私たちは議論のためにFerenc Krausz教授に感謝し、原稿を完成させる彼女の支援についてNajd Altwaijryに感謝したいと思います。この作業は、Advanced Laser Applications Center（CALA）によって資金提供されています。

<ol>
	<li>Fattahi, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Third-generation+femtosecond+technology.">Third-generation femtosecond technology.</a> Optica. 1 (1), 45-63 (2014).</li><li>Hentschel, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Attosecond+metrology.">Attosecond metrology.</a> Nature. 414 (6863), 509-513 (2001).</li><li>Cavalieri, A. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Intense+1.5-cycle+near+infrared+laser+waveforms+and+their+use+for+the+generation+of+ultra-broadband+soft-x-ray+harmonic+continua.">Intense 1.5-cycle near infrared laser waveforms and their use for the generation of ultra-broadband soft-x-ray harmonic continua.</a> New J Phys. 9 (7), 242 (2007).</li><li>Schweinberger, W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Waveform-controlled+near-single-cycle+milli-joule+laser+pulses+generate+sub-10+nm+extreme+ultraviolet+continua.">Waveform-controlled near-single-cycle milli-joule laser pulses generate sub-10 nm extreme ultraviolet continua.</a> Opt Lett. 37, 3573-3575 (2012).</li><li>Buck, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Real-time+observation+of+laser-driven+electron+acceleration.">Real-time observation of laser-driven electron acceleration.</a> Nature Phys. 7 (7), 543-548 (2011).</li><li>Zhong, H., Karpowicz, N., Zhang, X. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Terahertz+emission+profile+from+laser-induced+air+plasma.">Terahertz emission profile from laser-induced air plasma.</a> Appl Phys Lett. 88 (26), 261103 (2006).</li><li>Herrmann, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Generation+of+sub-three-cycle,+16+TW+light+pulses+by+using+noncollinear+optical+parametric+chirped-pulse+amplification.">Generation of sub-three-cycle, 16 TW light pulses by using noncollinear optical parametric chirped-pulse amplification.</a> Opt Lett. 34 (16), 2459-2461 (2009).</li><li>Adachi, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=1.5+mJ,+6.4+fs+parametric+chirped-pulse+amplification+system+at+1+kHz.">1.5 mJ, 6.4 fs parametric chirped-pulse amplification system at 1 kHz.</a> Opt Lett. 32 (17), 2487-2489 (2007).</li><li>Adachi, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=5-fs,+multi-mJ,+CEP-locked+parametric+chirped-pulse+amplifier+pumped+by+a+450-nm+source+at+1+kHz.">5-fs, multi-mJ, CEP-locked parametric chirped-pulse amplifier pumped by a 450-nm source at 1 kHz.</a> Opt express. 16 (19), 14341-14352 (2008).</li><li>Yin, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-efficiency+optical+parametric+chirped-pulse+amplifier+in+BiB3O6+for+generation+of+3+mJ,+two-cycle,+carrier-envelope-phase-stable+pulses+at+1.7+&#181;m.">High-efficiency optical parametric chirped-pulse amplifier in BiB3O6 for generation of 3 mJ, two-cycle, carrier-envelope-phase-stable pulses at 1.7 &#181;m.</a> Opt Lett. 41 (6), 1142-1145 (2016).</li><li>Deng, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Carrier-envelope-phase-stable,+1.2+mJ,+1.5+cycle+laser+pulses+at+2.1+&#181;m.">Carrier-envelope-phase-stable, 1.2 mJ, 1.5 cycle laser pulses at 2.1 &#181;m.</a> Opt Lett. 37 (23), 4973-4975 (2012).</li><li>Rothhardt, J., Demmler, S., H&#228;drich, S., Limpert, J., T&#252;nnermann, A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Octave-spanning+OPCPA+system+delivering+CEP-stable+few-cycle+pulses+and+22+W+of+average+power+at+1+MHz+repetition+rate.">Octave-spanning OPCPA system delivering CEP-stable few-cycle pulses and 22 W of average power at 1 MHz repetition rate.</a> Opt express. 20 (10), 10870-10878 (2012).</li><li>Heckl, O. H., Nolte, S., Schrempel, F., Dausinger, F., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Ultrafast Thin-Disk Lasers.Ultrashort Pulse Laser Technology. 195, 93-115 (2016).</li><li>Zapata, L. E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cryogenic+Yb:YAG+composite-thin-disk+for+high+energy+and+average+power+amplifiers.">Cryogenic Yb:YAG composite-thin-disk for high energy and average power amplifiers.</a> Opt. Lett. 40 (11), 2610-2613 (2015).</li><li>Schulz, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Yb:YAG+Innoslab+amplifier:+efficient+high+repetition+rate+subpicosecond+pumping+system+for+optical+parametric+chirped+pulse+amplification.">Yb:YAG Innoslab amplifier: efficient high repetition rate subpicosecond pumping system for optical parametric chirped pulse amplification.</a> Opt Lett. 36 (13), 2456-2458 (2011).</li><li>Roeser, F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Millijoule+pulse+energy+high+repetition+rate+femtosecond+fiber+chirped-pulse+amplification+system.">Millijoule pulse energy high repetition rate femtosecond fiber chirped-pulse amplification system.</a> Opt Lett. 32 (24), 3495-3497 (2007).</li><li>Russbueldt, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=400+W+Yb:YAG+Innoslab+fs-amplifier.">400 W Yb:YAG Innoslab fs-amplifier.</a> Opt Express. 17 (15), 12230-12245 (2009).</li><li>Baumgarten, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=0.5+kHz+repetition+rate+picosecond+laser.">0.5 kHz repetition rate picosecond laser.</a> Opt Lett. 41 (14), 3339-3342 (2016).</li><li>Klingebiel, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=220mJ,+1+kHz+Picosecond+Regenerative+Thin-Disk+Amplifier.">220mJ, 1 kHz Picosecond Regenerative Thin-Disk Amplifier.</a> , (2015).</li><li>Nubbemeyer, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=1+kW,+200+mJ+picosecond+thin-disk+laser+system.">1 kW, 200 mJ picosecond thin-disk laser system.</a> Opt Lett. 42 (7), 1381-1384 (2017).</li><li>Fattahi, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=High-power,+1-ps,+all-Yb:YAG+thin-disk+regenerative+amplifier.">High-power, 1-ps, all-Yb:YAG thin-disk regenerative amplifier.</a> Opt Lett. 41 (6), 1126-1129 (2016).</li><li>Brons, J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Energy+scaling+of+Kerr-lens+mode-locked+thin-disk+oscillators.">Energy scaling of Kerr-lens mode-locked thin-disk oscillators.</a> Opt Lett. 39 (22), 6442-6445 (2014).</li><li>Trebino, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Measuring+ultrashort+laser+pulses+in+the+time-frequency+domain+using+frequency-resolved+optical+gating.">Measuring ultrashort laser pulses in the time-frequency domain using frequency-resolved optical gating.</a> Rev Sci Instrum. 68 (9), 3277-3295 (1997).</li><li>Arisholm, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=General+numerical+methods+for+simulating+second-order+nonlinear+interactions+in+birefringent+media.">General numerical methods for simulating second-order nonlinear interactions in birefringent media.</a> J Opt Soc Am B. 14 (10), 2543-2549 (1997).</li><li>Zhang, D. X., Kong, Y. F., Zhang, J. Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+parametric+properties+of+532-nm-pumped+beta-barium-borate+near+the+infrared+absorption+edge.">Optical parametric properties of 532-nm-pumped beta-barium-borate near the infrared absorption edge.</a> Opt Commun. 184 (5), 485-491 (2000).</li><li>Kato, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Temperature-tuned+90o+phase-matching+properties+of+LiB3O5.">Temperature-tuned 90o phase-matching properties of LiB3O5.</a> IEEE J Quant Electron. 30 (12), 2950-2952 (1994).</li><li>Fattahi, H. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=.">.</a> Third-generation femtosecond technology. , (2016).</li></ol>

著者は何も開示することはない。

発振器のターンキー動作は、レーザの様々な構成要素の最適な熱管理によって達成される。オシレータの出力は、余分なアラインメントや最適化を必要とせずに、毎日再現可能です。さらに、シードレーザのパルス間エネルギー安定性および空間指向安定性は、再生増幅器の安定動作を達成するための前提条件を満たしている。 ファイバ増幅器のような他の低エネルギーシード源を使用して増幅器をシードすることができる。この研究では、2μJのYb：YAGシンディスクKLMオシレータを使用して、蓄積された非線形相の成長を減少させることによって再生増幅器の増幅を支援しました。これは、より高い入力シードエネルギー。さらに、より高いシードエネルギーは、増幅プロセスに影響を及ぼし、ゲインの狭小化を低減する。増幅されたパルスの測定されたスペクトル帯域幅固定されたポンプ出力での異なる種エネルギーに対する変化を図5cに示す。増幅狭帯域化のため、増幅されたスペクトル帯域幅は、より低い種子エネルギーについて減少する。 10pJのシードエネルギーの場合、レーザは倍増する時間に動作し、往復回数を増やしても安定した動作に達することはできません。冷却システムの慎重な最適化とダイオードの電源供給に加えて、飽和時の再生増幅器の動作は、増幅器の達成された安定性において主要な役割を果たす。 レーザの基本波または第2高調波を用いてOPCPAシステムを励起することができる。 SHGについては、LBOとBBO結晶の性能は、大きな非線形係数と損傷閾値を提供するので、BBOの場合には空間的ウォークオフが大きく、利用可能な開口は限られているにもかかわらず、比較されている。 BBOの非線形係数がLBOのそれのほぼ2倍であるので、より短い結晶は、SHGの飽和限度に達するのに十分な程度である（ 図6a ）。累積非線形位相が28小さいしたがって、BBOは、より適切な選択です。 SHパルスのパルス持続時間は、異なる変換効率で実験的に特徴付けられる。高い変換効率では、SHGスペクトルが広がり、高次スペクトル相が現れることが観察された（ 図6 ）。したがって、変換効率が70％のケースBは、SHおよび変換されない基本ビームが優れた品質を維持する場合に選択されます。

高い繰返し率で高エネルギー、数サイクルレーザーパルスの生成は、直接利益を得るために立つようアト秒科学1、2、3、4、および高磁場物理5,6として適用分野に大きな関心がありますそのような情報源の入手可能性から。 OPCPAは、数パルスパルスを同時にサポートする高いパルスエネルギーと大きな増幅帯域幅を達成するための最も有望なルートです1 。現在までに、光媒介型チャープパルス増幅は、いくつかのサイクルのパルス7、8、9、10を生成する超広帯域の増幅を可能にします。しかしながら、ピコ秒スケールで短いポンプパルスを使用するOPCPA方式の修正された実施形態は、より高いパルスエネルギー及び少ないサイクルレジーム1、11、12の平均電力のためのこのアプローチは、スケーラブルとなります。短パルスポンプOPCPAのポンプ強度が高いため、シングルパス利得が高いため、非常に薄い結晶を使用して大きな増幅帯域幅をサポートできます。短パルス励起OPCPAには多くの利点があるが、このアプローチの実現可能性は、この目的のために特別に調整されたレーザの利用可能性に依存する。そのようなポンプレーザはMHz範囲13、14、15キロヘルツで反復速度で近回折限界ビーム品質を有する高エネルギーピコ秒パルスを送達するために必要とされます。 高いエネルギーおよび高い平均出力を有するピコ秒レーザパルスを送出することができる、異なる幾何学的形状のイッテルビウムドープレーザの導入、フィールド1、13、14、15、16、17、18の現在の状態を変更しようとしています。 Yb：YAGは優れた熱伝導率と長い上部寿命を持ち、費用対効果の高いダイオードレーザーでポンピングできます。シンディスクジオメトリで使用されたときのその性能は、ピークと平均電力を同時にスケーリングするための利得媒体の効率的な冷却のために際立っています。さらに、増幅プロセス中の利得媒体内での自己収束の発生は、他の利得媒体の形状と比較して薄いディスクの細長さのために抑制され、増幅されたパルスの優れた時間的および空間的プロファイルをもたらす。このコンセプトをCPAと組み合わせると、数百ミリジュールのエネルギーと数百個のピコ秒パルスを生成することができます平均パワー19、20ワット。 この作業の目的は、OPCPA 21を圧送するのに適した日常的な性能を備えたターンキーYb：YAG薄型ディスク再生アンプを実証することです。この目標を達成するために、この研究では、増幅プロセス中に蓄積された非線形位相を最小限に抑えるために増幅器をシードするために数マイクロジュールのパルスエネルギーを有するYb：YAG薄ディスク発振器22を使用する。このプロトコルは、他の場所で21説明されているレーザシステムを構築し、操作するためのレシピを提供します。コンポーネントの実装と制御ソフトウェアの詳細が提示され、システムのアライメントプロセスが説明されています。

<table><tbody><tr><td>&lt;strong&gt;Electrooptics&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Fiber-Coupled Diode Laser Module</td><td>Dilas Diodenlaser GmbH</td><td>M1F8H12-940.5-500C-IS11.34</td><td></td></tr><tr><td>Fiber-Coupled Diode Laser Module</td><td>Laserline GmbH</td><td>LDM1000-500</td><td></td></tr><tr><td>Power Supply for Diode Laser</td><td>Delta Elektronika B.V.</td><td>SM 15-100</td><td></td></tr><tr><td>Power Supply for Diode Laser</td><td>Delta Elektronika B.V.</td><td>SM 35-45</td><td></td></tr><tr><td>Pulse Picker&#039;s Driver</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>N/A, customized</td><td></td></tr><tr><td>Pockels Cell&#039;s Driver</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>N/A, customized</td><td></td></tr><tr><td>Pulse Picker&#039;s Driver Power Supply</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>PCD8m7</td><td></td></tr><tr><td>Pockels Cell&#039;s Driver Power Supply</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>PCD8m7</td><td></td></tr><tr><td>Delay Generator PCI</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>BME_SG08p</td><td></td></tr><tr><td>Splitter Box</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>N/A, customized</td><td></td></tr><tr><td>Resonant Preamplifier</td><td>Bergmann Messger&amp;auml;te Entwicklung KG&amp;nbsp;</td><td>BME_P03</td><td></td></tr><tr><td>Pulse Picker&#039;s crystal</td><td>Castech Inc.</td><td>N/A, customized</td><td>12*12*20 mm&amp;sup3;</td></tr><tr><td>Pockels Cell&#039;s crystal</td><td>Castech Inc.</td><td>N/A, customized</td><td>12*12*20 mm&amp;sup3;</td></tr><tr><td>&lt;strong&gt;Name&lt;/strong&gt;</td><td>&lt;strong&gt;Company&lt;/strong&gt;</td><td>&lt;strong&gt;Catalog Number&lt;/strong&gt;</td><td>&lt;strong&gt;Comments&lt;/strong&gt;</td></tr><tr><td>&lt;strong&gt;Optics&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Thin-disk</td><td>TRUMPF Scientific Lasers&amp;nbsp;</td><td>N/A, customized</td><td></td></tr><tr><td>Thin-disk Head</td><td>TRUMPF Scientific Lasers&amp;nbsp;</td><td>N/A, customized</td><td></td></tr><tr><td>Fiber</td><td>Frank Optic Products GmbH</td><td>N/A, customized</td><td></td></tr><tr><td>Fiber Objective</td><td>Edmund Optics GmbH</td><td>N/A, customized</td><td></td></tr><tr><td>Faraday Isolator</td><td>Electro-Optics Technology, Inc</td><td>EOT.189.12231</td><td></td></tr><tr><td>Faraday Rotator</td><td>Electro-Optics Technology, Inc</td><td>EOT.189.22040</td><td></td></tr><tr><td>Stretcher&#039;s Grating 1</td><td>Horiba Jobin Yvon GmbH</td><td>N/A, customized</td><td>60*40*10 mm&amp;sup3;</td></tr><tr><td>Stretcher&#039;s Grating 2</td><td>Horiba Jobin Yvon GmbH</td><td>N/A, customized</td><td>350*190*50 mm&amp;sup3;</td></tr><tr><td>Compressor&#039;s Grating 1</td><td>Plymouth Grating Laboratory, Inc.</td><td>N/A, customized</td><td>40*40*16 mm&amp;sup3;</td></tr><tr><td>Compressor&#039;s Grating 2</td><td>Plymouth Grating Laboratory, Inc.</td><td>N/A, customized</td><td>300*100*50 mm&amp;sup3;</td></tr><tr><td>HR Mirror, 1&quot; (1030nm), flat, 0&amp;deg;</td><td>Layertec GmbH</td><td>108060</td><td></td></tr><tr><td>HR Mirror, 1&quot; (1030nm), flat, 0&amp;deg;</td><td>Laseroptik GmbH</td><td>B-09965, S-04484</td><td></td></tr><tr><td>HR Mirror, 1&quot; (1030nm), flat, 45&amp;deg;</td><td>Layertec GmbH</td><td>108063</td><td></td></tr><tr><td>HR Mirror, 1&quot; (1030nm), flat, 45&amp;deg;</td><td>Laseroptik GmbH</td><td>B-09966, S-04484</td><td></td></tr><tr><td>HR Mirror, 1&quot; (1030nm), curved</td><td>Layertec GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>HR Mirror, 2&quot; (1030nm), flat, 0&amp;deg;</td><td>Laseroptik GmbH</td><td>B-09965, S-05474</td><td></td></tr><tr><td>HR Mirror, 2&quot; (1030nm), flat, 45&amp;deg;</td><td>Laseroptik GmbH</td><td>B-09966, S-05474</td><td></td></tr><tr><td>Thin Film Polarizer (1030nm), 2&quot;</td><td>Layertec GmbH</td><td>103930</td><td></td></tr><tr><td>Waveplate L/2 (1030nm)</td><td>Layertec GmbH</td><td>106058</td><td>&amp;Oslash;=25mm</td></tr><tr><td>Waveplate L/4 (1030nm)</td><td>Layertec GmbH</td><td>106060</td><td>&amp;Oslash;=25mm</td></tr><tr><td>AR Window (1030nm), wedge</td><td>Laseroptik GmbH</td><td>B-00183-01, S-00988</td><td>&amp;Oslash;=38mm</td></tr><tr><td>Output Coupler, 1&quot; (1030nm)</td><td>Layertec GmbH</td><td>N/A, customized</td><td>PR = 88 %</td></tr><tr><td>High-dispersion Mirror (1030nm)</td><td>UltraFast Innovations GmbH</td><td>N/A, customized</td><td>GDD = -3000 fs&amp;sup2;</td></tr><tr><td>Lens, 1&quot; (1030nm), Plano-Convex</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>Lens, 1&quot; (1030nm), Plano-Concave</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>Lens, 2&quot; (1030nm), Plano-Convex</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>Lens, 2&quot; (1030nm), Plano-Concave</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>HR Mirror, 1&quot; (515nm), flat, 0&amp;deg;</td><td>Layertec GmbH</td><td>129784</td><td></td></tr><tr><td>HR Mirror, 1&quot; (515nm), flat, 0&amp;deg;</td><td>Eksma Optics</td><td>042-0515-i0</td><td></td></tr><tr><td>HR Mirror, 1&quot; (515nm), flat, 45&amp;deg;</td><td>Layertec GmbH</td><td>110924</td><td></td></tr><tr><td>HR Mirror, 1&quot; (515nm), flat, 45&amp;deg;</td><td>Eksma Optics</td><td>042-0515</td><td></td></tr><tr><td>HR Mirror, 1&quot; (515nm), curved</td><td>Layertec GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>HR Mirror, 1&quot; (515nm), curved</td><td>Eksma Optics</td><td>N/A, customized</td><td>set</td></tr><tr><td>HR Mirror, 2&quot; (515nm), flat, 0&amp;deg;</td><td>Eksma Optics</td><td>045-0515-i0</td><td></td></tr><tr><td>HR Mirror, 2&quot; (515nm), flat, 45&amp;deg;</td><td>Eksma Optics</td><td>045-0515</td><td></td></tr><tr><td>Thin Film Polarizer (515nm), 2&quot;</td><td>Layertec GmbH</td><td>112544</td><td></td></tr><tr><td>Waveplate L/2 (515nm)</td><td>Layertec GmbH</td><td>112546</td><td>&amp;Oslash;=25mm</td></tr><tr><td>Lens, 1&quot; (515nm), Plano-Convex</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>Lens, 1&quot; (515nm), Plano-Concave</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>Kerr Medium</td><td>Meller Optics, Inc.</td><td>N/A, customized</td><td>Sapphire, 1mm</td></tr><tr><td>BBO Crystal</td><td>Castech Inc.</td><td>N/A, customized</td><td>7*7*1.5 mm&amp;sup3;</td></tr><tr><td>Harmonic Separator, 1&quot;, 45&amp;deg;</td><td>Eksma Optics</td><td>042-5135</td><td></td></tr><tr><td>Harmonic Separator, 2&quot;, 45&amp;deg;</td><td>Eksma Optics</td><td>045-5135</td><td></td></tr><tr><td>Silver Mirror, 1&quot;, flat</td><td>Thorlabs GmbH</td><td>PF10-03-P01</td><td></td></tr><tr><td>Silver Mirror, 1&quot;, curved</td><td>Eksma Optics</td><td>N/A, customized</td><td>set</td></tr><tr><td>Filter - Absorptive Neutral Density</td><td>Thorlabs GmbH</td><td>NE##A</td><td>set</td></tr><tr><td>Filter - Reflective Neutral Density</td><td>Thorlabs GmbH</td><td>ND##A</td><td>set</td></tr><tr><td>Filter - Round Continuously Variable</td><td>Thorlabs GmbH</td><td>NDC-50C-4M</td><td></td></tr><tr><td>Filter - Edgepass Filter (Longpass)</td><td>Thorlabs GmbH</td><td>FEL####</td><td>set</td></tr><tr><td>Filter - Edgepass Filter (Shortpass)</td><td>Thorlabs GmbH</td><td>FES####</td><td>set</td></tr><tr><td>Wedge</td><td>Thorlabs GmbH</td><td>N/A, customized</td><td>set</td></tr><tr><td>&lt;strong&gt;Name&lt;/strong&gt;</td><td>&lt;strong&gt;Company&lt;/strong&gt;</td><td>&lt;strong&gt;Catalog Number&lt;/strong&gt;</td><td>&lt;strong&gt;Comments&lt;/strong&gt;</td></tr><tr><td>&lt;strong&gt;Optomechanics &amp;amp; Motion&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Mirror Mount 1&quot; (small)</td><td>S. Maier GmbH</td><td>S1M4-##-1&amp;rdquo;</td><td></td></tr><tr><td>Mirror Mount 1&quot; (large)</td><td>S. Maier GmbH</td><td>S3-##</td><td></td></tr><tr><td>Mirror Mount 1&quot;</td><td>TRUMPF Scientific Lasers&amp;nbsp;</td><td>1&quot; adjustable&amp;nbsp;</td><td></td></tr><tr><td>Mirror Mount 2&quot;</td><td>S. Maier GmbH</td><td>S4-##</td><td></td></tr><tr><td>Mirror Mount 2&quot;</td><td>TRUMPF Scientific Lasers&amp;nbsp;</td><td>2&quot; adjustable&amp;nbsp;</td><td></td></tr><tr><td>Rotation Mount 1&amp;rdquo;</td><td>S. Maier GmbH</td><td>D25</td><td></td></tr><tr><td>Rotation Mount 1&amp;rdquo;</td><td>Thorlabs GmbH</td><td>RSP1/M</td><td></td></tr><tr><td>Rotation Mount 2&amp;rdquo;</td><td>Thorlabs GmbH</td><td>RSP2/M</td><td></td></tr><tr><td>Precision Rotation Stage</td><td>Newport Corporation</td><td>M-UTR120</td><td></td></tr><tr><td>Four-Axis Diffraction Grating Mount</td><td>Newport Corporation</td><td>DGM-1</td><td></td></tr><tr><td>Translation Stage</td><td>OptoSigma Corporation</td><td>TADC-651SR25-M6</td><td></td></tr><tr><td>Pockels cell stage</td><td>Newport Corporation</td><td>9082-M</td><td></td></tr><tr><td>Pockels Cell Holder</td><td>Home-made</td><td>N/A, customized</td><td></td></tr><tr><td>Picomotor Controller/Driver Kit</td><td>Newport Corporation</td><td>8742-12-KIT</td><td></td></tr><tr><td>Picomotor Piezo Linear Actuators</td><td>Newport Corporation</td><td>8301NF</td><td></td></tr><tr><td>Picomotor Rotation Mount</td><td>Newport Corporation</td><td>8401-M</td><td></td></tr><tr><td>Hand Control Pad</td><td>Newport Corporation</td><td>8758</td><td></td></tr><tr><td>&lt;strong&gt;Name&lt;/strong&gt;</td><td>&lt;strong&gt;Company&lt;/strong&gt;</td><td>&lt;strong&gt;Catalog Number&lt;/strong&gt;</td><td>&lt;strong&gt;Comments&lt;/strong&gt;</td></tr><tr><td>&lt;strong&gt;Light Analysis&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Beam Profiling Camera</td><td>Ophir Optronics Solutions Ltd</td><td>SP620</td><td></td></tr><tr><td>Beam Profiling Camera</td><td>DataRay Inc.</td><td>WCD-UCD23</td><td></td></tr><tr><td>Photodiodes (solw)</td><td>Thorlabs GmbH</td><td>DET10A/M</td><td></td></tr><tr><td>Photodiodes (fast)</td><td>Alphalas GmbH</td><td>UPD-200-SP</td><td></td></tr><tr><td>Thin-disk Camera</td><td>Imaging Development Systems GmbH</td><td>UI-2220SE-M-GL</td><td></td></tr><tr><td>Oscilloscope</td><td>Tektronix GmbH</td><td>DPO5204</td><td></td></tr><tr><td>Oscilloscope</td><td>Teledyne LeCroy GmbH</td><td>SDA 760Zi-A</td><td></td></tr><tr><td>Spectrometer</td><td>Avantes</td><td>AvaSpec-ULS3648-USB2</td><td></td></tr><tr><td>Spectrometer</td><td>Ocean Optics, Inc</td><td>HR4C1769</td><td></td></tr><tr><td>Spectrometer</td><td>Ocean Optics, Inc</td><td>HR4C3762</td><td></td></tr><tr><td>Spectrometer</td><td>Ocean Optics, Inc</td><td>HR4D464</td><td></td></tr><tr><td>Spectrometer</td><td>Ocean Optics, Inc</td><td>HR4D466</td><td></td></tr><tr><td>Laser Thermal Power Sensor</td><td>Ophir Optronics Solutions Ltd</td><td>L50(150)A-PF-35</td><td></td></tr><tr><td>Laser Thermal Power Sensor</td><td>Ophir Optronics Solutions Ltd</td><td>FL500A</td><td></td></tr><tr><td>Laser Thermal Power Sensor</td><td>Ophir Optronics Solutions Ltd</td><td>3A-P-V1</td><td></td></tr><tr><td>Power and Energy Meter</td><td>Ophir Optronics Solutions Ltd</td><td>Vega</td><td></td></tr><tr><td>&lt;strong&gt;Name&lt;/strong&gt;</td><td>&lt;strong&gt;Company&lt;/strong&gt;</td><td>&lt;strong&gt;Catalog Number&lt;/strong&gt;</td><td>&lt;strong&gt;Comments&lt;/strong&gt;</td></tr><tr><td>&lt;strong&gt;Systems&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Laser Beam Stabilization System</td><td>TEM-Messtechnik GmbH</td><td>Aligna</td><td></td></tr><tr><td>Laser M&amp;sup2; Measuring System</td><td>Ophir Optronics Solutions Ltd</td><td>M&amp;sup2;-200s</td><td></td></tr><tr><td>FROG</td><td>Home-made</td><td>N/A, customized</td><td></td></tr><tr><td>XFROG</td><td>Home-made</td><td>N/A, customized</td><td></td></tr><tr><td>&lt;strong&gt;Name&lt;/strong&gt;</td><td>&lt;strong&gt;Company&lt;/strong&gt;</td><td>&lt;strong&gt;Catalog Number&lt;/strong&gt;</td><td>&lt;strong&gt;Comments&lt;/strong&gt;</td></tr><tr><td>&lt;strong&gt;Miscellaneous&lt;/strong&gt;</td><td></td><td></td><td></td></tr><tr><td>Cooling Chiller</td><td>H.I.B Systemtechnik GmbH</td><td>6HE-000800-W-W-R23-2-DI</td><td></td></tr><tr><td>Cooling Chiller</td><td>Termotek GmbH</td><td>P201</td><td></td></tr><tr><td>Cooling Chiller</td><td>Termotek GmbH</td><td>P208</td><td></td></tr><tr><td>Laser Safety Goggles</td><td>Protect - Laserschutz GmbH</td><td>BGU 10-0165-G-20</td><td></td></tr><tr><td>Infra-red Viewer</td><td>FJW Optical Systems</td><td>84499A</td><td></td></tr><tr><td>Laser Viewing Card</td><td>Thorlabs GmbH</td><td>VRC4</td><td></td></tr><tr><td>Laser Viewing Card</td><td>Thorlabs GmbH</td><td>VRC5</td><td></td></tr><tr><td>Laser Viewing Card</td><td>Laser Components GmbH</td><td>LDT-1064 BG</td><td></td></tr><tr><td>Flowmeter</td><td>KOBOLD Messring GmbH</td><td>DTK-1250G2C34P</td><td></td></tr><tr><td>Pressure Gauge</td><td>KOBOLD Messring GmbH</td><td>EN 837-1</td><td></td></tr><tr><td>Temperature Sensor</td><td>KOBOLD Messring GmbH</td><td>TDA-15H* ***P3M</td><td></td></tr><tr><td>WinLase Software</td><td>Dr. C. Horvath &amp;amp; Dr. F. Loesel</td><td>WinLase Version 2.1 pro.</td><td>Laser Cavity Software</td></tr></tbody></table>

20 mj, 1 ps yb:yag thin-disk regenerative amplifier

これは、100 W、20 mJ、1 ps Yb：YAG薄型ディスク再生アンプに関するレポートです。手作りのYb：YAG薄ディスク、ターンキー性能とマイクロジュールレベルのパルスエネルギーを持つKerrレンズモードロック発振器を使用して、再生チャープパルス増幅器をシードします。アンプは気密ハウジング内に設置されています。これは室温で作動し、1％未満のパルス間安定性を有する5kHzの繰り返し速度で安定した動作を示す。厚さ1.5mmのベータバリウムホウ酸塩結晶を用いることにより、レーザー出力の周波数は515nmに倍増し、平均出力は70Wであり、光 - 光効率70％に相当する。この優れた性能により、システムは、近赤外および中赤外スペクトル範囲の光パラメトリックチャープパルス増幅器の魅力的なポンプ源になります。ターンキー性能と回生増幅器の優れた安定性を組み合わせることにより、システムは広帯域のCEP安定性の生成を容易にしますシード。 1つのレーザ源から光パラメトリックチャープパルス増幅（OPCPA）のシード及びポンプを提供することは、これらのパルス間の能動的時間同期の要求を排除する。この作品は、光パラメトリックチャープパルス増幅器のポンプ源として、チャープパルス増幅（CPA）に基づくYb：YAG薄型ディスク再生増幅器のセットアップと操作に関する詳細なガイドを提供します。

<html>この発振器は、1MHzのパルス幅で1％（rms）の安定性と0.6％未満のビーム指向の変動を伴い、11MHzの繰返し率で350fs、2μJ、25Wのパルスを出力します （ 図4 ）。 <img alt="図4" class="xfigimg" src="/files/ftp_upload/55717/55717fig4.jpg" /> 図4 ：Yb：YAGシンディスク、カーレンズモード同期発振器 （ a ）発振器パルスのスペクトル（赤色）、検索された時間強度プロファイル（青色）、および空間プロファイル（インセット）。 （ b ）オシレータのSHG-FROG分光器の測定および検索。この図は、Fattahi et al。参照21からの許可を得て。&gt;この図の拡大版を見るには、ここをクリックしてください。 シードパルスは、再生増幅器内で125Wに増幅され、280nmで940nmの波長のCWファイバ結合ダイオードで励起され、47％の光対光学効率に対応する。アンプのパルス間安定度は1％未満で、連続運転10時間後の優れた長期安定性を示します。増幅されたビームが1のM 2（M 2 x = 1.08およびM 2 Y = 1.07）及び（FWHMで）1ピコ秒に圧縮後の優れた経時的プロファイル（ 図5）を用いて、優れた空間プロファイルを有します。 <img alt="図5" class="xfigimg" src="/files/ftp_upload/55717/55717fig5.jpg" /> 図5 ：回生アンプの特性出力とゲイン・ナローイング効果が得られます。 （ a ）連続運転10時間後の再生増幅器の平均出力の安定性。挿入：（ a-1 ）0.5時間の時間窓でその平均値に対する正規化電力。 （ a-2 ）回生増幅器の出力ビームプロファイル。 （ b ）グレーティング圧縮器の後の平均出力100Wでのレーザ出力パルスの増幅出力スペクトル（緑色）および取り出された時間強度（青色）。 （ c ）アンプ出力のシードエネルギー対スペクトル帯域幅（FWHM）と、ポンプ出力300Wでの同じ出力平均電力に対する必要なラウンドトリップ。この図は、Fattahi et al。参照21からの許可を得て。 <a href="https://ecsource-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/55717/55717fig5large.jpg" target="_blank">この図の拡大版を見るには、ここをクリックしてください。</a> 25を用いてSHGを分析した。次のパラメータを有する2つの異なる結晶が考慮された：1）13.7°の位相整合角および0.819pm / Vの非線形係数を有するタイプI、厚さ6mmのリチウムトリボレート（LBO）、および2） I型、23.4°の位相整合角と午後2時/ V 26、27の非線形係数と3mm厚BBO。 1030nmにおける1ps、20mJパルスおよび100GW / cm 2のピーク強度が、シミュレーションの入力として考慮された。シミュレーション結果から、BBOの性能はSHGのLBOの性能より優れていることが示された（ 図6 ）。 <img alt="図6" class="xfigimg" src="/files/ftp_upload/55717/55717fig6.jpg" /> 図6 ：2次高調波生成。 （ a ）シミュレートされたSHGENE厚さ6mmのLBO結晶と厚さ3mmのBBO結晶のためのrgy。 （ b ）アンプ出力の0.5mJ（黒）と20mJ（緑）を使用した厚さ1.5mmのBBO結晶における入力SHG効率対入力ポンプピーク強度。 （ c ）（ b ）の点A、B、およびCに対応する異なるSHG効率に対する、取り出されたスペクトル強度および（ d ）XFROG測定の群遅延。この図は、Fattahi et al。 、 参照21からの許可を得て。 <a href="https://ecsource-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/55717/55717fig6large.jpg" target="_blank">この図の拡大版を見るには、ここをクリックしてください。</a>

Watch this Scientific Journal Video about 20 mJ, 1 ps Yb:YAG Thin-disk Regenerative Amplifier at JoVE.com

20 mJ, 1 ps Yb:YAG Thin-disk Regenerative Amplifier

Yb：YAG薄ディスク再生増幅器に基づく高エネルギー、高出力光パラメトリックチャープパルス増幅器の動作のためのプロトコルがここに示されている。

20mJ、1ps Yb：YAGシンディスク再生アンプ

This is a report on a 100 W, 20 mJ, 1 ps Yb:YAG thin-disk regenerative amplifier. A homemade Yb:YAG thin-disk, Kerr-lens mode-locked oscillator with ...

20-mj-1-ps-ybyag-thin-disk-regenerative-amplifier
