1. Preparation of the Experimental Site for TSC Measurement
<ol>
	<li>To measure the full characteristics of the TSC method, use the commercially available conductometer equipped with four electrode cells (alternatively, two electrode cells can be used for low conductivities) and a temperature sensor. Connect it to the PC and record the conductivity and temperature of the sample (4% wt% of methyl-4,6-O-(p-nitrobenzylidene)-&#945;-D-glucopyranoside in 1 M molar concentration of tetraethylammonium bromide - TEABr in glycerol - Glyc used in studied case, see paragraph 3 for ionic gel sample preparation) along with computer time.</li>
	<li>For automatic readouts, use the software supplied by the manufacturer along with the conductometer, and set the measuring mode to continuous with interval readings every 1 s.</li>
	<li>Prepare the nitrogen line (fill the high-pressure nitrogen tank with liquid nitrogen and start to evaporate it to get gaseous nitrogen in the nitrogen line), and set the pressure to 2 bars and required flow, then decrease the initial temperature of the nitrogen gas with the aid of a refrigerator.</li>
	<li>Tightly mount the screw cap of the vial on the conductive sensor, and secure it with a piece of teflon tape (crucial with volatile samples) (see Figure 2).</li>
</ol>
2. Preparation of Electrolyte Solution
<ol>
	<li>Prepare the electrolytes by mixing an appropriate amount of glycerol, used as a solvent, and tetraethylammonium bromide (TEABr) (use scale to weigh the required amount of compounds accordingly for the concentration needed for investigation), used as a solute, in a glass vial tightly closed and heated at 100 &#176;C for 15 min.</li>
	<li>Next, stir the mixture for 1 min and heat it again at 100 &#176;C for 5 min to ensure that all the solute is dissolved and the mixture is homogeneous.</li>
	<li>Use these prepared electrolyte solutions for measurements, and afterwards for preparation of ionogels.</li>
</ol>
3. Preparation of Low Molecular Weight Ionic Gels
<ol>
	<li>Prepare the ionogels from the electrolyte solutions (see section 2) by adding 178.6 mg of the low molecular weight gelator to 4 mL of 1 M TEABr/Glyc electrolyte solution to obtain 4% wt% of ionic gel sample.
	NOTE: The chemical synthesis of the used gelator was described elsewhere11.</li>
	<li>To dissolve the gelator, add it to the glass vial with the electrolyte solution and heat it at 130 &#176;C for 20 min with additional stirring to assist dissolution.</li>
	<li>After completely dissolving the gelator, heat the mixture for an additional 5 min to ensure the sample is homogenous.</li>
	<li>Next, quickly cool down the sample in a dry cooling block at 10 &#176;C to ensure physical gelation. After the procedure, a homogeneous, transparent, or opaque gel phase should be obtained (Figure 3).
	NOTE: After the first gelation has been performed, the sample becomes liquid when turning to sol phase at high temperatures, but after returning to room temperature it turns to the gel phase again. The temperature needed for the gel-sol phase transition is lower than the temperature needed for dissolution of the crystalline gelator. By changing the kinetics of the cooling stage, one can influence the physical properties of the obtained ionogel, like microstructure, optical appearance, or the gel-sol phase transition temperature (Tgs).</li>
</ol>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/56607/56607fig3.jpg" />
Figure 3: The physical appearance of the investigated sample. The 1M TEABr/Glyc electrolyte (a), 4% ionogel with 1M TEABr/Glyc electrolyte in transparent phase (b), 4% ionogel with 1M TEABr/Glyc electrolyte in opaque phase (c). <a href="//cloudfront-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/56607/56607fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
4. In Situ Thermal Scanning Conductometry of Ionogels
<ol>
	<li>To prepare the sample for TSC measurement, heat the ionogel above the Tgs temperature, 94.85 &#176;C in the studied case. Transfer it to the precooled polypropylene vial after it turns to sol phase. Due to the fast cooling down of the sol, the gel phase is created.</li>
	<li>Insert the conductivity sensor (with the screw cap of the vial on it) into the vial by pushing it into the gel, tighten the screw cap, and secure it with Teflon tape.</li>
	<li>Perform the TSC measurement and record conductivity, temperature, and time to prepare conductivity vs temperature, temperature vs time, and conductivity vs time dependencies. Repeat the measurement in the investigated temperature range (9.85 - 99.85 &#176;C) in heating-cooling cycles (at least 2 times).
	NOTE: Remember the 1st cycle is used to eliminate all discrepancies of the sample caused by the preparation procedure.</li>
	<li>Perform the measurements with different cooling rates (7 &#176;C/min, 4 &#176;C/min, and 1 &#176;C/min in studied case) to explore how it influences the conductive and thermal properties of investigated ionogels.
	NOTE: To demonstrate how the TSC method can be used as a tool to obtain ionogels with targeted properties, a series of experiments with non-aqueous ionogel based on gelator 1, glycerol, and TEABr was performed and presented in this manuscript.</li>
</ol>
5. Example of TSC Measurement
<ol>
	<li>Insert the investigated ionogel into the vial, and push in the conductivity sensor.</li>
	<li>Perform the 1st heating-cooling cycle to improve the electrode contact, and remove all imperfections of the ionogel microstructure resulting from placing the sample in the vial and seen as scratches, cracks, and air bubbles included in the gel.</li>
	<li>Measure the conductivity and temperature along with time during the 2nd and 3rd heating-cooling cycle to investigate the performance of the ionogel, and the reproducibility of the system. Set the heating rate to 2 &#176;C/min and cooling rate to 7 &#176;C/min, and gelation temperature to 10 &#176;C. As a result, obtain a transparent gel phase.</li>
	<li>Perform the 4th and 5th heating-cooling cycle, with the heating and cooling rates equal to 2 &#176;C/min, and the gelation temperature equal to 10 &#176;C. As a result, obtain a mixture of the transparent and opaque gel phases.</li>
	<li>Perform the 6th and 7th heating-cooling cycle with heating and cooling rates equal to 2 &#176;C/min, and a gelation temperature equal to 60 &#176;C. As a result, obtain an opaque, white gel phase.</li>
	<li>Perform the analysis of the 1st derivatives for recorded data to see differences between samples.</li>
	<li>Keep the sample for 20 min at each of the gelation temperatures to ensure that the gelation process is completed.</li>
</ol>

<ol>
	<li>Bielejewski, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Novel+approach+in+determination+of+ionic+conductivity+and+phase+transition+temperatures+in+gel+electrolytes+based+on+Low+Molecular+Weight+Gelators.">Novel approach in determination of ionic conductivity and phase transition temperatures in gel electrolytes based on Low Molecular Weight Gelators.</a> Electochim. Acta. 174, 1141-1148 (2015).</li><li>Bielejewski, M., &#321;api&#324;ski, A., Luboradzki, R., Tritt-Goc, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Influence+of+solvent+on+the+thermal+stability+and+organization+of+self-assembling+fibrillar+networks+in+methyl-4,6-O-(p-nitrobenzylidene)-&#945;-D-glucopyranoside+gels.">Influence of solvent on the thermal stability and organization of self-assembling fibrillar networks in methyl-4,6-O-(p-nitrobenzylidene)-&#945;-D-glucopyranoside gels.</a> Tetrahedron. 67, 7222-7230 (2011).</li><li>Atsbeha, T., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Photophysical+characterization+of+low-molecular+weight+organogels+for+energy+transfer+and+light+harvesting.">Photophysical characterization of low-molecular weight organogels for energy transfer and light harvesting.</a> J. Mol. Struct. 993, 459-463 (2011).</li><li>Gronwald, O., Snip, E., Shinkai, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Gelator+for+organic+liquids+based+on+self-assembly:+a+new+facet+of+supramolecular+and+combinatorial+chemistry.">Gelator for organic liquids based on self-assembly: a new facet of supramolecular and combinatorial chemistry.</a> Curr. Opinion in Coll. Interface Sci. 7, 148-156 (2002).</li><li>Vintiloiu, A., Leroux, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Organogels+and+their+use+in+drug+delivery-a+review.">Organogels and their use in drug delivery-a review.</a> Control. Rel. 125, 179-192 (2008).</li><li>Wang, Z., Fujisawa, S., Suzuki, M., Hanabusa, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Low+Molecular+Weight+Gelators+Bearing+Electroactive+Groups+as+Cathode+Materials+for+Rechargeable+Batteries.">Low Molecular Weight Gelators Bearing Electroactive Groups as Cathode Materials for Rechargeable Batteries.</a> Macromol. Symp. 364, 38-46 (2016).</li><li>Sharma, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Physical+gels+of+[BMIM][BF4]+by+N-tert-butylacrylamide/ethylene+oxide+based+triblock+copolymer+self-assembly:+Synthesis,+thermomechanical,+and+conducting+properties.">Physical gels of [BMIM][BF4] by N-tert-butylacrylamide/ethylene oxide based triblock copolymer self-assembly: Synthesis, thermomechanical, and conducting properties.</a> J. Appl. Polym. Sci. 128, 3982-3992 (2013).</li><li>Tao, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Stable+quasi-solid-state+dye-sensitized+solar+cell+using+a+diamide+derivative+as+low+molecular+mass+organogelator.">Stable quasi-solid-state dye-sensitized solar cell using a diamide derivative as low molecular mass organogelator.</a> J. Power Sources. 262, 444-450 (2014).</li><li>Kataoka, T., Ishioka, Y., Mizuhata, M., Minami, H., Maruyama, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Highly+Conductive+Ionic-Liquid+Gels+Prepared+with+Orthogonal+Double+Networks+of+a+Low-Molecular-Weight+Gelator+and+Cross-Linked+Polymer.">Highly Conductive Ionic-Liquid Gels Prepared with Orthogonal Double Networks of a Low-Molecular-Weight Gelator and Cross-Linked Polymer.</a> ACS Appl. Mater. Interfaces. 7, 23346-23352 (2015).</li><li>Bielejewski, M., Nowicka, K., Bielejewska, N., Tritt-Goc, J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Ionic+Conductivity+and+Thermal+Properties+of+a+Supramolecular+Ionogel+Made+from+a+Sugar-Based+Low+MolecularWeight+Gelator+and+a+Quaternary+Ammonium+Salt+Electrolyte+Solution.">Ionic Conductivity and Thermal Properties of a Supramolecular Ionogel Made from a Sugar-Based Low MolecularWeight Gelator and a Quaternary Ammonium Salt Electrolyte Solution.</a> J. Electrochem. Soc. 163, G187-G195 (2016).</li><li>Gronwald, O., Shinkai, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bifunctional'+sugar-integrated+gelators+for+organic+solvents+and+water-on+the+role+of+nitro-substituents+in+1-O-methyl-4,6-O-(nitrobenzylidene)-monosaccharides+for+the+improvement+of+gelation+ability.">Bifunctional' sugar-integrated gelators for organic solvents and water-on the role of nitro-substituents in 1-O-methyl-4,6-O-(nitrobenzylidene)-monosaccharides for the improvement of gelation ability.</a> J. Chem. Soc., Perkin Trans. 2, 1933-1937 (2001).</li><li>Bielejewski, M., Ghorbani, M., Zolfigol, M., Tritt-Goc, J., Noura, S., Narimani, M., Oftadeh, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Thermally+reversible+solidification+of+novel+ionic+liquid+[im]HSO4+by+self-nucleated+rapid+crystallization:+investigations+of+ionic+conductivity,+thermal+properties,+and+catalytic+activity.">Thermally reversible solidification of novel ionic liquid [im]HSO4 by self-nucleated rapid crystallization: investigations of ionic conductivity, thermal properties, and catalytic activity.</a> RSC Adv. 6, 108896-108907 (2016).</li></ol>

The author has nothing to disclose

The thermal scanning conductometry is a new experimental method which has proven to be an efficient and effective way of investigating dynamically changing systems, like ionogels based on low molecular weight gelators, electrolytes, or ionic liquids. However, its applicability is not restricted only to ionogels. The TSC method can be easily used with other types of conducting soft matter systems like hydrogels, emulsions, creams, or any other charge containing carriers into which the conductivity sensor can be inserted. ...

Thermally Reversible Ionogels
Physical gelation is a process which allows the construction of structures of self-assembled gelator molecules in presence of the solvent molecules. Due to non-covalent nature of the interactions responsible for this phenomenon (e.g. hydrogen bonding, van der Waals interactions, dispersion forces, electrostatic forces, &#960;-&#960; stacking, etc.), these systems are thermally reversible. This thermal reversibility, together with the very low concentration of the gelator and the wide variety of the systems that can be created, are some of the main advantages of physical gels over chemical ones. Thanks to the unique properties of the physical gel state, the ionogels are characterized with desirable features like easy recycling, long cycle life, enhanced physical properties (e.g. ionic conductivity), ease of production, and lowering of the production costs. Taking into the account the above advantages of physical gels (which already have a wide range of different applications1,2,3,4), these were thought to be used as an alternative way for electrolyte solidification and obtaining of ionogels5,6,7,8. However, the classical conductometry was not sensitive and accurate enough to follow such dynamically changing systems. Therefore,it could not detect the phase transitions and enhanced dynamics of ions in the gel matrix9. The reason for this insensitivity was the time needed for the temperature stabilization, during which dynamic changes of the sample properties were underway before the measurement was started. Furthermore, the number of measured temperatures was limited in order, not to significantly extend the experimental time. Therefore, to fully and accurately characterize the ionogels, a new method was needed, which would be able to follow the dynamic changes of properties as a function of temperature, and record data continuously in real time. The way the gelation process is conducted determines the properties of the created ionogel. The intermolecular non-covalent interactions are defined during the cooling stage; by changing the gelation temperature and cooling rates, one can strongly influence those interactions. Therefore, it was extremely important to measure the system during cooling when the gelation takes place. With the classical approach, this was impossible due to temperature stabilization time for the measurement, and the fast cooling rates required for successful gelation. However, with the thermal scanning conductometry method this task is very simple, delivers accurate and reproducible results, and allows the investigation of the influence of different kinetics of thermal changes applied to the sample on sample properties10. As a result, the ionogels with targeted properties can be studied and manufactured at the same time.
Thermal Scanning Conductometry (TSC)
The thermal scanning conductometry is supposed to deliver a reproducible, accurate, and fast responding experimental method for the conductivity measurement of dynamically changing and thermally reversible systems, like ionogels based on low molecular weight gelators. However, it can be also used with electrolytes, ionic liquids, and any other conducting sample that can be placed in the measuring cell and has conductivity in the measuring range of the sensor. Additionally, besides the research application, the method was successfully used to manufacture ionogels with targeted properties like microstructure, optical appearance or thermal stability, and phase transition temperature in an accurate and easy way. Depending on the kinetics and history of thermal treating with use of the TSC method, we gain full control over some basic properties of physical gel systems. Additionally the chamber have been equipped in a video camera to inspect the sample state and record the changes of the sample especially during gelation and dissolution processes. An additional advantage of the TSC method is its simplicity, as the system can be built from a standard conductometer, a programmable temperature controller, the gaseous nitrogen line for the heating/cooling medium, the refrigerator, measuring chamber, and a PC, which can be found in most laboratories.
The TSC Experimental Site
The thermal scanning conductometry experimental setup can be built in almost every laboratory with relatively low costs. In return, one obtains an accurate, reproducible, and fast method for measuring liquid and semisolid conductive samples at different external conditions. A detailed scheme of the TSC experimental setup built in our laboratory is given in Figure 1.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/56607/56607fig1v2.jpg" />
Figure 1: Block diagram of the measurement site. The components consisting on working experimental setup for thermal scanning conductometry method. <a href="//cloudflare-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/56607/56607fig1v2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
For the temperature change, a homemade temperature controller was used, but any kind of programmable temperature controller, which can change the temperature linearly with a defined change rate, can be used. For thermal isolation, a special chamber has been built. The purpose of using an isolation chamber is to minimize temperature horizontal gradients in the sample, and to assure fast cooling rates. The chamber consists of a glass cylinder with a 40-mm inner diameter and 300 mm length. At the bottom side, where the heater with gaseous nitrogen inlets are located, the end of the inlet is equipped with a diffusor to evenly spread the hot or cold gas. This is also the place where the temperature sensor PT100 of the variable temperature controller (VTC) is located. The temperature of the sample is recorded independently by the temperature sensor located in the conductivity sensor. Additionally, the chamber have been equipped in a video camera to inspect the sample state and record the changes of the sample especially during gelation and dissolution processes. The gaseous nitrogen obtained from evaporation of liquid nitrogen in the 250 L high pressure tank is used as a heating and cooling medium. The working pressure in the nitrogen line is set to 6 bars, and reduced to 2 bars at the measuring site. Such settings allow the obtainment of flow rates between 4 and 28 L/min without any disturbances, which allows a cooling rate of 10 &#176;C/min. To lower the initial temperature of the nitrogen gas, the external refrigerator has been used, and the decreased temperature was 10 &#176;C. This allows the obtainment of good linearity of the temperature change, starting from room temperature. During fast cooling, the temperature of the nitrogen gas is decreased to -15 &#176;C to assist high cooling rates. It is necessary to use gaseous nitrogen, and not even dry air, to avoid icing the refrigerator because of low temperatures.
The samples were inserted into a vial of 9 mm inner diameter and length of 58 mm, made of polypropylene, and equipped with a screw cap, which has a rubber ring for tight closing. The vials can be used up to 120 &#176;C. (see Figure 2).
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/56607/56607fig2.jpg" />
Figure 2: The picture of a polypropylene vial and its mounting on the conductivity sensor. (1) the polypropylene vial, (2) the screw cap with rubber ring, 2a - the screw cap mounted on the conductivity sensor, (3) the vial with mounted conductivity sensor, the screw cap secured with Teflon tape. <a href="//cloudflare-jove-com.bdigitaluss.remotexs.co/files/ftp_upload/56607/56607fig2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>

<table><tbody><tr><td>SevenCompact S230 conductometer</td><td>Mettler-Toledo</td><td></td><td>equiped with InLab 710 sensor</td></tr><tr><td>home-build VTC</td><td></td><td></td><td></td></tr><tr><td>LabX PH 3.2 software</td><td>Mettler-Toledo</td><td></td><td>software used for data aqusition</td></tr><tr><td>tetraethylammonium bromide</td><td>Sigma-Aldrich</td><td>140023</td><td></td></tr><tr><td>glycerol</td><td>Sigma-Aldrich</td><td>G5516</td><td></td></tr><tr><td>methyl-4,6-O-(p-nitrobenzylidene)-a-D-glucopyranose</td><td></td><td></td><td>synthezied according to Gronwald, O., Shinkai, S., J. chem. Soc., Perkin Trans. 2 1933-1937 (2001).</td></tr><tr><td>[im]HSO&lt;sub&gt;4&lt;/sub&gt;</td><td></td><td></td><td>synthezeid by group of prof. Mohammad Ali Zolfigol, Faculty of Chemistry&lt;br/&gt; Bu-Ali Sina University&lt;br/&gt; Hamedan, I.R.Iran&amp;nbsp; according to Bielejewski, M., Ghorbani, M., Zolfigol, M., Tritt-Goc, J., Noura, S., Narimani, M., Oftadeh, M. RSC Adv. 6, 108896-108907 (2016).</td></tr><tr><td>polypropylene vial</td><td>Paradox Company, Cracow, Poland</td><td>PTC 088</td><td>www.insectnet.eu</td></tr></tbody></table>
