Description: Watch this Scientific Journal Video about Determining if DNA Stained with a Cyanine Dye Can Be Digested with Restriction Enzymes at JoVE.com

This research was funded by the National Institute for General Medical Science (NIGMS) (5605100122001), a component of the National Institutes of Health (NIH), as well as University of Nebraska at Kearney (UNK) Summer Student Research Program (SSRP), and UNK Undergraduate Research Fellowship (URF).

1. Preparation of Dyes, Buffers and Agarose Gel
<ol>
	<li>Prepare the following solutions for staining DNA or the digestion of stained DNA.
	<ol>
		<li>Prepare 1x TE (Tris-HCl and ethylenediaminetetraacetic acid; EDTA) buffer using 10 mM Tris-HCl and 1 mM EDTA in a graduated cylinder or volumetric flask. Store at room temperature (18 - 25 &#176;C).</li>
		<li>Make aliquots of each dye: TOTO-1, YOYO-1, POPO-1, BOBO-1, TOTO-3, YOYO-3, POPO-3, BOBO-3 (Table 1). Pipette 4 &#181;L of 1 mM dye into a dark amber or black 1.5 mL tube and add 36 &#181;L of 1x TE, mix using the pipette; this concentration makes a 100 &#181;M dye solution (40 &#181;L total). Complete this step for each dye. Store at 4 &#176;C.
		NOTE: Avoid exposing dye to light to prevent photobleaching or degradation of the dye.</li>
		<li>Prepare buffer 1 using 10 mM Bis-Tris-Propane-HCl, 10 mM MgCl2, and 100 &#181;g/mL bovine serum albumin (BSA). Prepare buffer 2 using 50 mM NaCl, 10 mM Tris-HCl, 10 mM MgCl2, and 100 &#181;g/mL BSA. Prepare buffer 3 using 50 mM Potassium Acetate, 20 mM Tris-acetate, 10 mM magnesium acetate, and 100 &#181;g/mL BSA. Each enzyme will require one of these specific buffers to function.</li>
	</ol>
	</li>
	<li>Prepare the following solutions for gel electrophoresis.
	<ol>
		<li>Make a 6x loading dye by combining 0.25% bromophenol blue, 0.25% xylene cyanol, 15% Ficoll in dH2O. Store at room temperature.</li>
		<li>To make a 0.7% agarose gel, weigh out 0.07 g of high gelling temperature (HGT) agarose in an Erlenmeyer flask, add 100 mL of 1x TAE buffer and place an inverted beaker on top of the flask.
		<ol>
			<li>Heat the solution on a hot plate until bubbles begin to form on the bottom of the flask and float to the top.</li>
			<li>Remove the solution from the hot plate, let the solution cool until the flask can be touched with a bare hand, and then pour the gel into a 24.5 cm x 21.8 cm gel mold with a gel comb to create wells.</li>
			<li>Remove bubbles near the comb or on the surface of the gel by popping them with a pipette tip and allow the gel to solidify for at least 15 minutes. This can be stored in a fridge (4 &#176;C) wrapped in plastic wrap for 1 week to prevent drying of the gel or contamination. For more information on how to run a gel refer to Lee et al.33.
			NOTE: Use a gel comb with 30 individual wells. Each well should be 4.5 mm wide with a depth of 2 mm. The height of the well will depend on the amount of gel poured into the box.</li>
		</ol>
		</li>
		<li>Prepare 1x TAE (Tris - acetate - EDTA) buffer using 40 mM Tris-HCl, 20 mM acetic acid, and 1 mM EDTA. Store at room temperature (18 - 25 &#176;C).</li>
	</ol>
	</li>
</ol>
2. Preparation of Stained DNA
<ol>
	<li>Stain lambda DNA (300-800 ng) using different aliquots of dyes. Each dye (Table 1) will have six different concentrations tested, for a total of 48 reactions per restriction enzyme. The following process outlines a set up for 1 reaction (Figure 1).
	<ol>
		<li>Dilute lambda DNA using 1x TE to 100 ng/&#181;L. Store in 4 &#176;C. Make a solution with total volume of 300 &#181;L.</li>
		<li>Stain unmethylated lambda DNA. For each band expected from the digest, estimate 75 - 100 ng/band. Add appropriate amounts of dye to produce concentrations of 1.9 &#181;M, 3.8 &#181;M, 19.4 &#181;M, 32.2 &#181;M, 48.3 &#181;M, 63.5 &#181;M / 100 ng of DNA.</li>
		<li>Incubate overnight (15 h - 18 h) at 4 &#176;C.</li>
		<li>Leave one reaction unstained to act as a control25.
		NOTE: Use unmethylated DNA for the digestion reaction. Methylation sensitive enzymes cannot cut methylated regions in DNA and will give an appearance of an incomplete digestion.</li>
	</ol>
	</li>
</ol>
3. Preparation of the Restriction Enzyme Assay
<ol>
	<li>Digest stained DNA with a restriction enzyme to determine if that enzyme can digest prestained DNA (Figure 1).
	<ol>
		<li>The following day, add 20 U of restriction enzyme, 3 &#181;L of the appropriate buffer ( Table 2), and distilled, autoclaved and filtered water for a total of 30 &#181;L. For each enzyme reaction, choose the buffer with the highest cutting efficiency, which can be found on the manufacturer&#39;s website.</li>
		<li>Place the reactions in a water bath at the temperature of optimal enzymatic activity, listed in Table 2 for the 6 enzymes used in Maschmann et al., for 2 - 4 h (Table 2)25.</li>
		<li>Stop the reaction by adding 2 &#181;L of 0.5 M EDTA pH 8.0.</li>
	</ol>
	</li>
</ol>
4. Electroeluting Stained DNA in an Agarose Gel
<ol>
	<li>Remove the sides from the 24.5 cm x 21.8 cm gel mold (Step 1.2.2) and place the gel into the gel electrophoresis box. Pour 2.5 L of 1x TAE buffer into the box. Carefully remove the gel comb from the gel, so the wells are accessible33.</li>
	<li>Pipette the restriction enzyme reactions onto a plastic film and combine each reaction with 6x loading dye. For each reaction solution, add 1 &#181;L of 6x loading dye per 5 - 6 &#181;L of DNA solution (1x). Then pipette the reactions (containing the loading dye, &#60;18 &#181;L) into the wells.</li>
	<li>Mix 1 &#181;L of 1 kb ladder, 9 &#181;L of 1x TE, and 2 &#181;L of 6x loading dye. Load solution into the wells that flank the other solutions.</li>
	<li>Cover the gel box with dark blue or black paper or fabric. Connect the gel box to a power supply, set the power supply to 30 V, and run it overnight (15 - 20 h). Turn off the lights while the gel is running, to prevent photocleavage of the labeled DNA.</li>
	<li>The next morning turn off the power supply. Take the gel out using the tray and transfer it to a container with 45 &#181;L ethidium bromide and 1 L of 1x TAE buffer. Store the container at room temperature in the dark or cover in foil to prevent exposure to light. Let gel stain for at least 45 min at room temperature.
	CAUTION: Use ethidium bromide with gloves and wear safety glasses. When cleaning out the container containing ethidium bromide solution and throwing away the gel, consult your states disposal guidelines to determine how to deal with used ethidium bromide; additionally, other stains may be utilized instead of ethidium bromide.</li>
</ol>
5. Imaging the Agarose Gel
<ol>
	<li>Place the gel on top of a blue light transilluminator, which emits maximum light output between 400-500 nm. Take pictures with the camera attached to the station.
	CAUTION: Make sure to use the cover for the illuminator and put on protective glasses prior to turning on the light source.
	NOTE: This step may also be completed using any UV light source or standard gel scanner.</li>
	<li>View the pictures in ImageJ by dragging the file to the ImageJ status bar and the image will pop up.</li>
	<li>Determine the digestion rate for the experiment by comparing the bands on the gel to the expected in silico gel pattern. To determine the digestion rate, the number of experimental bands is divided by the expected number of DNA bands24,25. If the experimental digested DNA band pattern has the expected pattern, the digestion rate is 1. If the pattern has more fragments than expected, the digestion rate is greater than 1. If the pattern has less fragments than expected, the digestion rate is less than one.</li>
</ol>

<ol>
	<li>Teague, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-resolution+human+genome+structure+by+single-molecule+analysis.">High-resolution human genome structure by single-molecule analysis.</a> Proc Natl Acad Sci U S A. 107 (24), 10848-10853 (2010).</li><li>Ananiev, G. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+mapping+discerns+genome+wide+DNA+methylation+profiles.">Optical mapping discerns genome wide DNA methylation profiles.</a> BMC Mol Biol. 9, 68 (2008).</li><li>Zhou, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Validation+of+rice+genome+sequence+by+optical+mapping.">Validation of rice genome sequence by optical mapping.</a> BMC Genomics. 8, 278 (2007).</li><li>Reslewic, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole-genome+shotgun+optical+mapping+of+Rhodospirillum+rubrum.">Whole-genome shotgun optical mapping of Rhodospirillum rubrum.</a> Appl Environ Microbiol. 71 (9), 5511-5522 (2005).</li><li>Zhou, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Whole-genome+shotgun+optical+mapping+of+Rhodobacter+sphaeroides+strain+2.4.1+and+its+use+for+whole-genome+shotgun+sequence+assembly.">Whole-genome shotgun optical mapping of Rhodobacter sphaeroides strain 2.4.1 and its use for whole-genome shotgun sequence assembly.</a> Genome Res. 13 (9), 2142-2151 (2003).</li><li>Gupta, A., Kounovsky-Shafer, K. L., Ravindran, P., Schwartz, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+mapping+and+nanocoding+approaches+to+whole-genome+analysis.">Optical mapping and nanocoding approaches to whole-genome analysis.</a> Microfluidics and Nanofluidics. 20 (44), 1-14 (2016).</li><li>Kounovsky-Shafer, K. L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Presentation+of+large+DNA+molecules+for+analysis+as+nanoconfined+dumbbells.">Presentation of large DNA molecules for analysis as nanoconfined dumbbells.</a> Macromolecules. 46 (20), 8356-8368 (2013).</li><li>Kim, Y., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Nanochannel+confinement:+DNA+stretch+approaching+full+contour+length.">Nanochannel confinement: DNA stretch approaching full contour length.</a> Lab Chip. 11 (10), 1721-1729 (2011).</li><li>Yu, H., Jo, K., Kounovsky, K. L., de Pablo, J. J., Schwartz, D. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+propulsion:+chemical+sensing+and+chemotaxis+of+DNA+driven+by+RNA+polymerase.">Molecular propulsion: chemical sensing and chemotaxis of DNA driven by RNA polymerase.</a> J Am Chem Soc. 131 (16), 5722-5723 (2009).</li><li>Lam, E. T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genome+mapping+on+nanochannel+arrays+for+structural+variation+analysis+and+sequence+assembly.">Genome mapping on nanochannel arrays for structural variation analysis and sequence assembly.</a> Nat Biotechnol. 30 (8), 771-776 (2012).</li><li>Cao, H., Tegenfeldt, J. O., Austin, R. H., Chou, S. Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Gradient+nanostructures+for+interfacing+microfluidics+and+nanofluidics.">Gradient nanostructures for interfacing microfluidics and nanofluidics.</a> Applied Physics Letters. 81 (16), 3058-3060 (2002).</li><li>Gupta, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single-molecule+analysis+reveals+widespread+structural+variation+in+multiple+myeloma.">Single-molecule analysis reveals widespread structural variation in multiple myeloma.</a> Proc Natl Acad Sci U S A. 112 (25), 7689-7694 (2015).</li><li>Wu, C. W., Schramm, T. M., Zhou, S., Schwartz, D. C., Talaat, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+mapping+of+the+Mycobacterium+avium+subspecies+paratuberculosis+genome.">Optical mapping of the Mycobacterium avium subspecies paratuberculosis genome.</a> BMC Genomics. 10, 25 (2009).</li><li>Jo, K., Schramm, T. M., Schwartz, D. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+single-molecule+barcoding+system+using+nanoslits+for+DNA+analysis+:+nanocoding.">A single-molecule barcoding system using nanoslits for DNA analysis : nanocoding.</a> Methods Mol Biol. 544, 29-42 (2009).</li><li>Jo, K., Chen, Y. L., de Pablo, J. J., Schwartz, D. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Elongation+and+migration+of+single+DNA+molecules+in+microchannels+using+oscillatory+shear+flows.">Elongation and migration of single DNA molecules in microchannels using oscillatory shear flows.</a> Lab Chip. 9 (16), 2348-2355 (2009).</li><li>Jo, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+single-molecule+barcoding+system+using+nanoslits+for+DNA+analysis.">A single-molecule barcoding system using nanoslits for DNA analysis.</a> Proc Natl Acad Sci U S A. 104 (8), 2673-2678 (2007).</li><li>Reccius, C. H., Mannion, J. T., Cross, J. D., Craighead, H. G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Compression+and+free+expansion+of+single+DNA+molecules+in+nanochannels.">Compression and free expansion of single DNA molecules in nanochannels.</a> Phys Rev Lett. 95 (26), 268101 (2005).</li><li>Staerk, D., Hamed, A. A., Pedersen, E. B., Jacobsen, J. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bisintercalation+of+homodimeric+thiazole+orange+dyes+in+DNA:+effect+of+modifying+the+linker.">Bisintercalation of homodimeric thiazole orange dyes in DNA: effect of modifying the linker.</a> Bioconjug Chem. 8 (6), 869-877 (1997).</li><li>Spielmann, H. P., Wemmer, D. E., Jacobsen, J. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Solution+structure+of+a+DNA+complex+with+the+fluorescent+bis-intercalator+TOTO+determined+by+NMR+spectroscopy.">Solution structure of a DNA complex with the fluorescent bis-intercalator TOTO determined by NMR spectroscopy.</a> Biochemistry. 34, 8542-8553 (1995).</li><li>Carlsson, C., Jonsson, M., Akerman, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Double+bands+in+DNA+gel+electrophoresis+caused+by+bis-intercalating+dyes.">Double bands in DNA gel electrophoresis caused by bis-intercalating dyes.</a> Nucleic Acids Res. 23 (13), 2413-2420 (1995).</li><li>Kundukad, B., Yan, J., Doyle, P. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effect+of+YOYO-1+on+the+mechanical+properties+of+DNA.">Effect of YOYO-1 on the mechanical properties of DNA.</a> Soft Matter. 10 (48), 9721-9728 (2014).</li><li>Technologies, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> The Molecular Probes Handbook: A guide to Fluorescent Probes and Labeling Technologies. , (2010).</li><li>Riehn, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Restriction+mapping+in+nanofluidic+devices.">Restriction mapping in nanofluidic devices.</a> Proc Natl Acad Sci U S A. 102 (29), 10012-10016 (2005).</li><li>Meng, X., Cai, W., Schwartz, D. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Inhibition+of+restriction+endonuclease+activity+by+DNA+binding+fluorochromes.">Inhibition of restriction endonuclease activity by DNA binding fluorochromes.</a> J Biomol Struct Dyn. 13 (6), 945-951 (1996).</li><li>Maschmann, A., Kounovsky-Shafer, K. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Determination+of+restriction+enzyme+activity+when+cutting+DNA+labeled+with+the+TOTO+Dye+family.">Determination of restriction enzyme activity when cutting DNA labeled with the TOTO Dye family.</a> Nucleosides Nucleotides Nucleic Acids. , 1-12 (2017).</li><li>Biebricker, A. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+impact+of+DNA+intercalators+on+DNA+and+DNA-processing+enzymes+elucidated+through+force-dependent+binding+kinetics.">The impact of DNA intercalators on DNA and DNA-processing enzymes elucidated through force-dependent binding kinetics.</a> Nature Communications. 6, 7304 (2015).</li><li>Gunther, K., Mertig, M., Seidel, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mechanical+and+structural+properties+of+YOYO-1+complexed+DNA.">Mechanical and structural properties of YOYO-1 complexed DNA.</a> Nucleic Acids Res. 38 (19), 6526-6532 (2010).</li><li>Zhou, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+clone-free,+single+molecule+map+of+the+domestic+cow+(Bos+taurus)+genome.">A clone-free, single molecule map of the domestic cow (Bos taurus) genome.</a> BMC Genomics. 16, 644 (2015).</li><li>Ray, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Discovery+of+structural+alterations+in+solid+tumor+oligodendroglioma+by+single+molecule+analysis.">Discovery of structural alterations in solid tumor oligodendroglioma by single molecule analysis.</a> BMC Genomics. 14, 505 (2013).</li><li>Chen, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Genome+sequence+of+the+model+medicinal+mushroom+Ganoderma+lucidum.">Genome sequence of the model medicinal mushroom Ganoderma lucidum.</a> Nat Commun. 3, 913 (2012).</li><li>Zhou, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+single+molecule+scaffold+for+the+maize+genome.">A single molecule scaffold for the maize genome.</a> PLoS Genet. 5 (11), e1000711 (2009).</li><li>Sischka, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Molecular+mechanisms+and+kinetics+between+DNA+and+DNA+binding+ligands.">Molecular mechanisms and kinetics between DNA and DNA binding ligands.</a> Biophys J. 88 (1), 404-411 (2005).</li><li>Lee, P. Y., Costumbrado, J., Hsu, C. Y., Kim, Y. H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Agarose+gel+electrophoresis+for+the+separation+of+DNA+fragments.">Agarose gel electrophoresis for the separation of DNA fragments.</a> J Vis Exp. (62), (2012).</li><li>Zipper, H., Brunner, H., Bernhagen, J., Vitzthum, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Investigations+on+DNA+intercalation+and+surface+binding+by+SYBR+Green+I,+its+structure+determination+and+methodological+implications.">Investigations on DNA intercalation and surface binding by SYBR Green I, its structure determination and methodological implications.</a> Nucleic Acids Res. 32 (12), e103 (2004).</li></ol>

The authors have nothing to disclose.

In order to digest fluorescently labeled DNA (Figure 1), a series of steps are required. First, DNA is stained with a fluorochrome overnight. DNA can be incubated with cyanine dimers for a shorter period of time; however, Carlsson et al. found that DNA created double bands for each DNA size due to incomplete staining20. To remedy this, the DNA can be stained overnight to prevent double bands from occurring. This is a critical step in the prot...

The TOTO series (TOTO-1, YOYO-1, POPO-1, BOBO-1, TOTO-3, YOYO-3, POPO-3, and BOBO-3; Table 1) is utilized in a wide variety of experiments where the visualization of DNA is required1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16,17. The cyanine dimer family is widely used due to their quantum yield, sensitivity, and high affinity for DNA molecules18,19,20. Cyanine dimer dyes have great selectivity for double stranded DNA and when intercalated have a 100 to 1000 fold increase of fluorescence21. Pyridinium dyes (YOYO-1, TOTO-1, YOYO-3, and TOTO-3) have a shorter emission wavelength than their quinolium dye (BOBO-1, POPO-1, BOBO-3, and POPO-3) counterparts (Table 1)22. Also, the quantum yield for cyanine dimers intercalated into DNA is high (0.2 - 0.6)22. However, using an enzyme to determine the methylation profile of a DNA molecule2 or stretch23 of a DNA molecule already stained with fluorescent dye requires a method to determine what enzymes will digest stained DNA. Any type of dye that intercalates into DNA or any enzyme that gives a discernable pattern of the DNA substrate can be used for this method.
Meng et al. first determined the digestion rate of prestained DNA through gel electrophoresis using a variety of different dyes24. Maschmann et al. delved in deeper to look at the TOTO family of dyes. Both determined the digestion rate of stained DNA to see if DNA stained with a given dye could be digested with a restriction enzyme25. Other methods study binding effects of dyes intercalated with DNA using optical tweezers26 or NMR27. Either method requires specialized equipment; whereas, this method allows equipment that most molecular biology labs have to determine if a dye interferes with a restriction enzyme digestion.
Additionally, in other methods to measure the length of a given molecule, optical mapping has elongated unstained DNA molecules on a surface and digested DNA to determine the stretch and size of fragments. Intercalation of dye has been shown to increase the contour length of fluorescently stained DNA molecules and depending on the dye used, the contour lengths are different21. This method has been utilized in a variety of genomes1,3,4,6,13,28,29,30,31. However, if molecules were pre-stained, depending on the dye and enzyme, the enzyme may not be able to cut DNA stained with a given dye. Therefore, this method determines if DNA stained with a given dye can be digested with an enzyme. Additionally, depending on the concentration of the dye and the dye utilized, the mobility of the DNA bands in a gel will migrate more slowly than native DNA due to the partial unwinding of the DNA backbone to make room for the dye to insert between base pairs32.
However, sometimes these dyes can partially or completely inhibit the action of certain restriction enzymes7,24. This is thought to be due to a structural change in DNA caused by the attachment of the fluorescent dye, which may prevent the enzyme from recognizing its specific sequence. Understanding how these dyes affect restriction enzymes can help in experiments where the methylation profile or the stretch of stained DNA is required.
In our method, DNA was stained with a fluorochrome of interest and digested with a restriction enzyme. Then DNA was electrophoresed on a gel, imaged, and the restriction enzyme digestion rate was measured. The restriction enzymes were chosen based on the cut pattern on a gel. Too many bands caused overlap of DNA bands and too few bands did not give a complete picture of the DNA molecule. There is a sweet spot to be able to determine the profile of the digested DNA molecule; therefore, it will depend on the DNA used and the enzyme. An advantage of this method is its simplicity; it only requires equipment used in a restriction digestion and gel electrophoresis.
