1. Fabrication of a PDMS Microfluidic Platform
<ol>
	<li>Prepare 20 mL of liquid PDMS prepolymer by mixing base polymer and catalyst in a volume ratio of 10:1. Pour 10 mL of the liquid PDMS onto a prepared SU-8 mold on a silicon wafer for the upper part of the microfluidic network. For the bottom flat part, pour the same volume of liquid PDMS on the silicon wafer without a mold structure.
	Note: The microfluidic network is designed in a CAD program and then converted into a photomask in order to fabricate a master using the typical photolithography process (See Supplemental Figures). This master is comprised of the negative photoresist SU-8 mold on the silicon wafer11.</li>
	<li>Place two silicon wafers coated with liquid PDMS prepolymer on the hot plate and cure at 75 &#176;C for 30 min.
	<ol>
		<li>Manually peel off the cured PDMS layer from the SU-8 mold. Align a 1.5 mm diameter round hole punching tool to the oil port on the replicated microfluidic network for interfacing micron-scale flow channels with the macro fluid samples. Punch out the through-hole manually.</li>
		<li>Repeat this punching process three times for the formation of the two solutions and the outlet port.</li>
	</ol>
	</li>
	<li>Perform hydrophilic surface treatment on both the upper and bottom PDMS layers using a hand-held corona treater12 for several seconds per sample.
	<ol>
		<li>Stack two plasma-treated PDMS layers and heat at 90 &#176;C for 30 minutes using a hot plate for the PDMS-to-PDMS bonding process. Supply the pressurized water using the syringe pump into three inlet ports for the structural bonding and leakage testing of the fabricated device.</li>
	</ol>
	</li>
</ol>
2. Production of Polyacrylamide Oligo-Microspheres
<ol>
	<li>Prepare bead-mixture detailed in Table 1.</li>
	<li>Vortex and briefly centrifuge the standard ssDNA acrydite labeled probe (Ap, 100 &#956;M) and acrylamide:bis (19:1) stock solution.</li>
	<li>Prepare solution I by mixing 25 &#956;L of 40% acrylamide bis solution, 10 &#956;L of ssDNA (acrydite probe), 10 &#956;L of 5x TBE buffer (1.1 M Tris; 900 mM borate; 25 mM EDTA), and 5 &#956;L of water. Prepare solution II with 50 &#956;L of 20% ammonium persulfate.</li>
	<li>Prepare two syringes individually filled with solution I and solution II, and mount them onto the pump to introduce solution flows into the microfluidic platform. Prepare mineral oil mixed with 0.4% TEMED for surface solidification of the microsphere.
	Note: TEMED is well-known as a free radical stabilizer. Free radicals can accelerate the rate of polymer formation with ammonium persulfate (APS) in order to catalyze acrylamide polymerization.</li>
	<li>Fill a glass bottle with 4 mL of the mineral oil to generate a continuous flow.</li>
	<li>Insert two tubes to two ports in the cap of the glass bottle as a microfluidic reservoir: the pneumatic port for applying the compressed air into the glass bottle from the air compressor and the fluid port for supplying the pressurized oil to the micro channel network from the glass bottle. Connect tubes between the glass bottle and the oil port in the microfluidic device.
	<ol>
		<li>Connect the tubes to the two solution ports in the microfluidic device in order to supply the two solutions from the syringe pumps. Insert tubes to the outlet port in order to transfer the generated microsphere into the beaker.</li>
	</ol>
	</li>
	<li>Set the flow rate of the syringe pump to 0.4 - 0.7 mL/h. Adjust compressed air pressure of the compressor using a regulator (82 - 116 kPa). Set the rotational speed (500 rpm) of the magnetic stirrer bar in the glass beaker on a hot plate. Operate the syringe pump and supply the compressed air generated by an external compressor into the glass bottle using the ON/OFF control of an electromagnetic valve13.</li>
	<li>Observe the formation of microspheres in the flow-focusing geometry and solidification of generated microspheres in the glass beaker with a digital microscope.
	Note: The size and production speed of the microsphere depend on the flowrate of solutions and the pressure applied for the mineral oil flow (Table 2).</li>
</ol>
3. Performing Polyacrylamide Oligo-Microspheres Counts
<ol>
	<li>For hemocytometer quantification, take a small amount (approximately 100 &#956;L) of aqueous solution of polyacrylamide oligo-microspheres and place on the glass hemocytometer, and gently fill the microsphere suspension up the well of the counting chamber.
	Note: For further details, see http://www.abcam.com/protocols/counting-cells-using-a-haemocytometer.</li>
	<li>Use a microscope and hand tally counter to count microspheres in one set of 16 squares. Then, move the hemocytometer to the next set of the chamber and carry on counting until all four sets of 16 corners are counted.</li>
	<li>Determine the average microsphere count and calculate the number of microspheres in the original bead suspension.</li>
	<li>Transfer 100 &#956;L of microspheres to a 1.5 mL microcentrifuge tube. Remove the supernatant through gentle centrifuging (400 x g) and pipetting.</li>
</ol>
4. Performing DNA Hybridization on the Surface of Polyacrylamide Oligomicrosphere
Note: An identical DNA probe with a 5&#8217;-NH2-group instead of 5&#8217;-acrytide modification is added into solution I and tested for Ap-containing microspheres in parallel. DNA hybridization results are shown in Figure 2. The Cy3-labeled complementary oligonucleotide probes (cAp) solution should be placed in a dark room.
<ol>
	<li>Resuspend Cy3-cAp using 100 &#956;L of 1xTE buffer (TE buffer: 10 mM Tris and 1&#956;M EDTA, pH 8.0) in order to achieve a final concentration of 100 &#956;M. For example, resuspend 1 pmol of cAp in 100 mL of TE buffer and transfer to a microcentrifuge tube covered with aluminum foil.
	Note: For strand sequences, see Table 3.</li>
	<li>Add 100 &#956;M of Cy3-cAp to a sterile 1.5 mL microcentrifuge tube containing Ap-copolymerized microspheres.</li>
	<li>Tap the tube a few times to mix and incubate at room temperature in the dark for 1 h.</li>
	<li>Discard the supernatant and remove residual buffer through pipetting.</li>
	<li>Rinse three times with 500 &#956;L of TE buffer.</li>
	<li>Resuspend microspheres by gently tapping the microcentrifuge tube. Then, repeat step 4.4.</li>
	<li>Place microspheres on the glass slide (75 mm x 50 mm) and cover with aluminum foil prior to imaging.</li>
</ol>
5. Asymmetric PCR for Amplifying ssDNA
<ol>
	<li>Prepare an asymmetric PCR reagent mix for amplifying ssDNA to be analyzed. Thaw the reagents in Table 4 on ice. Do not keep the Taq polymerase enzyme (50 U/&#181;L) on ice, but rather store it at -20 &#176;C until needed.</li>
	<li>Gently vortex all reagents and then briefly centrifuge tubes at 10,000 x g for 10 s.</li>
	<li>Combine all reagents as described in Table 4.</li>
	<li>Place samples into a thermocycler and start the asymmetric PCR under the following conditions: 25 cycles (95 &#176;C for 30 s, 52 &#176;C for 30 s, and 72 &#176;C for 30 s), 85 &#176;C for 5 min, hold at 4 &#176;C.</li>
</ol>
6. Microsphere-PCR for Amplifying ssDNA
Note: This section describes the protocol for amplifying ssDNA in a PCR reaction tube. Microsphere-PCR reactions were performed in 50 &#956;L of reaction volume. The detailed sequences used to amplify ssDNA are listed in Table 5. In this case, Ap on the surface of microspheres can anneal to random DNA templates in a complementary manner. This is a very important step for producing complementary DNA strands (antisense DNA strand, Figure 3). The DNA extended is used as a template for microsphere-PCR amplification.
<ol>
	<li>Prepare microsphere-PCR reagent mix. Thaw the reagents in Table 6 on ice; however, do not keep the Taq polymerase enzyme on ice. Store it at -20 &#176;C until needed.</li>
	<li>Gently vortex all reagents and then briefly centrifuge tubes at 10,000 x g for 10 s.</li>
	<li>Obtain approximately ~25 microspheres through microscopic counting.
	Note: The number of microspheres in one reaction tube are calculated using a light microscope with 40X magnification. About ~25 microspheres are used for microsphere-PCR amplification. More detailed information is in Step 3.</li>
	<li>Combine all reagents as described in Table 6.</li>
	<li>Place samples into a thermocycler and start the asymmetric PCR under the following conditions: 25 cycles (95 &#176;C for 30 s, 52 &#176;C for 30 s, and 72 &#176;C for 30 s), 85 &#176;C for 5 min, hold at 4 &#176;C.</li>
	<li>Following amplification, add 8 &#956;L of 6x loading buffer and load 15 &#956;L of each sample into 2% agarose gel. Then, perform electrophoresis at 100 V for 35 min in 1x TAE (Tris-acetate-EDTA, 40 mM Tris acetate, 1 mM EDTA, pH 8.2) buffer.</li>
</ol>
7. Confocal Microscopy Acquisition
Note: The results of microsphere-DNA probe hybridization are imaged under a confocal microscope. Image analysis is performed using ImageJ.
<ol>
	<li>Fix hybridized microspheres to the stage of the microscope in a holder.</li>
	<li>Select the laser (Helium/Neon laser, 543 nm line) and turn it on in laser control.</li>
	<li>Select the objective lens in microscope control.</li>
	<li>Select the desired filter for Cy3 and channel in configuration control.</li>
	<li>Start the experiment and observe the sample. Settings for the confocal microscope are summarized in Table 7.</li>
</ol>

<ol>
	<li>Smith, A. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+use+of+exonuclease+III+for+preparing+single+stranded+DNA+for+use+as+a+template+in+the+chain+terminator+sequencing+method.">The use of exonuclease III for preparing single stranded DNA for use as a template in the chain terminator sequencing method.</a> Nucleic Acids Research. 6 (3), 831-848 (1979).</li><li>Sekhon, S. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Aptabody-aptatope+interactions+in+aptablotting+assays.">Aptabody-aptatope interactions in aptablotting assays.</a> Nanoscale. 9 (22), 7464-7475 (2017).</li><li>Ng, J. K., Ajikumar, P. K., Stephanopoulos, G., Too, H. P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Profiling+RNA+polymerase-promoter+interaction+by+using+ssDNA-dsDNA+probe+on+a+surface+addressable+microarray.">Profiling RNA polymerase-promoter interaction by using ssDNA-dsDNA probe on a surface addressable microarray.</a> Chembiochem. 8 (14), 1667-1670 (2007).</li><li>Sekhon, S. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Defining+the+copper+binding+aptamotif+and+aptamer+integrated+recovery+platform+(AIRP).">Defining the copper binding aptamotif and aptamer integrated recovery platform (AIRP).</a> Nanoscale. 9 (8), 2883-2894 (2017).</li><li>Mikhailov, V. S., Bogenhagen, D. F. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Effects+of+Xenopus+laevis+mitochondrial+single-stranded+DNA-binding+protein+on+primer-template+binding+and+3'--&gt;5'+exonuclease+activity+of+DNA+polymerase+gamma.">Effects of Xenopus laevis mitochondrial single-stranded DNA-binding protein on primer-template binding and 3'--&gt;5' exonuclease activity of DNA polymerase gamma.</a> Journal of Biological Chemistry. 271 (31), 18939-18946 (1996).</li><li>Yu, X., Cheng, G., Zhou, M. D., Zheng, S. Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=On-demand+one-step+synthesis+of+monodisperse+functional+polymeric+microspheres+with+droplet+microfluidics.">On-demand one-step synthesis of monodisperse functional polymeric microspheres with droplet microfluidics.</a> Langmuir. 31 (13), 3982-3992 (2015).</li><li>Akamatsu, K., Kanasugi, S., Nakao, S., Weitz, D. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane-Integrated+Glass+Capillary+Device+for+Preparing+Small-Sized+Water-in-Oil-in-Water+Emulsion+Droplets.">Membrane-Integrated Glass Capillary Device for Preparing Small-Sized Water-in-Oil-in-Water Emulsion Droplets.</a> Langmuir. 31 (25), 7166-7172 (2015).</li><li>Lee, S. H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=On-Flow+Synthesis+of+Co-Polymerizable+Oligo-Microspheres+and+Application+in+ssDNA+Amplification.">On-Flow Synthesis of Co-Polymerizable Oligo-Microspheres and Application in ssDNA Amplification.</a> PLoS One. 11 (7), e0159777 (2016).</li><li>Anna, S. L., Bontoux, N. B., Stone, H. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Formation+of+dispersions+using+&amp;#34;flow+focusing&amp;#34;+in+microchannels.">Formation of dispersions using &amp;#34;flow focusing&amp;#34; in microchannels.</a> Applied Physics Letters. 82 (3), 364-366 (2003).</li><li>Gupta, A., Matharoo, H. S., Makkar, D., Kumar, R. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Droplet+formation+via+squeezing+mechanism+in+a+microfluidic+flow-focusing+device.">Droplet formation via squeezing mechanism in a microfluidic flow-focusing device.</a> Computers &amp; Fluids. 100, 218-226 (2014).</li><li>McDonald, J. C., Whitesides, G. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Poly(dimethylsiloxane)+as+a+material+for+fabricating+microfluidic+devices.">Poly(dimethylsiloxane) as a material for fabricating microfluidic devices.</a> Accounts of Chemical Research. 35 (7), 491-499 (2002).</li><li>Haubert, K., Drier, T., Beebe, D. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=PDMS+bonding+by+means+of+a+portable,+low-cost+corona+system.">PDMS bonding by means of a portable, low-cost corona system.</a> Lab on a Chip. 6 (12), 1548-1549 (2006).</li><li>Olsen, T. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Integrated+Microfluidic+Selex+Using+Free+Solution+Electrokinetics.">Integrated Microfluidic Selex Using Free Solution Electrokinetics.</a> Journal of the Electrochemical Society. 164 (5), B3122-B3129 (2017).</li><li>Dorris, D. R., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Oligodeoxyribonucleotide+probe+accessibility+on+a+three-dimensional+DNA+microarray+surface+and+the+effect+of+hybridization+time+on+the+accuracy+of+expression+ratios.">Oligodeoxyribonucleotide probe accessibility on a three-dimensional DNA microarray surface and the effect of hybridization time on the accuracy of expression ratios.</a> BMC Biotechnology. 3, 6 (2003).</li><li>Heiat, M., Ranjbar, R., Latifi, A. M., Rasaee, M. J., Farnoosh, G. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Essential+strategies+to+optimize+asymmetric+PCR+conditions+as+a+reliable+method+to+generate+large+amount+of+ssDNA+aptamers.">Essential strategies to optimize asymmetric PCR conditions as a reliable method to generate large amount of ssDNA aptamers.</a> Biotechnology and Applied Biochemistry. 64 (4), 541-548 (2017).</li></ol>

The authors have no conflicts of interest to disclose.

Contaminants of dsDNA are a major issue in ssDNA amplification. It remains difficult to minimize dsDNA amplification in conventional asymmetric PCR amplification15. In addition, although technical improvements for generating ssDNA have enabled us to increase the efficiency of sample throughput, ssDNA isolation is still problematic due to its high costs and incomplete purification yields.
Asymmetric PCR is one of the most challenging methods used when working with ssDNA. This method applies unequal amounts of primer (e.g., 20: 1 ratio) in order to generate large amounts of ssDNA. However, it is very difficult to optimize every amplification reaction to yield ssDNA. Thus, the byproducts (dsDNA) must be eliminated from the resultants4.
In order to generate ssDNA without additional separation steps, we produced polyacrylamide microspheres to expose DNA probes based on the acrydite copolymerization method. Our DNA attachment method was easily adapted by using a droplet-based microfluidic platform. Copolymerized oligomicrospheres having microscale diameters were successfully produced. Consequently, microsphere-PCR was used to amplify the ssDNA in a single-tube reaction. Of course, to adapt this procedure for other PCR experiments, commonly necessary adjustments (e.g., changing the amplification cycle, annealing temperature, and template sequences) are required. In conclusion, microsphere-PCR has been detailed here, making it available for bioassay development, DNA sequencing, and DNA microarray analysis.

Single-stranded DNA (ssDNA) has been extensively considered as a molecular recognition element (MRE) due to its intrinsic properties for DNA-DNA hybridization1,2. The development of ssDNA synthetic systems can lead to biological applications such as DNA microarrays3, oligotherapeutics, diagnostics, and integrated molecular sensing based on complementary interactions4,5.
To date, micrometer-scale polymer particles have been successfully demonstrated using microfluidic devices. Several microfluidic techniques have been proven to be powerful for producing highly homogenous microspheres on continuous flow in the microchannel environment6,7.
In the study of Lee et al.8, a droplet-based microfluidic platform for the microfluidic synthesis of copolymerizable oligo-microsphere and ssDNA amplification was reported. The microfluidic platform consists of two PDMS (polydimethylsiloxane) layers: an upper part with a microfluidic channel network for generating microsphere and a bottom flat part. These consist of three kinds of PDMS fluidic channels: 1) a flow focusing channel for droplet generation, 2) a serpentine channel for mixing two solutions, and 3) a sequential polymerization channel for microsphere solidification. Once two immiscible flows are introduced into a single PDMS fluidic channel, the flows can be forced through the narrow orifice structure. The flow behaviors such as channel geometry, flow-rate, and viscosity affect the size and morphology of the microsphere. Therefore, the main liquid stream can be divided into microscale monospheres9,10.
Here, a detailed microsphere-PCR protocol is provided for the amplification of ssDNA. First, a droplet-based microfluidic device design process is described. Then, the way in which polyacrylamide microspheres can be functionalized with random DNA template in a complementary manner is explained. Finally, a microsphere-PCR protocol for amplifying ssDNA is shown.

<table><tbody><tr><td>liquid polydimethylsiloxane, PDMS</td><td>Dow Corning Inc.</td><td>Sylgard 184</td><td>Components of chip</td></tr><tr><td>40% Acrylamide:bis solution (19:1)</td><td>Bio-rad</td><td>1610140</td><td>Components of Copolymerizable oligo-microsphere</td></tr><tr><td>Ammonium persulfate, APS</td><td>Sigma Aldrich</td><td>A3678</td><td>Hardener of acrylamide:bis solution</td></tr><tr><td>N,N,N&amp;prime;,N&amp;prime;-Tetramethylethylenediamine, TEMED</td><td>Sigma Aldrich</td><td>T9281</td><td>Catalyst of ammonium persulfate</td></tr><tr><td>Mineral oil</td><td>Sigma Aldrich</td><td>M5904</td><td>Table 1. Solution III. Component of microsphere reagents</td></tr><tr><td>Cy3 labeled complementary oligonucleotide probes</td><td>Bioneer</td><td>synthesized</td><td>Table 3. Sequence information&amp;nbsp;</td></tr><tr><td>ssDNA acrydite labeled probe</td><td>Bioneer</td><td>synthesized</td><td>Table 1. Solution I. Component of microsphere reagents</td></tr><tr><td>Tris</td><td>Biosesang</td><td>&amp;nbsp;T1016</td><td>Components of TE buffer, pH buffer solution</td></tr><tr><td>EDTA</td><td>Sigma Aldrich</td><td>EDS</td><td>Components of TE buffer, removal of ion (Ca&lt;sup&gt;2+&lt;/sup&gt;)</td></tr><tr><td>Ex taq</td><td>Takara</td><td>RR001A</td><td>ssDNA amplification</td></tr><tr><td>Confocal microscope&amp;nbsp;</td><td>Carl Zeiss</td><td>LSM 510</td><td>Identifying oligonucleotides expossure of microsphere surface</td></tr><tr><td>Light Microscope</td><td>Nikon Instruments Inc.</td><td>eclipse 80i</td><td>Caculating number of microspheres</td></tr><tr><td>T100 Thermal Cycler</td><td>Bio-rad</td><td>1861096</td><td>ssDNA amplification</td></tr><tr><td>Hand-held Corona Treater</td><td>Electro-Technic</td><td>BD-20AC Laboratory Corona Treater</td><td>Hydrophilic surface treatment</td></tr><tr><td>Hot plate</td><td>As one</td><td>HI-1000</td><td>heating plate for curing of liquid PDMS</td></tr><tr><td>Syringe pump</td><td>kd Scientific</td><td>78-1100</td><td>Uniform flow of Solution I and Solution II</td></tr><tr><td>Compressor</td><td>Kohands</td><td>KC-250A</td><td>Flow control of Solution III</td></tr><tr><td>Bright-Line Hemacytometer</td><td>Sigma Aldrich</td><td>Z359629</td><td>Caculating number of microspheres</td></tr></tbody></table>

a droplet-based microfluidic approach and microsphere-pcr amplification for single-stranded dna amplicons

Droplet-based microfluidics enable the reliable production of homogeneous microspheres in the microfluidic channel, providing controlled size and morphology of the obtained microsphere. A microsphere copolymerized with an acrydite-DNA probe was successfully fabricated. Different methods such as asymmetric PCR, exonuclease digestion, and isolation on streptavidin-coated magnetic beads can be used to synthesize single-stranded DNA (ssDNA). However, these methods cannot efficiently use large amounts of highly purified ssDNA. Here, we describe a microsphere-PCR protocol detailing how ssDNA can be efficiently amplified and separated from dsDNA simply by pipetting from a PCR reaction tube. The amplification of ssDNA can be applied as potential reagents for the DNA microarray and DNA-SELEX (Systematic evolution of ligands by exponential enrichment) processes.

The fabricated polymeric droplet-based microfluidic platform consists of two PDMS layers (Figure 1a). Three kinds of microfluidic channel networks are used for generating microspheres: 1) Flow-focusing geometry as shown in Figure 1b, 2) a serpentine channel for mixing solution I and solution II, and 3) a polymerization channel for microsphere solidification. The height of all channels was 60 &#956;m. The channel length for mixing and polymerization were 74.35 mm and 94.45 mm, respectively. The widths of the microchannel for two immiscible fluid flows and the one for mineral oil flow were 100 &#956;m and 200 &#956;m, respectively. The orifice structure used for microsphere formation was of 50 &#956;m length and 25 &#956;m width. The angle of the diffuser structure was 37&#176;. A lab-based pneumatic control system for continuous flow of the mineral oil and two syringe-pumps for the solution flow (Figure 1c) were used for generating microspheres in the microfluidic platform (Figure 1d). The production speed of microspheres was about 30 microspheres per second when the flow rate of solutions and applied pressure were at 0.6 mL/h and 108 kPa, respectively (Table 2). Its diameter in the micro channel is 78.7 &#177; 2.5 &#956;m. The on-flow synthesis of microspheres can be successfully manipulated using the microfluidic device. Bead sizes were measured after swelling. The average diameter of the resulting microspheres was 150.4 &#177; 12.8 &#956;m. The size variations were about 8.5%. The microspheres undergo swelling in water, resulting in an enormous size increase.
The copolymerizable property of microsphere can be varied. We incorporated a 5&#39;-acrydite-DNA probe into the microsphere solution (solution I, see Table 1). Following co-polymerization, a complementary DNA probe is labeled with fluorescent dye, Cy3, at room temperature for 1 h. Confocal microscopy can be used to prove the synthesis of copolymerizable oligomicrospheres as well as functional hybridization on the surface of microspheres. Fluorescent images of the microsphere are shown in Figure 2. If microspheres are correctly functionalized with the 5&#39;-acrydite-DNA probe, they should result in coverage of fluorescent activity on the surface during the hybridization experiment. If copolymerization did not occur correctly, the optical microsphere image would exhibit internal-contamination inside the microspheres. As shown in Figure 2, there is no interference of random-interior orientation. This result allowed us to carry out the DNA probe presentation in a 3-dimensional (3-D) arrangement and microsphere-PCR. It should be noted that an identical DNA probe with a 5&#39;-NH2-group instead of a 5&#39;-acrytide modification did not copolymerize during on-flow synthesis of microsphere8.
When working with microspheres, manipulating the 3-D surface with a DNA oligo-probe is a much faster process14. Therefore, an on-flow microsphere synthesis platform can provide a tool for ssDNA amplification and purification, as outlined in Figure 3. The anti-sense DNA template (-, complementary template) can be extended by adding a random DNA template (+, template). In this case, the initially copolymerized 5&#39;-Ap provides a 3&#39;-OH end for DNA polymerization after annealing to its complementary template (76 nt). Microsphere-PCR can be performed in a single PCR microtube using functionalized microspheres, a random DNA template, and a Tag-forward primer. In order to distinguish the resultant ssDNA amplicons from random DNA template (+ template, 76 nt), the forward primer has an additional 24 nucleotide tag. If the forward primer does not have an additional tag sequence, it is very hard to recognize between ssDNA amplicons and the initial random DNA template.
An asymmetric PCR experiment was performed. We were able to observe dsDNA contaminants as shown in Figure 4. In most cases, it is necessary to isolate ssDNA using streptavidin-coated magnetic beads and exonuclease digestion. However, microsphere-PCR makes efficient use of a single primer (Tag-forward primer) to accumulate ssDNA in aqueous phase. It is expected that dsDNA contaminants will attach to the surface of microspheres. Therefore, ssDNA amplicons can be obtained through pipetting without the need for centrifugation. The resultant ssDNA was demonstrated by comparing it to the synthetic size markers (76 nt ssDNA and 100 nt ssDNA) through gel electrophoresis analysis.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/57703/57703fig1.jpg" />
Figure 1: The microfluidic platform. (a) Fabricated microfluidic platform, (b) enlarged view of the flow-focusing geometry, (c) experimental set-up, and (d) Captured images showing continuous generation of microspheres. 1: Micro channel structure for flow focusing geometry, 2: for mixing solutions, 3: for microsphere solidification. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/57703/57703fig1large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/57703/57703fig2.jpg" />
Figure 2: Fluorescent readout of DNA hybridization on the surface of microspheres. 5&#39;-Acrydite-modified DNA probes (Ap) were capable of hybridizing with complementary Cy3 labeled DNA probes (cAp). <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/57703/57703fig2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/57703/57703fig3.jpg" />
Figure 3: Illustration of the microsphere-PCR protocol. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/57703/57703fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 4" class="xfigimg" src="/files/ftp_upload/57703/57703fig4.jpg" />
Figure 4: Comparison between conventional asymmetric PCR and microsphere-PCR. M; ssDNA marker (76mer and 100mer), Lane 1; Asymmetric PCR, Lane 2; Microbeads-PCR. Reprinted with permission from previous work8. <a href="https://www-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/57703/57703fig4large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td colspan="2">Reagent</td>
			<td>Volume in mix (&#956;L)</td>
			<td>Final Concentration</td>
		</tr>
		<tr>
			<td rowspan="4">Solution I</td>
			<td>40% Acrylamide:bis solution (19:1)</td>
			<td>25</td>
			<td>10%</td>
		</tr>
		<tr>
			<td>100 &#956;M Acrydite probe (Ap, 5&#8217;-Acrydite-(TTTTTTT, linker sequence) AGA TTG CAC TTA CTA TCT-3&#8217;)</td>
			<td>10</td>
			<td>10 &#956;M</td>
		</tr>
		<tr>
			<td>5X TBE buffer (Tris-base-EDTA)</td>
			<td>10</td>
			<td>0.5X</td>
		</tr>
		<tr>
			<td>Water</td>
			<td>5</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Solution II</td>
			<td>20% Ammonium persulfate</td>
			<td>50</td>
			<td>10%</td>
		</tr>
		<tr>
			<td rowspan="2">Solution III</td>
			<td>TEMED (N,N,N&#8242;,N&#8242;-Tetramethylethylenediamine)</td>
			<td>8</td>
			<td>0.40%</td>
		</tr>
		<tr>
			<td>Mineral oil</td>
			<td>1000</td>
			<td>-</td>
		</tr>
	</tbody>
</table>
Table 1. Reagent mix components for on-flow polyacrylamide microsphere synthesis.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td colspan="2">Operational condition</td>
			<td rowspan="2">Microsphere
			production speed</td>
		</tr>
		<tr>
			<td>Solution flowrate</td>
			<td>Oil pressure</td>
		</tr>
		<tr>
			<td>(mL/h)</td>
			<td>(kPa)</td>
			<td>( / sec)</td>
		</tr>
		<tr>
			<td>0.4</td>
			<td>82</td>
			<td>7.1</td>
		</tr>
		<tr>
			<td>0.5</td>
			<td>94</td>
			<td>13.3</td>
		</tr>
		<tr>
			<td>0.6</td>
			<td>108</td>
			<td>28.9</td>
		</tr>
		<tr>
			<td>0.7</td>
			<td>116</td>
			<td>36.5</td>
		</tr>
	</tbody>
</table>
Table 2. Summary of operational conditions and produced microsphere.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>DNA probe</td>
			<td>Sequences</td>
		</tr>
		<tr>
			<td>Cy3 labeled complementary oligonucleotide probe (cAp)</td>
			<td>5&#8217;-Cy3-AGATAGTAAGTGCAATCT-3&#8217;</td>
		</tr>
		<tr>
			<td>Tag (first 24 nt)-forward primer&#160;</td>
			<td>5&#8217;- GGT AAT ACG ACT CAC TAT AGG GAG ATA CCA GCT TAT TCA ATT-3&#8217;</td>
		</tr>
	</tbody>
</table>
Table 3. Sequence information of DNA probes.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Reagent</td>
			<td>Volume for 1x reaction (&#956;L)</td>
			<td>Final concentration</td>
		</tr>
		<tr>
			<td>Random DNA template</td>
			<td>1</td>
			<td>1 ng/&#956;L</td>
		</tr>
		<tr>
			<td>Tag-forward primer</td>
			<td>1</td>
			<td>0.4 &#956;M</td>
		</tr>
		<tr>
			<td>Reverse primer</td>
			<td>1</td>
			<td>0.02 &#956;M</td>
		</tr>
		<tr>
			<td>10X Taq buffer</td>
			<td>5</td>
			<td>1X</td>
		</tr>
		<tr>
			<td>10 mM of dNTP</td>
			<td>4</td>
			<td>2.5 mM</td>
		</tr>
		<tr>
			<td>Ex taq (1000U)</td>
			<td>0.2</td>
			<td>1 U</td>
		</tr>
		<tr>
			<td>Water</td>
			<td>37.8</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Total</td>
			<td>50</td>
			<td>-</td>
		</tr>
	</tbody>
</table>
Table 4. Asymmetric PCR reagent mix components in 20 &#956;L reaction.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Template</td>
			<td>Sequence</td>
			<td>Length (nt)</td>
		</tr>
		<tr>
			<td>Random DNA template</td>
			<td>5&#8217;- ATA CCA GCT TAT TCA ATT (Random sequence, 40 mer) AGA TAG TAA GTG CAA TCT-3&#8217;</td>
			<td>76</td>
		</tr>
		<tr>
			<td>Tag-Forward primer (Tag-F)</td>
			<td>5&#8217;- GGT AAT ACG ACT CAC TAT AGG GAG ATA CCA GCT TAT TCA ATT-3&#8217;</td>
			<td>42</td>
		</tr>
		<tr>
			<td>Reverse primer</td>
			<td>5&#8217;- AGA TTG CAC TTA CTA TCT-3&#8217;</td>
			<td>18</td>
		</tr>
	</tbody>
</table>
Table 5. Sequence information for Microsphere-PCR.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Reagent</td>
			<td>Volume for 1x reaction (&#956;L)</td>
			<td>Final concentration</td>
		</tr>
		<tr>
			<td>Ap-Microspheres</td>
			<td>~25 microspheres</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Random DNA template</td>
			<td>1</td>
			<td>1 ng/&#956;L</td>
		</tr>
		<tr>
			<td>Tag-Forward primer</td>
			<td>1</td>
			<td>0.4 &#956;M</td>
		</tr>
		<tr>
			<td>10X Taq buffer</td>
			<td>5</td>
			<td>1X</td>
		</tr>
		<tr>
			<td>10 mM dNTP</td>
			<td>4</td>
			<td>2.5 mM</td>
		</tr>
		<tr>
			<td>Ex taq (1000U)</td>
			<td>0.2</td>
			<td>1 U</td>
		</tr>
		<tr>
			<td>Water</td>
			<td>37.8</td>
			<td>-</td>
		</tr>
		<tr>
			<td>Total</td>
			<td>50</td>
			<td>-</td>
		</tr>
	</tbody>
</table>
Table 6. Microsphere-PCR reagent mix components in 50 &#956;L reaction.
<table border="1" fo:keep-together.within-page="1" fo:keep-with-next.within-page="always">
	<tbody>
		<tr>
			<td>Scan mode</td>
			<td>Plane</td>
		</tr>
		<tr>
			<td>Scaling </td>
			<td>X: 2.49 &#956;m, Y: 2.49 &#956;m</td>
		</tr>
		<tr>
			<td>Stack size</td>
			<td>X: 1272.79 &#956;m, Y: 1272.79 &#956;m</td>
		</tr>
		<tr>
			<td>Scan zoom</td>
			<td>0.7</td>
		</tr>
		<tr>
			<td>objective</td>
			<td>EC Plan-Neofluar 10 x / 0.3 M27</td>
		</tr>
		<tr>
			<td>Average</td>
			<td>1</td>
		</tr>
		<tr>
			<td>Pinhole</td>
			<td>Ch2: 104 um</td>
		</tr>
		<tr>
			<td>Filters</td>
			<td>Ch3: LP 420</td>
		</tr>
		<tr>
			<td>Beam splitters</td>
			<td>MBS: HFT 488 / 543, DBS1: mirror, DBS2: NFT 515, FW1: None</td>
		</tr>
		<tr>
			<td>Wavelength</td>
			<td>543 nm 100.0 %</td>
		</tr>
	</tbody>
</table>
Table 7. Settings for the confocal microscope.

Watch this Scientific Journal Video about A Droplet-Based Microfluidic Approach and Microsphere-PCR Amplification for Single-Stranded DNA Amplicons at JoVE.com

A Droplet-Based Microfluidic Approach and Microsphere-PCR Amplification for Single-Stranded DNA Amplicons

This work provides a method for the fabrication of droplet-based microfluidic platforms and the application of polyacrylamide microspheres for microsphere-PCR amplification. The microsphere-PCR method makes it possible to obtain single-stranded DNA amplicons without separating double-stranded DNA.

Droplet-based microfluidics enable the reliable production of homogeneous microspheres in the microfluidic channel, providing controlled size and ...

a-droplet-based-microfluidic-approach-microsphere-pcr-amplification

Universidad San Sebastian

Research

JoVE Journal

Bioengineering

8.5K Views.  Chungbuk National University. This work provides a method for the fabrication of droplet-based microfluidic platforms and the application of polyacrylamide microspheres for microsphere-PCR amplification. The microsphere-PCR method makes it possible to obtain single-stranded DNA amplicons without separating double-stranded DNA.

Video: A Droplet-Based Microfluidic Approach and Microsphere-PCR Amplification for Single-Stranded DNA Amplicons

Single Droplet Digital Polymerase Chain Reaction for Comprehensive and Simultaneous Detection of Mutations in Hotspot Regions

Droplet digital polymerase chain reaction (ddPCR) is a highly sensitive quantitative polymerase chain reaction (PCR) method based on sample fractionation into thousands of nano-sized water-in-oil individual reactions. Recently, ddPCR has become one of the most accurate and sensitive tools for circulating tumor DNA (ctDNA) detection. One of the major limitations of the standard ddPCR technique is the restricted number of mutations that can be screened per reaction, as specific hydrolysis probes recognizing each possible allelic version are required. An alternative methodology, the drop-off ddPCR, increases throughput, since it requires only a single pair of probes to detect and quantify potentially all genetic alterations in the targeted region. Drop-off ddPCR displays comparable sensitivity to conventional ddPCR assays with the advantage of detecting a greater number of mutations in a single reaction. It is cost-effective, conserves precious sample material, and can also be used as a discovery tool when mutations are not known a priori.

Here, we present a protocol to accurately quantify multiple genetic alterations of a target region in a single reaction using drop-off ddPCR and a unique pair of hydrolysis probes.

Droplet digital polymerase chain reaction (ddPCR) is a highly sensitive quantitative polymerase chain reaction (PCR) method based on sample fractionation ...

Genetics

Visual Detection of Multiple Nucleic Acids in a Capillary Array

Multi-target, short time, and resource-affordable methodologies for the detection of multiple nucleic acids in a single, easy to operate test are urgently needed in disease diagnosis, microbial monitoring, genetically modified organism (GMO) detection, and forensic analysis. We have previously described the platform called CALM (Capillary Array-based Loop-mediated isothermal amplification for Multiplex visual detection of nucleic acids). Herein, we describe improved fabrication and performance processes for this platform. Here, we apply a small, ready-to-use cassette assembled by capillary array for multiplex visual detection of nucleic acids. The capillary array is pre-treated into a hydrophobic and hydrophilic pattern before fixing loop-mediated isothermal amplification (LAMP) primer sets in capillaries. After assembly of the loading adaptor, LAMP reaction mixture is loaded and isolated into each capillary, due to capillary force by a single pipetting step. The LAMP reactions are performed in parallel in the capillaries. The results are visually read out by illumination with a hand-held UV flashlight. Using this platform, we demonstrate monitoring of 8 frequently appearing elements and genes in GMO samples with high specificity and sensitivity. In summary, the platform described herein is intended to facilitate the detection of multiple nucleic acids. We believe it will be widely applicable in fields where high-throughput nucleic acid analysis is required.

This protocol describes the fabrication of a small, ready-to-use cassette that can be applied for visual detection of multiple nucleic acids in a single, test that is easy to operate. In this approach, a capillary array was used for multiplex and highly efficient detection of GMO targets.

Multi-target, short time, and resource-affordable methodologies for the detection of multiple nucleic acids in a single, easy to operate test are urgently ...

High-throughput Detection of Respiratory Pathogens in Animal Specimens by Nanoscale PCR

Nanoliter scale real-time PCR uses spatial multiplexing to allow multiple assays to be run in parallel on a single plate without the typical drawbacks of combining reactions together. We designed and evaluated a panel based on this principle to rapidly identify the presence of common disease agents in dogs and horses with acute respiratory illness. This manuscript describes a nanoscale diagnostic PCR workflow for sample preparation, amplification, and analysis of target pathogen sequences, focusing on procedures that are different from microliter scale reactions. In the respiratory panel presented, 18 assays were each set up in triplicate, accommodating up to 48 samples per plate. A universal extraction and pre-amplification workflow was optimized for high-throughput sample preparation to accommodate multiple matrices and DNA and RNA based pathogens. Representative data are presented for one RNA target (influenza A matrix) and one DNA target (equine herpesvirus 1). The ability to quickly and accurately test for a comprehensive, syndrome-based group of pathogens is a valuable tool for improving efficiency and ergonomics of diagnostic testing and for acute respiratory disease diagnosis and management.

High-throughput testing of DNA and RNA based pathogens by nanoscale PCR is described using a syndromic canine and equine respiratory PCR panel.

Nanoliter scale real-time PCR uses spatial multiplexing to allow multiple assays to be run in parallel on a single plate without the typical drawbacks of ...

Immunology and Infection

An Ultrahigh-throughput Microfluidic Platform for Single-cell Genome Sequencing

Sequencing technologies have undergone a paradigm shift from bulk to single-cell resolution in response to an evolving understanding of the role of cellular heterogeneity in biological systems. However, single-cell sequencing of large populations has been hampered by limitations in processing genomes for sequencing. In this paper, we describe a method for single-cell genome sequencing (SiC-seq) which uses droplet microfluidics to isolate, amplify, and barcode the genomes of single cells. Cell encapsulation in microgels allows the compartmentalized purification and tagmentation of DNA, while a microfluidic merger efficiently pairs each genome with a unique single-cell oligonucleotide barcode, allowing &gt;50,000 single cells to be sequenced per run. The sequencing data is demultiplexed by barcode, generating groups of reads originating from single cells. As a high-throughput and low-bias method of single-cell sequencing, SiC-seq will enable a broader range of genomic studies targeted at diverse cell populations.

Single-cell sequencing reveals genotypic heterogeneity in biological systems, but current technologies lack the throughput necessary for the deep profiling of community composition and function. Here, we describe a microfluidic workflow for sequencing &gt;50,000 single-cell genomes from diverse cell populations.

Sequencing technologies have undergone a paradigm shift from bulk to single-cell resolution in response to an evolving understanding of the role of ...

Methylation Specific Multiplex Droplet PCR using Polymer Droplet Generator Device for Hematological Diagnostics

A multiplexed droplet PCR (mdPCR) workflow and detailed protocol for determining epigenetic-based white blood cell (WBC) differential count is described, along with a thermoplastic elastomer (TPE) microfluidic droplet generation device. Epigenetic markers are used for WBC&#160;subtyping which is of important prognostic value in different diseases. This is achieved through the quantification of DNA methylation patterns of specific CG-rich regions in the genome (CpG loci). In this paper, bisulfite-treated DNA from peripheral blood mononuclear cells (PBMCs) is encapsulated in droplets with mdPCR reagents including primers and hydrolysis fluorescent probes specific for CpG loci that correlate with WBC sub-populations. The multiplex approach allows for the interrogation of many CpG loci without the need for separate mdPCR reactions, enabling more accurate parametric determination of WBC sub-populations using epigenetic analysis of methylation sites. This precise quantification can be extended to different applications and highlights the benefits for clinical diagnosis and subsequent prognosis.

Epigenetic markers are used for white blood cell (WBC) subtyping through the quantification of DNA methylation patterns. This protocol presents a multiplex droplet polymerase chain reaction (mdPCR) method using a thermoplastic elastomer (TPE)-based microfluidic device for droplet generation allowing for precise and multiplex methylation-specific target quantification of WBC differential counts.

A multiplexed droplet PCR (mdPCR) workflow and detailed protocol for determining epigenetic-based white blood cell (WBC) differential count is described, ...

Human Respiratory Bacterial Infection Diagnosis Using Isothermal Amplification

Rapid Detection of Bacterial Pathogens Causing Lower Respiratory Tract Infections via Microfluidic-Chip-Based Loop-Mediated Isothermal Amplification

Respiratory tract infections (RTIs) are among the most common problems in clinical settings. Rapid and accurate identification of bacterial pathogens will provide practical guidelines for managing and treating RTIs. This study describes a method for rapidly detecting bacterial pathogens that cause respiratory tract infections via multi-channel loop-mediated isothermal amplification (LAMP). LAMP is a sensitive and specific diagnostic tool that rapidly detects bacterial nucleic acids with high accuracy and reliability. The proposed method offers a significant advantage over traditional bacterial culturing methods, which are time-consuming and often require greater sensitivity for detecting low levels of bacterial nucleic acids. This article presents representative results of K. pneumoniae infection and its multiple co-infections using LAMP to detect samples (sputum, bronchial lavage fluid, and alveolar lavage fluid) from the lower respiratory tract. In summary, the multi-channel LAMP method provides a rapid and efficient means of identifying single and multiple bacterial pathogens in clinical samples, which can help prevent the spread of bacterial pathogens and aid in the appropriate treatment of RTIs.

Author Spotlight: Advancing Rapid Detection of Respiratory Pathogens Using Microfluidic Chip

Various bacterial pathogens can cause respiratory tract infections and lead to serious health issues if not detected accurately and treated promptly. Rapid and accurate detection of these pathogens via&#160;loop-mediated isothermal amplification provides effective management and control of respiratory tract infections in clinical settings.

Respiratory tract infections (RTIs) are among the most common problems in clinical settings. Rapid and accurate identification of bacterial pathogens will ...

Simple Bulk Readout of Digital Nucleic Acid Quantification Assays

Digital assays are powerful methods that enable detection of rare cells and counting of individual nucleic acid molecules. However, digital assays are still not routinely applied, due to the cost and specific equipment associated with commercially available methods. Here we present a simplified method for readout of digital droplet assays using a conventional real-time PCR instrument to measure bulk fluorescence of droplet-based digital assays.
We characterize the performance of the bulk readout assay using synthetic droplet mixtures and a droplet digital multiple displacement amplification (MDA) assay. Quantitative MDA particularly benefits from a digital reaction format, but our new method&#160;applies to any digital assay. For established digital assay protocols such as digital PCR, this method serves to speed up and simplify assay readout.
Our bulk readout methodology brings the advantages of partitioned assays without the need for specialized readout instrumentation. The principal limitations of the bulk readout methodology are reduced dynamic range compared with droplet-counting platforms and the need for a standard sample, although the requirements for this standard are less demanding than for a conventional real-time experiment. Quantitative whole genome amplification (WGA) is used to test for contaminants in WGA reactions and is the most sensitive way to detect the presence of DNA fragments with unknown sequences, giving the method great promise in diverse application areas including pharmaceutical quality control and astrobiology.

We describe an endpoint digital assay for quantifying nucleic acids with a simplified (analog) readout. We measure bulk fluorescence of droplet-based digital assays using a standard qPCR machine rather than specialized instrumentation and confirm our results by microscopy.

Digital assays are powerful methods that enable detection of rare cells and counting of individual nucleic acid molecules. However, digital assays are ...

Biology

Particle Templated Emulsification enables Microfluidic-Free Droplet Assays

Reactions performed in monodispersed droplets afford enhanced accuracy and sensitivity compared to equivalent ones performed in bulk. However, the requirement of microfluidics to form controlled droplets imposes a barrier to non-experts, limiting their use. Here, we describe particle templated emulsification, an approach to generate monodisperse droplets without microfluidics. Using templating hydrogel spheres, we encapsulate samples in monodispersed droplets by simple vortexing. We demonstrate the approach by using it to perform microfluidic-free digital PCR.

Water-in-oil droplet assays are useful for analytical chemistry, enzyme evolution, and single cell analysis, but typically require microfluidics to form the droplets. Here, we describe particle templated emulsification, a microfluidic-free approach to perform droplet assays.

Reactions performed in monodispersed droplets afford enhanced accuracy and sensitivity compared to equivalent ones performed in bulk. However, the ...

Microsphere Polymerase Chain Reaction to Amplify Single-Stranded DNA

Source: Lee, S. H. et al., <a href="https://app-jove-com.bdigitaluss.remotexs.co/v/57703">A Droplet-Based Microfluidic Approach and Microsphere-PCR Amplification for Single-Stranded DNA Amplicons.</a> J. Vis. Exp. (2018).
This video describes the technique of amplifying single-stranded DNA using oligonucleotide-coated polymer microspheres in a single-tube reaction. This process yields pure single-stranded DNA, which can be further used for DNA sequencing and microarray analysis.

Source: Lee, S. H. et al., A Droplet-Based Microfluidic Approach and Microsphere-PCR Amplification for Single-Stranded DNA Amplicons. J. Vis. Exp.
...

JoVE Encyclopedia of Experiments

Biological Techniques

PCR Techniques

Droplet Digital Polymerase Chain Reaction: A Method to Generate Nanodroplet PCR Reactions for Detecting Rare Tumor Mutations

Source: Bonner, E. R. et al. <a href="https://www-jove-com.bdigitaluss.remotexs.co/video/59721" target="_blank">Detection and Monitoring of Tumor Associated Circulating DNA in Patient Biofluids.</a> J. Vis. Exp. (2019)
In this video, we present a step-by-step procedure to generate emulsified nano-droplets to detect target nucleic acids by digital polymerase chain reaction or dPCR.

Source: Bonner, E. R. et al. Detection and Monitoring of Tumor Associated Circulating DNA in Patient Biofluids. J. Vis. Exp. (2019)
In this video, we ...
