We thank Dr. Akira Yasui at Tohoku University, Japan for the GFP-NTH1 expression plasmid, and Dr. Eros Lazzerini Denchi at the Scripps Research Institute, La Jolla, California for the TRF2-YFP and EGFP-53BP11220-1711 expression plasmids. This work was supported by the Air Force Office of Scientific Research (FA9550-04-1-0101) and the Beckman Laser Institute Inc. Foundation (to M.W.B), the Ford Foundation Fellowship from the National Academy of Sciences (to B.A.S), and NSF MCB-1615701 and CRCC CRR-17-426665 (to K. Y.).

The authors have nothing to disclose.

The advantages of using laser microirradiation for DDR research are:
1. It is feasible to induce different types and amounts of DNA damage from simple strand breaks to complex DNA damage, and to detect different repair factors at the DNA damage sites by adjusting the laser irradiation parameters. It is also possible to inflict damage multiple times in the same cell nucleus in order to evaluate trans effects (as in Figure 3).
2. Importantly, events happening at damage sites and the secondary events that occur elsewhere in the nucleus can easily be distinguished.
3. It is possible to carry out high-resolution real-time measurements of fluorescently tagged protein dynamics in response to damage at a single cell level, including, but not limited to: F&#246;rster Resonance Energy Transfer (FRET), Fluorescence Lifetime Imaging (FLIM), Pair Correlation Function (pCF), etc., to capture DDR in live cells.
4 .Combining with RNA interference or inhibitor treatment, it is relatively straightforward to test upstream factor requirement in a small number of cells.
5. It should also be noted that NIR (or green) laser radiation does not require pre-sensitization of DNA with nucleotide analogs or DNA-intercalating dyes, thus avoiding unwanted side effects on chromatin packing. This is in contrast to the UV laser system that requires sensitization at low dose and causes aberrant DDR at high dose39,49,61.
Critical Steps Within the Protocol/Modifications and Troubleshooting
It is important that the cells are in healthy conditions when DDR analyses are performed in order to minimize artifact and experimental variations. DNA- or siRNA-transfected cells usually are more sensitive or easily detached when growing on the gridded coverslip. It helps to keep cells for shorter times in the transfection reagent as long as the transfection works, and seed more transfected cells onto the gridded coverslip dish compared to the untransfected cells. This is necessary in order to achieve comparable cell confluences for the experiments.
It has been reported that the thymidine block leads to increased levels of &#947;H2AX in the synchronized cells62, which may affect DDR and skew the results. Furthermore, the base line &#947;H2AX signal was shown to be higher in S and G2/M phase even without any exogenous damage63,64. We, however, do not observe any significant &#947;H2AX signal in the nucleoplasm that would affect or interfere with the specific &#947;H2AX response at laser-induced damage sites in the cells synchronized in S/G2 phase by a double thymidine block51.
In order to obtain consistent results, it is necessary to periodically check the laser system output parameters (every 2 to 4 weeks) and optical alignment (every 2 months). Over time, laser system components may need to be re-aligned, objective lens may be damaged and need to be replaced, and the stability of the total input power may change. The key is to evaluate the presence of damage (crosslinking (CPD and/or 6-4PP) and base damage (8-oxoG)), marker proteins (e.g., DNA glycosylases, Rad51, cohesin, and Ku), and PAR modification described in this protocol to determine the dosage and complexity of DNA damage induced by the laser microscope system used.
Limitations of the Technique
Laser microirradiation has limitations. DNA damage induced by the laser beam is highly clustered in one area in the nucleus compared to naturally occurring damage that may be spread throughout the nucleus. This may change how damage signaling is propagated in the neighboring chromatin or in the nucleus. Since a relatively low number of cells can be irradiated at one time, population-based biochemical assays (e.g., Western blot, protein complex purification, chromatin immunoprecipitation (ChIP)) cannot be easily performed. Reliance on fluorescently tagged proteins (with over expression of the exogenous recombinant proteins or even with those expressed endogenously using CRISPR-mediated tag insertion) for dynamic imaging makes the studies vulnerable to protein fusion-induced artifacts. The unique nature of laser-induced damage and potential artifactual effects of tagged proteins, therefore, need to be evaluated by comparison with the results using conventional DNA damaging methods (IR, chemical damaging agents) and with the endogenous untagged proteins (though sometimes it is not possible to perform complete parallel experiments).
Significance with Respect to Existing Methods
The use of sequence-specific endonucleases such as I-SceI, FokI, AsiSI, and I-PpoI provides an alternative strategy to induce site-specific DSBs (strictly simple DSBs). Factor recruitment or modifications can be analyzed by site-specific or genome-wide ChIP analysis65,66,67,68,69. Relatively synchronous induction of DSBs can be achieved by tagging the endonuclease with a steroid hormone receptor and a degradation signal (degron) for rapid nuclear translocation and degradation, respectively65,66,67,68,69. One must take into consideration, however, that the efficiency of endonuclease expression and target site accessibility, and ongoing repair status can be variable in different cells and at different target sites. These heterogeneities will be averaged in the population-based ChIP analysis, which may skew the results. Laser microirradiation, on the other hand, offers the highest possible temporal resolution (milliseconds) as well as spatial resolution (submicrometer) of damage response dynamics, which can be analyzed at the single-cell level. High damage density, however, may influence the outcome. Both strategies can be sensitive to artifacts caused by antibody accessibility and/or peptide tagging. It is, therefore, important to understand the pros and cons of both strategies, which may potentially be used to complement each other.
Future Applications
With rapid advancement of fluorescence imaging and dynamics techniques, versatility of laser systems to induce different amounts and types of DNA damage at specific locations and cell cycle stage provides a valuable opportunity to interrogate the cellular and molecular responses to DNA damage with high spatiotemporal resolution at a single cell level. It will be possible, for example, to tease out damage site-specific and nucleus- and cell-wide DDR signal transduction with millisecond-resolution (e.g., detect molecular interactions or modifications that occur exclusively at damage sites, examine dynamic changes of chromatin structure in real-time, or observe real-time spreading of damage signaling from damage sites to the whole nucleus). It is also possible to follow the same cell over a long period of time to examine the effects of DNA damage on cell fate. We envision that the laser microirradiation methods, if used properly, will continue to contribute significantly to advancement of the DNA repair field.

In Vivo DNA Damage Signaling is Not Well Understood
In vivo, DNA is complexed with histones and other factors to form chromatin fibers. Regulation of chromatin structure is of paramount importance for DNA metabolism. For example, the histone variant H2AX is phosphorylated by ataxia-telangiectasia mutated (ATM) and other kinases following double-strand breaks (DSB) induction, and is important for DSB damage signal amplification as well as providing a docking site for other factors. Spreading of damage signaling and repair pathway choice appear to be critically influenced by local chromatin structure at damage sites1. A number of chromatin remodeling factors, histone chaperones, and histone modifying enzymes are indeed recruited to damage sites and are important for efficient DNA repair, highlighting the significance of chromatin regulation in the DDR and repair2,3,4. Furthermore, damage site clustering or repositioning was observed in yeast and drosophila5,6,7,8, reminiscent of relocalization of gene loci in the subnuclear compartment associated with gene regulation9,10. Recent studies in mouse and human cells also revealed mobilization of DSB sites, which influences repair fidelity and pathway choice11,12. This raises the possibility that DDR/repair may also be intimately linked to nuclear architecture, higher-order chromatin organization, and chromosome dynamics in the cell nucleus. Thus, it is critical to develop high-resolution methods to study DDR and repair processes in the context of the endogenous nuclear environment in a live cell in order to understand short- and long-term consequences of DNA damage.
Critical Role of PAR Polymerase (PARP) in Gauging the Extent and Type of Damage and Regulating Protein Assembly at the Damage Site
PARP1 is a DNA nick sensor rapidly activated by DNA damage that plays a critical role in DNA repair13. PARP1 was originally thought to function together with X-Ray Repair Cross Complementing 1 (XRCC1) to facilitate base excision repair (BER), but recent studies reveal its role in other DNA repair pathways, including DSB repair14. Activated PARP1 uses nicotinamide adenine dinucleotide (NAD+) as a substrate to ADP-ribosylate multiple target proteins, including itself. This enzyme and other family members have attracted much attention in recent years as PARP inhibitors have emerged as promising therapeutic drugs for cancers. Although PARP inhibitors were initially found to be effective in breast cancer gene (BRCA)-mutated breast cancer cells, there is now a plethora of evidence for their effects in mono- and combination therapies together with DNA damaging agents/irradiation against a broad spectrum of cancers with mutations not limited to BRCA15,16,17,18,19,20.
At the molecular level, PARP activation was shown to play critical roles in organizing the local chromatin structure at damage sites. PAR-dependent recruitment of chromatin modification enzymes facilitates DSB repair and dictates repair pathway choices, suggesting the important scaffolding role of PAR modification at damage sites. 13,21,22,23,24,25,26,27,28,29,30,31 We recently demonstrated the exclusion of p53-binding protein 1 (53BP1) from damage sites by PAR 32, providing an alternative explanation for 53BP1-dependent hyperactivation of non-homologous endjoining (NHEJ) by PARP inhibitor and highlighting the significance of PARP in DSB repair pathway choice33,34. PARP1 also directly PARylates and affects the activity of multiple DNA repair factors14.
Using Laser Microirradiation as a Tool to Study DDR/Repair In Vivo
Laser microirradiation to produce sub-micron alterations on individual chromosomes was first described in 196935 and reviewed in detail in 198136. Several decades later, laser microirradiation was shown to induce DNA damage at a defined submicrometer region in the cell nucleus, and was proven to be a valuable technique to study recruitment or modifications of various factors to DNA lesions in vivo13,37,38,39,40,41. This method allows detection of those factors that do not form distinct irradiation-induced foci (IRIF) at damage sites39,42. It is also possible to examine the spatiotemporal dynamics of chromatin structural changes both at damage sites and in the rest of the nucleus. We carefully compared the DDRs induced by different laser systems and input powers to evaluate the relationship between the type of DNA damage and the microirradiation conditions32,43,44,45. The aberrant recruitment patterns of 53BP1 and telomeric repeat binding factor 2 (TRF2) were observed in the previous laser damage studies, which provided the basis for the recurring concern for the &#34;non-physiological&#34; nature of laser-induced damage46,47,48,49. We found that these apparent discrepancies could now be explained by differential PARP signaling which gauges the amount and complexity of induced damage32. We confirmed that: 1) laser-microirradiated cells (even after high input-power irradiation) are arrested in interphase in a damage checkpoint control-dependent manner and remain viable (at least up to 48 h)32,50; and 2) repair factor recruitment/modifications faithfully recapitulate those observed with treatment with conventional DNA damaging agents and DSB induction by endonucleases32,39,42,44,50,51,52. These results strongly support the physiological relevance of studying laser damage-induced cellular responses.

<table><tbody><tr><td>Ti:Sapphire NIR pulsed femtosecond laser Mira-900</td><td>Coherent Inc.</td><td>Mira 900</td><td></td></tr><tr><td>Inverted microscope&amp;nbsp;</td><td>Carl Zeiss</td><td>Axiovert 200M</td><td></td></tr><tr><td>63X/1.4 NA objective</td><td>Zeiss</td><td>APOCHROMAT Ph3&amp;nbsp;</td><td></td></tr><tr><td>Compact Rotation Stage&amp;nbsp;</td><td>Newport Corp</td><td>PR50PP</td><td></td></tr><tr><td>Temperature Controller</td><td>Warner</td><td>TC-344B</td><td></td></tr><tr><td>Heating System</td><td>Ibidi&amp;nbsp;</td><td>10918</td><td></td></tr><tr><td>Gas Incubation System</td><td>Ibidi&amp;nbsp;</td><td>11920</td><td></td></tr><tr><td>Laser Power and Energy Meter (RoHS)</td><td>Coherent</td><td>FieldMaxII-TOP&amp;nbsp;</td><td></td></tr><tr><td>ORCA-R2 Digital CCD Camera</td><td>Hamamatsu</td><td>C10600</td><td></td></tr><tr><td>LSM 510 META Laser Scanning Microscopes</td><td>Carl Zeiss</td><td></td><td></td></tr><tr><td>100X/1.3 NA Zeiss Plan APO</td><td>Carl Zeiss</td><td></td><td></td></tr><tr><td>35mm Gridded Dishes&amp;nbsp;</td><td>MatTek</td><td>P35G-1.5-14-CGRD-D</td><td></td></tr><tr><td>PtK2 kidney epithelial cells</td><td>ATCC</td><td>CCL 56&amp;nbsp;</td><td></td></tr><tr><td>HeLa cells</td><td>ATCC</td><td>CCL-2</td><td></td></tr><tr><td>DMEM</td><td>Life Technologies</td><td>11885-092</td><td></td></tr><tr><td>CO2-Independent Medium&amp;nbsp;</td><td>Life Technologies</td><td>18045-088</td><td></td></tr><tr><td>Advanced MEM&amp;nbsp;</td><td>Life Technologies</td><td>12492-013</td><td>supplemented with L-Glutamine, 4% FBS</td></tr><tr><td>penicillin/streptomycin</td><td>Fisher Scientific</td><td>15140122</td><td></td></tr><tr><td>L-Glutamine</td><td>Fisher Scientific</td><td>25030081</td><td></td></tr><tr><td>FBS</td><td>Omega Scientific</td><td>FB-02</td><td></td></tr><tr><td>Thymidine&amp;nbsp;</td><td>&amp;nbsp;SIGMA</td><td>T9250</td><td></td></tr><tr><td>serum free media&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp; (Opti-MEM I Reduced Serum Media)</td><td>Fisher Scientific</td><td>11058021</td><td></td></tr><tr><td>Anti-Cycolbutance pyrimidine dimer (CPD) (mouse)</td><td>Kamiya Biomedical Company</td><td>MC-062</td><td></td></tr><tr><td>Anti-XRCC1 (mouse )</td><td>Gene Tex Inc</td><td>GTX72311</td><td></td></tr><tr><td>Anti-53BP1 (rabbit)</td><td>Santa Cruz Biotech</td><td>sc-22760</td><td></td></tr><tr><td>Anti-CtIP (rabbit)</td><td>Abcam</td><td>ab70163</td><td></td></tr><tr><td>Anti-PAR polymers (mouse)</td><td>Enzo Life Sciences</td><td>BML-SA216-0100</td><td></td></tr><tr><td>Anti-PAR (rabbit)</td><td>Trevigen</td><td>4336-BPC-100</td><td></td></tr><tr><td>Anti-TRF2 (mouse)</td><td>Novus Biological&amp;nbsp;</td><td>NB100-56506</td><td></td></tr><tr><td>Anti 6-4PP (mouse)</td><td>Kamiya Biomedical</td><td></td><td></td></tr><tr><td>Anti-Rad21 (Rabbit)&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp; (for cohesin detection)</td><td>generated in Yokomori (KY) lab</td><td></td><td></td></tr><tr><td>Anti-Rad51 (Rabbit)</td><td>Santa Cruz Biotechnology</td><td>SC-8349</td><td></td></tr><tr><td>Anti-Ku70 (mouse)</td><td>&amp;nbsp;Novus Biologicals</td><td>NB100-102</td><td></td></tr><tr><td>8-oxiguanine&amp;nbsp;</td><td>Trevigen, Inc.</td><td></td><td></td></tr><tr><td>Anti-PARP1&amp;nbsp; (Rabbit)&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;</td><td>generated in KY lab</td><td></td><td>ref 43</td></tr><tr><td>&amp;nbsp;Anti-hCAPG (Rabbit)&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp; (for condensin detection)</td><td>generated in KY lab</td><td></td><td>ref 42</td></tr><tr><td>Cy3 AffiniPure Donkey Anti-Rabbit IgG</td><td>&amp;nbsp;Jackson ImmunoResearch Inc</td><td>711-165-152</td><td></td></tr><tr><td>Donkey Anti-Mouse Alexa Fluor 488 IgG</td><td>Thermo Fisher Scientific</td><td>A-21202</td><td></td></tr><tr><td>HiPerFect siRNA Transfection Reagent</td><td>Qiagen</td><td>301705</td><td></td></tr><tr><td>Lipofectamine 2000 Transfection Reagent</td><td>Thermo Fisher Scientific</td><td>11668019</td><td></td></tr><tr><td>GFP-SMC1 stable cell line&amp;nbsp;&amp;nbsp;&amp;nbsp;&amp;nbsp;</td><td>generated in KY lab</td><td></td><td>ref 49&amp;nbsp;</td></tr><tr><td>GFP-NEIL2 stable cell line</td><td>generated in KY lab</td><td></td><td>ref 54</td></tr><tr><td>GFP-NTH1 stable cell line</td><td>generated in KY lab</td><td></td><td>ref 32</td></tr><tr><td>GFP-SMC1 plasmid</td><td>generated in KY lab</td><td></td><td></td></tr><tr><td>GFP-Ku plasmid</td><td>generated in KY lab</td><td></td><td></td></tr><tr><td>Anti-MDC1 (rabbit)</td><td>&amp;nbsp;Novus Biologicals</td><td>NB100&amp;ndash;395</td><td></td></tr><tr><td>Anti-gH2AX (rabbit)</td><td>&amp;nbsp;Millipore</td><td>07&amp;ndash;164</td><td></td></tr><tr><td>EGFP-53BP1(1220-1711) PtK2 stable cell line</td><td>generated in Berns lab</td><td></td><td>ref 32</td></tr><tr><td>TRF2-YFP PtK2 stable cell line</td><td>generated in Berns lab</td><td></td><td>ref 32</td></tr><tr><td>DMSO</td><td>Sigma</td><td>D2650-100ML</td><td></td></tr><tr><td>PARG inhibitor</td><td>Trevigen</td><td>4680-096-03</td><td></td></tr><tr><td>DNA&amp;ndash;PKcs inhibitor&amp;nbsp; NU7026&amp;nbsp;</td><td>Sigma</td><td>N1537</td><td></td></tr><tr><td>ATM inhibitor KU55933</td><td>&amp;nbsp;Calbiochem</td><td>118500</td><td></td></tr><tr><td>Olaparib&amp;nbsp;</td><td>Apexbio Technology</td><td>A4154</td><td></td></tr><tr><td>Paraformaldehyde&amp;nbsp;</td><td>ELECTRON MICROSCOPY SCIENC MS</td><td>100503-916 (EA)</td><td></td></tr><tr><td>Quantity One 1-D Analysis Software Version 4.6.9</td><td>Bio-Rad</td><td>SOFT-LIT-70-9600-Q1-469PC&amp;nbsp;</td><td>image analysis program</td></tr><tr><td>Excel</td><td>microsoft</td><td></td><td>spreadsheet program</td></tr><tr><td>Triton X100</td><td>Fisher Scientific</td><td>BP151-500</td><td>detergent</td></tr><tr><td>Dulbecco&#039;s phosphate-buffered saline (DPBS) 10X without calcium and magnesium</td><td>Fisher Scientific</td><td>14200166</td><td>dilute to 1X&amp;nbsp;</td></tr></tbody></table>

laser microirradiation to study in vivo cellular responses to simple and complex dna damage

DNA damage induces specific signaling and repair responses in the cell, which is critical for protection of genome integrity. Laser microirradiation became a valuable experimental tool to investigate the DNA damage response (DDR) in vivo. It allows real-time high-resolution single-cell analysis of macromolecular dynamics in response to laser-induced damage confined to a submicrometer region in the cell nucleus. However, various laser conditions have been used without appreciation of differences in the types of damage induced. As a result, the nature of the damage is often not well characterized or controlled, causing apparent inconsistencies in the recruitment or modification profiles. We demonstrated that different irradiation conditions (i.e., different wavelengths as well as different input powers (irradiances) of a femtosecond (fs) near-infrared (NIR) laser) induced distinct DDR and repair protein assemblies. This reflects the type of DNA damage produced. This protocol describes how titration of laser input power allows induction of different amounts and complexities of DNA damage, which can easily be monitored by detection of base and crosslinking damages, differential poly (ADP-ribose) (PAR) signaling, and pathway-specific repair factor assemblies at damage sites. Once the damage conditions are determined, it is possible to investigate the effects of different damage complexity and differential damage signaling as well as depletion of upstream factor(s) on any factor of interest.

Using PtK2 cells stably expressing EGFP-53BP11220-1711 or TRF2-YFP, laser input power titration was carried out to determine the optimal condition for their recruitment (Figure 1)32.
At high input-power laser damage sites, the significant clustering of CPD (crosslinking damage typically generated by ultraviolet (UV) damage) as well as GFP-NTH1 DNA glycosylase that specifically recognizes base damage were observed. In addition, higher XRCC1 and CtIP signals were observed, reflecting the increased number of strand breaks, and demonstrating that complex DNA damage is induced under this condition (Figure 2A). Other DNA glycosylases fused to fluorescent proteins (e.g., GFP-nei endonuclease VIII-like 2 (NEIL2) and GFP-8-Oxoguanine glycosylase (OGG1)) as well as condensin I can also be used as base damage markers44,59. Consistent with this, we found that the PAR response is induced significantly by high input-power laser (i.e., energy and irradiance in the focal spot in the specimen), but only weakly by low laser power in the focal spot (Figure 2B, top left). PAR signals, but not PARP1 protein localization, at damage sites were sensitive to the PARP inhibitor (data not shown). Additionally, siRNA specific for PARP1 diminished both PAR and PARP1 at damage sites (Figure 2B, top right)32. Under the high input power condition, &#947;H2AX initially appears at the damage sites, and rapidly spreads to the entire nucleus in an ATM/DNA-PK-dependent manner (Figure 2B, bottom). Similar ATM/DNA-PK-dependent spreading of &#947;H2AX was reported for &#947;-irradiation60. Consistent results were obtained with both 800 and 780 nm NIR laser systems32. Taken together, the results reveal that it is possible to titrate laser input power (and therefore, energy and irradiance in the focal spot in the cell) to find the conditions that induce different degrees of PARP response correlating with the number of DSBs and the complexity of the DNA damage.
The above results initially suggested that the presence of complex DNA damage might have caused differential recruitment of 53BP1 and TRF2. Interestingly, however, the 53BP11220-1711 recruitment to a low-power damage site was effectively inhibited by the presence of the second damage site induced by high-input-power in the same cell nucleus (Figure 3A in contrast to Figure 3B). The results indicate that high-input-power laser damage suppresses 53BP1 recruitment in trans. Inhibition of PAR by PARP inhibitor as well as inhibition of nuclear-wide &#947;H2AX spreading by ATM/DNA-PK inhibitors restore this recruitment even to the high input power damage site (Figure 3A). This is distinct from the recruitment of Mediator of DNA Damage Checkpoint 1 (MDC1) to damage sites, which was primarily inhibited by &#947;H2AX dispersion, and therefore, was restored by ATM/DNA-PK inhibitors, not PARP inhibitor (Figure 3A, bottom). Importantly, hyperactivation of PAR by PARG inhibition (without affecting &#947;H2AX status) effectively suppressed initial 53BP1 recruitment even at the low input-power damage sites that normally recruit 53BP1 efficiently (Figure 3B)32. Taken together, these results indicate that PAR signaling, and not the type of damage per se, interferes with the recruitment of 53BP132. This is an example of the versatility of laser microirradiation, which allows us to examine how multiple damage sites influence and interact with each other.
<img alt="Figure 1" class="xfigimg" src="/files/ftp_upload/56213/56213fig1.jpg" />
Figure 1: Titration of laser input power. To determine the laser power to use for future experiments, PtK2 cells stably expressing EGFP-53BP1 and TRF2-YFP were subjected to laser microirradiation with input powers ranging between 20 mW and 155 mW using the 800 nm NIR laser/inverted epi-fluorescence microscope system. EGFP-53BP1 recruitment was monitored for 15 min post irradiation (p.i.), while TRF2-YFP cells were followed for 6 min p.i. The numbers directly above the bars represent the number of cells that showed positive recruitment of EGFP-53BP1 or TRF2-YFP to the damage sites over the total number of cells tested. This figure was modified from Saquilabon Cruz32. <a href="/files/ftp_upload/56213/56213fig1large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 2" class="xfigimg" src="/files/ftp_upload/56213/56213fig2.jpg" />
Figure 2: Induction of complex damage and robust DDR signaling by high input-power laser. (A) High-input-power laser microirradiation induces complex damage including strand breaks (both SSBs and DSBs), crosslinking, and base damage. CPD, XRCC1 (SSB and DSB repair), NTH1 DNA glycosylase (BER), and CtIP (alternative NHEJ and HR) are shown (only GFP-NTH1 is a live cell image and the rest are observed following immunofluorescence staining). Quantitative fluorescence intensity measurements of the damage site recruitment were done as stated in protocol Section 7 and are shown in the boxplots. The total number of cells (n) tested can be seen under each quantified protein. *p-value &#60;0.05. (B) Top (left): Robust PAR and PARP1 signals at high input-power damage sites. Top (right): PARP1 siRNA depletion is sufficient to abolish the PAR signal32,44. Bottom: Time course analysis of &#947;H2AX in cells with low (top) and high (bottom) input power damage as indicated. Scale bars = 10 &#181;m. This figure was modified from Saquilabon Cruz32. <a href="/files/ftp_upload/56213/56213fig2large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>
<img alt="Figure 3" class="xfigimg" src="/files/ftp_upload/56213/56213fig3.jpg" />
Figure 3: Differential activation of DDR signaling affects 53BP1 recruitment to damage sites. (A) Top: PtK2 cells stably expressing EGFP-53BP11220-1711 were microirradiated with both low (15%) and high (25%) input power (white and yellow arrowheads, respectively) in the same nucleus using the 780 nm NIR/confocal microscope system. This was performed in the presence of DMSO, PARP inhibitor (Pi), or the combination of ATM, DNA-PK, and PARP inhibitors (Ai+Di+Pi) as indicated. Live-cell imaging of EGFP-53BP11220-1711 was captured at 30 min after DSB induction. Cells were then fixed and stained with an antibody specific for &#947;H2AX as a DSB marker. Changes of fluorescence intensity of EGFP-53BP11220-1711 at damage sites are shown on the right with p-values (mean values are: DMSO, 0.03 &#177; 0.02; Pi, 0.34 &#177; 0.19; Ai+Di+Pi, 0.98 &#177; 0.23). Bottom: The effect of Pi and Ai+Di treatment on MDC1 localization with high input-power damage as indicated. Scale bar is 10 &#181;m. Right: Changes of fluorescence signals of MDC1 at high input-power damage sites in the presence of DMSO, Pi, or Ai+Di with p-values (mean values are: DMSO, 0.07 &#177; 0.10; Pi, 0.05 &#177; 0.07; Ai+Di, 0.86 &#177; 0.26). Scale bar = 10 &#181;m. N = 10 for each intensity measurement. (B) The effect of enhancement of PAR signals by PARGi treatment on the endogenous 53BP1 recruitment to low input-power damage sites. Right: Boxplots representing the quantitative analysis of endogenous 53BP1 recruitment (detected by immunofluorescence staining) with low input-power laser (60 mW in the 800 nm NIR laser/inverted epi-fluorescence microscope system) at 15 min post irradiation in the presence of DMSO or PARGi as indicated. Left: PAR and 53BP1 immunofluorescence staining pictures of cells damaged under the same conditions with DMSO or PARGi treatment. For DMSO treatment, 100% of cells examined (N = 25) exhibited robust 53BP1 recruitment (right). In contrast, 20/25 showed no 53BP1 recruitment in the presence of PARGi (bottom right), and 5 cells showed weak recruitment. Scale bar = 10 &#181;m. This figure was modified from Saquilabon Cruz32. <a href="/files/ftp_upload/56213/56213fig3large.jpg" target="_blank">Please click here to view a larger version of this figure.</a>

Watch this Scientific Journal Video about Laser Microirradiation to Study In Vivo Cellular Responses to Simple and Complex DNA Damage at JoVE.com

Laser Microirradiation to Study In Vivo Cellular Responses to Simple and Complex DNA Damage

The goal of this protocol is to describe how to use laser microirradiation to induce different types of DNA damage, including relatively simple strand breaks and complex damage, to study DNA damage signaling and repair factor assembly at damage sites in vivo.

Laser Microirradiation to Study In Vivo Cellular Responses to Simple and Complex DNA Damage

DNA damage induces specific signaling and repair responses in the cell, which is critical for protection of genome integrity. Laser microirradiation ...
