<p class="jove_content">We would like to thank Florencia Mata, Mar&#237;a Elena Ch&#225;vez, Miguel Burgos, and Alejandro Tapia for providing technical assistance. We also wish to thank Sarah Gordon Frances for her useful comments on a previous draft of this article and Vladimir Ordu&#241;a for kindly providing raw data from a published paper. Thanks to Claudio Nallen for creating the diagram in <strong>Figure 1</strong>. We are grateful to the Direcci&#243;n de Investigaci&#243;n of the Universidad Iberoamericana Ciudad de M&#233;xico for funding proofreading/editing services and the video producing expenses.</p>

<p class="jove_content">The authors have nothing to disclose.</p>

<p class="jove_content">The present article provided a description of a miscellaneous variety of protocols for screening impulsivity in rats. It is argued that these particular protocols are favored for their ease of programming and data analysis and require fewer operating and stimulus devices than other available alternatives. There are several crucial steps for the effective implementation of these protocols, such as (1) yielding a research question, (2) selecting an appropriate study design, (3) programming the selected protocol, (4) conduc...

<p class="jove_content">Impulsivity can be conceptualized as a behavioral dimension associated with maladaptive outcomes<sup class="xref">1</sup>. Despite the widespread use of this term, there is no universal consensus on its precise definition. In fact, several authors have defined impulsivity by giving examples of impulsive behaviors or their consequences, rather than delineating which distinctive aspects govern the phenomenon. For instance, impulsivity is assumed to involve an inability to wait, plan, inhibit prepotent behaviors, or an insensitivity to delayed outcomes<sup class="xref">2</sup>, and it has been considered a core vulnerability to addictive behavior<sup class="xref">3</sup>. Bari and Robbins<sup class="xref">4</sup> have characterized impulsivity as the co-occurrence of strong impulses, being triggered by dispositional and situational variables, and dysfunctional inhibitory processes. A different definition was provided by Dalley and Robbins, who stated that impulsivity could be regarded as a predisposition to rapid, often premature, actions without appropriate insight<sup class="xref">5</sup>. Yet, another definition of impulsivity, proposed by Sosa and dos Santos<sup class="xref">6</sup>, is a behavior tendency that deviates an organism from maximizing available rewards due to the acquired control exerted over the organism&#39;s responding by stimuli incidentally related to those rewards.</p>
<p class="jove_content">Due to the behavioral processes related to impulsivity, its neurophysiological substrate involves structures in common with those of motivated behavior, decision making and reward valuing. This is supported by studies that show that structures of the cortico-striatal pathway (e.g., nucleus accumbens [NAc], prefrontal cortex [PFC], amygdala, and caudate putamen [CPU]), as well as the ascending monoaminergic neurotransmitter system, participate in the expression of impulsive behavior<sup class="xref">7</sup>. However, the neural substrate of impulsivity is more complex than that. Although NAc and PFC are involved in impulsive behavior, these structures are part of a more complex system, and also are composed by substructures that have different functions (for more detailed documentation, see Dalley and Robbins<sup class="xref">5</sup>).</p>
<p class="jove_content">Regardless of the controversies about its nature and biological substrate, this behavioral dimension is known to vary across individuals, in which case it can be considered as a trait, and within individuals, in which case it can be considered as a state<sup class="xref">8</sup>. Impulsivity has long been recognized as a feature of some psychiatric conditions, such as attention-deficit/hyperactivity disorder (ADHD), substance abuse, and manic episodes<sup class="xref">9</sup>. There seems to be a high consensus that impulsivity is composed by multiple dissociable factors, including unwillingness to wait (i.e., delay discounting), incapacity to refrain prepotent responses (i.e., inhibitory deficit), difficulty to focus on relevant information (i.e., inattention), and a tendency to engage in risky situations (i.e., sensation seeking)<sup class="xref">5</sup><sup>,</sup><sup class="xref">10</sup><sup>,</sup><sup class="xref">11</sup>. Each of these factors can be assessed through special behavioral tasks, which are usually assigned to two broad categories: choice and response inhibition (these may have different labels between each authors&#39; taxonomies). Some important features of such behavioral tasks are that they could be applied across several animal species<sup class="xref">2</sup>&#160;and that they allow&#160;studying impulsivity in controlled laboratory conditions.</p>
<p class="jove_content">Modeling a behavioral dimension with laboratory non-human animals has a number of advantages including the possibility of measuring specific, operationalized behavioral tendencies, allowing the researchers to largely reduce confounding variables (e.g., contamination by past life events<sup class="xref">4</sup>) and to implement experimental manipulations such as chronic pharmacological administration, performing neurotoxic lesions, or genetic manipulations. Most of these protocols have analogue versions for humans, which make comparisons easy<sup class="xref">5</sup>. Importantly, using analogues of these laboratory protocols in humans is effective to aid diagnosis of psychiatric conditions, such as ADHD (especially when more than one protocol is applied<sup class="xref">12</sup>).</p>
<p class="jove_content">Like any other psychological measurement, laboratory protocols for assessing impulsivity must comply with particular criteria in order to achieving the goal of providing insight into the phenomenon under study. To be considered as an appropriate model of impulsive behavior a laboratory protocol should be reliable, and possess (at least, in some degree) face, construct, and/or predictive validity<sup class="xref">13</sup>. Reliability could imply either that an effect upon the measurement would replicate if a manipulation is conducted two or more times, or that the measurement is consistent over time or across different situations<sup class="xref">14</sup><sup>,</sup><sup class="xref">15</sup>. The former feature would be especially useful for experimental studies, while the latter would be so for correlational studies<sup class="xref">14</sup>. Face validity refers to the degree in which what is measured resembles the phenomenon that is supposed to be modeled, as to being, for example, affected by the same variables. Predictive validity refers to the ability of a measure to forecast future performance in protocols, which aim to measure the same or a related construct. Finally, construct validity refers to whether the protocol reproduces behavior that is theoretically sound regarding the process or processes assumed to be involved in the phenomenon under study. However, although these are highly desirable features, one should be cautious when stating that a protocol is valid purely based on these criteria<sup class="xref">16</sup>.</p>
<p class="jove_content">There are several protocols to measure impulsivity in laboratory settings. However, the present article presents only three such methods: intertemporal choice, differential reinforcement of low rates, and feature-negative discrimination. Intertemporal procedures aim to assess the delay discounting (i.e., the difficulty of delayed outcomes to control behavior) component of impulsivity. The basic rationale of this protocol is confronting subjects with two rewards that differ in both magnitude and delay<sup class="xref">17</sup>. One alternative provides a small immediate reward (termed <em>smaller sooner, </em>SS) and the other provides a larger but delayed reward (termed <em>larger later, </em>LL). The proportion of responses to the SS alternative can be used as an index of impulsivity<sup class="xref">18</sup>. In differential reinforcement of low rates procedures, the factor of impulsivity to be assessed is response inhibition (i.e., incapacity to withhold prepotent responses) when there is a negative punishment contingency upon inappropriate responding. The rationale of this protocol is introducing subjects to a situation in which the only way of obtaining rewards is to pause their responding<sup class="xref">19</sup>. Finally, feature-negative discrimination procedure evaluates response inhibition when there is no explicit punishment upon inappropriate responding. The rationale of this protocol (also known as Pavlovian conditioned inhibition or the A+/AX- procedure) is to evaluate subjects&#39; ability to withhold unnecessary responses<sup class="xref">20</sup>.</p>
<p class="jove_content">These procedures stand out in comparison to others as having some convenient features. For example, the procedures presented here are suitable for being conducted in minimally equipped conditioning chambers (also known as &#39;the Skinner box&#39;). <strong>Figure 1</strong> shows a diagram of a typical conditioning chamber. Conditioning chambers are useful research instruments due to a number of advantages. They allow automated collection of a relatively large volume of data, maximizing the number of subjects assessed for unity of time and space<sup class="xref">21</sup>. Moreover, behavioral studies conducted in conditioning chambers require minimal researcher intervention, which reduces the time and effort invested by laboratory staff, unlike other available methods (e.g., non-automated T-mazes, set-shifting boxes)<sup class="xref">21</sup>. Minimizing researchers&#39; intervention also help in reducing researchers&#39; bias, decreasing effects of researchers&#39; learning curve, and a reduction of handling-induced stress<sup class="xref">22</sup>. Typical conditioning chambers are fairly standardized to be used with medium sized rodents, such as rats (<em>R. norvegicus</em>), but can be employed to study other taxa, like similar-sized marsupials (e.g., <em>D. albiventris, and L. crassicaudata</em><sup class="xref">23</sup>). There are also commercial conditioning chambers adapted for smaller (e.g., mice [<em>M. musculus</em>]) and larger (e.g., non-human primates) species. Setting up and conducting the protocols presented in this article require minimal programming skills and demand a quite low number of attainable input and output devices, unlike more sophisticated alternative methods (e.g., 5-choice serial reaction time task [5-CSRTT]<sup class="xref">24</sup> and sign-tracking<sup class="xref">25</sup>).</p>
<p class="jove_content" fo:keep-together.within-page="1"><img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/59070/59070fig1.jpg" /><br />
<strong>Figure 1: Diagram of a conditioning chamber prototype. </strong>The main components of the conditioning chamber include: (1) left lever, (2) food receptacle (equipped with lateral infrared diodes to detect head entries), (3) focalized light, (4) speaker for tone emission (rear view), (5) house light (rear view), (6) food dispenser. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/59070/59070fig1large.jpg" target="_blank">Please click here to view a larger version of this figure.</a></p>

<table><tbody><tr><td>25 Pin Cables</td><td>Med Associates</td><td>SG-213F</td><td>Connect smart control cards to smart control panels</td></tr><tr><td>40 Pin Ribbon Cable</td><td>Med Associates</td><td>DIG-700C</td><td>Connects the computer with the interface cabinet</td></tr><tr><td>Computer</td><td>Dell Computer Company</td><td>T8P8T-7G8MR-4YPQV-96C2F-7THHB</td><td>For controlling and monitoring protocols&amp;rsquo; processes</td></tr><tr><td>Conductor Cables</td><td>Med Associates</td><td>SG-210CP-8</td><td>Provide power to the smart control panels via the rack mount power supply</td></tr><tr><td>Food dispenser with pedestal</td><td>Med Associates</td><td>ENV-203M-45 (12937)</td><td>Silently provides 45 mg food pellets&amp;nbsp;</td></tr><tr><td>Head-Entry Detector</td><td>Med Associates</td><td>ENV-254-CB</td><td>Uses an infrared photo-beam to detect head entries into the food receptacle</td></tr><tr><td>House Light</td><td>Med Associates</td><td>ENV-215M</td><td>For providing&amp;nbsp; diffuse illumination inside the chamber&amp;nbsp;&amp;nbsp;</td></tr><tr><td>Interface Cabinet</td><td>Med Associates</td><td>SG-6080D</td><td>Pod that can hold up to eight smart control cards</td></tr><tr><td>Med-PC IV Software</td><td>Med Associates</td><td>SOF-735</td><td>Translate codes into commands for operating outputs and recording/storing input information</td></tr><tr><td>Multiple tone generator&amp;nbsp;</td><td>Med Associates</td><td>ENV-223 (597)</td><td>For controlling the frequency of the tones</td></tr><tr><td>Panel fillers</td><td>Med Associates</td><td>ENV-007-FP</td><td>For filling modular walls when devices are not used</td></tr><tr><td>Pellet Receptacle</td><td>Med Associates</td><td>ENV-200R2M</td><td>Receives and holds food pellets delivered by the dispenser</td></tr><tr><td>Rack Mount Power Supply</td><td>Med Associates</td><td>DIG-700F</td><td>Provides power to the interface cabinet</td></tr><tr><td>Retractable Lever</td><td>Med Associates</td><td>ENV-112CM (10455)</td><td>Detects lever-pressing responses; projects into the chamber or retracts as needed</td></tr><tr><td>Smart Control Cards</td><td>Med Associates</td><td>DIG-716</td><td>Controls up to eight inputs and four outputs of a conditioning chamber&amp;nbsp;</td></tr><tr><td>Smart Control Panels</td><td>Med Associates</td><td>SG-716 (3341)</td><td>Connect smart cards to the devices within the conditioning chambers</td></tr><tr><td>Speaker&amp;nbsp;</td><td>Med Associates</td><td>ENV-224AM</td><td>For providing tones inside the chamber</td></tr><tr><td>Standard Modular Chambers for Rat</td><td>Med Associates</td><td>ENV-008</td><td>Made of aluminum channels designed to hold modular devices&amp;nbsp;</td></tr><tr><td>Standard sound-, light-, and temperature isolating shells</td><td>Med Associates</td><td>ENV-022MD</td><td>Serve to harbor each conditioning chamber</td></tr><tr><td>Stimulus Light</td><td>Med Associates</td><td>ENV-221M</td><td>For providing a round focalized light stimulus</td></tr><tr><td>Three Pin Cables</td><td>Med Associates</td><td>SG-216A-2</td><td>Connects smart control panel with each of the input and output devices in the conditioning chambers</td></tr></tbody></table>

three laboratory procedures for assessing different manifestations of impulsivity in rats

<p class="jove_content">The present article provides a guide for the conduction and analysis of three conditioning-based protocols to evaluate impulsivity in rats. Impulsivity is a meaningful concept because it is associated with psychiatric conditions in humans and with maladaptive behavior in non-human animals. It is believed that impulsivity is composed of separate factors. There are laboratory protocols devised to assess each of these factors using standardized automated equipment. Delay discounting is associated with the incapacity to be motivated by delayed outcomes. This factor is evaluated through intertemporal choice protocols, which consist&#160;of presenting the individual with a choice situation involving an immediate reward and a larger but delayed reward. Response inhibition deficit is associated with the incapacity to withhold prepotent responses. Differential reinforcement of low rates (DLR) and feature-negative discrimination protocols assess the response inhibition deficit factor of impulsivity. The former imposes a condition to a motivated individual in which most wait a minimum period of time for a response to be rewarded. The latter evaluates the capacity of individuals to refrain from food seeking responses when a signal of the absence of food is presented. The purpose of these protocols is to construct an objective quantitative measure of impulsivity, which serves to make cross-species comparisons, allowing the possibility of translational research. The advantages of these particular protocols include their easy set-up and application, which stems from the relatively small amount of equipment needed and the automated nature of these protocols.</p>

<p class="jove_content" fo:keep-together.within-page="1">The three protocols described in this article may be each conducted alone or in conjunction with other procedures; this will depend on the research question, which in turn will determine the study design. Some examples of study designs that are compatible with these protocols are: (1) time series studies, which aim to describe longitudinal changes in performance; (2) quantification of individual variability, which aims to determine the reliability of the measures; (3) cross-sectional corr...

Watch this Scientific Journal Video about Three Laboratory Procedures for Assessing Different Manifestations of Impulsivity in Rats at JoVE.com

Three Laboratory Procedures for Assessing Different Manifestations of Impulsivity in Rats

<p class="jove_content">We present three protocols that assess different forms of impulsivity in rats and other small mammals. Intertemporal choice procedures evaluate the tendency to discount the value of delayed outcomes. Differential reinforcement of low rates and feature-negative discrimination evaluate response inhibition capacity with and without punishment for inappropriate responses, respectively.</p>

The present article provides a guide for the conduction and analysis of three conditioning-based protocols to evaluate impulsivity in rats. Impulsivity is ...

three-laboratory-procedures-for-assessing-different-manifestations

Universidad San Sebastian

Research

JoVE Journal

Behavior

9.4K Views.  Universidad Iberoamericana. We present three protocols that assess different forms of impulsivity in rats and other small mammals. Intertemporal choice procedures evaluate the tendency to discount the value of delayed outcomes. Differential reinforcement of low rates and feature-negative discrimination evaluate response inhibition capacity with and without punishment for inappropriate responses, respectively.

Video: Three Laboratory Procedures for Assessing Different Manifestations of Impulsivity in Rats

Scientific Measurement and Lab Skills

Two-Dimensional Graphs, Curve Fitting, and Standard Deviation - Procedure

Source: Smaa Koraym at Johns Hopkins University, MD, USA

	Measuring Diameter and CircumferenceExpand
	Error can be introduced in any experiment, even ...

Education

JoVE Lab Manual

Chemistry

Lab Manual Sub Articles

Lab Techniques

<p>Source: Smaa Koraym at Johns Hopkins University, MD, USA</p>
<ol class="note-items">
	<li data-note-item="1" data-parent-collapse=""><strong>Determining the Density of an Egg</strong><button class="expand">Expand</button>
	<p>Density is a measure of how compact a substance or object is, and it is calculated as mass divided by volume. When a dense object is placed in a liquid with a lower density, the object sinks; when the object is less dense than the liquid, it floats. When the densities are the same, the object will be suspended in the liquid. In this experiment, we&#39;ll determine the density of an egg by creating a solution with the same density. We&#39;ll measure the density of the salt solution using different volume measurement glassware and determine which is the most accurate.</p>
	<ul class="lab-items">
		<li data-sub-note-item="1-1">
		<div class="lab-step">To begin, wear the appropriate personal protective equipment, including close-toed shoes, long pants, long-sleeved shirt, lab coat, chemical splash goggles, and gloves.</div>
		</li>
		<li data-sub-note-item="1-2">
		<div class="lab-step">Measure the mass of the egg. Set a weigh boat on the balance and tare it. Carefully set the egg in the weigh boat while you record the mass in your notebook.</div>
		</li>
		<li data-sub-note-item="1-3">
		<div class="lab-step">Prepare the salt solution that will be used to suspend your egg. Use the 600-mL beaker and fill it 3/4 of the way full with deionized water.</div>
		</li>
		<li data-sub-note-item="1-4">
		<div class="lab-step">Gently place your egg in the beaker, and then add about one teaspoon of NaCl into the water. Stir the solution gently until the NaCl dissolves. Continue to add NaCl until the egg floats just below the surface.</div>
		</li>
		<li data-sub-note-item="1-5">
		<div class="lab-step">Use different glassware to measure the volume of the salt solution. Weigh the 50-mL graduated cylinder on the top loading balance and record the mass. Then, measure 20 mL of your salt solution and record the volume in your notebook. <strong>Note: </strong>Place a blank sheet of paper behind the graduated cylinder to read the volume more clearly. Always view the measurement at eye level and measure the volume from the bottom of the meniscus. The lines on the graduated cylinder are 0.2 mL apart, meaning that you can read the volume to the hundredths place.
		<h4><b>Table 1: Measuring Mass</b></h4>
		<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
			<tbody>
				<tr>
					<td style="text-align: center;"><strong>Container</strong></td>
					<td style="text-align: center;"><strong>Mass of empty container (g)</strong></td>
					<td style="text-align: center;"><strong>Mass of full containter (g)</strong></td>
					<td style="text-align: center;"><strong>Mass of solution (g)</strong></td>
					<td style="text-align: center;"><strong>Percent error</strong></td>
				</tr>
				<tr>
					<td>50-mL graduated cylinder</td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
				</tr>
				<tr>
					<td>10-mL volumetric pipette</td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
				</tr>
				<tr>
					<td>50-mL beaker</td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
				</tr>
				<tr>
					<td>20-mL volumetric flask</td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
					<td style="text-align: center;"></td>
				</tr>
			</tbody>
		</table>
		<a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/41/Table_1._Measuring_Mass.xlsx" target="_blank">Click Here to download Table 1</a></div>
		</li>
		<li data-sub-note-item="1-6">
		<div class="lab-step">Weigh the filled graduated cylinder and record the mass in your notebook. Then, pour the salt solution back into the 600-mL beaker.</div>
		</li>
		<li data-sub-note-item="1-7">
		<div class="lab-step">Use the volumetric pipette to measure volume. First, weigh the empty 50-mL beaker and record the mass in your notebook. Then, carefully measure 10 mL of the salt solution using the volumetric pipette and dispense the salt solution into the beaker.</div>
		</li>
		<li data-sub-note-item="1-8">
		<div class="lab-step">Measure another 10 mL and add it to the beaker. Weigh the filled beaker and record the mass in your notebook. Then, empty, rinse, and dry the beaker.</div>
		</li>
		<li data-sub-note-item="1-9">
		<div class="lab-step">Use the volumetric flask to measure volume. Weigh the empty 20-mL volumetric flask and record the mass. Then, carefully fill the flask with the salt solution to just below the 20-mL fill mark. Do not fill it all the way. Use an eyedropper to finish filling the flask so that the bottom of the meniscus just touches the fill line on the neck of the flask. Then, weigh the full flask and record the weight.</div>
		</li>
		<li data-sub-note-item="1-10">
		<div class="lab-step">Lastly, use the 50-mL beaker to measure volume. Weigh the empty beaker, then fill the beaker with salt solution to the 20-mL line and weigh the full beaker. Record the masses in your notebook.</div>
		</li>
		<li data-sub-note-item="1-11">
		<div class="lab-step">Measure the displacement of the egg when it is submerged in the salt solution. First, remove the egg and look at the level of the salt solution in the 600-mL beaker. <strong>Note:</strong> If it is not at a marked line, add deionized water to the solution so that the meniscus is at a readable volume and record the volume.&#160;
		<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
			<tbody>
				<tr>
					<td><strong>Measurements</strong></td>
					<td><strong>Salt solution using 20-mL volumetric flask&#160;</strong></td>
					<td><strong>Egg</strong></td>
				</tr>
				<tr>
					<td>Mass (g)</td>
					<td></td>
					<td></td>
				</tr>
				<tr>
					<td>Displacement of water (cm)</td>
					<td style="text-align: center;">-</td>
					<td></td>
				</tr>
				<tr>
					<td>Inner diameter of 600-mL beaker (cm)</td>
					<td style="text-align: center;">-</td>
					<td></td>
				</tr>
				<tr>
					<td>Volume (cm&#179;)</td>
					<td style="text-align: center;">-</td>
					<td></td>
				</tr>
				<tr>
					<td>Volume (mL)</td>
					<td style="text-align: center;">20</td>
					<td></td>
				</tr>
				<tr>
					<td>Density (g/mL)</td>
					<td></td>
					<td></td>
				</tr>
			</tbody>
		</table>
		<strong><a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/41/Table_2._Measuring_Density.xlsx" target="_blank">Click Here to download Table 2</a> </strong></div>
		</li>
		<li data-sub-note-item="1-12">
		<div class="lab-step">Gently place the egg in the beaker.</div>
		</li>
		<li data-sub-note-item="1-13">
		<div class="lab-step">Use a ruler to measure the new height of the solution level and record the height. Then, place the ruler across the top of the beaker to measure the inner diameter.</div>
		</li>
		<li data-sub-note-item="1-14">
		<div class="lab-step">Calculate the new volume from these measurements. Subtract the initial volume to obtain the displacement of the egg (volume).</div>
		</li>
		<li data-sub-note-item="1-15">
		<div class="lab-step">To clean up from the experiment, return the egg to your instructor and pour the salt solution down the sink. Rinse all used glassware with tap water and set them out to dry. Finally, return the sodium chloride to your instructor.</div>
		</li>
	</ul>
	</li>
	<li data-note-item="2" data-parent-collapse=""><strong>Results</strong><button class="expand">Expand</button>
	<ul class="lab-items">
		<li data-sub-note-item="2-1">
		<div class="lab-step">Calculate the mass of the solution in each of the different volumetric glassware by subtracting the empty glassware mass from the full glassware mass.</div>
		</li>
		<li data-sub-note-item="2-2">
		<div class="lab-step">Keep track of uncertainty in your measurement by using significant figures. For example, when we look at the graduated cylinder measurement, the weight of the empty container is 90.92, and the weight of the full container is 111.59. The weight measurements have significant figures to the hundredths place, so it is important that significant figures are maintained throughout our calculations. Thus, the mass of the 20-mL salt solution is 20.67 g.</div>
		</li>
		<li data-sub-note-item="2-3">
		<div class="lab-step">The 50-mL beaker weighed 28.65 g when it was empty and 47.96 g when it contained 20 mL of salt solution. Therefore, the mass of 20 mL of the salt solution is 19.31 g.</div>
		</li>
		<li data-sub-note-item="2-4">
		<div class="lab-step">Repeat the calculation to obtain the mass of 20 mL of salt solution that was measured using the 10-mL pipette and the 200-mL volumetric flask.<b> Note:</b> Generally speaking, volumetric measurements are more accurate when using a volumetric flask.</div>
		</li>
		<li data-sub-note-item="2-5">
		<div class="lab-step">Look at the accuracy of the other methods compared to the volumetric flask in terms of percent error. Percent error is calculated by subtracting the theoretical value from the experimental value, then dividing by the theoretical value times 100.
		<ul>
			<li><img src="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/41/41_Procedure_1b.jpg" /></li>
		</ul>
		</div>
		</li>
		<li data-sub-note-item="2-6">
		<div class="lab-step">Use the volumetric flask measurement as the theoretical value to determine the percent error for the other volume measurement methods. As expected, the volume measurement that uses the markings on the beaker is the least accurate.<strong> Note: </strong>We also know this because the known density of pure water is 1 g/mL. Thus, 20 mL of pure water weighs 20 g. The density of the salt solution must be higher than 20 g since salt was added to the water.</div>
		</li>
		<li data-sub-note-item="2-7">
		<div class="lab-step">Calculate the density of the salt solution using the volumetric flask measurement. Divide the mass of the solution by the volume of the solution. Thus, the density of the salt solution is 1.053 g/mL.</div>
		</li>
		<li data-sub-note-item="2-8">
		<div class="lab-step">Compare the calculated density of the salt solution to the density of the egg. The volume calculated using the displacement of water in a beaker was found to be 61.14 cm<sup>3</sup> or 61.14 mL. The weight of the egg was measured to be 60.15 g, so its density is 0.9838 g/mL. The disparity between the density of the egg and the density of the salt solution arises from error introduced in both calculations, primarily due to volume measurement readings.</div>
		</li>
	</ul>
	</li>
</ol>

Accuracy, Precision, Uncertainty, and Significant Figures - Procedure

Source: Smaa Koraym at Johns Hopkins University, MD, USA

	Determining the Density of an EggExpand
	Density is a measure of how compact a substance or ...

Energy Dynamics

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Caterpillar Energy Dynamics
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">NOTE: In this lab you will grow caterpillars in conditions with and without food to examine the transfer of biomass in a typical trophic system.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">Weigh and record the wet mass of enough leaves of cabbage to line the bottom of a plastic tub.
</div></li><li data-sub-note-item="1-3"><div class="lab-step">Then, collect two batches of five caterpillars from their cabbage habitat, and weigh and record the wet mass of each batch separately in individual weigh boats. Make sure to tare the balance before each measurement. HYPOTHESES: The experimental hypothesis is that only a fraction of energy will be transferred between the trophic levels of the cabbage and the caterpillars and a significant amount will be lost as waste and heat energy. The null hypothesis is that there will be no significant difference between the energy input from the cabbage, and the obtained energy stored as biomass in the caterpillars.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Place the weighed cabbage and five caterpillars in a plastic tub lined with damp paper towels, leaving the lid slightly cracked open for ventilation, but not wide enough for the animals to escape.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">Place the other five caterpillars in a second clean container prepared the same way, but with no cabbage.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">After three days, transfer the caterpillars to new weigh boats, and weigh and record the final wet mass of both groups of caterpillars and the cabbage.
</div></li><li data-sub-note-item="1-7"><div class="lab-step">Then place the caterpillar waste, or frass, and cabbage into two separate dishes, and put both dishes into a 37 &#176;C incubator to dry for 48 hours.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">Euthanize the weighed caterpillars by putting them into a minus 20 &#176;C freezer for 24 hours.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">Then, transfer the dishes to a 37 &#176;C incubator for 48 hours.
</div></li><li data-sub-note-item="1-10"><div class="lab-step">After drying, weigh and record the dry mass of the uneaten cabbage, the two groups of caterpillars, and the frass, and use these data to calculate the percent biomass of the caterpillars.
</div></li><li data-sub-note-item="1-11"><div class="lab-step">Finally, discard all of the dried organisms and plates into the hazardous waste bin, and wipe down your workspace with 70% ethanol.
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">Take a look at the data you collected. Ensure the initial wet mass, the final wet mass, and the final dry mass columns are accurately filled out in your table. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/13/Table_1_Energy_Dynamics.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 1</a>
</div></li><li data-sub-note-item="2-2"><div class="lab-step">NOTE: Remember an object&#39;s biomass is equal to its dry mass. Therefore, percent biomass for each group is the final dry mass divided by the final wet mass times 100. For example, obtain the percent biomass of the cabbage by dividing the final dry mass by the final wet mass and multiplying by 100. This means that approximately 15% of the cabbage&#39;s total weight is biomass.
</div></li><li data-sub-note-item="2-3"><div class="lab-step">After this, estimate the initial biomass of the cabbage and caterpillars by multiplying the percent biomass by the initial wet mass, and put the values in this new table. NOTE: Remember, biomass equals dry mass. Therefore, the final dry mass is equal to the final biomass of each group.
</div></li><li data-sub-note-item="2-4"><div class="lab-step">To calculate the approximate initial and final energy in the form of kilocalories within the cabbage, caterpillars, and frass, multiply the biomass values recorded in your table by the conversions, and record the calculated values in the table. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/13/Table_2_Energy_Dynamics.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 2</a>
</div></li><li data-sub-note-item="2-5"><div class="lab-step">After this, subtract the initial energy from the final energy to obtain the change in energy for each group.
</div></li><li data-sub-note-item="2-6"><div class="lab-step">NOTE: The negative sign denotes loss in energy, and positive indicates gain.
</div></li><li data-sub-note-item="2-7"><div class="lab-step">Using your data table, calculate the energy in kilocalories that the fed caterpillars lost to respiration. The formula is the energy gained from cabbage, which is the positive of the energy lost by cabbage, minus the biomass gained from cabbage, minus the energy lost via frass. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/13/Table_3_Energy_Dynamics.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 3</a>
</div></li><li data-sub-note-item="2-8"><div class="lab-step">Then, repeat the same calculation for the unfed group of caterpillars. Make another column in the table and note this down.
</div></li><li data-sub-note-item="2-9"><div class="lab-step">Finally, add up all of the energy gained via biomass and cabbage consumption, and the energy lost via frass and respiration for each group of caterpillars. NOTE: For both groups of caterpillars the net energy is zero, meaning that this experiment obeyed the first law of thermodynamics.
</div></li></ul></li></ol>

Studying Energy Dynamics and Productivity - Procedure

Caterpillar Energy Dynamics
ExpandNOTE: In this lab you will grow caterpillars in conditions with and without food to examine the transfer of biomass in a ...

Biology

Ecology

Extinction

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Diversity and Extinction during the Paleogene Epoch
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">Begin this procedure by reading the extinction reading supplement that has been printed out for you. <br /><strong>NOTE:</strong> Alternatively, you may download the reading supplement at the link below.&nbsp; <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/24/Lab_20_Reading Supplement.docx" style="display:block;margin:20px;" target="_blank">Click here to download the extinction reading supplement</a>
</div></li><li data-sub-note-item="1-2"><div class="lab-step">Using the information contained in the extinction reading supplements pertaining to the taxa of interest and the Chicxulub impact event, make predictions for each taxon listed in Table 1. Consider whether diversity in each taxon increased, decreased, or stayed the same immediately following the Cretaceous-Paleogene boundary and later on in the Paleogene epoch. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/24/Table_1_Extinction.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 1</a>
</div></li><li data-sub-note-item="1-3"><div class="lab-step">Then, fill out the reasons for each of your predictions in the Contributing Factors column. HYPOTHESES: The experimental hypothesis is that many of the different taxa will show changes in diversity after the Cretaceous-Paleogene event, and again at the end of the Paleogene, with some increasing in diversity, while others decrease. The null hypothesis is that there will be no changes in diversity between taxa following the Cretaceous-Paleogene event, or at the end of the Paleogene.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Gather diversity data by going to the Paleobiology Database: <a href="http://www.paleobiodb.org" target="_blank">www.paleobiodb.org</a>.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">In the center of the screen, click the yellow box labeled Download Data. Under the italicized heading, &#8220;What do you want to download?&#8221;, select Diversity over time on the left side and Comma-separated values on the right side.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">Scroll down to the heading &#8220;Select by taxonomy&#8221;.
</div></li><li data-sub-note-item="1-7"><div class="lab-step">In the first box labeled 'Taxon or taxa to include', type in the name of the taxon that data is being gathered on.  NOTE: Ensure the spelling is correct.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">Now, go to the dropdown menu right below that box labeled &#8220;Taxonomic resolution&#8221;, and select genera.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">Under the next heading, Select by time, type Maastrichtian into the first box and Chattian in the box directly below. Make sure the dropdown menu labeled Time rule is set to major and the Temporal resolution is set to stage.
</div></li><li data-sub-note-item="1-10"><div class="lab-step">Select &#8220;Assume extant taxa range through to present&#8221;. Scroll back up to the middle of the page and click download. A save window will open.
</div></li><li data-sub-note-item="1-11"><div class="lab-step">Save the .csv file to a safe and accessible place and rename it to make it easy to identify.
</div></li><li data-sub-note-item="1-12"><div class="lab-step">Open the file and scroll down to the main dataset under Records.  NOTE: The data are arranged in reverse time order by geological stage. The second column, interval_name, gives the accepted name of the stage in question. The next two columns give the appropriate dates of the stage in millions of years before the present. The final column, number of occurrences, gives a total count of the genera extant during that geological stage as determined from occurrence of fossils.
</div></li><li data-sub-note-item="1-13"><div class="lab-step">To more easily work with this data, copy and paste each column into a new sheet. Be sure to label this sheet with the taxon in question, the data and time the data were obtained, and the data source.
</div></li><li data-sub-note-item="1-14"><div class="lab-step">Repeat this process for each of the taxa in Table 1 (steps 4 &#8211; 12). NOTE: Data from multiple taxa can be kept on the same sheet, so long as they are kept distinct and labeled appropriately.
</div></li><li data-sub-note-item="1-15"><div class="lab-step">To create line plots for each of the taxa showing the change in diversity over time, select the max_ma column and the number of occurrences column simultaneously.
</div></li><li data-sub-note-item="1-16"><div class="lab-step">In Excel, select Insert from the top toolbar and find the section labeled Charts. Select the bottom center icon, Insert Scatter Chart.
</div></li><li data-sub-note-item="1-17"><div class="lab-step">Then, select the Scatter with Straight Lines and Markers and a graph should appear. NOTE: Since the axis of this graph is in units of millions of years ago, the axis is in the reverse direction of time when put in numerical order.
</div></li><li data-sub-note-item="1-18"><div class="lab-step">To fix this, click on the green plus sign in the top-right corner of the graph and hover over Axes. This should reveal a small black arrow. Click the arrow to open up a small menu and select More Options.
</div></li><li data-sub-note-item="1-19"><div class="lab-step">This will open the Axis Options menu. Under Axis Options, click the box next to Values in reverse order. NOTE: It is also possible to change the axis scales from this menu, which can be used to eliminate the excess time that is not being analyzed in this lab. Keep any changes consistent between different graphs.
</div></li><li data-sub-note-item="1-20"><div class="lab-step">Double-click on the title at the top of the graph and change it to the taxon being represented.
</div></li><li data-sub-note-item="1-21"><div class="lab-step">Make a separate graph for each of the taxa in Table 1. Keep them organized and in one location. A separate sheet for graphs is recommended.
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">For each graph, identify the location of the Cretaceous-Paleogene boundary and draw a vertical line through the graph at this point.
</div></li><li data-sub-note-item="2-2"><div class="lab-step">Using the information from the graphs, fill out Table 2. In some cases, it may be helpful to go back to the original dataset and compare actual values, particularly when they are small. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/24/Table_2_Extinction.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 2</a>
</div></li><li data-sub-note-item="2-3"><div class="lab-step">Compare these values to the predictions made in Table 1 and discuss if the original contributing factors are still likely candidates.
</div></li><li data-sub-note-item="2-4"><div class="lab-step">Using the dataset, calculate the percentage of total taxa that went extinct over the Cretaceous-Paleogene boundary using this equation.
</div></li><li data-sub-note-item="2-5"><div class="lab-step">There is an event in the middle of the Paleogene known as the Paleocene-Eocene Thermal Maximum about 55.5 million years ago. This represents a high point in temperature during the Paleogene epoch at approximately 8 &#176;C higher than today&#39;s average temperature. Does this point seem to have an effect on diversity for any of the taxa? If yes, then which ones?
</div></li></ul></li></ol>

Extinction: Diversity and Extinction during the Paleogene Epoch - Procedure

Diversity and Extinction during the Paleogene Epoch
ExpandBegin this procedure by reading the extinction reading supplement that has been printed out for ...

Group Behavior

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">The Hawk-Dove Game
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">NOTE: In this activity, you will play the hawk and dove game with a single partner and then with multiple partners to observe hypothetical costs and benefits of the antagonist or cooperative behavior respectively.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">Before the activity starts, review the cost-benefit table so that you understand how to score the game. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/33/Table_1_Group_behavior.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 1</a>
</div></li><li data-sub-note-item="1-3"><div class="lab-step">HYPOTHESES: The experimental hypothesis for this exercise could be that the dove strategy will become more frequent between repeated partners, and the hawk strategy will become more frequent when interactions are with a variety of partners. The null hypothesis could be that there will be no change in strategy over time with repeat or different partner combinations. NOTE: Benefit can be determined by looking at the left column and choosing the row that corresponds to the card you played. The box that corresponds to the choice of your partner can be found in the top row. For the purposes of this game, B equals four and C equals three. So depending on the cards played, player one here, which is you, would gain a score of two, four, zero or one half.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Collect a set of two game cards.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">Take out the cards labeled hawk and dove and place them face down on the table or conceal them in your hands.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">When the instructor gives the signal show either of the two cards to the student sitting across from you. Try to strategize how to receive the highest benefit from every interaction on your own but do not communicate with your partner.
</div></li><li data-sub-note-item="1-7"><div class="lab-step">In the Single Partner Recording Table (Table 2) provided by your instructor, note the cards played as well as the benefit you received for that round.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">Repeat showing cards to the same partner and determining benefit on your instructor&#39;s signal for a total of 15 rounds.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">At the end of those rounds, the student with the highest total benefit value was determined to be the &#8220;winner&#8221;, or the most fit.
</div></li><li data-sub-note-item="1-10"><div class="lab-step">As a class, determine the percentages of hawks and doves played as well as the average benefit received for each round, using this formula: Class average benefit=(sum total benefit)/(number of players)
</div></li><li data-sub-note-item="1-11"><div class="lab-step">For the second game, and then for each round of play, one row of students should rotate to their right, leaving all players with a new partner.
</div></li><li data-sub-note-item="1-12"><div class="lab-step">Continue playing for 15 rounds or until students end up back in their starting positions, recording the data in the Multiple Partner Recording Table (Table 3) given to you by your instructor.
</div></li><li data-sub-note-item="1-13"><div class="lab-step">For each round, determine the percentages of hawks and doves played that round, as well as the average benefit received.
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Cheating and Cooperation Exercise
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">NOTE: In this activity, you will exchange benefits, represented by colored or similar items, with your classmates. In this simulation, a cheater is defined as a person who gives fewer benefits than they receive. During this activity, you will observe the frequency of cheating behavior over time.
</div></li><li data-sub-note-item="2-2"><div class="lab-step">HYPOTHESES: The experimental hypothesis is that cheaters will receive fewer benefits over time and cooperators will continue to provide equal benefits to one another. The null hypothesis is that the frequency of cheaters and cooperators does not change over time.
</div></li><li data-sub-note-item="2-3"><div class="lab-step">Each person should collect beads of one color to represent a tangible benefit, as well as one paper bag and a three-ring binder.
</div></li><li data-sub-note-item="2-4"><div class="lab-step">Get into a group of three so that all members have objects of the same color.
</div></li><li data-sub-note-item="2-5"><div class="lab-step">Now find another group with a different color to pair with. In each round, partners will exchange benefits without knowing what they are receiving from their partner and without discussion within their group.  NOTE: Benefits of a different color from your starting color are worth twice as much.
</div></li><li data-sub-note-item="2-6"><div class="lab-step">Turn face to face with a member from the other group while still being able to conceal the objects in your possession.  TIP:<strong> </strong>Setting up a screen using a notebook or sitting behind a desk can be helpful here.
</div></li><li data-sub-note-item="2-7"><div class="lab-step">When given a signal from the instructor, place zero to two benefits into the paper bag and pass it to your partner.
</div></li><li data-sub-note-item="2-8"><div class="lab-step">Simultaneously, receive the bag from your partner and then remove the benefits from the bag.
</div></li><li data-sub-note-item="2-9"><div class="lab-step">Make a note of how many benefits you gave away and how many you received in the Cheating and Cooperation Table (Table 4) provided by your instructor.
</div></li><li data-sub-note-item="2-10"><div class="lab-step">Turn to a new member from the other group and repeat the exchange.
</div></li><li data-sub-note-item="2-11"><div class="lab-step">Rotate through all of the members of the other group for as many rounds as the instructor determines - which will not be revealed until the game ends so as not to alter player behavior.
</div></li><li data-sub-note-item="2-12"><div class="lab-step">Once the game has ended, note for each round in the cheating and cooperation table whether you gave more than your partner, received more from them or if you gave the same amount.
</div></li><li data-sub-note-item="2-13"><div class="lab-step">Now total up all of the benefits in your possession, with benefits you&#39;ve received from the other group being worth twice as much.
</div></li><li data-sub-note-item="2-14"><div class="lab-step">For each round, the whole class should total up the number of cheaters - with cheaters defined as those who gave less than they received.
</div></li></ul></li><li data-note-item="3" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="3-1"><div class="lab-step">For both the single partner hawk-dove game and the multiple partners hawk-dove game, use the whole class data to plot the percentages as two separate lines - one for the percentage of hawks, and one for the percentage of doves, for each of the 15 rounds.
</div></li><li data-sub-note-item="3-2"><div class="lab-step">Take note of whether the cards played changed as more rounds were played.
</div></li><li data-sub-note-item="3-3"><div class="lab-step">Manipulate the values for B and C to see if you can find the point at which values of B and C would render the hawk strategy no longer effective (this would be the point when there is no benefit to choosing the hawk strategy over always choosing the dove strategy).
</div></li><li data-sub-note-item="3-4"><div class="lab-step">As a class, use the data from the cheating and cooperation activity to make a graph showing the percentage of rounds each individual player cheated versus the amount of benefits they ended with.
</div></li><li data-sub-note-item="3-5"><div class="lab-step">Consider whether it is better to be a cheater or a cooperator in this scenario and discuss as a class what makes this scenario different from the hawk-dove game.
</div></li><li data-sub-note-item="3-6"><div class="lab-step">Now, use the class data to graph the percentage of cheaters against the number of rounds, and look for any trends over time.
</div></li><li data-sub-note-item="3-7"><div class="lab-step">Consider which type of strategy would most likely evolve in a setting where partners interact repeatedly.
</div></li><li data-sub-note-item="3-8"><div class="lab-step">Then, note which tactic might be beneficial for a species that relies on cooperation.
</div></li><li data-sub-note-item="3-9"><div class="lab-step">Discuss as a class what would likely happen if you increased or decreased the relative value of the benefits you receive.
</div></li></ul></li></ol>

Group Behavior: Hawk-Dove Game and Trading Exercise - Procedure

The Hawk-Dove Game
ExpandNOTE: In this activity, you will play the hawk and dove game with a single partner and then with multiple partners to observe ...

Optimal Foraging

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Simulating Foraging with Artificial Habitats and Prey
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">NOTE: The foragers will hunt for prey represented by pinto beans in four buckets of rice with varying prey densities. Without knowing what these densities are, foragers must obtain as many prey items as possible in as little time as possible.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">HYPOTHESES: In this experiment, the experimental hypothesis could be that foragers will catch the most prey in the higher prey density bucket and also spend the most time foraging there.  The null hypothesis would then be that foragers will catch an equal number of prey in each bucket and that foragers will spend an equal amount of time foraging in each patch.
</div></li><li data-sub-note-item="1-3"><div class="lab-step">To begin the foraging activity, record the names and role of each participant at the top of the student data collection sheet.  NOTE: Before starting the experiment, the forager is allowed to become familiar with the foraging process &#8211; the following steps are a practice round.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">The forager should kneel or sit in front of the average density bucket.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">Once the timer says start, the forager may begin looking for the pinto beans representing the prey. The forager can spend as much time as they like foraging in this bucket.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">Once a prey item is located, the forager must signal that one has been found and place the prey in the cup next to the bucket.
</div></li><li data-sub-note-item="1-7"><div class="lab-step">Once they believe they have acquired most of the prey in the patch, they should tell the timer to stop the time and the practice round is over.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">To begin the simulation proper, the forager should sit or kneel in front of bucket A.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">The timer must be ready to start the stopwatch.
</div></li><li data-sub-note-item="1-10"><div class="lab-step">The recorder should be ready to record the time each prey item is located, in addition to the time that the forager arrived at and left each bucket.
</div></li><li data-sub-note-item="1-11"><div class="lab-step">When all parties are ready, the timer should start the stopwatch and say &#8220;start&#8221;,  and the forager should begin foraging. NOTE: The stopwatch will run through the rest of the round for buckets B and C.
</div></li><li data-sub-note-item="1-12"><div class="lab-step">As the forager signals finding pinto beans and places them in the cup next to the bucket, the timer should tell the recorder the time.
</div></li><li data-sub-note-item="1-13"><div class="lab-step">The recorder should then write the time in the student data collection sheet.  <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/34/Table_1_Optimal_foraging.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 1</a>
</div></li><li data-sub-note-item="1-14"><div class="lab-step">Once the forager has decided to move on to the next bucket, they should tell the timer &#8220;done&#8221;, and begin moving to the next patch.
</div></li><li data-sub-note-item="1-15"><div class="lab-step">The recorder should record the time the forager left and the time they arrived at bucket B in the student data collection sheet.
</div></li><li data-sub-note-item="1-16"><div class="lab-step">Repeat the same procedure for buckets B and C. Once the forager has completed the activity, it is time for the next forager to begin using the same procedure.
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">Before performing any data analysis, review the data collection sheet and compile your individual data for captured prey, foraging time, and travel time for each bucket in your student calculations table. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/34/Table_2_Optimal_foraging.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 2</a>
</div></li><li data-sub-note-item="2-2"><div class="lab-step">After this, calculate your individual capture rate for each bucket by dividing the number of prey captured by the sum of the foraging time and travel time and record these values in your table. Individual capture rate =  Number of prey captured / (foraging time + travel time)
</div></li><li data-sub-note-item="2-3"><div class="lab-step">To calculate your Giving-Up-Time or a GUT for each bucket, subtract the time that the last prey item was acquired from the time you left the bucket.  GUT = time forager left bucket  -  time last prey item acquired
</div></li><li data-sub-note-item="2-4"><div class="lab-step">Next, calculate the mean GUT for your foraging group and record the values in your table.
</div></li><li data-sub-note-item="2-5"><div class="lab-step">Finally, calculate your scaled GUT for each bucket by dividing the bucket GUT by your group&#39;s mean GUT. Scaled GUT =  Bucket GUT / Group mean GUT NOTE: The scaled GUT will allow class data to be pooled later on without differences in individual foragers skewing the data.
</div></li><li data-sub-note-item="2-6"><div class="lab-step">The instructor should now compile the data into the classroom spreadsheet.  <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/34/Table_3_Optimal_foraging.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 3</a>
</div></li><li data-sub-note-item="2-7"><div class="lab-step">Plot a bar graph of the average number of prey collected in each bucket. On the x-axis, A should represent the low prey density bucket, B should represent the medium prey density bucket, and C the high prey density bucket. Plot the y-axis as the number of prey items caught.
</div></li><li data-sub-note-item="2-8"><div class="lab-step">Next, plot the graph of the class average scaled GUT, where the x-axis represents the buckets with varying levels of prey density and the y-axis shows the values for the average scaled GUT.
</div></li><li data-sub-note-item="2-9"><div class="lab-step">Plot a third graph of the average time spent foraging in each bucket.
</div></li><li data-sub-note-item="2-10"><div class="lab-step">Now review the Marginal Value Theorem (MVT) from the concepts video and examine the three graphs that you generated from your class data. Take note of whether the graphs conform to the predictions of MVT.
</div></li></ul></li></ol>

Optimal Foraging: Foraging with Artificial Habitats and Prey - Procedure

Simulating Foraging with Artificial Habitats and Prey
ExpandNOTE: The foragers will hunt for prey represented by pinto beans in four buckets of rice with ...

Sexual Selection and Mate Choice

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Sexual Selection Class Simulation
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">Note: In this activity, you and your classmates will portray a sexually reproducing population consisting of an equal number of male and female animals. You will simulate several different mating scenarios to determine how relative quality, attractiveness, sex, and parental commitment affect mate choice and reproductive success. The goal of this activity is to maximize your progeny.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">Hypotheses: There are several overall hypotheses for female and male behavior for this activity. The main experimental hypothesis for female behavior is that females will mate with males of high quality more frequently than those of low quality, yielding a higher reproductive success. The null hypothesis is that females will not demonstrate preference towards high- or low-quality males in any of the four rounds of mating. For males, one experimental hypothesis is that males with a higher visible score will have greater reproductive success. Another could be that males will be more selective for females in scenarios in which they join females to care for offspring as opposed to scenarios in which they exhibit no parental commitment. The null hypothesis for male behavior might be that males will not demonstrate preference towards high- or low-quality females in any of the four rounds of mating.
</div></li><li data-sub-note-item="1-3"><div class="lab-step">Activity Overview: To begin, each student will be assigned a sex as well as a relative quality and attractiveness score. Remember - the goal is to maximize your reproductive success in each round. You do this by mating with partners of the highest possible quality which is rated on a scale of one to three with three being the highest possible score. Attractiveness scores, which follow the previously described scoring paradigm, correlate with quality but do not exactly predict the score. Though useful, they are not a perfect way to choose the best mate.  If you are assigned a male ID holder, you will have 16 gametes. However, if you are assigned a female ID holder, you will only have four. A successful mating occurs when one sperm and one egg are paper-clipped together and deposited at the fertilization area.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Note - Rules of the activity:
<ul>
	<li>Assigned male and female identities for these experiments are not representative of students&#39; personal gender identities. </li>
	<li>Running is not permitted. </li>
	<li>Talking is not permitted.</li>
	<li>Hidden values cannot be shared but individuals can attempt to hide their visible scores. </li>
	<li>Respect the space around each individual and remain an arm&#39;s length away. </li>
	<li>Offspring will only be counted towards an individual score if both gametes are paper-clipped together and dropped off in the designated fertilization area before the end of the two-minute round. </li>
</ul>
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Round 1 &#8211; Hidden Quality Score
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">To begin the first simulation, take the clip-on ID holder you were randomly assigned and make sure it contains four gametes if you are assigned female or sixteen gametes if male. Males should also have a strip of white paper and two paperclips.
</div></li><li data-sub-note-item="2-2"><div class="lab-step">Next, males should paperclip the white strip of paper over their quality score to hide it, but keep the attractiveness score visible.
</div></li><li data-sub-note-item="2-3"><div class="lab-step">Record your ID number for round one in table two.  <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/35/Table_2_sexual_selection.xlsx" style="display:block;margin:20px;" target="_blank">Click Here to download Table 2</a>
</div></li><li data-sub-note-item="2-4"><div class="lab-step">Next, clip on the ID holder and move to the designated mating area.
</div></li><li data-sub-note-item="2-5"><div class="lab-step">When the instructor says begin, you may commence the mating simulation. You will have exactly two minutes to produce as many offspring as possible. Males may freely give their sperm to females, and females may choose to use these sperm immediately after which they would walk to the fertilization area and paperclip it to one of their eggs, or they may choose to wait until they receive other sperm to do so.
</div></li><li data-sub-note-item="2-6"><div class="lab-step">Once the gametes have been deposited in the fertilization area, females may resume mating.
</div></li><li data-sub-note-item="2-7"><div class="lab-step">When the two minutes have elapsed, all matings must stop and any gametes not in the fertilization area at this time will not be counted.
</div></li><li data-sub-note-item="2-8"><div class="lab-step">The instructor should now tally all of the matings and record the numbers of the individuals who produced each offspring.
</div></li><li data-sub-note-item="2-9"><div class="lab-step">Now, find all the gametes that came with your ID holder and repackage them for the next round.
</div></li></ul></li><li data-note-item="3" data-parent-collapse="">Round 2 &#8211; Hidden Attractiveness Score
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="3-1"><div class="lab-step">For the second round, obtain a new randomly assigned ID holder and again ensure it contains the proper number of gametes.
</div></li><li data-sub-note-item="3-2"><div class="lab-step">Next, males should use the paperclip and strip of white paper to hide their attractiveness score (instead of the quality score, which was covered in round one).
</div></li><li data-sub-note-item="3-3"><div class="lab-step">Record the ID number of your clip in table two under round two.  Note: The mating simulation process for round two will be the same as round one.
</div></li><li data-sub-note-item="3-4"><div class="lab-step">Move to the designated mating area and with for the instructor to signal the start of the round. As before, males may freely give away their sperm while females will choose to use it now or wait for different sperm. When a female decides to fertilize an egg, she will walk to the fertilization area and paperclip the gametes together.
</div></li><li data-sub-note-item="3-5"><div class="lab-step">Proceed with the simulation for two minutes, and at the signal from the instructor all mating activity should stop.
</div></li><li data-sub-note-item="3-6"><div class="lab-step">The instructor should now tally all of the matings from this second round.
</div></li><li data-sub-note-item="3-7"><div class="lab-step">Now, find and return the gametes to your ID holder, and then return the holder to the instructor.
</div></li></ul></li><li data-note-item="4" data-parent-collapse="">Round 3 &#8211; Visible Quality and Attractiveness Scores
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="4-1"><div class="lab-step">For the third simulation, you should again obtain a new clip-on ID holder and check that it contains the appropriate number of gametes. Record the ID number of your clip in table two.
</div></li><li data-sub-note-item="4-2"><div class="lab-step">For this round, leave both attractiveness and quality scores visible on male IDs. Note: The mating simulation process for round three will be the same as the previous two rounds.
</div></li><li data-sub-note-item="4-3"><div class="lab-step">Move to the mating area and wait for the signal to begin the simulation.
</div></li><li data-sub-note-item="4-4"><div class="lab-step">Once the instructor starts the timer and gives the signal, commence mating. As before, males are allowed to freely give away their sperm to females and females may use the sperm immediately or wait for different sperm. Again, fertilized eggs only count if placed in the fertilization area.
</div></li><li data-sub-note-item="4-5"><div class="lab-step">After the two-minute time limit, the instructor should tally all matings.
</div></li><li data-sub-note-item="4-6"><div class="lab-step">Now, find and return the gametes to your ID holder, and then return the holder to the instructor.
</div></li></ul></li><li data-note-item="5" data-parent-collapse="">Round 4 &#8211; Increased Male Parental Care
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="5-1"><div class="lab-step">In the final round, males will again leave their attractiveness and quality scores visible.
</div></li><li data-sub-note-item="5-2"><div class="lab-step">Obtain an ID holder and ensure it contains the appropriate number of gametes.
</div></li><li data-sub-note-item="5-3"><div class="lab-step">Clip on the ID holder and move to the mating area. Note: As before, males may freely give away their sperm to females. However, in this round, once a female chooses to mate with a male, both the male and female will walk to the fertilization area to paperclip their gametes together. After placing the paper-clipped gametes on the table, both male and female actors may return to the mating area.
</div></li><li data-sub-note-item="5-4"><div class="lab-step">The instructor should signal the start of the round and begin the timer &#8211; at this point participants can begin the simulation.
</div></li><li data-sub-note-item="5-5"><div class="lab-step">Once the two-minute time limit is up, all matings must stop.
</div></li><li data-sub-note-item="5-6"><div class="lab-step">The instructor should tally all mating events.
</div></li><li data-sub-note-item="5-7"><div class="lab-step">Find and return the gametes to your ID holder. Give your ID holder to the instructor and notify them if any gametes or supplies are missing.
</div></li></ul></li><li data-note-item="6" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="6-1"><div class="lab-step">To analyze the data generated during the mating activities, first split up into groups of four.
</div></li><li data-sub-note-item="6-2"><div class="lab-step">Collect the class data from the instructor for ONE of the four rounds of mating. Note: In this activity, there were several types of females and males distinguished by different letters. These letter types correspond to specific combinations of quality and attractiveness scores. In the compiled data, the average number of matings and reproductive success has already been sorted by letter type for you by the instructor.
</div></li><li data-sub-note-item="6-3"><div class="lab-step">Use these data to generate four graphs for the round you were assigned. First plot two graphs for the average number of matings against female and male type.
</div></li><li data-sub-note-item="6-4"><div class="lab-step">Then plot the reproductive success for males and females against male or female type, giving a total of four graphs.
</div></li><li data-sub-note-item="6-5"><div class="lab-step">Once these graphs are complete, each group should present their data to the class, making sure to state the original hypothesis for your assigned round and whether or not the hypothesis was upheld.
</div></li><li data-sub-note-item="6-6"><div class="lab-step">After each group presents, discuss the overall results of the four rounds together.
</div></li><li data-sub-note-item="6-7"><div class="lab-step">Note the affect that hiding the quality score had on the overall quality of mates chosen.
</div></li><li data-sub-note-item="6-8"><div class="lab-step">Note how hiding or revealing the attractiveness score affected the results.
</div></li><li data-sub-note-item="6-9"><div class="lab-step">Discuss the effect of male parental investment on the number and overall quality of mating pairs.
</div></li></ul></li></ol>

Sexual Selection Class Simulation
ExpandNote: In this activity, you and your classmates will portray a sexually reproducing population consisting of an ...

Animal Behavior

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Making Choice Chambers
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">Before beginning the experiments, use one of the Sharpies from the lab table to trace a line around the circumference of the bottom of both bottles. One line should be 1 cm from the base of the bottle and the other should be 1.5 cm from the base of the bottle.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">Use a razor blade to make a small cut in each bottle at the mark.
</div></li><li data-sub-note-item="1-3"><div class="lab-step">Then, insert the scissors and carefully cut along the line until the bottoms of the bottles are removed completely.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Fit one bottle bottom into the other.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">Tape the bottles together to make a secure chamber.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">Use the razor blade and scissors to poke a hole into the center of the chamber.
</div></li><li data-sub-note-item="1-7"><div class="lab-step">Take a piece of tape and fold the edge onto itself to make a tab and place the tape over the hole.  Note: The tab helps with easy removal and reattachment of the tape to the chamber.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">Use the Sharpie to label one side of the chamber A and the other side B.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">Upon receiving the colony of <em>Drosophila</em>, perform a count to make sure there are 40 living individuals in the vial.
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Geotaxis
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">To perform a geotaxis assay, first attach a clean, empty bottle cap to each end of the choice chamber and turn the fly vial upside down onto its lid.
</div></li><li data-sub-note-item="2-2"><div class="lab-step">Open the tape flap in the center of the choice chamber.
</div></li><li data-sub-note-item="2-3"><div class="lab-step">Insert the funnel into the hole and tap all of the flies into the chamber. HYPOTHESES: The alternate hypothesis is that more flies will be moving against gravity, or up, regardless of the orientation of the choice chamber. Alternatively, if the flies are positively geotactic, then more flies will move down, or with gravity. The null hypothesis is that the flies will have no preference with regard to gravity and will move randomly within the chamber.
</div></li><li data-sub-note-item="2-4"><div class="lab-step">Once the <em>Drosophila</em> are in the chamber, close the tape flap, rotate the chamber so that it stands vertically with side A on the bottom, and start the timer.
</div></li><li data-sub-note-item="2-5"><div class="lab-step">Immediately, count the number of <em>Drosophila</em> that are moving up and the number that are moving down. Record these data for time point 0 in the table.
</div></li><li data-sub-note-item="2-6"><div class="lab-step">After 30 seconds, rotate the chamber so that side B is on the bottom and count the number of <em>Drosophila</em> that are moving up or down. Record these data for time point 30 in the table.
</div></li><li data-sub-note-item="2-7"><div class="lab-step">After 60 seconds, rotate the chamber so that side A is on the bottom again and record the number of moving flies for time point 60.  <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/15/Table_1_Animal_behavior.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 1</a>
</div></li><li data-sub-note-item="2-8"><div class="lab-step">Hold the chamber over the fly vial and carefully open the cap to return all of the <em>Drosophila</em> back to their empty vial.
</div></li></ul></li><li data-note-item="3" data-parent-collapse="">Phototaxis
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="3-1"><div class="lab-step">To perform a phototaxis analysis, first cover side A of the choice chamber with tin foil, taking care that the foil reaches to the exact center between the two sides.
</div></li><li data-sub-note-item="3-2"><div class="lab-step">Ensure the caps are secured on both ends of the chamber.  HYPOTHESES: In this exercise, the alternative hypothesis is that more flies will be found in the light side of the choice chamber, if the flues are attracted to light, or on the dark side if they are repelled by light. The null hypothesis is that <em>Drosophila</em> will have no preference with regard to either stimulus. Therefore, equal numbers of flies will be found on either side of the choice chamber.
</div></li><li data-sub-note-item="3-3"><div class="lab-step">Open the tape flap in the center of the choice chamber, insert the funnel into the hole, and tap all 40 flies into the chamber as previously described.
</div></li><li data-sub-note-item="3-4"><div class="lab-step">Set the timer to sound an alarm at 10 minutes.
</div></li><li data-sub-note-item="3-5"><div class="lab-step">When the alarm sounds, stop the timer, and count the number of flies in the open side B of the chamber.
</div></li><li data-sub-note-item="3-6"><div class="lab-step">Subtract that number from the total number of flies added to the choice chamber to calculate the number of flies in the covered side A.
</div></li><li data-sub-note-item="3-7"><div class="lab-step">Record these data in the table for time point 10.  <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/15/Table_2_Animal_behavior.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 2</a>
</div></li><li data-sub-note-item="3-8"><div class="lab-step">Carefully, return all of the flies back to their empty vial.
</div></li></ul></li><li data-note-item="4" data-parent-collapse="">Chemotaxis
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="4-1"><div class="lab-step">HYPOTHESES: In this exercise, the alternative hypothesis is that more flies will be found on the side of the chamber with the apple cider vinegar if the flies are attracted to the odor. Or, if the flies are repelled by the vinegar, then more of them will be found on the side of the chamber presenting the odorless water. The null hypothesis is that <em>Drosophila</em> will have no preference with regard to either stimulus and will move randomly in the chamber.  Use an individual disposable plastic pipette to dispense two drops of the apple cider vinegar onto one cotton ball for side A of the chamber.
</div></li><li data-sub-note-item="4-2"><div class="lab-step">Use an individual disposable plastic pipette to dispense two drops of the distilled water onto a cotton ball for side B of the chamber.
</div></li><li data-sub-note-item="4-3"><div class="lab-step">Fold two pieces of tape over themselves to create individual pieces of double-sided tape and use the tape to attach each cotton ball to the inside of the single bottle cap.
</div></li><li data-sub-note-item="4-4"><div class="lab-step">Screw the bottle caps with the cotton balls onto their corresponding sides of the chamber.
</div></li><li data-sub-note-item="4-5"><div class="lab-step">Transfer all of the flies into the chamber and set the timer to sound an alarm after 10 minutes.
</div></li><li data-sub-note-item="4-6"><div class="lab-step">When the alarm sounds, stop the timer and record the number of flies in each side of the chamber. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/15/Table_3_Animal_behavior.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 3</a>
</div></li><li data-sub-note-item="4-7"><div class="lab-step">At the end of the final experiment, funnel the flies into a morgue tube containing 70% ethanol.
</div></li><li data-sub-note-item="4-8"><div class="lab-step">Dismantle the choice chambers for recycling.  NOTE: Since all of the chemicals used in these experiments are lab safe, the liquids can be disposed of down the sink, the chambers rinsed, and the solids can be thrown away in the trash.
</div></li></ul></li><li data-note-item="5" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="5-1"><div class="lab-step">Gather all of the data collected for the geotaxis, phototaxis, and chemotaxis experiments.
</div></li><li data-sub-note-item="5-2"><div class="lab-step">Plot these values as bar graphs for different conditions and different time points.
</div></li><li data-sub-note-item="5-3"><div class="lab-step">Use these data to draw inferences about the behavior of <em>drosophila melanogaster</em>.
</div></li></ul></li></ol>

Animal Behavior: Studying Taxis Behavior of Drosophila - Procedure

Making Choice Chambers
ExpandBefore beginning the experiments, use one of the Sharpies from the lab table to trace a line around the circumference of the ...

Artificial Selection

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Observing Artificial Selection in Plants
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">To begin the experiment, collect five two-week old grown plants from the generation one population that appear healthy. Note: Plants should appear green, not wilted, and not have damaged leaves. Experimental Hypothesis: The experimental hypothesis for this lab might be that the number of lead trichomes varies naturally, but the average number will increase over generations if only plants with the highest number of trichomes are interbred or decrease if those with the least are interbred. Null Hypothesis: The null hypothesis might be that the average number of trichomes will not change over subsequent generations after artificial selection.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">Label each plant with a letter from A to E and with both partners&#8217; names.
</div></li><li data-sub-note-item="1-3"><div class="lab-step">Record any natural differences you see between your plant samples. Note: All of the plants are the same age, so any observed variation is due to expressed phenotype, not development.
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Use a hand lens to count the number of trichomes found on the petiole of the lowest leaf, not including the round, first-grown cotyledons for each plant. Note: It can be helpful to shine a light onto the plant and to hold it against a dark background, such as a lab bench, during the trichome analysis.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">Both partners will conduct counts on each plant independently and compare answers. If the counts are different, enlist a third counter or take the average of the two results.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">After this, determine the median number of trichomes for the entire class.  <a target="__blank" style="display:block;padding:20px;" href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/2/Lab_2_Table_A.xlsx">Click Here to download Table A</a>
</div></li><li data-sub-note-item="1-7"><div class="lab-step">Determine the top and bottom 10% of the plants from the class trichome count. These groups will make up the two artificially selected lines: high hairiness and low hairiness, respectively.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">If more than 10% of the plants have no trichomes, select 10% of those plants randomly for the low hairiness plant line.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">Separate the two groups of selected plants and label them clearly.
</div></li><li data-sub-note-item="1-10"><div class="lab-step">Move the plants to a well-lit area and keep them well watered until they develop flowers. Note: Flowers typically develop around 14 days.
</div></li><li data-sub-note-item="1-11"><div class="lab-step">When the flowers are fully developed, use a pollination wand or paintbrush to rub the stigma and anther of one plant&#8217;s flowers for a few seconds.
</div></li><li data-sub-note-item="1-12"><div class="lab-step">Using the same wand or brush, rub the inside of each flower of every other plant in the same selection line.
</div></li><li data-sub-note-item="1-13"><div class="lab-step">Using a different wand or brush, repeat steps 11 through 12 on the other line. Note: Take care not to cross the lines. Spread the pollen only among the appropriately selected plants.
</div></li><li data-sub-note-item="1-14"><div class="lab-step">Return the generation one plants to the growing areas. When the plants reach approximately 1 month old, they should produce mature seed pods.
</div></li><li data-sub-note-item="1-15"><div class="lab-step">Allow the plants to dry out once the seed pods turn yellow.
</div></li><li data-sub-note-item="1-16"><div class="lab-step">Break the seed pods open and collect the seeds.
</div></li><li data-sub-note-item="1-17"><div class="lab-step">Obtain new pots for the generation two seeds.
</div></li><li data-sub-note-item="1-18"><div class="lab-step">Fill the pots with moist potting soil about halfway and add a fertilizer pellet to each pot.
</div></li><li data-sub-note-item="1-19"><div class="lab-step">Fill the pots with more soil to fill just below the lip.
</div></li><li data-sub-note-item="1-20"><div class="lab-step">Make a shallow depression in the soil of each pot with a probe.
</div></li><li data-sub-note-item="1-21"><div class="lab-step">Touch a clean toothpick to a gluestick and use the toothpick to transplant the seeds into the soil one by one.
</div></li><li data-sub-note-item="1-22"><div class="lab-step">Cover the seeds with a thin layer of soil.
</div></li><li data-sub-note-item="1-23"><div class="lab-step">Label the pots with their hairiness line and place them in the designated growing area.
</div></li><li data-sub-note-item="1-24"><div class="lab-step">Use a plastic dropper to water the plants as needed to ensure they do not dry out.
</div></li><li data-sub-note-item="1-25"><div class="lab-step">When the plants are two weeks old, collect five plants from each line and label them A to E.
</div></li><li data-sub-note-item="1-26"><div class="lab-step">Then, count the trichomes on these plants as previously described (steps 4- 5).
<a target="__blank" style="display:block;padding:20px;" href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/2/Lab_2_Table_B.xlsx">Click Here to download Table B</a>
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Data Analysis
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">Create a frequency graph based on the generation one class data with the trichome count on the x axis and the number of plants on the y axis. Label the mean.
</div></li><li data-sub-note-item="2-2"><div class="lab-step">Then, create frequency graphs for both of the selected hairiness lines.
</div></li><li data-sub-note-item="2-3"><div class="lab-step">Compare the frequency graphs for generation one and both hairiness lines.
</div></li><li data-sub-note-item="2-4"><div class="lab-step">Take note of phenotypic shifts observed in the selected hairiness lines.
</div></li></ul></li></ol>

Artificial Selection: Visualization in Plants and Data Analysis - Procedure

Observing Artificial Selection in Plants
ExpandTo begin the experiment, collect five two-week old grown plants from the generation one population that ...

Evolution

Animal Diversity

<ol class="note-items"><li data-note-item="1" data-parent-collapse="">Form and Function of Crickets and Crayfish
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="1-1"><div class="lab-step">NOTE: To observe the relationship between form and function in animals, you will be examining and dissecting a cricket and a crayfish. Each pair of students will receive one of each of these organisms. When dissecting, be sure to wear gloves, closed-toed shoes, and safety goggles. Take care when handling dissecting tools, as they may be sharp. HYPOTHESES: In this experiment, the experimental hypothesis could be that the cricket and crayfish have similar body structures because they are both arthropods, but that they will have some specific adaptations for their different habitats and lifestyles. The null hypothesis might be that the cricket and crayfish have identical adaptations and body plans.
</div></li><li data-sub-note-item="1-2"><div class="lab-step">To begin, place the cricket on its back and observe its appendages.
</div></li><li data-sub-note-item="1-3"><div class="lab-step">In Table 1, make detailed notes about your observations and try to predict the potential function of each of the forms you observe. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/27/Table_1_Animal_Diversity.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 1</a>
</div></li><li data-sub-note-item="1-4"><div class="lab-step">Do the same with the wings of the cricket if they are present.
</div></li><li data-sub-note-item="1-5"><div class="lab-step">Consider how the structure of the wings benefits the cricket.
</div></li><li data-sub-note-item="1-6"><div class="lab-step">If the cricket does not have wings, consider the reasons behind their absence.
</div></li><li data-sub-note-item="1-7"><div class="lab-step">If the cricket is female, it will have an ovipositor. This can be observed as a long dark tube protruding from the posterior end and it is used to deposit eggs.
</div></li><li data-sub-note-item="1-8"><div class="lab-step">Consider why the ovipositor is useful.
</div></li><li data-sub-note-item="1-9"><div class="lab-step">Next, flip the cricket over onto its back and observe the mouth parts under a microscope. NOTE: Use a probe to move structures when necessary.
</div></li><li data-sub-note-item="1-10"><div class="lab-step">Make a hypothesis about the size and type of prey the cricket consumes based upon your observations.
</div></li><li data-sub-note-item="1-11"><div class="lab-step">Continue to examine the external parts of the cricket, making hypotheses about their function until you have filled at least five rows in the table with your observations.
</div></li><li data-sub-note-item="1-12"><div class="lab-step">Using tweezers to hold the cricket down, carefully remove the wings and legs from the body with the scissors.
</div></li><li data-sub-note-item="1-13"><div class="lab-step">Next, position the body of the cricket so that its underside is facing down.
</div></li><li data-sub-note-item="1-14"><div class="lab-step">Again with the scissors, cut the thin outer exoskeleton from the anus to the head trying not to damage any of the organs underneath.
</div></li><li data-sub-note-item="1-15"><div class="lab-step">Use the tweezers to open the incision and dissecting pins to hold open the exoskeleton.
</div></li><li data-sub-note-item="1-16"><div class="lab-step">Next, use the water pitcher to carefully add water to the Petri dish until it reaches just below the top edge. This should make the exposed organs of the cricket easier to see.
</div></li><li data-sub-note-item="1-17"><div class="lab-step">Move the Petri dish to the stage of the dissecting microscope and turn on the light.
</div></li><li data-sub-note-item="1-18"><div class="lab-step">Use the cricket figure as a reference and observe the organs under the dissecting microscope. Where necessary, use the probe to move organs that may be blocking others.
</div></li><li data-sub-note-item="1-19"><div class="lab-step">Identify as many internal structures as possible and fill out the form and predicted function for at least three internal structures.
</div></li><li data-sub-note-item="1-20"><div class="lab-step">Next, you&#39;ll observe the outer and inner structures of the crayfish. Begin with the crayfish on its back and observe the appendages.
</div></li><li data-sub-note-item="1-21"><div class="lab-step">In Table 1, take notes about the structures you notice.
</div></li><li data-sub-note-item="1-22"><div class="lab-step">Observe the tail. Devise a hypothesis for its jointed structure. Consider how a crayfish moves in its environment.
</div></li><li data-sub-note-item="1-23"><div class="lab-step">Next, with the crayfish still on its back, look for the swimmerets under its tail.  NOTE: If the crayfish is male, the swimmerets nearest the legs are long extending between the legs. These are specialized reproductive structures that transfer sperm to the female. Females do not have these long structures, but instead have swimmerets that store developing embryos.
</div></li><li data-sub-note-item="1-24"><div class="lab-step">Consider the benefits of this strategy. Be sure to observe both a male and female crayfish, checking with neighboring students to identify these structures.
</div></li><li data-sub-note-item="1-25"><div class="lab-step">Next, observe the mouth parts of your crayfish using a probe.
</div></li><li data-sub-note-item="1-26"><div class="lab-step">Based on these structures, make a hypothesis about the size and type of prey you think crayfish consume.
</div></li><li data-sub-note-item="1-27"><div class="lab-step">Before beginning the dissection, be sure to fill in Table 1 with at least five external structures you observed in the crayfish along with their predicted function. With the organism lying legs down, use scissors to cut an incision in the exoskeleton from the tail to between the eyes. Take care to not disturb the organs underneath.
</div></li><li data-sub-note-item="1-28"><div class="lab-step">Next, remove the carapace as demonstrated in the video.
</div></li><li data-sub-note-item="1-29"><div class="lab-step">Open the tail and use the pins to secure the exoskeleton down to the dissecting tray exposing the organs.
</div></li><li data-sub-note-item="1-30"><div class="lab-step">Observe the organs first with the naked eye. Use the figure to identify the different body parts of the animal.
</div></li><li data-sub-note-item="1-31"><div class="lab-step">Then, if there is enough space on the stage, place the dissecting tray with the crayfish under the dissecting microscope to view these structures more closely.
</div></li><li data-sub-note-item="1-32"><div class="lab-step">Fill out at least three rows of Table 1 with these observations and predicted functions of internal structures in the crayfish.
</div></li></ul></li><li data-note-item="2" data-parent-collapse="">Results
<button class="expand">Expand</button><ul class="lab-items"><li data-sub-note-item="2-1"><div class="lab-step">To analyze the data, first separate into groups. Within your groups, compare observations from your tables.
</div></li><li data-sub-note-item="2-2"><div class="lab-step">Using these observations, create class predictions that relate the observed forms to the hypothesized functions for both the cricket and the crayfish. As a group, fill out Table 2 with at least five of these predictions and discuss how you would go about testing these hypotheses. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/27/Table_2_Animal_Diversity.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 2</a>
</div></li><li data-sub-note-item="2-3"><div class="lab-step">Compare the internal and external structures you observed in the cricket and crayfish. Fill out Table 3 with similarities and differences you noticed in the structures of these organisms. <a href="https://www-jove-com.bdigitaluss.remotexs.co/CDNSource/lm/labs/27/Table_3_Animal_Diversity.xlsx" style="display:block;margin:20px;" target="__blank">Click Here to download Table 3</a>
</div></li></ul></li></ol>
