1. Sample preparation
<ol>
	<li>Obtain 3 nm, 20 nm, 40 nm, 70 nm, 100 nm, 200 nm, and 500 nm nickel powder from commercial sources (see Table of Materials). The morphology characterization is shown in Figure 1.</li>
	<li>Prepare 8 nm nickel particles by heating 3 nm nickel particles using a reaction kettle (see Table of Materials).
	<ol>
		<li>Put ~20 mL of absolute ethanol and ~50 mg of 3 nm nickel powder into the reaction kettle. NOTE: The whole solution should not reach ~70% of the kettle volume.</li>
		<li>Heat the reaction kettle at 80 &#176;C for 24 h.</li>
		<li>Cool the solution to room temperature and drop a little solution to one copper mesh (TEM grid, see Table of Materials).</li>
		<li>Put the dried copper mesh into the Transmission Electron Microscopy (TEM) chamber and observe the sample morphology under 200 kV voltage electron beam.
		NOTE: The copper mesh was air-dried for ~5 min or used a drying light of 5 min.</li>
		<li>Measure the particle size distribution from the TEM images manually.
		NOTE: The particle size measurement can also be done using any freely available software such as Image J.</li>
		<li>Take out the solution and vaporize the ethanol at room temperature; then, the rest of the black solid is the pure nickel powder with an average particle size of 8 nm.</li>
	</ol>
	</li>
	<li>Prepare 12 nm nickel powder
	<ol>
		<li>Repeat step 1.2, but change the &#34;absolute ethanol&#34; and &#34;80 &#176;C for 24 h&#34; to &#34;absolute isopropanol&#34; and &#34;150 &#176;C for 12 h&#34; to obtain the pure nickel powder with the average particle of 12 nm.</li>
	</ol>
	</li>
</ol>
2. High-pressure radial DAC XRD measurements
<ol>
	<li>Make X-ray transparent boron-epoxy gasket utilizing a laser drilling machine (see Table of Materials).
	<ol>
		<li>Prepare Kapton (a kind of plastic) supporting gaskets
		NOTE: Kapton is a polyimide film material (see Table of Materials).
		<ol>
			<li>Cut the inner circle with a laser drilling machine using the mentioned parameters: 35% laser power, three passes, 0.4 mm/s (cutting speed).</li>
			<li>Cut the outer rectangular using the parameters: 80% of laser power, two passes, 1.2 mm/s (cutting speed). The rectangular dimension is 8 x 1.4 mm.</li>
		</ol>
		</li>
		<li>Prepare boron-epoxy gaskets from a larger boron disc with a diameter of ~10 mm.
		NOTE: The boron disc is made by compressing the mixture of amorphous boron powder and epoxy glue36.
		<ol>
			<li>Polish the raw discs to a thickness of 60-100 &#181;m with sandpaper manually.
			NOTE: The sandpaper is from ~400 mesh to ~1000 mesh.</li>
			<li>Cut the inner circles with a laser drilling machine using the mentioned parameters: 35% laser power, three passes, 0.4 mm/s (cutting speed).</li>
			<li>Cut the outer circle with a laser drilling machine: 30% of laser power, one pass, 0.4 mm/s (cutting speed). Repeat and stop immediately when it comes off.</li>
		</ol>
		</li>
		<li>Assemble the gaskets
		<ol>
			<li>Place a Kapton supporting gasket (prepared in step 2.1.1) on a glass slide.</li>
			<li>Place a drilled boron gasket on the inner hole of the Kapton gasket. Ensure that the larger end of the boron gasket is at the top.</li>
			<li>Put another clean glass slide on the top. Hold it firmly and press it till the gasket is firmly inserted in the hole of Kapton gasket.</li>
			<li>Store the fabricated gasket assemblies between two clean glass slides and wrap them with glue tape for future use.
			NOTE: The gasket diameter, &#216; = diamond culet size + 150 &#181;m. For better reproducibility, the same setups can be used (possibly with small adjustments if something is found wrong) for the laser drilling and cutting during the gasket preparation. For good size matching, the diameter of gaskets entered for laser cutting is &#216; + 23 &#181;m while the diameter of the inner hole of the Kapton supporting gaskets (entered for laser cutting) is &#216; - 23 &#181;m.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>Radial DAC experiment loading
	<ol>
		<li>Mount the gasket assembly
		<ol>
			<li>On the viewing computer monitor (connected to the optical microscope), mark a dot to locate the center of the diamond (the piston diamond of the DAC).</li>
			<li>Mount the boron-epoxy gasket (prepared in step 2.1) and the mark at the center of the gasket hole.</li>
			<li>Use a glass slide to press down the gasket assembly such that the gasket firmly sets on the diamond of the piston.
			NOTE: A DAC has two identical pieces of diamonds. Generally, the upper one is called cylinder diamond, and the lower one is called piston diamond.</li>
		</ol>
		</li>
		<li>Cleaning and compacting the gasket setup
		<ol>
			<li>Load samples with a chunk size smaller than the gasket hole such that there is no overflow of materials on the gasket surface.
			NOTE: The samples here mean the candidate materials that we studied in our experiments. In this study, the samples are different-sized Ni powders and Pt chips.</li>
			<li>Close the cell after the loading of a new piece of sample to achieve compactness.</li>
		</ol>
		</li>
		<li>Loading of soft materials (such as gold)
		<ol>
			<li>Load only one piece of the soft sample (make the soft material as a small fraction of the loaded materials).</li>
			<li>Use hard amorphous materials to fill up the gasket hole for good compactness.</li>
		</ol>
		</li>
		<li>Loading of low atomic number materials (such as spinel, pyrope, serpentine)
		<ol>
			<li>Mix the sample with 10% Pt or Au. Fill up the gasket hole with the mixture but without overflow.</li>
			<li>If necessary, put hard amorphous materials on the top for good compactness.</li>
		</ol>
		</li>
	</ol>
	</li>
	<li>X-ray diffraction study
	<ol>
		<li>Mount the X-ray transparent boron-Kapton gasket (prepared in step 2.1) with a thickness of 100 &#181;m and a chamber hole of 60 &#181;m on the top of 300 &#181;m culet of DAC with the support of the clays.</li>
		<li>Place a small piece of Pt chip on top of the Ni sample as a pressure calibrant.
		NOTE: No pressure medium was used to maximize the differential stress between the axial and radial.</li>
		<li>Use a monochromatic synchrotron X-ray (see Table of Materials) with an energy of 25 or 30 keV to conduct the x-ray diffraction experiments.</li>
		<li>Focus the X-ray beam to ~30 x 30 &#181;m2 surface area on the sample.</li>
		<li>Collect the X-ray diffraction patterns at pressure intervals of 1-2 GPa by a two-dimension image plate (see Table of Materials) with a resolution of 100 &#181;m/pixel. The setup used is shown in Figure 2 and Figure 3.</li>
	</ol>
	</li>
	<li>The experimental data analysis
	<ol>
		<li>Process each X-ray diffraction image into a file containing 72 spectra over 5&#176; azimuthal steps using Fit2d37,38,39,40,41,42.
		NOTE: A two-dimensional diffraction image contains 360&#176; information. To analyze the stress and texture information, it is needed to separate into 72 files with 5&#176; azimuthal information contained in each one. Fit2d is the software used to analyze X-ray diffraction data37,38,39,40,41,42.</li>
		<li>Refine the diffraction pattern with the Rietveld method in the MAUD37 software. The lattice strain of each lattice plane was obtained by fitting the pattern37,40.</li>
		<li>Calculate the differential stress and yield strength according to the lattice strain theory38 and von Mises yield criterion38,39 following step 2.5.</li>
	</ol>
	</li>
	<li>The lattice strain theory for the experimental data analysis
	<ol>
		<li>Determine the differential stress (the difference between these maximum (&#963;22 = &#963;33) and minimum stress (&#963;11) components) that provides a lower-bound estimate of a material&#39;s yield strength38, &#963;y, based on the von Mises yield criterion following equation (1)38:
		(1)&#160;t= &#963;11-&#963;33&#60;2&#964;= &#963;y.</li>
		<li>Obtain the direction-dependent deviatoric strain Qhkl by measuring the d-spacings from different diffraction directions by following equation (2)38:
		(2) <img alt="Equation 1" src="/files/ftp_upload/61819/61819eq01.jpg" />
		where d0&#176; and d90&#176; are the d-spacings measured from &#936; = 0&#176; and &#936; = 90&#176; (the angle between the diffraction vector and load axis), respectively.</li>
		<li>Then, derive the value of t using equation (3)38:
		<img alt="Equation 2" src="/files/ftp_upload/61819/61819eq02.jpg" />
		where GR(hkl) and Gv are the shear modulus of the aggregates under the Reuss (iso-stress) condition and Voigt (iso-strain) condition, respectively; &#945; is the factor to determine the relative weight of Reuss and Voigt conditions40.
		NOTE: Considering the current experiments&#39; complicated stress/strain conditions, &#945; = 0.5 is used in this study.</li>
		<li>For a cubic system, calculate GR(hkl) and Gv as follows using equations 4-638,40,41:
		(4) <img alt="Equation 3" src="/files/ftp_upload/61819/61819eq03.jpg" />
		(5) <img alt="Equation 4" src="/files/ftp_upload/61819/61819eq04.jpg" />
		(6) <img alt="Equation 5" src="/files/ftp_upload/61819/61819eq05.jpg" />
		where Sij are the single crystal elastic compliances and can be obtained from the elastic stiffness constants Cij of materials.</li>
	</ol>
	</li>
</ol>
3. TEM measurements
<ol>
	<li>Prepare thin pressurized Ni foils for TEM using a focused ion beam (FIB) system (see Table of Materials). To reduce possible artifacts during ion milling of the specimen, deposit a protective Pt layer using the Pt gun equipped in the SEM with a thickness of ~1 &#181;m on the candidate region.</li>
	<li>Perform TEM measurements on a 300 kV aberration-corrected transmission electron microscope equipped with high angle annular dark-field (HAADF) and bright-field (BF) detectors.</li>
	<li>Take high-resolution TEM images.</li>
</ol>

The authors have nothing to disclose.

Computational simulations have been widely employed to study the grain size effect on the strength of nanometals5,6,16,17,27,42. Perfect dislocations, partial dislocations, and GB deformation have been proposed to play decisive roles in the deformation mechanisms of the nanomaterials. In a molecular dynamics simulation, Yamak...

The resistance to plastic deformation determines the materials&#39; strength. The strength of the metals usually increases with the decreasing grain sizes. This size strengthening phenomenon can be well illustrated by the traditional Hall-Petch relationship theory from the millimeter down to submicron regime1,2, which is based on the dislocation-mediated deformation mechanism of bulk-sized metals, i.e., dislocations pile up at grain boundaries (GBs) and hinder their motions, leading to the mechanical strengthening in metals3,4.
In contrast, mechanical softening, often referred to as the inverse Hall-Petch relationship, has been reported for fine nanometals in the last two decades5,6,7,8,9,10. Therefore, the strength of the nanometals is still puzzling as continuous hardening was detected for grain sizes down to ~10 nm11,12, while the cases of size softening below 10 nm regime were also reported7,8,9,10. The main difficulty or challenge for this debated topic is to make statistically reproducible measurements on the mechanical properties of ultrafine nanometals and establish a reliable correlation between the strength and grain size of the nanometals. Another part of the difficulty comes from the ambiguity in the plastic deformation mechanisms of the nanometals. Various defects or processes at nanoscale have been reported, including dislocations13,14, deformation twinning15,16,17, stacking faults15,18, GB migration19, GB sliding5,6,20,21, grain rotation22,23,24, atomic bond parameters25,26,27,28, etc. However, which one dominates the plastic deformation and thus determines the strength of nanometals is still unclear.
For these above issues, traditional approaches of mechanical strength examining, such as tensile test29, Vickers hardness test30,31, nano-indentation test32, micropillar compression33,34,35, etc. are less effective because the high quality of large pieces of nanostructured materials is so difficult to fabricate and conventional indenter is much larger than single nanoparticle of materials (for the single-particle mechanics). In this study, we introduce radial DAC XRD techniques36,37,38 to material science to in situ track the yield stress and deformation texturing of nano nickel of various grain sizes, which are used in the geoscience field in previous studies. It has been found that the mechanical strengthening can be extended down to 3 nm, much smaller than the previously reported most substantial sizes of nanometals, which enlarges the regime of conventional Hall-Petch relationship, implying the significance of rDAC XRD techniques to material science.

<table><tbody><tr><td>20 nm Ni</td><td>Nanomaterialstore</td><td>SN1601</td><td>Flammable</td></tr><tr><td>3 nm Ni</td><td>nanoComposix</td><td></td><td>Flammable</td></tr><tr><td>40, 70, 100, 200, 500 nm Ni</td><td>US nano</td><td>US1120</td><td>Flammable</td></tr><tr><td>Absolute ethanol</td><td></td><td></td><td>as the solution to make 8 nm Ni</td></tr><tr><td>Absolute isopropanol</td><td></td><td></td><td>as the solution to make 12 nm Ni</td></tr><tr><td>Amorphous boron powder</td><td>alfa asear</td><td></td><td></td></tr><tr><td>Copper mesh</td><td>Beijing Zhongjingkeyi Technology Co., Ltd.</td><td></td><td>TEM grid</td></tr><tr><td>Epoxy glue</td><td></td><td></td><td></td></tr><tr><td>Ethanol</td><td></td><td></td><td>clean experimental setup</td></tr><tr><td>Focused ion beam</td><td>FEI</td><td></td><td></td></tr><tr><td>Glass slide</td><td></td><td></td><td></td></tr><tr><td>Glue tape</td><td>Scotch</td><td></td><td></td></tr><tr><td>Kapton</td><td>DuPont</td><td></td><td>Polyimide film material</td></tr><tr><td>Laser drilling machine</td><td></td><td></td><td>located in high pressure lab of ALS</td></tr><tr><td>Monochromatic synchrotron X-ray</td><td>Beamline 12.2.2, Advanced Light Source (ALS), Lawrence Berkeley National Laboratory</td><td></td><td>X-ray energy: 25-30 keV</td></tr><tr><td>Optical microscope</td><td>Leica</td><td></td><td>to mount the gasket and load samples</td></tr><tr><td>Pt powder</td><td>thermofisher</td><td>38374</td><td></td></tr><tr><td>Reaction kettle</td><td>Xian Yichuang Co.,Ltd.</td><td></td><td>50 mL</td></tr><tr><td>Sand paper</td><td></td><td></td><td>from 400 mesh to 1000 mesh</td></tr><tr><td>Transmission Electron Microscopy</td><td>FEI</td><td></td><td>Titan G2 60-300</td></tr><tr><td>Two-dimension image plate</td><td>ALS, BL 12.2.2</td><td></td><td>mar 345</td></tr></tbody></table>

determining the mechanical strength of ultra-fine-grained metals

The mechanical strengthening of metals is the long-standing challenge and popular topic of materials science in industries and academia. The size dependence of the strength of the nanometals has been attracting a lot of interest. However, characterizing the strength of materials at the lower nanometer scale has been a big challenge because the traditional techniques become no longer effective and reliable, such as nano-indentation, micropillar compression, tensile, etc. The current protocol employs radial diamond-anvil cell (rDAC) X-ray diffraction (XRD) techniques to track differential stress changes and determine the strength of ultrafine metals. It is found that ultrafine nickel particles have more significant yield strength than coarser particles, and the size strengthening of nickel continues down to 3 nm. This vital finding immensely depends on effective and reliable characterizing techniques. The rDAC XRD method is expected to play a significant role in studying and exploring nanomaterial mechanics.

Under hydrostatic compression, unrolled X-ray diffraction lines should be straight, not curved. However, under non-hydrostatic pressure, the curvature (ellipticity of the XRD rings, which translates into the non-linearity of the lines plotted along the azimuth angle) significantly increases ultrafine-grained-nickel at similar pressures (Figure 4). At a similar pressure, the differential strain of the 3 nm sized nickel is the highest. The mechanical strength results (stress-strain curves) are...

Watch this Scientific Journal Video about Determining the Mechanical Strength of Ultra-Fine-Grained Metals at JoVE.com

Determining the Mechanical Strength of Ultra-Fine-Grained Metals

The protocol presented here describes the high-pressure radial diamond-anvil-cell experiments and analyzing the related data, which are essential for obtaining the mechanical strength of the nanomaterials with a significant breakthrough to the traditional approach.

The mechanical strengthening of metals is the long-standing challenge and popular topic of materials science in industries and academia. The size ...
