The authors would like to acknowledge the funding received from the American Heart Association (SDG12SDG9130039).

1. Scaffold Liposome Preparation
NOTE: Ideally, initial experiments should use a relatively simple and featureless scaffold (comprised of DOPC (1,2-dioleoyl-sn-glycero-3-phosphocholine or PC) and DGS-NTA(Ni2+) (1,2-dioleoyl-sn-glycero-3-[(N-(5-amino-1-carboxypentyl)iminodiacetic acid)succinyl](nickel salt)). Building off of these experiments, lipid charge, flexibility, and curvature can be introduced as individual factors with the potential to alter membrane-proximal interactions. These changes can be achieved by adding defined amounts of specific lipid constituents, including phosphatidylserine or cardiolipin (CL), phosphatidylethanolamine (DOPE or PE), or galactosyl(&#946;) ceramide.
<ol>
	<li>Combine lipids dissolved in chloroform in a clean glass test tube. Evaporate the solvent with dry nitrogen gas while rotating the tube to form a thin lipid film. Remove residual solvent with a centrifugal evaporator for 1 h at 37 &#176;C.
	NOTE: Various liposome formulations are used in the protocols described below: scaffold liposomes (3.3 mol% DGS-NTA(Ni2+) / 96.7 mol% DOPC), scaffold liposomes with cardiolipin (3.3 mol% DGS-NTA(Ni2+) / 10 mol% cardiolipin / 86.7 mol% DOPC), flexible scaffold liposomes with cardiolipin (3.3 mol% DGS-NTA(Ni2+) / 10 mol% cardiolipin / 35 mol% DOPE / 51.7 mol% DOPC), and enriched scaffold liposomes (10 mol% DGS-NTA(Ni2+) / 15 mol% cardiolipin / 35 mol% DOPE / 40 mol% DOPC).</li>
	<li>Add Buffer A (25 mM HEPES (4-(2-hydroxyethyl)-1-piperazineethanesulfonic acid), 150 mM KCl, pH adjusted to 7.5 with KOH) preheated to 37 &#176;C such that the final lipid concentration is 1 - 2 mM. Incubate 30 min at 37 &#176;C with occasional vortexing to fully resuspend the lipid mixture (Figure 1a).</li>
	<li>Transfer to a plastic test tube, place the tube in liquid nitrogen until completely frozen (roughly 30 s), and place in a 37 &#176;C water bath until fully thawed (roughly 1 - 2 min). Repeat for a total of 4 freeze-thaw cycles (Figure 1b).</li>
	<li>Prepare a lipid extruder by soaking 4 filter supports and a polycarbonate filter in buffer and assembling the extruder according to manufacturer instructions. Extrude the lipid solution through the filter 21 times. Use gentle, constant pressure to ensure a homogenous size distribution (Figure 1c).
	NOTE: For all experiments described in this protocol, a 1.0 &#181;m polycarbonate filter was used for extrusion. Drp1 interaction with anionic lipids can be observed with a variety of liposome diameters ranging from 50 nm to 400 nm12 or larger13. Hence, the filter size of 1 &#181;m was chosen to be ideal for both GTPase activity and for electron microscopy. If other liposome diameters are desired, preparation of giant unilamellar vesicles14,15 (GUVs) or small unilamellar vesicles16 (SUVs) can be used. Dynamic light scattering can be used to assess liposome size heterogeneity13.</li>
	<li>Store extruded liposomes at 4 &#176;C and discard after 3 - 5 d.</li>
</ol>
2. Use of Scaffold Liposomes for Protein Binding Analysis
<ol>
	<li>Sample Preparation
	<ol>
		<li>Incubate His-tagged Mff&#916;TM (5 &#181;M final) with scaffold liposomes (40 mol% PC / 35 mol% PE / 15 mol% CL / 10 mol% DGS-NTA(Ni2+); 50 &#181;M final) for at least 15 min at RT in Buffer A + BME (25 mM HEPES, 150 mM KCl, 10 mM &#946;-mercaptoethanol (BME), pH adjusted to 7.5 with KOH). For an Mff-free control, incubate liposomes with a his-tagged control protein (such as GFP) to bind and shield exposed NTA(Ni2+).
		NOTE: Mff&#916;TM was expressed and purified as described in a previous study2. GFP was purified in a similar manner, but the ion-exchange step was omitted. BME was required for these experiments because Drp1 is sensitive to oxidation, which can alter its activity and assembly properties.</li>
		<li>Add Drp1 (2 &#181;M final) and incubate for 1 h at RT.
		NOTE: Drp1 was expressed and purified as described in a previous study2. After incubation with Drp1, the effect of nucleotide binding on membrane deformation can be investigated by incubating one additional hour with 2 mM MgCl2 and either 1 mM GTP, 1 mM GMP-PCP, or Buffer A + BME.</li>
	</ol>
	</li>
	<li>Negative Stain Transmission Electron Microscopy (EM) Analysis
	<ol>
		<li>Transfer 5 &#181;L of sample to a sheet of laboratory film, and lay a carbon-coated Cu/Rh grid on the sample. Incubate the grid 1 min on the sample, blot away excess liquid on filter paper, and transfer to a drop of 2% uranyl acetate. Incubate 1 min, blot excess stain on filter paper, and transfer to a grid box. Store under vacuum O/N to ensure full desiccation.</li>
		<li>Image samples using a transmission electron microscope at 18,500 - 30,000X&#160;magnification to observe ultrastructural changes in protein and liposome morphologies17.&#160;
		Note: Ultrastructural changes can be quantified using image analysis software, such as ImageJ13 (http://imagej.nih.gov/ij/). Protein decoration can be measured when compared with naked lipid templates. Additionally, the diameters of tubular segments can be measured from the outermost portion of the assemblies13. A more detailed analysis can be performed using cryo-electron microscopy17. This method can be used to image native protein-lipid assemblies in solvent without the use of heavy metal stains that coat the sample. In this way, detailed structural features not apparent in negative stain, including changes in the underlying lipid morphology, can be examined and quantified.</li>
	</ol>
	</li>
</ol>
3. Use of Scaffold Liposomes for Enzymatic Assay
Note: A colorimetric GTPase assay18 was used to measure phosphate liberation via GTP hydrolysis. Alternative GTPase assays are available19 and can be implemented as needed.
<ol>
	<li>Incubate His-tagged Mff&#916;TM (Mff), Fis1&#916;TM(Fis1), or GFP (5 &#181;M final for all) with scaffold liposomes (150 &#181;M final) for 15 min at RT in Buffer A + BME (volume = 30 &#181;L). Add Drp1 (500 nM final) and incubate an additional 15 min at RT (volume = 80 &#181;L).
	NOTE: Fis1 was purified in a similar manner to Mff2, but the ion-exchange chromatography step was omitted. The purpose of His-tagged GFP is to shield the NTA(Ni2+) headgroups and prevent nonspecific charge interactions with other proteins. If no effect is observed in the absence of GFP, then this control may not be required. Alternative blocking proteins (of comparable size to the protein of interest) can be used as well, but GFP allows for direct visualization of the interactions with scaffold liposomes.</li>
	<li>Transfer tubes to a thermocycler set to 37 &#176;C, and initiate reactions by addition of GTP and MgCl2 (1 mM and 2 mM final, respectively; volume = 120 &#181;L).</li>
	<li>At desired time points (i.e. T = 5, 10, 20, 40, 60 min), transfer 20 &#181;L of reaction to wells of a microtiter plate containing 5 &#181;L of 0.5 M EDTA to chelate Mg2+ and stop the reaction.</li>
	<li>Prepare a set of phosphate standards by diluting KH2PO4 in Buffer A + BME to calibrate results. A useful set of standards is 100, 80, 60, 40, 20, 10, 5, and 0 &#181;M. Add 20 &#181;L of each to wells containing 5 &#181;L of 0.5 M EDTA.</li>
	<li>Add 150 &#181;L of Malachite green reagent (1 mM malachite green carbinol, 10 mM ammonium molybdate tetrahydrate, and 1 N HCl) to each well, and read OD650 5 min after addition.
	NOTE: GTP is acid labile, and will hydrolyze in the presence of malachite green reagent. Ensure that the time between adding malachite reagent and reading is constant to ensure reproducible results.</li>
	<li>Generate a standard curve by plotting OD650 of the standards as a function of phosphate concentration. Use linear regression to determine the relationship between OD650 and phosphate concentration in a sample.</li>
	<li>Using the linear regression, convert the OD650 of the protein reaction samples to &#181;M phosphate. Determine the rate of phosphate generation for each reaction mixture by plotting phosphate concentration as a function of time, and convert to kcat by dividing the rate by the Drp1 concentration (0.5 &#181;M).
	NOTE: Only the initial linear rate should be used to determine the rate of phosphate generation, and a minimum of 3 data points must be used. If the rate of reaction is sufficiently rapid that the first three data points are not linear (i.e. the r2 of the linear fit is less than 0.9) a significantly shorter time course with at least 3 time points should be performed.</li>
</ol>

<ol>
	<li>Seddon, A. M., Curnow, P., Booth, P. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Membrane+proteins,+lipids+and+detergents:+not+just+a+soap+opera.">Membrane proteins, lipids and detergents: not just a soap opera.</a> Biochim Biophys Acta (BBA) - Biomembranes. 1666 (1-2), 105-117 (2004).</li><li>Clinton, R. W., Francy, C. A., Ramachandran, R., Qi, X., Mears, J. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamin-related+Protein+1+Oligomerization+in+Solution+Impairs+Functional+Interactions+with+Membrane-anchored+Mitochondrial+Fission+Factor.">Dynamin-related Protein 1 Oligomerization in Solution Impairs Functional Interactions with Membrane-anchored Mitochondrial Fission Factor.</a> J Biol Chem. 291 (1), 478-492 (2016).</li><li>Chan, D. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mitochondrial+Fusion+and+Fission+in+Mammals.">Mitochondrial Fusion and Fission in Mammals.</a> Annual Review of Cell and Dev Biol. 22 (1), 79-99 (2006).</li><li>Bui, H. T., Shaw, J. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dynamin+Assembly+Strategies+and+Adaptor+Proteins+in+Mitochondrial+Fission.">Dynamin Assembly Strategies and Adaptor Proteins in Mitochondrial Fission.</a> Curr Biol. 23 (19), R891-R899 (2013).</li><li>Elgass, K., Pakay, J., Ryan, M. T., Palmer, C. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Recent+advances+into+the+understanding+of+mitochondrial+fission.">Recent advances into the understanding of mitochondrial fission.</a> Biochim Biophys Acta (BBA) - Mol Cell Res. 1833 (1), 150-161 (2013).</li><li>Los&#243;n, O. C., Song, Z., Chen, H., Chan, D. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Fis1,+Mff,+MiD49,+and+MiD51+mediate+Drp1+recruitment+in+mitochondrial+fission.">Fis1, Mff, MiD49, and MiD51 mediate Drp1 recruitment in mitochondrial fission.</a> Mol Biol Cell. 24 (5), 659-667 (2013).</li><li>Otera, H., Wang, C., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mff+is+an+essential+factor+for+mitochondrial+recruitment+of+Drp1+during+mitochondrial+fission+in+mammalian+cells.">Mff is an essential factor for mitochondrial recruitment of Drp1 during mitochondrial fission in mammalian cells.</a> J Cell Biol. 191 (6), 1141-1158 (2010).</li><li>Gandre-Babbe, S., van der Bliek, A. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Novel+Tail-anchored+Membrane+Protein+Mff+Controls+Mitochondrial+and+Peroxisomal+Fission+in+Mammalian+Cells.">The Novel Tail-anchored Membrane Protein Mff Controls Mitochondrial and Peroxisomal Fission in Mammalian Cells.</a> Mol Biol Cell. 19 (6), 2402-2412 (2008).</li><li>Koirala, S., Guo, Q., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Interchangeable+adaptors+regulate+mitochondrial+dynamin+assembly+for+membrane+scission.">Interchangeable adaptors regulate mitochondrial dynamin assembly for membrane scission.</a> Proc Natl Acad Sci. 110 (15), E1342-E1351 (2013).</li><li>Macdonald, P. J., Stepanyants, N., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+dimeric+equilibrium+intermediate+nucleates+Drp1+reassembly+on+mitochondrial+membranes+for+fission.">A dimeric equilibrium intermediate nucleates Drp1 reassembly on mitochondrial membranes for fission.</a> Mol Biol Cell. 25 (12), 1905-1915 (2014).</li><li>Macdonald, P. J., Francy, C. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Distinct+Splice+Variants+of+Dynamin-related+Protein+1+Differentially+Utilize+Mitochondrial+Fission+Factor+as+an+Effector+of+Cooperative+GTPase+Activity.">Distinct Splice Variants of Dynamin-related Protein 1 Differentially Utilize Mitochondrial Fission Factor as an Effector of Cooperative GTPase Activity.</a> J Biol Chem. 291 (1), 493-507 (2016).</li><li>Bustillo-Zabalbeitia, I., Montessuit, S., Raemy, E., Basa&#241;ez, G., Terrones, O., Martinou, J. -. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Specific+Interaction+with+Cardiolipin+Triggers+Functional+Activation+of+Dynamin-Related+Protein+1.">Specific Interaction with Cardiolipin Triggers Functional Activation of Dynamin-Related Protein 1.</a> PLoS ONE. 9 (7), (2014).</li><li>Francy, C. A., Alvarez, F. J. D., Zhou, L., Ramachandran, R., Mears, J. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Mechanoenzymatic+Core+of+Dynamin-Related+Protein+1+Comprises+the+Minimal+Machinery+Required+for+Membrane+Constriction.">The Mechanoenzymatic Core of Dynamin-Related Protein 1 Comprises the Minimal Machinery Required for Membrane Constriction.</a> J Biol Chem. 290 (18), 11692-11703 (2015).</li><li>Walde, P., Cosentino, K., Engel, H., Stano, P. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Giant+Vesicles:+Preparations+and+Applications.">Giant Vesicles: Preparations and Applications.</a> ChemBioChem. 11 (7), 848-865 (2010).</li><li>Moscho, A., Orwar, O., Chiu, D. T., Modi, B. P., Zare, R. N. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Rapid+preparation+of+giant+unilamellar+vesicles.">Rapid preparation of giant unilamellar vesicles.</a> Proc Natl Acad Sci. 93 (21), 11443-11447 (1996).</li><li>Klingler, J., Vargas, C., Fiedler, S., Keller, S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Preparation+of+ready-to-use+small+unilamellar+phospholipid+vesicles+by+ultrasonication+with+a+beaker+resonator.">Preparation of ready-to-use small unilamellar phospholipid vesicles by ultrasonication with a beaker resonator.</a> Anal Biochem. 477, 10-12 (2015).</li><li>Mears, J. A., Hinshaw, J. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Chapter+13+Visualization+of+Dynamins.">Chapter 13 Visualization of Dynamins.</a> Methods Cell Biol. 88, 237-256 (2008).</li><li>Leonard, M., Doo Song, B., Ramachandran, R., Schmid, S. L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Robust+Colorimetric+Assays+for+Dynamin's+Basal+and+Stimulated+GTPase+Activities.">Robust Colorimetric Assays for Dynamin's Basal and Stimulated GTPase Activities.</a> Methods Enzymol. 404, 490-503 (2005).</li><li>Ingerman, E., Perkins, E. M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Dnm1+forms+spirals+that+are+structurally+tailored+to+fit+mitochondria.">Dnm1 forms spirals that are structurally tailored to fit mitochondria.</a> J Cell Biol. 170 (7), 1021-1027 (2005).</li><li>Fr&#246;hlich, C., Grabiger, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structural+insights+into+oligomerization+and+mitochondrial+remodelling+of+dynamin+1-like+protein.">Structural insights into oligomerization and mitochondrial remodelling of dynamin 1-like protein.</a> EMBO J. 32 (9), 1280-1292 (2013).</li><li>James, D. I., Parone, P. A., Mattenberger, Y., Martinou, J. -. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=hFis1,+a+Novel+Component+of+the+Mammalian+Mitochondrial+Fission+Machinery.">hFis1, a Novel Component of the Mammalian Mitochondrial Fission Machinery.</a> J Biol Chem. 278 (38), 36373-36379 (2003).</li><li>Yoon, Y., Krueger, E. W., Oswald, B. J., McNiven, M. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=The+Mitochondrial+Protein+hFis1+Regulates+Mitochondrial+Fission+in+Mammalian+Cells+through+an+Interaction+with+the+Dynamin-Like+Protein+DLP1.">The Mitochondrial Protein hFis1 Regulates Mitochondrial Fission in Mammalian Cells through an Interaction with the Dynamin-Like Protein DLP1.</a> Mol Cell Biol. 23 (15), 5409-5420 (2003).</li><li>Osellame, L. D., Singh, A. P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cooperative+and+independent+roles+of+Drp1+adaptors+Mff+and+MiD49/51+in+mitochondrial+fission.">Cooperative and independent roles of Drp1 adaptors Mff and MiD49/51 in mitochondrial fission.</a> J Cell Sci. 129 (11), 2170-2181 (2016).</li><li>Esposito, E. A., Shrout, A. L., Weis, R. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Template-Directed+Self-Assembly+Enhances+RTK+Catalytic+Domain+Function.">Template-Directed Self-Assembly Enhances RTK Catalytic Domain Function.</a> J Biomol Screen. 13 (8), 810-816 (2008).</li><li>Shrout, A. L., Esposito, E. A., Weis, R. M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Template-directed+Assembly+of+Signaling+Proteins:+A+Novel+Drug+Screening+and+Research+Tool.">Template-directed Assembly of Signaling Proteins: A Novel Drug Screening and Research Tool.</a> Chem Biol Drug Des. 71 (3), 278-281 (2008).</li><li>Celia, H., Wilson-Kubalek, E., Milligan, R. A., Teyton, L. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Structure+and+function+of+a+membrane-bound+murine+MHC+class+I+molecule.">Structure and function of a membrane-bound murine MHC class I molecule.</a> Proc Natl Acad Sci U.S.A. 96 (10), 5634-5639 (1999).</li><li>Li, E., Wimley, W. C., Hristova, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Transmembrane+helix+dimerization:+Beyond+the+search+for+sequence+motifs.">Transmembrane helix dimerization: Beyond the search for sequence motifs.</a> Biochim Biophys Acta (BBA) - Biomembranes. 1818 (2), 183-193 (2012).</li><li>Zhang, F., Crise, B., Su, B., Hou, Y., Rose, J. K., Bothwell, A., Jacobson, K. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lateral+diffusion+of+membrane-spanning+and+glycosylphosphatidylinositol-+linked+proteins:+toward+establishing+rules+governing+the+lateral+mobility+of+membrane+proteins.">Lateral diffusion of membrane-spanning and glycosylphosphatidylinositol- linked proteins: toward establishing rules governing the lateral mobility of membrane proteins.</a> J Cell Biol. 115 (1), 75-84 (1991).</li><li>Ramadurai, S., Holt, A., Krasnikov, V., van den Bogaart, G., Killian, J. A., Poolman, B. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lateral+diffusion+of+membrane+proteins.">Lateral diffusion of membrane proteins.</a> J Am Chem Soc. 131 (35), 12650-12656 (2009).</li><li>Gambin, Y., Reffay, M., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Variation+of+the+lateral+mobility+of+transmembrane+peptides+with+hydrophobic+mismatch.">Variation of the lateral mobility of transmembrane peptides with hydrophobic mismatch.</a> J Phys Chem. B. 114 (10), 3559-3566 (2010).</li><li>Wilson-Kubalek, E. M., Brown, R. E., Celia, H., Milligan, R. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lipid+nanotubes+as+substrates+for+helical+crystallization+of+macromolecules.">Lipid nanotubes as substrates for helical crystallization of macromolecules.</a> Proc Natl Acad Sci. 95 (14), 8040-8045 (1998).</li></ol>

The authors have nothing to disclose.

This protocol offers a method for investigating protein-protein interactions involving integral membrane proteins. By utilizing a modular liposome scaffold, investigators are capable of assessing the activity of one or more proteins in a lipid-proximal environment. Previous studies have demonstrated a similar method for receptor enzymes of the plasma membrane24-26. We have expanded this method to incorporate lipid cofactors and explore interactions between proteins that make up the mechan...

Studying membrane-proximal protein-protein interactions is a challenging endeavor due to difficulty in recapitulating the native environment of the integral membrane proteins involved1. This is due to the necessity of detergent solubilization and the inconsistent orientation of proteins in proteoliposomes. In order to avoid these issues, we have employed a strategy whereby soluble domains of integral membrane proteins are expressed as His-tag fusion proteins, and these soluble fragments are anchored to scaffold liposomes via interactions with NTA(Ni2+) headgroups at the lipid surface. Using these scaffolds, lipid-proximal protein interactions can be investigated over a range of lipid and protein compositions.
We have effectively applied this method to investigate the critical protein-protein interactions that govern assembly of the mitochondrial fission complex and examine lipid interactions that modulate this process2. During mitochondrial fission, a conserved membrane remodeling protein, called Dynamin-related protein 1 (Drp1)3, is recruited to the surface of the Outer Mitochondrial Membrane (OMM) in response to cellular signals that regulate energy homeostasis, apoptotic signaling, and several other integral mitochondrial processes. This large, cytosolic GTPase is recruited to the surface of mitochondria through interactions with integral OMM proteins4-8. The role of one such protein, Mitochondrial Fission Factor (Mff), has been difficult to elucidate due to an apparent weak interaction with Drp1 in vitro. Nevertheless, genetic studies have clearly demonstrated that Mff is essential for successful mitochondrial fission7,8. The method described in this manuscript was able to overcome previous shortcomings by introducing simultaneous lipid interactions that promote Drp1-Mff interactions. Overall, this novel assay revealed fundamental interactions guiding assembly of the mitochondrial fission complex and provided a new stage for ongoing structural and functional studies of this essential molecular machine.
To date, examination of interactions between Drp1 and Mff have been complicated by the inherent flexibility of Mff9, the heterogeneity of Drp1 polymers2,10, and the difficulty in purifying and reconstituting full-length Mff with an intact transmembrane domain11. We addressed these challenges by using NTA(Ni2+) scaffold liposomes to reconstitute His-tagged Mff lacking its transmembrane domain(Mff&#916;TM-His6). This strategy was advantageous because Mff&#916;TM was extremely soluble when over-expressed in E. coli, and this isolated protein was easily reconstituted on scaffold liposomes. When tethered to these lipid templates, Mff assumed an identical, outward facing orientation on the surface of the membrane. In addition to these advantages, mitochondrial lipids, such as cardiolipin, were added to stabilize Mff folding and association with the membrane11. Cardiolipin also interacts with the variable domain of Drp12,12 which may stabilize this disordered region and facilitate assembly of the fission machinery.
This robust method is widely applicable for future studies that seek to evaluate membrane-proximal protein interactions. Through the use of additional tethering/affinity interactions, the sophistication of these membrane reconstitution studies can be enhanced to mimic additional complexity found at the surface of membranes within cells. At the same time, lipid compositions can be modified to more accurately mimic the native environments of these macromolecular complexes. In summary, this method provides a means to examine the relative contributions of proteins and lipids in shaping membrane morphologies to during critical cellular processes.

<table><tbody><tr><td>Phosphatidylcholine (DOPC)</td><td>Avanti Polar Lipids</td><td>850375</td><td></td></tr><tr><td>Phosphatidylethanolamine (DOPE)</td><td>Avanti Polar Lipids</td><td>850725</td><td></td></tr><tr><td>DGS-NTA(Ni&lt;sup&gt;2+&lt;/sup&gt;)</td><td>Avanti Polar Lipids</td><td>790404</td><td></td></tr><tr><td>Bovine Heart Cardiolipin (CL)</td><td>Avanti Polar Lipids</td><td>840012</td><td></td></tr><tr><td>Chloroform</td><td>Acros Organics</td><td>268320010</td><td></td></tr><tr><td>Liposome Extruder</td><td>Avanti Polar Lipids</td><td>610023</td><td></td></tr><tr><td>Cu/Rh Negative Stain Grids</td><td>Ted Pella</td><td>79712</td><td></td></tr><tr><td>Microfuge Tube</td><td>Beckman</td><td>357448</td><td></td></tr><tr><td>GTP</td><td>Jena Biosciences</td><td>NU-1012</td><td></td></tr><tr><td>GMP-PCP</td><td>Sigma Aldrich</td><td>M3509</td><td></td></tr><tr><td>Microtiter Plate strips</td><td>Thermo Scientific</td><td>469949</td><td></td></tr><tr><td>EDTA</td><td>Acros Organics</td><td>40993-0010</td><td></td></tr><tr><td>Instant Blue Coomassie Dye</td><td>Expedeon</td><td>ISB1L</td><td></td></tr><tr><td>HEPES</td><td>Fisher Scientific</td><td>BP310</td><td></td></tr><tr><td>BME</td><td>Sigma Aldrich</td><td>M6250</td><td></td></tr><tr><td>KCl</td><td>Fisher Scientific</td><td>P330</td><td></td></tr><tr><td>KOH</td><td>Fisher Scientific</td><td>P250</td><td></td></tr><tr><td>Magnesium Chloride</td><td>Acros Organics</td><td>223211000</td><td></td></tr><tr><td>4 - 20% SDS-PAGE Gel</td><td>Bio Rad</td><td>456-1096</td><td></td></tr><tr><td>4x Laemmli Loading Dye</td><td>Bio Rad</td><td>161-0747</td><td></td></tr><tr><td>HCL</td><td>Fisher Scientific</td><td>A144S</td><td></td></tr><tr><td>Malachite Green Carbinol</td><td>Sigma Aldrich</td><td>229105</td><td></td></tr><tr><td>Ammonium Molybdate Tetrahydrate</td><td>Sigma Aldrich</td><td>A7302</td><td></td></tr><tr><td>Laboratory Film</td><td>Parafilm</td><td>PM-996</td><td></td></tr><tr><td>Uranyl Acetate</td><td>Polysciences</td><td>21447</td><td></td></tr><tr><td>Tecnai T12 100 keV Microscope</td><td>FEI</td><td></td><td></td></tr><tr><td>Optima MAX</td><td>Beckman</td><td></td><td></td></tr><tr><td>TLA-55 Rotor</td><td>Beckman</td><td></td><td></td></tr><tr><td>Refrigerated CentriVap Concentrator</td><td>Labconico</td><td></td><td></td></tr><tr><td>Mastercycler Pro Thermocycler</td><td>Eppendorf</td><td></td><td></td></tr><tr><td>VersaMax Microplate reader</td><td>Molecular Devices</td><td></td><td></td></tr></tbody></table>

using scaffold liposomes to reconstitute lipid-proximal protein-protein interactions in vitro

Studies of integral membrane proteins in vitro are frequently complicated by the presence of a hydrophobic transmembrane domain. Further complicating these studies, reincorporation of detergent-solubilized membrane proteins into liposomes is a stochastic process where protein topology is impossible to enforce. This paper offers an alternative method to these challenging techniques that utilizes a liposome-based scaffold. Protein solubility is enhanced by deletion of the transmembrane domain, and these amino acids are replaced with a tethering moiety, such as a His-tag. This tether interacts with an anchoring group (Ni2+ coordinated by nitrilotriacetic acid (NTA(Ni2+)) for His-tagged proteins), which enforces a uniform protein topology at the surface of the liposome. An example is presented wherein the interaction between Dynamin-related protein 1 (Drp1) with an integral membrane protein, Mitochondrial Fission Factor (Mff), was investigated using this scaffold liposome method. In this work, we have demonstrated the ability of Mff to efficiently recruit soluble Drp1 to the surface of liposomes, which stimulated its GTPase activity. Moreover, Drp1 was able to tubulate the Mff-decorated lipid template in the presence of specific lipids. This example demonstrates the effectiveness of scaffold liposomes using structural and functional assays and highlights the role of Mff in regulating Drp1 activity.

While the interaction between Drp1 and Mff has been demonstrated to be important for mitochondrial fission, this interaction has been difficult to recapitulate in vitro. Our goal was to better emulate the cellular environment wherein Drp1 and Mff interact. To this end, liposomes containing limiting concentrations of NTA(Ni2+) headgroups were prepared by rehydrating a lipid film as described above. The lipid solution initially consists of unilamellar and multilamellar v...

Watch this Scientific Journal Video about Using Scaffold Liposomes to Reconstitute Lipid-proximal Protein-protein Interactions In Vitro at JoVE.com

Using Scaffold Liposomes to Reconstitute Lipid-proximal Protein-protein Interactions In Vitro

This paper describes a method for assessing the interactions and assemblies of integral membrane proteins in vitro with various partner factors in a lipid-proximal environment.

Using Scaffold Liposomes to Reconstitute Lipid-proximal Protein-protein Interactions In Vitro

Studies of integral membrane proteins in vitro are frequently complicated by the presence of a hydrophobic transmembrane domain. Further complicating ...

using-scaffold-liposomes-to-reconstitute-lipid-proximal-protein
