The authors thank Dr. Darrel Kotton at Boston University for providing the pHAGE-EF1aL-dsRed-UBC-GFP-W vector and protocols for high titer lentiviral production used in these studies. This work was funded by DOD BCRP W81XWH-11-1-0101 (DMC), ACS IRG # 57-001-53 (DMC), NCI K22CA181250 (DMC) and R01 CA140985 (CAS).NCI P30CA046934 Center grant supported in vivo imaging and tissue culture cores at University of Colorado AMC.

All steps requiring the use of animals in this protocol follows the guidelines of University of Colorado animal research ethics committee (IACUC).
1. Preparation of Instruments, Culture Media and Other Reagents
<ol>
	<li>Prepare 100 ml mammosphere media containing Dulbecco&#39;s Modified Eagle Medium and Han&#39;s F-12 medium (DMEM/F12) (1:1), basic Fibroblast Growth Factor (bFGF, 20 ng/ml), epidermal growth factor (EGF, 10 ng/ml), Heparin (4 &#181;g/ml), 1x B27, Penicillin (100 U/ml), streptomycin (100 &#181;g/ml). Make media in sterile conditions and store at 4 &#176;C for up to 3 months.</li>
	<li>Prepare epithelial enrichment buffer (EEB) containing PBS pH 7.2, 0.5% Bovine Serum Albumin (BSA), 2 mM EDTA. Filter sterilize and store at 4 &#176;C for up to 6 months.</li>
	<li>Make 5 ml aliquots of digestion buffer in sterile 15 ml conical tubes and store at -20 &#176;C for months. The night before tumor digestion, thaw digestion buffer (5 ml per 500 mg tumor) on ice, at 4 &#176;C. Add 1x antibiotic-antimycotic mix before use.</li>
	<li>Autoclave (121 &#176;C for 30 min) at least two forceps, scalpel and scissors for dissection of PDXs.</li>
	<li>Make 500 ml wash buffer containing DMEM:F12 and 5% Fetal Bovine Serum (FBS). Store at 4 &#176;C for months. Aliquot 10 ml per tumor the day of tumor dissection.</li>
	<li>Prepare a polybrene stock at 4 &#181;g/&#181;l with sterile water. Filter and aliquot into 1.5 ml microcentrifuge tubes containing 100 &#181;l each, store at -20 &#176;C.</li>
</ol>
2. Generation of High Titer Lentiviral Particles Carrying Traceable Markers
<ol>
	<li>Purchase or generate high titer lentiviral particles carrying a reporter gene (i.e., GFP and Luc for in vivo tracking of tumor growth) 18,19.
	NOTE: A lentiviral titer of &#62; 108 TU/ml (transduction units per milliliter) is recommended for successful transduction of PDXs. The lentiviral particles should be pseudotyped with an envelope G glycoprotein from Vesicular Stomatitis Virus (VSV-G), allowing transduction of a wide variety of mammalian cells.
	NOTE: The protocol used here for the generation and titration of high titer lentiviral particles is available at <a href="http://www.kottonlab.com">www.kottonlab.com</a>. Vectors used in this protocol are pSIH1-H1-copGFP-T2A-puro and the dual promoter pHAGE-EF1aL-luciferase-UBC-GFP-W. This vector was generated by replacing dsRed with the luciferase gene downstream of EF1aL promoter in the pHAGE-EF1aL-dsRed-UBC-GFP-W vector, a kind gift of Darrell Kotton, Boston University.</li>
</ol>
3. Generation of Patient-derived Xenografts
<ol>
	<li>Generate patient derived xenografts (PDX) from breast cancer by implanting primary or metastatic breast tumors in the mammary fat pad of immunocompromised mice3,4. Generate tumors at a maximum recommended size of 1 cm diameter as larger tumors are likely to contain necrotic cores.
	NOTE: Detailed methods for establishing and transplanting xenografts are described in DeRose et al. 18. Growth of established-transplantable PDXs into &#62; 1 cm-diameter tumors takes between 4 and 24 weeks after implantation in immunocompromised NOD/SCID/ILIIrg&#8722;/&#8722; (NSG), depending on intrinsic tumor growth rates. While this protocol describes transduction of breast cancer PDXs, it can be used for viral transduction of any tumor suitable to short-term in vitro passage. The sensitivity of PDXs to short-term (24 - 96 hr) in vitro survival is intrinsic to each tumor and must be determined experimentally.</li>
</ol>
4. Tumor Dissection and Dissociation of PDX-derived Tumor Cells
<ol>
	<li>Euthanize mice carrying PDX using CO2 inhalation followed by cervical dislocation (follow institutional guidelines of animal research ethics committee). Submerge mice in a 0.2% Chlorhexidine solution for 1 min. Set mouse on a supine position on top of a dissection board, and use pins to fix the extended upper and lower limbs to the board.</li>
	<li>Using aseptic technique, use a scalpel to cut the skin around the tumor. Pull the skin with a set of forceps and separate it from the tumor using a clean scalpel until the tumor is completely exposed. Using a clean set of forceps and scalpel, remove the tumor and place it in 5 ml wash media on ice.</li>
	<li>Take dissected tumor into a BLS2 cabinet for further processing. Remove media and rinse tumor with 10 ml of Hank&#39;s Balanced Salt Sodium Modified with 10 mM Hepes (HBSS/Hepes), twice.</li>
	<li>Drop the tumor in a sterile pre-weighed 60 cm tissue culture plate. Weigh the plate containing the tumor to estimate tumor mass.</li>
	<li>Using a scalpel, cut the tumor in half, then cut a 3 mm disc from one half and place it in a container with 10% formalin for 24 hr. Use this tissue to verify the heterogeneity of the tumor sample (parental PDX). Add 200 &#181;l of HBSS/Hepes (enough to avoid the tissue to dry out) and mince the remaining tumor in the smallest possible pieces using forceps and a clean scalpel.</li>
	<li>Transfer the minced tumor into a sterile 50 ml conical tube. Add at least 1 ml of digestion buffer containing 1x antimycotic-antibiotic per 100 mg of tumor.
	NOTE: Addition of antibiotics/antimycotic prevents contamination of tumor cells in vitro.</li>
	<li>Digest tumor for 3 hr at 30 &#176;C, shaking at 125 - 200 rpm.
	NOTE: Increasing temperature up to 37 &#176;C increases the efficiency of the digestion (more single cells over time) but it is usually accompanied by increased cell death. For most tumors, digestion at 30 &#176;C for 3 hr results in sufficient numbers of viable dissociated cells to proceed to the labeling step.</li>
	<li>Stop the digestion adding 35 ml wash media (DMEM/F12 with 5% FBS). Filter through a 70 &#181;m nylon mesh into a clean 50 ml conical tube to remove undigested tissue. Centrifuge the filtered media containing digested cells at 400 x g for 5 min.</li>
	<li>Aspirate supernatant and resuspend pellet in 1 ml Red blood cell lysis buffer. Incubate at room temperature for 5 min.</li>
	<li>Add 10 ml Wash buffer (DMEM:F12, 5% FBS) to stop lysis. Pass cells through a 40 &#181;M nylon Mesh to remove clumps. Centrifuge at 400 x g for 5 min and remove supernatant, place on ice.</li>
	<li>Resuspend digested cells in 5 ml wash buffer and count both viable and non-viable cells using trypan blue exclusion. Briefly, mix 50 &#181;l of cells and 50 &#181;l of trypan blue and count trypan-blue excluding cells using a hemocytometer.
	NOTE: This crude digestion product will contain human tumor cells derived from the PDX, as well as mouse stromal cells (fibroblasts, blood cells, etc.). Digested cells can now be processed for labeling (step 6), or human cancer cells can be enriched using one of the procedures described in Ref 5.</li>
</ol>
5. Enrichment of Human Epithelial Cancer Cells
<ol>
	<li>Deplete the mouse stromal cells using a lineage (Lin+) cell depletion kit20.
	NOTE: Recommended for highly vascularized tumors and/or tumors with high stromal content in which EpCAM expression is unknown or lost).
	<ol>
		<li>Take up to 107 viable cells in a clean 5 ml polypropylene tube, add 2 ml EEB and centrifuge at 300 x g for 5 min. Pipette off supernatant completely.</li>
		<li>Resuspend cell pellet in 40 &#181;l of ice-cold EEB per 107 cells.</li>
		<li>Add 10 &#181;l of biotin-antibody cocktail per 107 cells, mix by gently pipetting and incubate at 4 &#176;C for 10 min (cocktail contains antibodies to Lin+ mouse cells).</li>
		<li>Add 30 &#181;l of cold EEB per 107 cells, mix by gently pipetting.</li>
		<li>Add 20 &#181;l of anti-biotin microbeads per 107 cells mix by gently pipetting and incubate at 4 &#176;C for 15 min.</li>
		<li>Wash cells with 3 ml cold EEB, centrifuge at 300 x g for 5 min at 4 &#176;C. Carefully aspirate supernatant. Resuspend pellet in 500 &#181;l of EEB and place on ice.</li>
		<li>Place column in the magnetic field of a magnetic separator. Rinse column with 0.5 ml epithelial enrichment buffer and allow it to drip through. Do not allow the column to dry out.</li>
		<li>Place a new polypropylene collection tube under the column. Slowly, add the 500 &#181;l containing labeled cells over the column (Lin+ labeled cells will be retained in the magnetic column). Collect effluent as a fraction with unlabeled cells, representing the enriched lineage negative (tumor) cell fraction.</li>
		<li>Rinse the column 3 times with 500 &#181;l of EBB and collect the effluent in the same tube as effluent of step 5.1.8. Keep effluent on ice and proceed to labeling step (6).</li>
		<li>Optional: Take the column outside of the magnetic field. Place a new polypropylene tube underneath and elute the LIN+ fraction by adding 500 &#181;l of EEB, three times and using the provided plunger.</li>
	</ol>
	</li>
	<li>Enrichment of human EpCAM+ epithelial cancer cells (recommended for tumors known to express CD326+ and contain high mouse stromal content).
	<ol>
		<li>Take up to 107 viable cells in a clean 5 ml polypropylene tube, add 2 ml cold EEB and centrifuge at 300 x g for 5 min. Pipette off supernatant completely.</li>
		<li>Resuspend cell pellet in 60 &#181;l of ice-cold EBB per 107 cells.</li>
		<li>Add 20 &#181;l of EpCAM microbeads per 107 cells, mix by gently pipetting and incubate at 4 &#176;C for 30 min.</li>
		<li>Wash cells with 3 ml cold EEB, centrifuge at 300 x g for 5 min at 4 &#176;C. Carefully aspirate supernatant. Resuspend pellet in 500 &#181;l of EEB and put on ice.</li>
		<li>Place column in the magnetic field of a mini separator. Rinse column with 0.5 ml EEB and allow it to drip through. Do not allow the column to dry out.</li>
		<li>Place a new polypropylene collection tube under the column. Slowly, add the 500 &#181;l containing labeled cells over the column (EpCAM+ labeled cells will be retained in the magnetic column). Collect effluent as a fraction with unlabeled cells, representing the mouse stromal cells.</li>
		<li>Rinse the column 4 times with 500 &#181;l of ME Buffer and collect the effluent in the same tube as effluent of step 5.1.8.</li>
		<li>Take the column outside of the magnetic field. Place a new polypropylene tube underneath and elute the EpCAM+ fraction by adding 500 &#181;l of ME buffer, three times. Flush out the magnetically labeled cells by firmly pushing the plunger into the column. Collect effluent containing the enriched EpCAM+ tumor cell fraction and keep on ice. Proceed to step 6.</li>
	</ol>
	</li>
</ol>
6. Transduction of PDX-derived Tumor Cells
<ol>
	<li>Centrifuge dissociated tumor cells at 300 g x 5 min and resuspend in 2 ml mammosphere media. Count viable cells using trypan blue exclusion as in 4.11.</li>
	<li>Prepare 10 ml of mammosphere media containing 8 &#181;g/ml polybrene (2 &#181;l of stock polybrene per ml of media).</li>
	<li>Determine the volume needed for 2 x 105 viable tumor cells. Centrifuge cells at 300 x g for 5 min, and resuspend pellet in 2 ml of polybrene containing media. Plate 2 x 105 viable tumor cells per well in a 6-well ultra-low adherence tissue culture plate.
	NOTE: This is an optimal number of cells required for transduction with one lentiviral vector.
	CAUTION! Lentiviral particles and all consumables used with lentiviral particles should be handled following institutional procedures for recombinant DNA biohazards.
	NOTE: Lentiviral transduction of primary breast cells strongly favors myoepithelial cells which can result in poor labeling of luminal cells and selection of subpopulations of tumor cells during labeling21.</li>
	<li>Incubate the virus with 200 mU/ml neuraminidase at 37 &#176;C for 1 hr prior to transduction to increase the binding of viral particles to different primary cell subpopulations and correct for this potential bias21.</li>
	<li>Add lentiviral particles at 10 MOI (2 x 106 TU for 2 x 105 viable cells) if PDX-dissociated cells are depleted from Lin+ mouse cells or enriched in EpCam+ cells. Add lentiviral particles at 30 MOI (6 x 106 TU for 2 x 105 viable cells) if using non-enriched PDX-dissociated cells.
	NOTE: The increased MOI allows for efficient transduction even in the presence of large amounts of debris and dead cells in crude extracts. Keep one well with unlabeled cells to serve as a control for viability and transduction efficiency.</li>
	<li>Swirl to mix virus with cells. Incubate at 37 &#176;C, 5% CO2 for up to 96 hr. Add 500 &#181;l of fresh mammosphere media 24 hr after transfection. Cells will not attach to plates, do not aspirate media.</li>
</ol>
7. Evaluation of Transduction Efficiency and Re-implantation of Labeled Cells in Immunocompromised Mice
<ol>
	<li>Monitor expression of the traceable marker (GFP) every 24 hr using a fluorescent microscope at 10X magnification.
	NOTE: GFP expression can be observed as early as 24 hr after infection but in most PDXs GFP expression is clearly visible after 72 hr (Figure 1).</li>
	<li>Estimate the efficiency of transduction by evaluating the percentage of GFP+ cells within the total well.
	NOTE: Since cultures contain tumor cells, residual stromal cells, and dead cells at various degrees, wells with as low as 10% GFP+ cells can be implanted in a host mouse.</li>
	<li>Transfer transduced cells from 6-well plates into a 15 ml conical tube. Add 1 ml of mammosphere media to the well to collect all the cells left behind. Place on ice.</li>
	<li>Add 10 ml of HBSS/hepes to transduced cells and centrifuge at 300 x g for 5 min, 4 &#176;C. Carefully aspirate supernatant and resuspend in 50 &#181;l basement matrix extract (BME) on ice.
	NOTE: BME aliquots must be thawed on ice, 1 - 2 hr prior to use. BME will solidify at room temperature; keep on ice at all times.</li>
	<li>Load BME-embedded cells into a 0.5 ml insulin syringe, keep on ice, and bring to the animal facility for reimplantation into NSG mice.</li>
	<li>Anesthetize female 4 - 8 week old NSG mice, using 5% isoflurane/95% oxygen for 5min, followed by 2% isoflurane/98% oxygen or according to approved animal research ethics approved protocol.</li>
	<li>When animal is unresponsive to pain stimuli (toe-pinch), clean the injection area with betadine followed by ethanol wipes, and inject the 50 &#181;l of cells in the 4th mammary fat pad. Provide mice with analgesia to alleviate injection discomfort as indicated in approved protocol.</li>
	<li>Allow cells to form tumors (2 - 12 weeks) and monitor GFP and/or luciferase activity using a tunable light system and/or in vivo luciferase imaging system (Figure 2).
	NOTE: Follow guidelines for anesthesia, analgesia, tumor burden measurements and euthanasia criteria as approved by institutional animal research ethics committee.</li>
</ol>
8. Quality Control of Labeled PDXs
<ol>
	<li>Determine the efficiency of labeling by assessing luciferase and GFP expression in labeled tumors.
	NOTE: Follow institutional animal research ethics committee approved procedures for in vivo bioluminescence imaging (Figures 2, 3).
	<ol>
		<li>Dissect tumors from euthanized mice when tumor size has reached 1.0 - 1.5 cm diameter (or before according to approved protocols, as described in 4). Dissection should be performed under a tunable light system (or an equivalent system that allows GFP fluorescence evaluation).</li>
		<li>From each tumor, qualitatively estimate the percentage of GFP+ tumor using microscopy. If less than 100%, dissect GFP+ portion only. Dissect a 3 mm disk and fix in 10% formalin for paraffin embedding and histological analysis, save a small piece for RNA or other desired analyses, and save as much of the tumor as possible in individual 1.5 ml cryotubes containing 90% FBS/10% DMSO for cryopreservation.</li>
	</ol>
	</li>
	<li>Re-implant pieces of labeled tumor into new recipient NSG mice18 to expand and use in experimental metastasis studies.</li>
	<li>Perform standard immunohistochemical staining of paraffin embedded tissue obtained from tumors prior to transduction and at each generation thereafter to verify that labeled PDXs remain histologically similar to the original PDXs.
	NOTE: The markers used for quality control vary with each PDXs. For breast cancer PDXs, expression of estrogen receptor, progesterone receptor, Epidermal growth factor receptor 2 (HER2), epidermal growth factor receptor 1 (HER1 or EGFR), pan-cytokeratin (pan-CK) are recommended for initial screening.</li>
</ol>
9. Experimental Metastasis Models with Labeled PDXs
<ol>
	<li>Following the steps described in section 4, dissociate tumor cells from a labeled PDX. If tumor is highly vascularized or rich in mouse stroma, perform enrichment of cancer cells as described in 4.5 or 4.6.</li>
	<li>Count viable cells using trypan blue exclusion, and dilute 250,000 cells in 100 &#181;l PBS (Ca2+, Mg2+ free) per mice. Keep cells on ice. For injection of multiple mice, adjust the numbers accordingly (and prepare an excess of at least one extra injection to account for pipetting errors).</li>
	<li>Bring cells on ice to the appropriate animal procedure room and proceed to intra-cardiac injection according to approved IACUC protocol.
	NOTE: Detailed protocols for intra-cardiac injection of cancer cells have been described elsewhere22,23.</li>
	<li>Track and quantify metastatic spread over time using bioluminescent imaging. Visualize macroscopic metastases at different organs using bioluminescence and/or GFP imaging of isolated organs at necropsy24 (Figure 6).</li>
</ol>

<ol>
	<li>Jin, K., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+human+tumour+tissue+xenografts+in+immunodeficient+mice:+a+systematic+review.">Patient-derived human tumour tissue xenografts in immunodeficient mice: a systematic review.</a> Clin Transl Oncol. 12 (7), 473-480 (2010).</li><li>Siolas, D., Hannon, G. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+tumor+xenografts:+transforming+clinical+samples+into+mouse+models.">Patient-derived tumor xenografts: transforming clinical samples into mouse models.</a> Cancer Res. 73 (17), 5315-5319 (2013).</li><li>DeRose, Y. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tumor+grafts+derived+from+women+with+breast+cancer+authentically+reflect+tumor+pathology,+growth,+metastasis+and+disease+outcomes.">Tumor grafts derived from women with breast cancer authentically reflect tumor pathology, growth, metastasis and disease outcomes.</a> Nat Med. 17 (11), 1514-1520 (2011).</li><li>Kabos, P., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+luminal+breast+cancer+xenografts+retain+hormone+receptor+heterogeneity+and+help+define+unique+estrogen-dependent+gene+signatures.">Patient-derived luminal breast cancer xenografts retain hormone receptor heterogeneity and help define unique estrogen-dependent gene signatures.</a> Breast cancer research and treatment. 135 (2), 415-432 (2012).</li><li>Zhang, X., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+renewable+tissue+resource+of+phenotypically+stable,+biologically+and+ethnically+diverse,+patient-derived+human+breast+cancer+xenograft+models.">A renewable tissue resource of phenotypically stable, biologically and ethnically diverse, patient-derived human breast cancer xenograft models.</a> Cancer Res. 73 (15), 4885-4897 (2013).</li><li>Lum, D. H., Matsen, C., Welm, A. L., Welm, B. E. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Overview+of+human+primary+tumorgraft+models:+comparisons+with+traditional+oncology+preclinical+models+and+the+clinical+relevance+and+utility+of+primary+tumorgrafts+in+basic+and+translational+oncology+research.">Overview of human primary tumorgraft models: comparisons with traditional oncology preclinical models and the clinical relevance and utility of primary tumorgrafts in basic and translational oncology research.</a> Curr Protoc Pharmacol. , (2012).</li><li>Marangoni, E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=A+new+model+of+patient+tumor-derived+breast+cancer+xenografts+for+preclinical+assays.">A new model of patient tumor-derived breast cancer xenografts for preclinical assays.</a> Clin Cancer Res. 13 (13), 3989-3998 (2007).</li><li>Garrido-Laguna, I., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Tumor+engraftment+in+nude+mice+and+enrichment+in+stroma-+related+gene+pathways+predict+poor+survival+and+resistance+to+gemcitabine+in+patients+with+pancreatic+cancer.">Tumor engraftment in nude mice and enrichment in stroma- related gene pathways predict poor survival and resistance to gemcitabine in patients with pancreatic cancer.</a> Clin Cancer Res. 17 (17), 5793-5800 (2011).</li><li>Landis, M. D., Lehmann, B. D., Pietenpol, J. A., Chang, J. C. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+breast+tumor+xenografts+facilitating+personalized+cancer+therapy.">Patient-derived breast tumor xenografts facilitating personalized cancer therapy.</a> Breast Cancer Res. 15 (1), 201 (2013).</li><li>Norum, J. H., Andersen, K., Sorlie, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lessons+learned+from+the+intrinsic+subtypes+of+breast+cancer+in+the+quest+for+precision+therapy.">Lessons learned from the intrinsic subtypes of breast cancer in the quest for precision therapy.</a> Br J Surg. 101 (8), 925-938 (2014).</li><li>Tentler, J. J., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+tumour+xenografts+as+models+for+oncology+drug+development.">Patient-derived tumour xenografts as models for oncology drug development.</a> Nat Rev Clin Oncol. 9 (6), 338-350 (2012).</li><li>Zhang, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+xenografts+of+triple-negative+breast+cancer+reproduce+molecular+features+of+patient+tumors+and+respond+to+mTOR+inhibition.">Patient-derived xenografts of triple-negative breast cancer reproduce molecular features of patient tumors and respond to mTOR inhibition.</a> Breast Cancer Res. 16 (2), R36 (2014).</li><li>Liu, H., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Cancer+stem+cells+from+human+breast+tumors+are+involved+in+spontaneous+metastases+in+orthotopic+mouse+models.">Cancer stem cells from human breast tumors are involved in spontaneous metastases in orthotopic mouse models.</a> Proc Natl Acad Sci U S A. 107 (42), 18115-18120 (2010).</li><li>Kang, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Analysis+of+cancer+stem+cell+metastasis+in+xenograft+animal+models.">Analysis of cancer stem cell metastasis in xenograft animal models.</a> Methods Mol Biol. 568, 7-19 (2009).</li><li>Thibaudeau, L., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mimicking+breast+cancer-induced+bone+metastasis+in+vivo:+current+transplantation+models+and+advanced+humanized+strategies.">Mimicking breast cancer-induced bone metastasis in vivo: current transplantation models and advanced humanized strategies.</a> Cancer Metastasis Rev. 33 (2-3), 721-735 (2014).</li><li>Francia, G., Cruz-Munoz, W., Man, S., Xu, P., Kerbel, R. S. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Mouse+models+of+advanced+spontaneous+metastasis+for+experimental+therapeutics.">Mouse models of advanced spontaneous metastasis for experimental therapeutics.</a> Nat Rev Cancer. 11 (2), 135-141 (2011).</li><li>Powell, E., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=p53+deficiency+linked+to+B+cell+translocation+gene+2+(BTG2)+loss+enhances+metastatic+potential+by+promoting+tumor+growth+in+primary+and+metastatic+sites+in+patient-derived+xenograft+(PDX)+models+of+triple-negative+breast+cancer.">p53 deficiency linked to B cell translocation gene 2 (BTG2) loss enhances metastatic potential by promoting tumor growth in primary and metastatic sites in patient-derived xenograft (PDX) models of triple-negative breast cancer.</a> Breast Cancer Res. 18 (1), (2016).</li><li>DeRose, Y. S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Patient-derived+models+of+human+breast+cancer:+protocols+for+in+vitro+and+in+vivo+applications+in+tumor+biology+and+translational+medicine.">Patient-derived models of human breast cancer: protocols for in vitro and in vivo applications in tumor biology and translational medicine.</a> Curr Protoc Pharmacol. , (2013).</li><li>Wang, X., McManus, M. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lentivirus+production.">Lentivirus production.</a> J Vis Exp. (32), (2009).</li><li>Indumathi, S., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Lineage+depletion+of+stromal+vascular+fractions+isolated+from+human+adipose+tissue:+a+novel+approach+towards+cell+enrichment+technology.">Lineage depletion of stromal vascular fractions isolated from human adipose tissue: a novel approach towards cell enrichment technology.</a> Cytotechnology. 66 (2), 219-228 (2014).</li><li>Hines, W. C., Yaswen, P., Bissell, M. J. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Modelling+breast+cancer+requires+identification+and+correction+of+a+critical+cell+lineage-dependent+transduction+bias.">Modelling breast cancer requires identification and correction of a critical cell lineage-dependent transduction bias.</a> Nat Commun. 6, 6927 (2015).</li><li>Campbell, J. P., Merkel, A. R., Masood-Campbell, S. K., Elefteriou, F., Sterling, J. A. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Models+of+bone+metastasis.">Models of bone metastasis.</a> J Vis Exp. (67), e4260 (2012).</li><li>Kang, Y. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Imaging+TGFbeta+Signaling+in+Mouse+Models+of+Cancer+Metastasis.">Imaging TGFbeta Signaling in Mouse Models of Cancer Metastasis.</a> Methods Mol Biol. 1344, 219-232 (2016).</li><li>Jenkins, D. E., Hornig, Y. S., Oei, Y., Dusich, J., Purchio, T. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Bioluminescent+human+breast+cancer+cell+lines+that+permit+rapid+and+sensitive+in+vivo+detection+of+mammary+tumors+and+multiple+metastases+in+immune+deficient+mice.">Bioluminescent human breast cancer cell lines that permit rapid and sensitive in vivo detection of mammary tumors and multiple metastases in immune deficient mice.</a> Breast Cancer Res. 7 (4), R444-R454 (2005).</li><li>Lawson, D. A., et al. <a target="_blank" href="http://www.ncbi.nlm.nih.gov/entrez/query.fcgi?db=PubMed&cmd=Search&doptcmdl=Citation&defaultField=Title+Word&term=Single-cell+analysis+reveals+a+stem-cell+program+in+human+metastatic+breast+cancer+cells.">Single-cell analysis reveals a stem-cell program in human metastatic breast cancer cells.</a> Nature. 526 (7571), 131-135 (2015).</li></ol>

The authors have nothing to disclose.

Critical steps within the protocol:
The use of high titer lentiviral particles (&#62;108 TU/ml) is a critical step in the success of this protocol, as allows careful control of the media composition during in vitro transduction. While multiple methods for production of high-titer viral particles have been well described18,19; this protocol uses lentiviral particles produced as described in detail at <a href="http://www.kottonlab.com">www.kottonla...

The development of patient-derived tumor xenografts (PDXs), where surgically resected tumor samples are engrafted directly into immune-compromised mice, offers several advantages over standard cell-line xenograft models and represents a major advance in cancer research1,2. PDXs can be maintained and expanded by successive passages with minimal alteration of the genetic and biological characteristics of the tumor grown at the first passage; and more accurately reflect tumor heterogeneity than xenografts derived from human cancer cell lines3-8. These models are now extensively used as a platform for personalizing cancer therapeutics9,10, as a preclinical platform in drug development6,11 and as an experimental tool for studying cancer biology4,12.
Most PDXs are implanted and propagated subcutaneously, which feasibly allows measurement of tumor growth over time using calipers. However, metastatic disease has been more difficult to model using PDXs. Specifically for breast cancer, xenografts with metastatic capacity to different organs have been described3,5,13, but the frequency of spontaneous dissemination to metastatic sites is extremely low. Where reported, the identification and quantification of metastatic burden relies in laborious histological examination of target organs post-mortem. Cancer cell lines expressing bioluminescent (luciferase, Luc) or fluorescent (Green Fluorescent Protein, GFP) gene reporters are commonly used in experimental models of breast cancer metastases to brain, lung, bone and liver after intracardiac, tail-vein, intrafemoral and splenic injection14-16. While these models bypass dissemination from the primary tumors, they are valuable to study the mechanisms of organ tropism and metastatic colonization. However, cells derived from primary patient tumors and PDXs can have low transfection or transduction rates using standard procedures. One alternative is to establish PDX-derived cell lines in vitro17, which can be then labeled using conventional tissue culture protocols. This approach however, is not suitable for labeling most PDXs, for which cell-line derivation is difficult and can change the phenotype of the cells. Here we present a protocol for transduction of PDX-dissociated tumor cells with lentiviral vectors suitable for in vivo imaging. In addition, we describe experimental metastasis using intracardiac injection of dissociated luc-GFP labeled PDX cells in immunocompromised mice.
A basic protocol for transduction of PDX-dissociated organoids with gene-reporter expressing lentivirus has previously been described 18. In the current protocol we describe additional methods to enrich for human tumor cells and obtain near 100% transduction efficiency, as well as the use of labeled PDXs for detecting experimental breast cancer metastases. This protocol can be adapted for labeling multiple cancer types of PDXs with various luminescent and fluorescent markers as well as modulation of gene expression (i.e., shRNA knockdown of genes of interest).

<table><tbody><tr><td>DMEM/F12 (1:1)</td><td>Hyclone</td><td>SH30023.01</td><td></td></tr><tr><td>bFGF</td><td>BD Biosciences</td><td>354060</td><td></td></tr><tr><td>EGF</td><td>BD Biosciences</td><td>354001</td><td></td></tr><tr><td>Heparin</td><td>Sigma</td><td>H4784</td><td></td></tr><tr><td>B27</td><td>Gibco/Thermo Fisher</td><td>17504-44</td><td></td></tr><tr><td>Anti-fungi-antibiotics</td><td>Hyclone</td><td>SV30010</td><td></td></tr><tr><td>Accumax</td><td>Innovative Cell Technologies</td><td>AM-105-500</td><td>Digestion Buffer</td></tr><tr><td>FBS</td><td>Atlanta Biologicals</td><td>S11550</td><td></td></tr><tr><td>HBSS Red Ca&lt;sup&gt;2+&lt;/sup&gt;/Mg&lt;sup&gt;2+&lt;/sup&gt; free</td><td>Hyclone</td><td>SH30031.02</td><td></td></tr><tr><td>Hepes</td><td></td><td></td><td></td></tr><tr><td>10x PBS</td><td>Hyclone</td><td>SH30258.01</td><td></td></tr><tr><td>Cultrex</td><td>Cultrex</td><td>3433-005-01</td><td>Basement Matrix Extract (BME)</td></tr><tr><td>30 &amp;#176;C shaker</td><td>NewBrunswick Scientific CO. INC</td><td>Series 25 Incubator Shaker</td><td></td></tr><tr><td>70 &amp;#956;m filters</td><td>Falcon</td><td>7352350</td><td></td></tr><tr><td>scalpels</td><td>Fisher</td><td>22079690</td><td></td></tr><tr><td>Clorhexidine disinfectant</td><td>Durvet&amp;nbsp;</td><td>NDC# 30798-624-35</td><td></td></tr><tr><td>Red blood&amp;nbsp; cell lysis reagent</td><td>Sigma</td><td>R7757</td><td></td></tr><tr><td>Neuraminidase</td><td>Sigma</td><td>N7885-1UN</td><td></td></tr><tr><td>EpCAM (CD326+) microbeads*</td><td>Miltenyil Biotec</td><td>130-061-101</td><td></td></tr><tr><td>Lineage cell depletion Kit, mouse*</td><td>Miltenyil Biotec</td><td>130-090-858</td><td></td></tr><tr><td>MiniMACS Separator&amp;nbsp;</td><td>Miltenyil Biotec</td><td>130-042-102</td><td></td></tr><tr><td>Mini MACS Magnetic Stand</td><td>Miltenyil Biotec</td><td>130-042-303</td><td></td></tr><tr><td>MS Columns</td><td>Miltenyil Biotec</td><td>130-042-201</td><td>MS or LS columns can be used, adjust to number of cells.</td></tr><tr><td>Illumatool Tunable light system</td><td>Lightools research</td><td>Various</td><td>For in vivo fluorescence imaging</td></tr><tr><td>Xenogen IVIS200 imaging device</td><td>Xenogen</td><td>Various</td><td>For in vivo luminiscence imaging</td></tr><tr><td>Human Cytokeratin Clone MNF116 Monoclonal antibody</td><td>DAKO</td><td>M0821</td><td>Pan-cytokeratin&amp;nbsp;</td></tr><tr><td>Epidermal Growth factor receptor antibody</td><td>Cell signaling</td><td>4267S</td><td>EGFR</td></tr></tbody></table>
