This project was funded by AFM-Telethon and A Foundation Building Strength for Nemaline Myopathies. The authors wish to acknowledge the creator of the products mentioned in this article, IONOptix Inc.

<ol>
	<li>Winter, J. M., Ottenheijm, C. A. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Sarcomere+Dysfunction+in+Nemaline+Myopathy.">Sarcomere Dysfunction in Nemaline Myopathy.</a> J. Neuromuscular. Disease. 4, 99-113 (2017).</li><li>Colomo, F., Piroddi, N., Poggesi, C., te Kronnie, G., Tesi, C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Active+and+passive+forces+of+isolated+myofibrils+from+cardiac+and+fast+skeletal+muscle+of+the+frog.">Active and passive forces of isolated myofibrils from cardiac and fast skeletal muscle of the frog.</a> Journal of Physiology. 500, 535-548 (1997).</li><li>Kulke, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=a+major+source+of+myofibrillar+stiffness+in+Drosophila+indirect+flight+muscle.">a major source of myofibrillar stiffness in Drosophila indirect flight muscle.</a> Journal of Cell Biology. 154, 1045-1057 (2001).</li><li>Stehle, R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Isometric+force+kinetics+upon+rapid+activation+and+relaxation+of+mouse,+guinea+pig+and+human+heart+muscle+studied+on+the+subcellular+myofibrillar+level.">Isometric force kinetics upon rapid activation and relaxation of mouse, guinea pig and human heart muscle studied on the subcellular myofibrillar level.</a> Basic Research in Cardiology. 97, 127-135 (2002).</li><li>Iorga, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Micromechanical+function+of+myofibrils+isolated+from+skeletal+and+cardiac+muscles+of+the+zebrafish.">Micromechanical function of myofibrils isolated from skeletal and cardiac muscles of the zebrafish.</a> Journal of General Physiology. 137, 255-270 (2011).</li><li>Ribeiro, P. A. B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Contractility+of+myofibrils+from+the+heart+and+diaphragm+muscles+measured+with+atomic+force+cantilevers:+Effects+of+heart-specific+deletion+of+arginyl-tRNA-protein+transferase.">Contractility of myofibrils from the heart and diaphragm muscles measured with atomic force cantilevers: Effects of heart-specific deletion of arginyl-tRNA-protein transferase.</a> International Journal of Cardiology. 168, 3564-3571 (2013).</li><li>Joureau, B., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dysfunctional+sarcomere+contractility+contributes+to+muscle+weakness+in+ACTA1-related+nemaline+myopathy+(NEM3).">Dysfunctional sarcomere contractility contributes to muscle weakness in ACTA1-related nemaline myopathy (NEM3).</a> Annals of Neurology. 83, 269-282 (2018).</li><li>de Souza Leite, F., Minozzo, F. C., Altman, D., Rassier, D. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Microfluidic+perfusion+shows+intersarcomere+dynamics+within+single+skeletal+muscle+myofibrils.">Microfluidic perfusion shows intersarcomere dynamics within single skeletal muscle myofibrils.</a> Proceedings of the National Academy of Sciences of the United States of America. 114, 8794-8799 (2017).</li><li>Shalabi, N., Cornachione, A., de Souza Leite, F., Vengallatore, S., Rassier, D. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Residual+force+enhancement+is+regulated+by+titin+in+skeletal+and+cardiac+myofibrils.">Residual force enhancement is regulated by titin in skeletal and cardiac myofibrils.</a> Journal of Physiology. 595, 2085-2098 (2017).</li><li>Cornachione, A. S., Leite, F., Bagni, M. A., Rassier, D. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+increase+in+non-cross-bridge+forces+after+stretch+of+activated+striated+muscle+is+related+to+titin+isoforms.">The increase in non-cross-bridge forces after stretch of activated striated muscle is related to titin isoforms.</a> American Journal of Physiology - Cell Physiology. 310, 19-26 (2016).</li><li>Labuda, A., Brastaviceanu, T., Pavlov, I., Paul, W., Rassier, D. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Optical+detection+system+for+probing+cantilever+deflections+parallel+to+a+sample+surface.">Optical detection system for probing cantilever deflections parallel to a sample surface.</a> Review of Scientific Instruments. 82, 013701 (2011).</li><li>Chavan, D., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ferrule-top+nanoindenter:+an+optomechanical+fiber+sensor+for+nanoindentation.">Ferrule-top nanoindenter: an optomechanical fiber sensor for nanoindentation.</a> Review of Scientific Instruments. 83, 115110 (2012).</li><li>Beekmans, S. V., Iannuzzi, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+metrological+approach+for+the+calibration+of+force+transducers+with+interferometric+readout.">A metrological approach for the calibration of force transducers with interferometric readout.</a> Surface Topography: Metrology and Properties. 3, (2015).</li><li>van Hoorn, H., Kurniawan, N. A., Koenderink, G. H., Iannuzzi, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Local+dynamic+mechanical+analysis+for+heterogeneous+soft+matter+using+ferrule-top+indentation.">Local dynamic mechanical analysis for heterogeneous soft matter using ferrule-top indentation.</a> Soft Matter. 12, 3066-3073 (2016).</li><li>Winter, J. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=KBTBD13+is+an+actin-binding+protein+that+modulates+muscle+kinetics.">KBTBD13 is an actin-binding protein that modulates muscle kinetics.</a> Journal of Clinical Investigation. , (2019).</li><li>Winter, J. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mutation-specific+effects+on+thin+filament+length+in+thin+filament+myopathy.">Mutation-specific effects on thin filament length in thin filament myopathy.</a> Annals of Neurology. 79, 959-969 (2016).</li><li>Ottenheijm, C. A. C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Deleting+exon+55+from+the+nebulin+gene+induces+severe+muscle+weakness+in+a+mouse+model+for+nemaline+myopathy.">Deleting exon 55 from the nebulin gene induces severe muscle weakness in a mouse model for nemaline myopathy.</a> Brain. 136, 1718-1731 (2013).</li><li>Ribeiro, P. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Contractility+of+myofibrils+from+the+heart+and+diaphragm+muscles+measured+with+atomic+force+cantilevers:+effects+of+heart-specific+deletion+of+arginyl-tRNA-protein+transferase.">Contractility of myofibrils from the heart and diaphragm muscles measured with atomic force cantilevers: effects of heart-specific deletion of arginyl-tRNA-protein transferase.</a> International Journal of Cardiology. 168, 3564-3571 (2013).</li><li>Pinniger, G. J., Bruton, J. D., Westerblad, H., Ranatunga, K. W. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+a+Myosin-II+Inhibitor+(N-benzyl-p-toluene+Sulphonamide,+BTS)+on+Contractile+Characteristics+of+Intact+Fast-twitch+Mammalian+Muscle+Fibres.">Effects of a Myosin-II Inhibitor (N-benzyl-p-toluene Sulphonamide, BTS) on Contractile Characteristics of Intact Fast-twitch Mammalian Muscle Fibres.</a> Journal of Muscle Research and Cell Motililty. 26, 135-141 (2005).</li><li>Stehle, R., Kr&#252;ger, M., Pfitzer, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Force+kinetics+and+individual+sarcomere+dynamics+in+cardiac+myofibrils+after+rapid+Ca(2+)+changes.">Force kinetics and individual sarcomere dynamics in cardiac myofibrils after rapid Ca(2+) changes.</a> Biophysics Journal. 83, 2152-2161 (2002).</li><li>Najafi, A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=End-diastolic+force+pre-activates+cardiomyocytes+and+determines+contractile+force:+role+of+titin+and+calcium.">End-diastolic force pre-activates cardiomyocytes and determines contractile force: role of titin and calcium.</a> Journal of Physiology. 597, 4521-4531 (2019).</li></ol>

Michiel Helmes is shareholder and co-owner of IONOptix Inc.

Described is a protocol to assess the contractile function of myofibrils isolated from human or animal skeletal muscle tissues. The force resolution of this setup has been described before by Chavan et al.12. In short, it is determined by the random fluctuations of the length of the Fabry-P&#233;rot cavity formed between the detection fiber and the cantilever, which produce the dominant part of the noise at the output of the readout (expressed in V) that, multiplied by the deflection sensitivity (expressed in m/V) and by the spring constant of the cantilever (expressed in N/m), provides the force noise. For our setup, the root mean square (rms) noise in air at the output of the readout, sampled at a 1,000 data points/s (sample/s), is approximately 2 mV. For a typical myofibril measurement, a ferrule-top probe is used with a spring constant of ~0.7 N/m (deflection sensitivity &#8764;300 nm/V). This rms value corresponds to a cantilever deflection resolution of 0.6 nm, which translates to a force sensitivity of ~0.37 nN. The force probe is calibrated by pushing the tip of the mounting needle against a weighing scale while keeping the bending of the cantilever equal to a multiple of the wavelength of the readout laser13. This method of calibration entails both the cantilever and mounting needle stiffness as well as possible variations in torque of the cantilever and mounting needle due to speed and magnitude of myofibril contraction. Currently, a setup for assessing myofibril contractility is available, which is based on the detection of a laser deflected from the cantilever, i.e., optical beam deflection (1,700 A; ~1 nN force resolution). This system was developed by Labuda et al. using an optical periscope to guide a laser light towards and away from the cantilever in constraining configurations11. In this system, a myofibril is mounted between the atomic force cantilever and a rigid glass needle. An advantage of the system described here is the higher force sensitivity and signal-to-noise ratio. Furthermore, in this setup, relatively stiff cantilevers can be used, which results in small cantilever deflection when myofibrillar force is applied. This is important, as it allows for force measurements at nearly constant sarcomere length. Finally, compared to the system described by Labuda et al., the system here utilizes similar or identical methods to control the temperature, to induce length changes on the myofibril, and to change the perfusion solutions using a &#415;-glass and fast-step motor. The advantage of the system described by Labuda et al. is that a change of solution composition (between cantilever and optical periscope) does not affect the signal output. In the system described here, the solution composition between cantilever and optical fiber must remain constant. The solution to this limitation is described in more detail below.
Optimization
The optical force probe in combination with the fast-step perfusion system led to complications. The difference in optical properties between low and high concentration Ca2+ solutions interferes with the force measurements. To prevent backflow of the high calcium solution, a custom flow chamber was engineered (Figure 3). A constant background flow of calcium-free solution is induced from right to left to keep the solution constant between the top of the optical fiber and the cantilever (Figure 3D).
To control the temperature, a Peltier element with liquid cooling is mounted on the flow chamber. This flow chamber is thermally uncoupled from the microscope by mounting it on a plastic adapter. With the Peltier element, controlled by a TEC system, it is possible to control the temperature of the solution over time with 0.1 &#176;C precision. Temperature is monitored by a temperature sensor mounted on the flow chamber. Temperature stability is important due to the nature of the force transducer. The cantilever consists of a gold-coated glass strip, effectively making it a thermometer. Thus, the cantilever bends with temperature changes.
The setup uses a fast-step perfusion system (see Table of Materials) to control the movement of the &#415;-glass. This system allows for perfusion switches within 10 ms. Combining the method of temperature control and solution switching makes this system particularly suitable to measure the kinetics of sarcomere contractility (i.e., rates of force development, tension redevelopment, and relaxation) in myofibrils.
Initially, the downside of using interferometry was the small usable range due to the necessity to use the linear part of the interference curve (&#955;/8, with &#955; being the wavelength of the laser). However, recent innovations eliminated this need by combining wavelength modulation with a lock-in amplifier. Therefore, the system is not limited to a single linear part of the interference curve. This enables the measurement of infinite deflection of the cantilever14. Thus, the range of cantilever deflection readout of this system is greatly enlarged compared to traditional interferometry. Additionally, the force probes described are easy to replace and there are many cantilevers available, with stiffnesses ranging from 0.5 N/m to &#62;20 N/m. Therefore, it is possible to quickly change between cantilevers and select the stiffness most suitable for the experiment conducted.
Challenges
The current system is a prototype based on a cardiomyocyte measuring system (see Table of Materials). Several components can be improved to provide a better user experience and data of higher quality. First, due to add-ons to the system, vibration and resonance can be an issue that will add noise to the signal. Also, the &#415;-glass holder and fast-step motor attachment method could be improved to make it less prone to vibration.
Second, it is desirable to replace the fast-step motor with a piezo length actuator to increase the speed of solution switching and to obtain a more consistent motion.
Third, the calcium solutions we previously used to activate single striated muscle fibers included propionic acid, but these solutions absorb near-infrared light, interfering with the force measurements. Calcium chloride was used to eliminate the need for propionic acid, which greatly reduced this effect. This issue is inherent to a system based on interferometry and not present when utilizing optical beam deflection.
Fourth, a custom flow bath was engineered to create a laminar flow, to match the flow of the &#415;-glass. This prevents backflow due to turbulence of the calcium-rich solution. Therefore, the solution between the tip of the optical fiber and the cantilever remains constant. The coverslip with the myofibrils can move freely under the flow chamber and therefore, selection of suitable myofibrils is not confined to the small area of the flow chamber.
Reproducibility and variability
There are several elements of the system and protocol that are important for the degree of reproducibility and variability of the data obtained.
First, the quality of the measurements strongly depends on the quality of the myofibril isolation. Identical protocols yield different qualities and quantities of myofibrils from different biopsies. In some cases, biopsies barely yield usable myofibrils or none at all. Common consensus is that damaged myofibrils will break during contraction and thus are not accounted for in the results.
Second, there is uncertainty in the determination of the cross-sectional area of the myofibril. Due to technical constraints, it is possible to measure the width of the myofibril in only one plane. Therefore, to calculate the cross-sectional area we assume that the width and depth are equal. When force is normalized to a cross-sectional area to calculate maximal active tension, one should be aware of this assumption.
Mounting of myofibrils due to myofibril mounting angle, position, and the integrity of the glue.
Although mounting angle and position can largely be controlled visually, small variations between myofibrils might be present. Glue integrity has not been investigated extensively. However, glue integrity can be verified by monitoring the sarcomere length in the myofibril before and after activation. When more sarcomeres are between the glue after a protocol, this suggests that slippage of the myofibril in the glue has occurred. Consequently, this myofibril should be excluded from the dataset.
Other applications of the setup: Calcium preactivation in cardiomyocytes isolated from rat left ventricle
In addition to assessing the contractile function of myofibrils, the system can also be used to measure cardiomyocyte mechanics. For example, Figure 11 illustrates the use of membrane-permeabilized single cardiomyocytes isolated from rat left ventricle21. Contrary to the experiments described above, relaxing solution was changed and activating solution was kept constant. Each cardiomyocyte underwent five sets of activations, exposing it to a 2 &#181;M free calcium solution for 1 s. The 1 s time constraint is chosen to mimic the time-limited nature of cardiac contractions, where the exposure to low calcium concentration solutions mimics the diastolic phase and the exposure to high calcium concentration solutions mimics the systolic phase of cardiac muscle contraction (Figure 11A). For each of the five sets diastolic calcium was varied (1, 80, 160, 250, and 400 nM calcium), while systolic calcium remained constant (Figure 11A). A set consisted of two sets of three activation-relaxation cycles at 1.8 &#181;m versus 2.0 &#181;m and 2.0 &#181;m versus 2.2 &#181;m for different experimental groups. Peak force was measured at 1 s from the switch of the pipette and averaged for the set of three activation-relaxation cycles. The high signal-to-noise ratio and the high dynamic range of this force transducer allowed us to measure both the small changes in diastolic force and the much larger systolic forces (Figure 11B). Increasing diastolic calcium resulted in a higher force at 2 &#181;M calcium relative to the first activation (Figure 11B). WT rat cardiomyocytes were compared with heterozygous (HET) RMB20 rat cardiomyocytes. Due to alternative splicing, HET rats have a more compliant titin protein as compared to the WT rats. The effect was exaggerated in HET cardiomyocytes at 80 and 160 &#181;M calcium (Figure 11C).

Striated muscle cells are indispensable for daily life activities. Limb movement, respiratory function, and the pumping motion of the heart rely on the force generated by muscle cells. Skeletal muscle consists of muscle fascicles containing bundles of single muscle fibers (Figure 1A). These muscle fibers are comprised of myofibrils, which are formed by serially linked sarcomeres (Figure 1B,D). The sarcomeres contain thin and thick filaments. These primarily consist of chains of actin and myosin molecules, respectively (Figure 1B). Actin-myosin interactions are responsible for the force-generating capacity of muscle. Patients with mutations in genes encoding for sarcomeric proteins, such as nebulin, actin, and troponin T, suffer from muscle weakness due to contractile dysfunction1.
The quality of muscle contractility can be studied at various levels of organization, ranging from in vivo whole muscles to actin-myosin interactions in in vitro motility assays. During the past decades, several research groups have developed setups to determine the contractility of individual myofibrils2,3,4,5,6,7,8,9,10. These setups are based on the detection of changes in laser deflection from a cantilever (i.e., optical beam deflection) caused by the contraction of the myofibril (for details, see Labuda et al.11). Although determining the contractile function of myofibrils has some limitations (e.g., the dynamics of the excitation-contraction coupling processes that are upstream of the myofibrils are lacking), there are multiple advantages to this approach. These include: 1) the ability to assess actin-myosin interactions in the presence of the geometrical constraints of the sarcomeres; 2) the ability to assess actin-myosin interactions without potential confounding effects of damaged, adjacent myofibrils (when measuring the contractility of single muscle fibers ultrastructural damage and misalignment of myofibrils might contribute to impaired contractility) (Figure 1D); 3) the small diameter of myofibrils (~1 &#181;m, Figure 2A) and the lack of membranes allow for almost instant calcium diffusion into the sarcomeres. Furthermore, if structural damage is present in the myofibrils, they likely break during their isolation or during the experiment. Hence, assessing myofibril contractility is an elegant method to study the basic mechanisms of muscle contraction and to understand whether disturbed actin-myosin interactions are the primary cause of muscle disease caused by mutations in sarcomeric proteins.
This protocol presents a newly developed setup to determine the contractility of myofibrils incorporating a cantilever force probe with nano-Newton resolution (i.e., Optiforce). This force probe is based on the principle of interferometry. Interferometry enables the use of relatively stiff cantilevers. This makes it possible to measure force with little deflection of the cantilever, approaching isometric contractions of the myofibril. The probe allows for the assessment of low passive and active forces that are produced by a single myofibril isolated from different muscle biopsies, including those from human subjects, with a high signal-to-noise ratio. The optical cantilever force probe incorporated in this setup is based on a Fabry-P&#233;rot interferometer12. The interferometer detects small displacements between an optical fiber and a gold-coated cantilever mounted on a ferrule (Figure 3). The gap between the optical fiber and the cantilever is called the Fabry-P&#233;rot cavity. Myofibrils are mounted between the probe and piezo motor using two glue-coated glass mounting fibers. The force produced by the myofibril can be mathematically derived from the interferometer data. Interferometry is based on the superposition or interference of two or more waves (in this setup three light waves). Laser light with a wavelength between 1,528.77&#8211;1,563.85 nm is emitted from the interferometer and is sent through the optical fiber. In the probe, the light is reflected 1) at the interface between the optical fiber and the medium (Figure 3A); 2) at the interface of the medium and the cantilever (Figure 3B); and 3) at the interface between the metal and gold coating of the cantilever (Figure 3C). The reflection at interface A and B is dependent on the refractive index (n) of the medium in which the probe is submerged. The light, consisting of the three superimposed reflections, returns to a photodiode in the interferometer. The photodiode measures the intensity of the light, which is the result of the interference pattern of the three superimposed reflections. When contractile force is generated by activating or stretching a myofibril, the myofibril pulls on the cantilever. This movement changes the cavity size (d) and consequently, the number of wavelengths that fit in the cavity. The light reflected at the cantilever will have a different phase, resulting in a different interference pattern. The photodiode records this change of interference pattern intensity as a change in Volts. Subsequently, myofibril force generation is calculated from this change, taking into account the cantilever stiffness. The force probe is calibrated by the manufacturer by pushing the tip of the mounting needle, attached to the free handing end of the cantilever, against a weighing scale while keeping the bending of the cantilever equal to a multiple of the wavelength of the readout laser13. Thus, interferometry is a highly sensitive method to detect small changes in distance, allowing for measurement of forces with nano-Newton resolution. This resolution enables the assessment of myofibrillar force production with a high signal-to-noise ratio. While traditional interferometry limits the range of measurements to the linear part of the interference curve, using a lock-in amplifier and modulation of the laser wavelength overcomes this limitation14. This is explained in more detail in the discussion section.
To measure myofibril active tension, a fast-step perfusion system was incorporated to expose the myofibril to calcium solutions (Figure 4A). The fast-step perfusion system enables solution changes to occur within 10 ms. Because of their small diameter, calcium diffusion into the myofibrils is nearly instantaneous. Hence, this system is particularly suitable for measuring the rates of actin-myosin binding during activation and release during relaxation. The rate of activation (kACT) and relaxation (kREL) can be determined from the activation-relaxation curves. Also, by exposing the myofibrils to calcium solutions of increasing concentration, the force-calcium relationship and calcium sensitivity can be determined.
Furthermore, a piezo length motor enables fast stretching and shortening of the myofibril. This offers the possibility to study the viscoelastic properties (i.e., passive tension) of the myofibril, as well as performing a rapid shortening and restretch of the myofibril to determine the rate of tension redevelopment (kTR). The parameters retrieved from both active and passive tension experiments can be altered by gene mutations in a sarcomeric protein.
This custom-built setup was used to measure the active and passive contractile characteristics of myofibrils isolated from healthy human, patient, and mouse skeletal muscle.

<table><tbody><tr><td>Bio Spec Products, Inc.</td><td>985370-XL</td><td>To isolate myofibrils</td><td></td></tr><tr><td>Custom coded</td><td></td><td>Matlab</td><td></td></tr><tr><td>Custom fabricated</td><td></td><td>Includes Labview program to control over serial connection; To control valves</td><td></td></tr><tr><td>Custom fabricated</td><td></td><td>To cool the Peltier module</td><td></td></tr><tr><td>Custom fabricated</td><td></td><td></td><td></td></tr><tr><td>Custom fabricated</td><td></td><td>Aluminum tissue chamber</td><td></td></tr><tr><td>Custom fabricated</td><td></td><td>To control the valves; Includes PC software to control over USB</td><td></td></tr><tr><td>IonOptix</td><td></td><td>System controller software: data recording software with advanced signal generator for piezo and fast-step</td><td></td></tr><tr><td>IonOptix</td><td>MCS100</td><td>To record sarcomere length</td><td></td></tr><tr><td>IonOptix</td><td></td><td>Includes: Optiforce (interferometer), Micromanipulators, Signal interface, Piezo motor and controller. Based on the MyoStretcher</td><td></td></tr><tr><td>IonOptix</td><td></td><td>Force probe</td><td></td></tr><tr><td>Koolance</td><td>ADT-EX004S</td><td></td><td></td></tr><tr><td>Koolance</td><td>EX2-755</td><td>To cool the Peltier module</td><td></td></tr><tr><td>Microsoft</td><td></td><td>Data registration</td><td></td></tr><tr><td>Olympus</td><td>IX71</td><td></td><td></td></tr><tr><td>Olympus</td><td>TH4-200</td><td></td><td></td></tr><tr><td>Sigma-Aldrich</td><td>529265</td><td>Poly(2-hydroxyethyl methacrylate); Coating for microscope slides to prevent sticking of tissue</td><td></td></tr><tr><td>Sigma-Aldrich</td><td>78471</td><td>Crystals to dissolve in ethanol resulting in glue</td><td></td></tr><tr><td>TE Technology, Inc.</td><td>TE-63-1.0-1.3</td><td>To cool the tissue flow chamber</td><td></td></tr><tr><td>TE Technology, Inc.</td><td>TC-720</td><td>Includes PC software to control over USB</td><td></td></tr><tr><td>Tecan Trading AG</td><td>20736652</td><td></td><td></td></tr><tr><td>Tecan Trading AG</td><td>20739263</td><td>Syringe pump to induce backgroundflow together with fast-step perfusion system; Outflow from tissue flow chamber</td><td></td></tr><tr><td>Thermo scientific</td><td>2441081</td><td></td><td></td></tr><tr><td>Warner Instruments (Harvard Bioscience, Inc.)</td><td>Discontinued</td><td>Alternative: SF-77CST/VCS-77CSP</td><td></td></tr><tr><td>Warner Instruments (Harvard Bioscience, Inc.)</td><td>TG150-4</td><td>To perfuse the tissue</td><td></td></tr><tr><td></td><td></td><td>1 PC for IonWizard and 1 PC for other software</td><td></td></tr></tbody></table>

isolating myofibrils from skeletal muscle biopsies and determining contractile function with a nano-newton resolution force transducer

Striated muscle cells are indispensable for the activity of humans and animals. Single muscle fibers are comprised of myofibrils, which consist of serially linked sarcomeres, the smallest contractile units in muscle. Sarcomeric dysfunction contributes to muscle weakness in patients with mutations in genes encoding for sarcomeric proteins. The study of myofibril mechanics allows for the assessment of actin-myosin interactions without potential confounding effects of damaged, adjacent myofibrils when measuring the contractility of single muscle fibers. Ultrastructural damage and misalignment of myofibrils might contribute to impaired contractility. If structural damage is present in the myofibrils, they likely break during the isolation procedure or during the experiment. Furthermore, studies in myofibrils provide the assessment of actin-myosin interactions in the presence of the geometrical constraints of the sarcomeres. For instance, measurements in myofibrils can elucidate whether myofibrillar dysfunction is the primary effect of a mutation in a sarcomeric protein. In addition, perfusion with calcium solutions or compounds is almost instant due to the small diameter of the myofibril. This makes myofibrils eminently suitable to measure the rates of activation and relaxation during force production. The protocol described in this paper employs an optical force probe based on the principle of a Fabry-P&#233;rot interferometer capable of measuring forces in the nano-Newton range, coupled to a piezo length motor and a fast-step perfusion system. This setup enables the study of myofibril mechanics with high resolution force measurements.

Watch this Scientific Journal Video about Isolating Myofibrils from Skeletal Muscle Biopsies and Determining Contractile Function with a Nano-Newton Resolution Force Transducer at JoVE.com

Isolating Myofibrils from Skeletal Muscle Biopsies and Determining Contractile Function with a Nano-Newton Resolution Force Transducer

Presented here is a protocol to assess the contractile properties of striated muscle myofibrils with nano-Newton resolution. The protocol employs a setup with an interferometry-based, optical force probe. This setup generates data with a high signal-to-noise ratio and enables the assessment of the contractile kinetics of myofibrils.

Striated muscle cells are indispensable for the activity of humans and animals. Single muscle fibers are comprised of myofibrils, which consist of ...
