq data.

An Experimental and Bioinformatics Protocol for RNA-seq Analyses of Photoperiodic Diapause in the Asian Tiger Mosquito, Aedes albopictus

Photoperiodic diapause is an important adaptation that allows individuals to escape harsh seasonal environments via a series of physiological changes, ...

an-experimental-bioinformatics-protocol-for-rna-seq-analyses

Universidad San Sebastian

Research

JoVE Journal

Biology

13.2K Views.  Georgetown University. RNA-Seq analyses are becoming increasingly important for identifying the molecular underpinnings of adaptive traits in non-model organisms. Here, a protocol to identify differentially expressed genes between diapause and non-diapause Aedes albopictus mosquitoes is described, from mosquito rearing, to RNA sequencing and bioinformatics analyses of RNA-Seq data.

Video: An Experimental and Bioinformatics Protocol for RNA-seq Analyses of Photoperiodic Diapause in the Asian Tiger Mosquito, Aedes albopictus

Protocol for RNAi Assays in Adult Mosquitoes (A. gambiae)

Reverse genetic approaches have proven extremely useful for determining  which genes underly resistance to vector pathogens in mosquitoes.  This video protocol illustrates a method used by the Dimopoulos lab to inject dsRNA into Anopheles gambiae mosquitoes, which harbor the malaria parasite.  The technique manipulating the injection setup and injecting dsRNA into the thorax is illustrated.

Protocol for RNAi Assays in Adult Mosquitoes A. gambiae

Reverse genetic approaches have proven extremely useful for determining which genes underly resistance to vector pathogens in mosquitoes. This video protocol illustrates a method used by the Dimopoulos lab to inject dsRNA into Anopheles gambiae mosquitoes, which harbor the malaria parasite. The technique manipulating the injection setup and injecting dsRNA into the thorax is illustrated.

Reverse genetic approaches have proven extremely useful for determining  which genes underly resistance to vector pathogens in mosquitoes.  This video ...

Reproducible dsRNA Microinjection and Oviposition Bioassay in Mosquitoes and House Flies

Synthetic dsRNAs, used to induce RNA interference, may have dose dependent phenotypic effects. These effects are difficult to define if the dsRNAs are delivered using a non-quantitative method. Accurate delivery of known quantities of nucleic acids or other chemicals is critical to measure the efficacy of the compound being tested and to allow reliable comparison between compounds.
Here we provide a reproducible, quantitative microinjection protocol that ensures accurate delivery of specific doses of dsRNA, reducing the mortality typically induced by injection injury. These modifications include the addition of Rhodamine B, a graduated injection needle, and an improved recovery method borrowed from Isoe and Collins. This method allows calculation of dose responses and facilitates comparisons between compounds. Versions of this method have been successfully used on three genera of mosquitoes as well as house flies to assess the reduction in fecundity resulting from gene silencing of ribosomal RNA transcripts.
This protocol provides strategies to reduce several challenges of small insect microinjection. Together, mechanical delivery of dsRNAs accompanied by visual verification, identification of effective locations for delivery, and inclusion of a post-injection recovery period ensure accurate dosing and low injury mortality. This protocol also describes an oviposition bioassay for uniform determination of effects on fecundity.

This protocol describes a microinjection methodology that we have standardized and used for several years to deliver specific quantities of nucleic acids directly to the hemolymph of mosquitoes and house flies. This protocol results in minimal injection mortality and allows dose correlated measurements of fecundity.

Synthetic dsRNAs, used to induce RNA interference, may have dose dependent phenotypic effects. These effects are difficult to define if the dsRNAs are ...

Environment

A FACS-based Protocol to Isolate RNA from the Secondary Cells of Drosophila Male Accessory Glands

To understand the function of an organ, it is often useful to understand the role of its constituent cell populations. Unfortunately, the rarity of individual cell populations often makes it difficult to obtain enough material for molecular studies. For example, the accessory gland of the Drosophila male reproductive system contains two distinct secretory cell types. The main cells make up 96% of the secretory cells of the gland, while the secondary cells (SC) make up the remaining 4% of cells (about 80 cells per male). Although both cell types produce important components of the seminal fluid, only a few genes are known to be specific to the SCs. The rarity of SCs has, thus far, hindered transcriptomic analysis study of this important cell type. Here, a method is presented that allows for the purification of SCs for RNA extraction and sequencing. The protocol consists in first dissecting glands from flies expressing a SC-specific GFP reporter and then subjecting these glands to protease digestion and mechanical dissociation to obtain individual cells. Following these steps, individual, living, GFP-marked cells are sorted using a fluorescent activated cell sorter (FACS) for RNA purification. This procedure yields SC-specific RNAs from ~40 males per condition for downstream RT-qPCR and/or RNA sequencing in the course of one day. The rapidity and simplicity of the procedure allows for the transcriptomes of many different flies, from different genotypes or environmental conditions, to be determined in a short period of time.

A FACS-based Protocol to Isolate RNA from the Secondary Cells of Drosophila Male Accessory Glands

Here, we present a protocol to dissociate and sort a specific cell population from the Drosophila male accessory glands (secondary cells) for RNA sequencing and RT-qPCR. Cell isolation is accomplished through FACS purification of GFP-expressing secondary cells after a multistep-dissociation process requiring dissection, proteases digestion and mechanical dispersion.

To understand the function of an organ, it is often useful to understand the role of its constituent cell populations. Unfortunately, the rarity of ...

Genetics

Electroporation-mediated RNA Interference Method in Odonata

Dragonflies and damselflies (order Odonata) represent one of the most ancestral insects with metamorphosis, in which they change their habitat, morphology, and behavior drastically from aquatic larvae to terrestrial/aerial adults without pupal stage. Odonata adults have a well-developed color vision and show a remarkable diversity in body colors and patterns across sexes, stages, and species. While many ecological and behavioral studies on Odonata have been conducted, molecular genetic studies have been scarce mainly due to the difficulty in applying gene functional analysis to Odonata. For instance, RNA interference (RNAi) is less effective in the Odonata, as reported in the Lepidoptera. To overcome this problem, we successfully established an RNAi method combined with in vivo electroporation. Here we provide a detailed protocol including a video of the electroporation-mediated RNAi method as follows: preparation of larvae, species identification, preparation of dsRNA/siRNA solution and injection needles, ice-cold anesthesia of larvae, dsRNA/siRNA injection, in vivo electroporation, and individual rearing until adult emergence. The electroporation-mediated RNAi method is applicable to both damselflies (suborder Zygoptera) and dragonflies (suborder Anisoptera). In this protocol, we present the methods for the blue-tailed damselfly Ischnura senegalensis (Coenagrionidae) as an example of damselfly species and the pied skimmer dragonfly Pseudothemis zonata (Libellulidae) as another example of dragonfly species. As representative examples, we show the results of RNAi targeting the melanin synthesis gene multicopper oxidase 2. This RNAi method will facilitate understanding of various gene functions involved in metamorphosis, morphogenesis, color pattern formation, and other biological features of Odonata. Moreover, this protocol may be generally applicable to non-model organisms in which RNAi is less effective in gene suppression due to the inefficiency and low penetrance.

We provide a detailed protocol for electroporation-mediated RNA interference in insects of the order Odonata (dragonflies and damselflies) using the blue-tailed damselfly (Ischnura senegalensis: Coenagironidae: Zygoptera) and the pied skimmer dragonfly (Pseudothemis zonata: Libellulidae: Anisoptera).

Dragonflies and damselflies (order Odonata) represent one of the most ancestral insects with metamorphosis, in which they change their habitat, ...

Developmental Biology

RNAi-mediated Gene Knockdown and In Vivo Diuresis Assay in Adult Female Aedes aegypti Mosquitoes

This video protocol demonstrates an effective technique to knockdown a particular gene in an insect and conduct a novel bioassay to measure excretion rate. This method can be used to obtain a better understanding of the process of diuresis in insects and is especially useful in the study of diuresis in blood-feeding arthropods that are able to take up huge amounts of liquid in a single blood meal.
This RNAi-mediated gene knockdown combined with an in vivo diuresis assay was developed by the Hansen lab to study the effects of RNAi-mediated knockdown of aquaporin genes on Aedes aegypti mosquito diuresis1.
The protocol is setup in two parts: the first demonstration illustrates how to construct a simple mosquito injection device and how to prepare and inject dsRNA into the thorax of mosquitoes for RNAi-mediated gene knockdown. The second demonstration illustrates how to determine excretion rates in mosquitoes using an in vivo bioassay.

RNAi-mediated Gene Knockdown and In Vivo Diuresis Assay in Adult Female Aedes aegypti Mosquitoes

In this protocol we combine RNAi-mediated gene silencing with an in vivo diuresis assay to study the effects knockdown of genes of interest has on mosquito fluid excretion.

This video protocol demonstrates an effective technique to knockdown a particular gene in an insect and conduct a novel bioassay to measure excretion ...

Purification of Transcripts and Metabolites from Drosophila Heads

For the last decade, we have tried to understand the molecular and cellular mechanisms of neuronal degeneration using Drosophila as a model organism. Although fruit flies provide obvious experimental advantages, research on neurodegenerative diseases has mostly relied on traditional techniques, including genetic interaction, histology, immunofluorescence, and protein biochemistry. These techniques are effective for mechanistic, hypothesis-driven studies, which lead to a detailed understanding of the role of single genes in well-defined biological problems. However, neurodegenerative diseases are highly complex and affect multiple cellular organelles and processes over time. The advent of new technologies and the omics age provides a unique opportunity to understand the global cellular perturbations underlying complex diseases. Flexible model organisms such as Drosophila are ideal for adapting these new technologies because of their strong annotation and high tractability. One challenge with these small animals, though, is the purification of enough informational molecules (DNA, mRNA, protein, metabolites) from highly relevant tissues such as fly brains. Other challenges consist of collecting large numbers of flies for experimental replicates (critical for statistical robustness) and developing consistent procedures for the purification of high-quality biological material. Here, we describe the procedures for collecting thousands of fly heads and the extraction of transcripts and metabolites to understand how global changes in gene expression and metabolism contribute to neurodegenerative diseases. These procedures are easily scalable and can be applied to the study of proteomic and epigenomic contributions to disease.

Purification of Transcripts and Metabolites from Drosophila Heads

We describe here the procedures for the extraction and purification of mRNA and metabolites from Drosophila heads. We are applying these techniques to better understand the cellular perturbations underlying neuronal degeneration. These methodologies can be easily scaled and adapted for other "omic" projects.

For the last decade, we have tried to understand the molecular and cellular mechanisms of neuronal degeneration using Drosophila as a model organism. ...

Ubiquitous and Tissue-specific RNA Targeting in Drosophila Melanogaster using CRISPR/CasRx

CasRx, a member of the RNA-targeting Cas13 family, is a promising new addition of the CRISPR/Cas technologies in efficient gene transcript reduction with an attractive off-target profile at both cellular and organismal levels. It is recently reported that the CRISPR/CasRx system can be used to achieve ubiquitous and tissue-specific gene transcript reduction in Drosophila melanogaster. This paper details the methods from the recent work, consisting of three parts: 1) ubiquitous&#160;in vivo endogenous RNA targeting using a two-component CasRx system; 2) ubiquitous in vivo exogenous RNA targeting using a three-component CasRx system; and 3) tissue-specific in vivo RNA targeting using a three-component CasRx system. The effects of RNA targeting observed include targeted gene specific phenotypic changes, targeted RNA transcript reduction, and occasional lethality phenotypes associated with high expression of CasRx protein and collateral activity. Overall, these results showed that the CasRx system is capable of target RNA transcript reduction at the organismal level in a programmable and efficient manner, demonstrating that in vivo transcriptome targeting, and engineering is feasible and lays the foundation for future in vivo CRISPR-based RNA targeting technologies.

Ubiquitous and Tissue-specific RNA Targeting in Drosophila Melanogaster using CRISPR/CasRx

This article outlines a detailed protocol for using the RNA-targeting Cas13D enzyme (RfxCas13D) in flies.

CasRx, a member of the RNA-targeting Cas13 family, is a promising new addition of the CRISPR/Cas technologies in efficient gene transcript reduction with ...

Immunology and Infection

Physiological Recordings and RNA Sequencing of the Gustatory Appendages of the Yellow-fever Mosquito Aedes aegypti

Electrophysiological recording of action potentials from sensory neurons of mosquitoes provides investigators a glimpse into the chemical perception of these disease vectors. We have recently identified a bitter sensing neuron in the labellum of female Aedes aegypti that responds to DEET and other repellents, as well as bitter quinine, through direct electrophysiological investigation. These gustatory receptor neuron responses prompted our sequencing of total mRNA from both male and female labella and tarsi samples to elucidate the putative chemoreception genes expressed in these contact chemoreception tissues. Samples of tarsi were divided into pro-, meso- and metathoracic subtypes for both sexes. We then validated our dataset by conducting qRT-PCR on the same tissue samples and used statistical methods to compare results between the two methods. Studies addressing molecular function may now target specific genes to determine those involved in repellent perception by mosquitoes. These receptor pathways may be used to screen novel repellents towards disruption of host-seeking behavior to curb the spread of harmful viruses.

Physiological Recordings and RNA Sequencing of the Gustatory Appendages of the Yellow-fever Mosquito Aedes aegypti

Using two methods to estimate gene expression in the major gustatory appendages of Aedes aegypti, we have identified the set of genes putatively underlying the neuronal responses to bitter and repulsive compounds, as determined by electrophysiological examination.

Electrophysiological recording of action potentials from sensory neurons of mosquitoes provides investigators a glimpse into the chemical perception of ...

RNAi Trigger Delivery into Anopheles gambiae Pupae

RNA interference (RNAi), a naturally occurring phenomenon in eukaryotic organisms, is an extremely valuable tool that can be utilized in the laboratory for functional genomic studies. The ability to knockdown individual genes selectively via this reverse genetic technique has allowed many researchers to rapidly uncover the biological roles of numerous genes within many organisms, by evaluation of loss-of-function phenotypes. In the major human malaria vector Anopheles gambiae, the predominant method used to reduce the function of targeted genes involves injection of double-stranded (dsRNA) into the hemocoel of the adult mosquito. While this method has been successful, gene knockdown in adults excludes the functional assessment of genes that are expressed and potentially play roles during pre-adult stages, as well as genes that are expressed in limited numbers of cells in adult mosquitoes. We describe a method for the injection of Serine Protease Inhibitor 2 (SRPN2) dsRNA during the early pupal stage and validate SRPN2 protein knockdown by observing decreased target protein levels and the formation of melanotic pseudo-tumors in SRPN2 knockdown adult mosquitoes. This evident phenotype has been described previously for adult stage knockdown of SRPN2 function, and we have recapitulated this adult phenotype by SRPN2 knockdown initiated during pupal development. When used in conjunction with a dye-labeled dsRNA solution, this technique enables easy visualization by simple light microscopy of injection quality and distribution of dsRNA in the hemocoel.

RNAi Trigger Delivery into Anopheles gambiae Pupae

RNA interference (RNAi) is an extremely valuable tool for uncovering gene function. However, the ability to target genes using RNAi during pre-adult stages is limited in the major human malaria vector Anopheles gambiae. We describe an RNAi protocol to reduce gene function via direct injection during pupal development.

RNA interference (RNAi), a naturally occurring phenomenon in eukaryotic organisms, is an extremely valuable tool that can be utilized in the laboratory ...

A Bioinformatics Pipeline for Investigating Molecular Evolution and Gene Expression using RNA-seq

Distilling and reporting large datasets, such as whole genome or transcriptome data, is often a daunting task. One way to break down results is to focus on one or more gene families that are significant to the organism and study. In this protocol, we outline bioinformatic steps to generate a phylogeny and to quantify the expression of genes of interest. Phylogenetic trees can give insight into how genes are evolving within and between species as well as reveal orthology. These results can be enhanced using RNA-seq data to compare the expression of these genes in different individuals or tissues. Studies of molecular evolution and expression can reveal modes of evolution and conservation of gene function between species. The characterization of a gene family can serve as a springboard for future studies and can highlight an important gene family in a new genome or transcriptome paper.

The purpose of this protocol is to investigate the evolution and expression of candidate genes using RNA sequencing data.

Distilling and reporting large datasets, such as whole genome or transcriptome data, is often a daunting task. One way to break down results is to focus ...

An Experimental and Bioinformatics Protocol for RNA-seq Analyses of Photoperiodic Diapause in the Asian Tiger Mosquito, Aedes albopictus

Summary

Explore More Videos

Chapters in this video

Protocol for RNAi Assays in Adult Mosquitoes (A. gambiae)

Reproducible dsRNA Microinjection and Oviposition Bioassay in Mosquitoes and House Flies

A FACS-based Protocol to Isolate RNA from the Secondary Cells of Drosophila Male Accessory Glands

Electroporation-mediated RNA Interference Method in Odonata

RNAi-mediated Gene Knockdown and In Vivo Diuresis Assay in Adult Female Aedes aegypti Mosquitoes

Purification of Transcripts and Metabolites from Drosophila Heads

Ubiquitous and Tissue-specific RNA Targeting in Drosophila Melanogaster using CRISPR/CasRx

Physiological Recordings and RNA Sequencing of the Gustatory Appendages of the Yellow-fever Mosquito Aedes aegypti

RNAi Trigger Delivery into Anopheles gambiae Pupae

A Bioinformatics Pipeline for Investigating Molecular Evolution and Gene Expression using RNA-seq
